1. 07/2017
2. What is Ultrasound? ➢ Sound waves with a frequency of > 16 kHz ➢ Speed of sound  ~ 340 m/s ➢ Needs a medium to travel in (air, water… not vacuum) ➢ Gets dampened a lot through air  loses its power, effect rises with the frequency  low frequencies for long distances and high frequencies for short distances ➢ Humans: 20 Hz – 20 kHz ➢ Dogs: 15 Hz – 50 kHz ➢ Bats: > 100 kHz Sound source Object
3. Ultrasound up to Today Animals Industry
4. Ultrasound up to Today Medical Ultrasound Nautical Sonars
5. ➢ First 3D ultrasound sensor worldwide by Toposens ➢ Point cloud of objects in the sensor’s range ➢ Patented technology ➢ Specific hardware layout + sophisticated algorithms 3D Ultrasound
6. 3D Ultrasound Video on https://vimeo.com/user7592279
7. 3D Ultrasound Video on https://vimeo.com/user7592279
8. 3D ultrasound sensors enable near-field vision for autonomous vehicles, e.g. for • ADAS • Autonomous Parking • Collision Avoidance for robots Autonomous Vehicles
9. Bringing a new 3D Sensor to Automotive Near-field environment monitoring (0 – 6 m) Collision avoidance for automatically opening doors Outside gesture control People Tracking In-car gesture control
10. Autonomous Vehicles Video on https://vimeo.com/user7592279
11. 3D ultrasound sensors enable reliable gesture control e.g. for • Consumer Electronics • Digital Signage • Industrial Applications Gesture Control
12. Gesture Control Video on https://vimeo.com/user7592279
13. Why Ultrasound? Competitive Price Ultra Low-Power Lightweight & Small Size Privacy Protection Robustness
14. Stage of Development and Traction Evaluation Kit Development Project Chip Sensor Testing and prototyping Proof of concept or finished product Software on a Chip for large quantities Complete sensor system for smaller quantities Next steps Available now!
15. Toposens GmbH +49 89 2375 1540 info@toposens.de Blütenstraße 15 80799 München www.toposens.com Happy to talk to you!
