  1. .consulting .solutions .partnership
    Getting Organized with
    Service Discovery for Microservices
    Alexander Schwartz, Principal IT Consultant
    Continuous Lifecycle London 2016 – 4 May 2016

    View full-size slide

  2. Getting Organized with Service Discovery for Microservices
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 2
    Everyday life in the cloud
    1
    etcd: Central Configuration Store
    2
    Consul: Service Discovery, Configuration and Monitoring
    3
    Eureka: Availability First!
    4
    Service Discovery Comparison
    5

    View full-size slide

  3. My sponsor and employer – msg systems ag
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 3
    Founded in 1980
    More than 5.500 employees
    727 M € (573 M £)
    turnover in 2015
    Offices in 24 countries
    Headquarter based
    near Munich in Germany

    View full-size slide

  4. That‘s me – Alexander Schwartz
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 4
    14 years of Java
    7 years of PL/SQL
    7 years of
    consumer finance
    3.5 years direct banking
    1 wife
    2 children
    471 found
    Geocaches
    @ahus1de

    View full-size slide

  5. Getting Organized with Service Discovery for Microservices
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 5
    Everyday life in the cloud
    1
    etcd: Central Configuration Store
    2
    Consul: Service Discovery, Configuration and Monitoring
    3
    Eureka: Availability First!
    4
    Service Discovery Comparison
    5

    View full-size slide

  6. Everyday life in the cloud
    A simple Cloud Setup
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 6
    Where are my application servers?
    Where is my database?

    View full-size slide

  7. Everyday life in the cloud
    A simple Cloud Setup
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 7

    View full-size slide

  8. Everyday life in the cloud
    A simple Cloud Setup
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 8

    View full-size slide

  9. Everyday life in the cloud
    Configuration at runtime saves you the hassle – and maintenance windows
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 9
    • Change parameters at runtime
     Target-IPs of servers
     Names of input and output folders
     Timeouts and other business parameters
    • Central database for
     Configuration parameters
     Service-Discovery for Clients
     Service-Discovery for Load Balancers

    View full-size slide

  10. Getting Organized with Service Discovery for Microservices
    10
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016
    Everyday life in the cloud
    1
    etcd: Central Configuration Store
    2
    Consul: Service Discovery, Configuration and Monitoring
    3
    Eureka: Availability First!
    4
    Service Discovery Comparison
    5

    View full-size slide

  11. CoreOS etcd
    etcd is a Central Configuration Store
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 11
    Suitable for configuration and service discovery
    • Simple: HTTP/REST w/ JSON
    • Reliable: highly available and consistent
    • Secure: optionally with SSL-Client-Certificates
    • Fast: several thousand write operations per second
    Operations: GET/PUT/DELETE/CAS/WAIT/TTL
    # PUT
    curl -L -X PUT http://127.0.0.1:4001/v2/keys/foo-service/container1 –d value="localhost:1111"
    # GET
    curl -L http://127.0.0.1:4001/v2/keys/foo-service/container1
    # WAIT
    curl -L http://127.0.0.1:4001/v2/keys/foo-service?wait=true\&recursive=true...

    View full-size slide

  12. CoreOS etcd + Hightower´s confd
    When values change, confd will update your Configuration Files
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 12
    confd

    View full-size slide

  13. CoreOS etcd + Hightower´s confd
    When values change, confd will update your Configuration Files
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 13
    • Service templates (*.toml)
    • Configuration templates (*.tmpl)
    # nginx.toml
    [template]
    src = "nginx.tmpl"
    dest = "/etc/nginx/sites-enabled/app.conf"
    keys = [ "/foo-service" ]
    check_cmd = "/usr/sbin/nginx -t"
    reload_cmd = "/usr/sbin/service nginx reload"
    # nginx.tmpl
    upstream app_pool {
    {{ range getvs "/foo-service/*" }}
    server {{ . }};
    {{ end }}
    }
    confd

    View full-size slide

  14. CoreOS etcd + Jurmous’ Java Client
    Use Jurmos’ Java Client to talk to etcd
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 14
    • Java-API for all of etcd’s API calls
    • Implemented on top of Netty (for asynchronous, non-blocking IO)
    // Simple put
    etcd.put("/foo-service/container1","localhost:1111").send();
    // Wait for next change on foo
    EtcdResponsePromise promise = etcd.getDir("/foo-service/")
    .recursive().waitForChange().send();
    // Java 8 lambda construction
    promise.addListener(promise -> {
    // do something on change
    });

    View full-size slide

  15. CoreOS etcd
    Pros and Cons etcd
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 15
    Pro:
    • Easy access (REST), simple installation (Go-Binary), transport security (SSL)
    • Changes are published to the clients immediately
    • Generic structure for flexible usage
    • Used by CoreOS and Kubernetes
    Contra:
    • No access controls for on a per client level
    Add-ons:
    • Vulcan (HTTP Load Balancer, configuration stored directly in etcd)
    • SkyDNS (Service discovery via DNS, data stored in etcd)

    View full-size slide

  16. Getting Organized with Service Discovery for Microservices
    16
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016
    Everyday life in the cloud
    1
    etcd: Central Configuration Store
    2
    Consul: Service Discovery, Configuration and Monitoring
    3
    Eureka: Availability First!
    4
    Service Discovery Comparison
    5

    View full-size slide

  17. Hashicorp Consul
    Consul
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 17
    Built for Service Discovery, Configuration and Monitoring
    • Easy to use: HTTP/REST w/ JSON
    • Reliable: highly available and consistent
    • Secure: built in Access Control Lists and Encryption
    Main Sponsor: HashiCorp (the ones also building Vagrant)
    Homepage: https://www.consul.io/

    View full-size slide

  18. Netflix Ribbon
    Ribbon
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 18
    Built for client side load balancing
    • Ribbon is well integrated into Feign: type safe web APIs
    Main-Sponsor: Netflix
    Homepage: https://github.com/Netflix/ribbon/

    View full-size slide

  19. Consul and Ribbon
    The Client contacts available Services directly
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 19
    Consul-Server
    (for Key Value Store
    und Service Catalogue)
    Services
    Client

    View full-size slide

  20. Services with Consul
    Every Consul Instance knows about its local Services
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 20
    "service": {
    "name": "web",
    "tags": ["master"],
    "port": 80
    }

    View full-size slide

  21. Services with Consul
    Every Consul Instance checks its local Services
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 21
    "check": {
    "id": "http",
    "name": "HTTP API on port 80",
    "http": "http://localhost:80",
    "service_id": "web",
    "interval": "10s",
    "timeout": "1s"
    }
    "check": {
    "id": "script",
    "name": "Script Check",
    "script": "/usr/local/bin/check_mem.py",
    "service_id": "web",
    "interval": "10s"
    }
    "check": {
    "id": "ttl",
    "name": "Web Status",
    "service_id": "web",
    "ttl": "30s"
    }

    View full-size slide

  22. Services with Consul
    Consul UI
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 22

    View full-size slide

  23. Services with Consul
    Lookup Services using DNS SRV Records
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 23
    $ dig @127.0.0.1 -p 8600 web.service.dc1.consul. SRV
    web.service.dc1.consul. 0 IN SRV 1 1 80 web2.node.dc1.consul.
    web.service.dc1.consul. 0 IN SRV 1 1 80 web1.node.dc1.consul.
    web1.node.dc1.consul. 0 IN A 192.168.23.21
    web2.node.dc1.consul. 0 IN A 192.168.23.22

    View full-size slide

  24. Consul and Ribbon
    Application Code for Ribbon
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 24
    MyService api = Feign.builder()
    .contract(new JAXRSContract())
    .encoder(new JacksonEncoder())
    .decoder(new JacksonDecoder())
    .client(RibbonClient.builder()
    .lbClientFactory(new ConsulLbFactory())
    .build())
    .target(MyService.class, "http://web");
    api.call();

    View full-size slide

  25. public class ConsulLbFactory implements LBClientFactory {
    private Map clients = new HashMap<>();
    public synchronized LBClient create(String clientName) {
    LBClient client = clients.get(clientName);
    if(client == null) {
    ILoadBalancer lb = new ConsulLoadBalancer(clientName);
    IClientConfig clientConfig = new DefaultClientConfigImpl();
    clientConfig.loadDefaultValues();
    client = LBClient.create(lb, clientConfig);
    clients.put(clientName, client);
    }
    return client;
    }
    }
    Consul and Ribbon
    Java-API for Consul
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 25
    public class ConsulLoadBalancer extends BaseLoadBalancer {
    public ConsulLoadBalancer(String serviceName) {
    Consul consul = Consul.builder().build();
    HealthClient client = consul.healthClient();
    ServiceHealthCache svHealth = ServiceHealthCache.newCache(client, serviceName);
    svHealth.addListener(map -> {
    List newServers = new ArrayList<>();
    map.forEach((hostAndPort, serviceHealth) ->
    newServers.add(new Server(hostAndPort.getHostText(),
    hostAndPort.getPort())));
    setServersList(newServers);
    });
    /* ... */
    }
    }

    View full-size slide

  26. Consul and Ribbon
    Pros and Cons Service Discovery with Consul
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 26
    Pro:
    • Contact to Services without a Single Point of Failure
    • Ready to use Libraries available
    • Decentralized monitoring of services
    • GUI for key value store and monitoring
    • Semantic of services instead of key value store only
    Add-ons:
    • eBay Fabio (HTTP Load Balancer, configuration directly in consul)
    • consul-template (writes configuration files like confd)
    • Nomad (scheduler that registers service automatically with consul)

    View full-size slide

  27. Getting Organized with Service Discovery for Microservices
    27
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016
    Everyday life in the cloud
    1
    etcd: Central Configuration Store
    2
    Consul: Service Discovery, Configuration and Monitoring
    3
    Eureka: Availability First!
    4
    Service Discovery Comparison
    5

    View full-size slide

  28. Netflix Eureka
    Eureka
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 28
    Build for Service Discovery inside Amazon Web Services (AWS)
    • REST: you choose from JSON and XML
    • Simple: Client-Pull
    • Reliable: highly available, availability before consistency
    Main Sponsor: Netflix
    Homepage: https://github.com/Netflix/eureka

    View full-size slide

  29. Netflix Eureka
    Brewers CAP Theorem
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 29
    „A distributed system can fulfil only two out of three availability modes at a time.“
    Consistency
    Here: After a service registered, clients can find it (Linearizability).
    Availability
    Here: Service registration and lookup available for clients.
    Partition Tolerance
    Hier: Service registration and lookup work even in the presence of networks being partly unavailable.

    View full-size slide

  30. Netflix Eureka
    Eureka – Availability first (1/2)
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 30
    Etcd:
    • Registration: CP
    • Lookup: AP (Standard) or CP („?quorum=true“)
    Consul:
    • Registration :
    CP for Key-Value-Store
    AP for Service-Registration and Health via local Agents („Anti-Entropy“)
    CP for combining the Information in the Service-Registry
    • Lookup via REST API: either CP („?consistent“),
    with the currently known leader, or AP („?stale“)
    • Lookup via DNS: with the currently known leader,
    alternatively AP with an upper time limit „stale reads“

    View full-size slide

  31. Netflix Eureka
    Eureka – Availability first (2/2)
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 31
    Eureka:
    • Registration of Services: AP (a Client registers with the server instance and publishes its status
    every 30 seconds)
    • Lookup of Services: AP (a client receives the view of the one server it connects to)
    • „Self-Preservation“ if a network partition is suspected between Server/Server or Clients/Server:
    The server keeps the current status of all known services

    View full-size slide

  32. Netflix Eureka
    Eureka – Pull and Cache instead of Query and Push (1/2)
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 32
    Etcd:
    • Service-Lookup with HTTP GET as synchronous call
    • Waiting for changes with HTTP GET blocking query („?wait=true&waitIndex=X“)
    Consul:
    • Service-Lookup with HTTP GET as synchronous call
    • Service-Lookup with HTTP GET as blocking query („?wait=Xs&index=Y“)

    View full-size slide

  33. Netflix Eureka
    Eureka – Pull and Cache instead of Query and Push (1/2)
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 33
    Eureka:
    • Clients pull every 30 seconds the delta from the service registry of their server
    • Server pull every 30 seconds the delta from other servers
    • Service lookup is a client-local operation
    • A status change can take up to 2 minutes to be published to all participants
    (Lookup with HTTP GET as a synchronous call is available via API, but rarely used)

    View full-size slide

  34. Getting Organized with Service Discovery for Microservices
    34
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016
    Everyday life in the cloud
    1
    etcd: Central Configuration Store
    2
    Consul: Service Discovery, Configuration and Monitoring
    3
    Eureka: Availability First!
    4
    Service Discovery Comparison
    5

    View full-size slide

  35. Service Discovery Comparison
    Capability Matrix
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 35
    Etcd Consul Eureka
    Configurations Yes Yes No
    Service Discovery
    via REST-API
    Yes
    (via KV-Store)
    Yes Yes
    Write configuration files Yes
    (via confd)
    Yes
    (native and confd)
    No
    Dynamic DNS Yes
    (via SkyDNS)
    Yes
    (native)
    No
    Topology Support No Yes (Data center
    & WAN)
    Yes
    (Region & Zone)
    Access Controls SSL Client-Certificates Detailed (ACLs) Servlet-Security
    Health Checks for Services No Yes No
    Edge Service (Vulcan) (Fabio) (Zuul)
    GUI No Yes No

    View full-size slide

  36. Service Discovery Comparison
    Who’s your favourite?
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 36
    Etcd – highly available Key-Value-Store
    • Part of CoreOS
    • Easy to use REST-API
    Consul – Services as „First Class Citizen“ in addition to Key-Value-Store
    • Active Monitoring of Services
    • Built in Security: Transport encryption und ACLs
    Eureka – Built for Amazon Cloud
    • Very good integration into the Amazon Infrastructure
    • Schedule-based replication of the complete service catalogue to the clients (Client Pull)
    • Availability first – Consistency second
    @ahus1de

    View full-size slide

  37. Service Discovery Comparison
    Links
    © msg | Getting Organized with Service Discovery for Microservices | Alexander Schwartz | Continuous Lifecycle London 2016 | 4 May 2016 37
    HashiCorps Consul für Service Discovery,
    Monitoring und Konfigurationsmanagement
    http://heise.de/-3040847
    eBay Fabio:
    https://github.com/eBay/fabio
    Nomad:
    https://www.nomadproject.io/
    Saltstack and Consul Examples
    https://github.com/ahus1/saltconsul-examples
    @ahus1de
    CoreOS etcd: https://github.com/coreos/etcd
    Jurnous etcdj: https://github.com/jurmous/etcd4j
    Vulcan: http://www.vulcanproxy.com/
    SkyDNS: https://github.com/skynetservices/skydns
    Netflix Eureka: https://github.com/Netflix/eureka
    Apache Zookeeper: https://zookeeper.apache.org/
    Netflix exhibitor: https://github.com/Netflix/exhibitor
    HashiCorp Consul: http://consul.io/

    View full-size slide

  38. .consulting .solutions .partnership
    Alexander Schwartz
    Principal IT Consultant
    +49 171 5625767
    [email protected]
    @ahus1de
    msg systems ag (Headquarters)
    Robert-Buerkle-Str. 1, 85737 Ismaning
    Germany
    www.msg-systems.com

    View full-size slide
