[14] TRAFFIC ANALYSIS

Kali Linux Tools

Transcript

1. Digital Forensics
   Penetration Testing
   @Aleks_Cudars
   Last updated: 25.04.2013


   View Slide

2. NB!
   • This reference guide describes every tool one by one and is aimed at anyone who wants to get familiar with digital forensics and penetration
   testing or refresh their knowledge in these areas with tools available in Kali Linux
   • Note! I’ve tried to gather as much information as possible, however, even despite that, some entries don’t have information, which I might update
   if I get more information. Also, mistakes are inevitable
   • The purpose was to create the most detailed source of every tool in Kali Linux for quick reference and better understanding
   • Some tools fall under several categories, which means that duplicate entries exist in the full ~670 pages long source
   • The information about every tool usually consists of: DESCRIPTION, USAGE, EXAMPLE and sometimes OPTIONS and TIPs
   • Kali Linux tools are not limited to Kali Linux / Backtrack (most can be installed on other Linux distributions taking into consideration all the
   necessary dependencies. Additionally, some tools are also available on other types of operating systems such as Windows and Mac OS)
   • Kali Linux is a new and developing OS – some tools may be added, some - updated, some – removed over time
   • It is assumed that all tools are run as root (or as administrator) (in Kali Linux you are root by default)
   • All the information gathered about each tool has been found freely on the Internet and is publicly available
   • Sources of information are referenced at the end
   • Most command line tools include options, however, due to space considerations, only some tools have options listed (search the internet for
   options, read documentation/manual, use –h or --help)
   • For more information on each tool - search the internet, click on links or check the references at the end
   • PLEASE DO NOT USE KALI LINUX AND THE TOOLS LISTED HERE FOR ANY ILLEGAL OPERATION!
   • Tools which are specifically aimed at DOS, DDOS or anonymity are rarely used in legitimate engagements, and are
   therefore not installed by default in Kali Linux
   List of Tools for Kali Linux 2013 2


   View Slide

3. [14] INFORMATION GATHERING - TRAFFIC ANALYSIS
   • cdpsnarf
   • intrace
   • irpas-ass
   • irpass-cdp
   • p0f
   • tcpflow
   • wireshark
   3
   List of Tools for Kali Linux 2013


   View Slide

4. cdpsnarf
   4
   List of Tools for Kali Linux 2013
   DESCRIPTION CDPSnarf if a network sniffer exclusively written to extract information from CDP packets. It
   provides all the information a “show cdp neighbors detail” command would return on a Cisco router and even
   more.
   Features: Time intervals between CDP advertisements, Source MAC address, CDP Version, TTL, Checksum, Device ID,
   Software version, Platform, Addresses, Port ID, Capabilities, Duplex, Save packets in PCAP dump file format, Read packets
   from PCAP dump files, Debugging information (using the "-d" flag), Tested with IPv4 and IPv6
   USAGE cdpsnarf -i
   OPTIONS cdpsnarf -h
   EXAMPLE ./cdpsnarf eth2


   View Slide

5. intrace
   5
   List of Tools for Kali Linux 2013
   DESCRIPTION InTrace is a traceroute-like application that enables users to enumerate IP hops exploiting existing
   TCP connections, both initiated from local network (local system) or from remote hosts. It could be useful for
   network reconnaissance and firewall bypassing. The difference between traceroute and InTrace is that InTrace
   will make use of an existing TCP connection, and piggyback its packets on this connection, effectively bypassing
   any firewall rules that block them, and quite often giving you more internal information than you expected.
   USAGE intrace [options]
   EXAMPLE ./intrace --h www.freescale.com (Locally initiated TCP connection)
   EXAMPLE ./intrace -i eth0 -h 217.17.34.18 (Remotely initiated TCP connection)
   EXAMPLE ./intrace -h paypal.com -p 80 (instead of port 80, you can use any other port such as 21 for FTP, or 22 for SSH)


   View Slide

6. irpas-ass
   6
   List of Tools for Kali Linux 2013
   DESCRIPTION Internet Router Protocol Attack Suite - a suite of tools designed to abuse inherent design insecurity
   in routers and routing protocols. Autonomous System Scanner – ASS is a protocol-aware scanner used to query
   routers for AS information and a valuable reconnaissance technique for attackers looking for insecure boundaries”
   between networks. Because routing protocols use autonomous systems to distinguish between various routing
   "domains" and various ways to communicate, you need something which works like a TCP port scanner but knows
   more then one protocol.
   USAGE ./ass [-v[v[v]]] -i [-p] [-c] [-A] [-M] [-P IER12]
   -a -b
   [-S ] [-D ]
   [-T ]
   OPTIONS http://www.phenoelit.org/irpas/docu.html
   EXAMPLE ./ass -i eth0 (Passive Mode)
   EXAMPLE ./ass -i eth0 –A (Active Mode)


   View Slide

7. irpass-cdp
   7
   List of Tools for Kali Linux 2013
   DESCRIPTION Internet Router Protocol Attack Suite - a suite of tools designed to abuse inherent design insecurity
   in routers and routing protocols. This program is for sending CDP (Cisco router Discovery Protocol) messages to the
   wire.
   The CDP tool can be used in two different modes:
   1. The flood mode is used to send garbage CDP messages to the wire, which has different effects to the routers depending on their IOS version.
   2. The second mode for CDP is spoofing. You can enable this mode with the command line option -m 1. It has no actuall use for attacking router and is mostly
   targeted fro social engineering or just to confuse the local administrator. It is used to send out 100% valid CDP infromation packets which look like generated by
   other Cisco routers. Here, you can specify any part of a CDP message yourself.
   USAGE ./cdp [depends on the mode; see documenation]
   OPTIONS http://www.phenoelit.org/irpas/docu.html
   EXAMPLE ./cdp -i eth0 -n 10000 -l 1480 –r (flood mode)
   EXAMPLE ./cdp -v -i eth0 -m 1 -D 'Hacker' -P 'Ethernet0' -C RI \ -L 'Intel' -S "`uname -a`" -F '255.255.255.255‘ (spoofing)
   TIP if you want to flood the routers completly, start two processes of cdp with different sizes. One of them running on full size (1480) to fill up the major
   part of the memory and another to fill up the rest with a length of 10 octets.


   View Slide

8. p0f
   8
   List of Tools for Kali Linux 2013
   DESCRIPTION p0f uses a fingerprinting technique based on analyzing the structure of a TCP/IP packet to determine
   the operating system and other configuration properties of a remote host. The process is completely passive and
   does not generate any suspicious network traffic. The other host has to either:
   connect to your network - either spontaneously or in an induced manner, for example when trying to establish a
   ftp data stream, returning a bounced mail, performing auth lookup, using IRC DCC, external html mail image
   reference and so on, or be contacted by some entity on your network using some standard means (such as a web
   browsing); it can either accept or refuse the connection.
   The method can see thru packet firewalls and does not have the restrictions of an active fingerprinting. The main
   uses of passive OS fingerprinting are attacker profiling (IDS and honeypots), visitor profiling (content
   optimization), customer/user profiling (policy enforcement), pen-testing, etc.
   USAGE p0f [ -f file ] [ -i device ] [ -s file ] [ -o file ]
   [ -w file ] [ -Q sock [ -0 ] ] [ -u user ] [ -FXVNDUKASCMROqtpvdlrx ]
   [ -c size ] [ -T nn ] [ -e nn ] [ 'filter rule' ]
   OPTIONS http://www.aldeid.com/wiki/P0f
   EXAMPLE p0f -i eth1 –vt (The following command will start p0f)
   EXAMPLE p0f -i eth1 –vto output.txt (The output of the ingerprint information can also be directed to a file using the –o option)


   View Slide

9. tcpflow
   9
   List of Tools for Kali Linux 2013
   DESCRIPTION tcpflow is a program that captures data transmitted as part of TCP connections (flows), and stores
   the data in a way that is convenient for protocol analysis and debugging. Each TCP flow is stored in its own file.
   Thus, the typical TCP flow will be stored in two files, one for each direction. tcpflow can also process stored
   'tcpdump' packet flows.
   tcpflow stores all captured data in files that have names of the form:
   [timestampT]sourceip.sourceport-destip.destport[--VLAN][cNNNN]
   USAGE tcpflow [-chpsv] [-b max_bytes] [-d debug_level] [-f max_fds] [-i iface] [-r file] [expression]
   OPTIONS http://linux.die.net/man/1/tcpflow
   EXAMPLE tcpflow -c -n en1 src or dst host api.example.com
   EXAMPLE tcpflow host sundown (To record all packets arriving at or departing from sundown)
   EXAMPLE tcpflow host helios and \( hot or ace \) (To record traffic between helios and either hot or ace)
   EXAMPLE tcpflow host ace and not helios (To record traffic between ace and any host except helios)
   EXAMPLE tcpflow net ucb-ether (To record all traffic between local hosts and hosts at Berkeley)
   EXAMPLE tcpflow 'gateway snup and (port ftp or ftp-data)‘ (To record all ftp traffic through internet gateway snup: (note that the
   expression is quoted to prevent the shell from (mis-)interpreting the parentheses))


   View Slide

10. wireshark
    10
    List of Tools for Kali Linux 2013
    DESCRIPTION wireshark - Interactively dump and analyze network traffic. Wireshark is a GUI network protocol
    analyzer. It lets you interactively browse packet data from a live network or from a previously saved capture
    file. Wireshark's native capture file format is libpcap format, which is also the format used by tcpdump and
    various other tools.
    USAGE wireshark [ -a ] ... [ -b ] ... [ -B size (Win32 only)> ] [ -c ] [ -C ] [ -D ] [ --display=
    ] [ -f ] [ -g ] [ -h ] [ -H ] [ -i |- ] [ -k ] [ -K ] [ -l ] [ -L ]
    [ -m ] [ -n ] [ -N ] [ -o ] ... [ -p ] [ -P ] [ -Q ]
    [ -r ] [ -R ] [ -S ] [ -s ] [ -tad|a|r|d|dd|e ] [ -v ] [ -w ] [ -
    y ] [ -X ] [ -z ] [ ]
    OPTIONS http://linux.die.net/man/1/wireshark
    EXAMPLE n/a; GUI tool


    View Slide

11. references
    • http://www.aldeid.com
    • http://www.morningstarsecurity.com
    • http://www.hackingdna.com
    • http://zer0byte.com/2013/03/19/kali-linux-complete-tools-list-installation-screen-shots/
    • http://www.monkey.org/~dugsong/fragroute/
    • http://www.sans.org/security-resources/idfaq/fragroute.php
    • http://flylib.com/books/en/3.105.1.82/1/
    • http://www.darknet.org.uk/2008/04/cdpsnarf-cdp-packet-sniffer/
    • http://mateslab.weebly.com/dnmap-the-distributed-nmap.html
    • http://www.tuicool.com/articles/raimMz
    • http://backtrackwasneversoeasy.blogspot.co.uk/2012/02/terminating-internet-of-whole-network.html
    • http://www.ethicalhacker.net
    • http://nmap.org/ncat/guide/ncat-tricks.html
    • http://nixgeneration.com/~jaime/netdiscover/
    • http://csabyblog.blogspot.co.uk
    • http://thehackernews.com
    • https://code.google.com/p/wol-e/wiki/Help
    • http://linux.die.net/man/1/xprobe2
    • http://www.digininja.org/projects/twofi.php
    • https://code.google.com/p/intrace/wiki/intrace
    • https://github.com/iSECPartners/sslyze/wiki
    • http://www.securitytube-tools.net/index.php@title=Braa.html
    • http://security.radware.com
    List of Tools for Kali Linux 2013 11
