Scala Reactive Streams

Scala Reactive Streams

This talk is about the Reactive Streams initiative which became a new feature of JDK 9, known as java.util.conucrrent.Flow and how Akka Streams implements its contract in Scala.

Alexey Novakov

November 23, 2017
Tweet

More Decks by Alexey Novakov

Other Decks in Programming

Transcript

  1. Reactive Streams
    control flow, back-pressure, akka-streams
    Rhein-Main Scala Enthusiasts

    View Slide

  2. • Working at dataWerks
    • 10 years with JVM, 3 years with Scala
    • Focusing on distributed systems
    • Did online courses for learning Java language
    About me - Alexey Novakov

    View Slide

  3. What is Reactive Stream?
    • It is an initiative to provide a standard
    for asynchronous stream processing with
    non-blocking back pressure. (JVM &
    JavaScript)
    • Started by Lightbend, Pivotal, Netflix and others
    http://www.reactive-streams.org

    View Slide

  4. JVM Interfaces
    "org.reactivestreams" % "reactive-streams" % "1.0.1”
    "org.reactivestreams" % "reactive-streams-tck" % "1.0.1" % "test"
    at Maven Central: API + Technology Compatibility Kit
    Now is in JDK 9 as
    java.util.concurrent.Flow
    It is a copy of RS API

    View Slide

  5. Content
    • Keywords:
    ➔ publisher, subscriber, processor, subscription
    ➔ data stream processing
    ➔ synchronous / asynchronous
    ➔ back-pressure

    View Slide

  6. Reactive Manifesto
    http://www.reactivemanifesto.org
    … Reactive Streams are also related to Reactive Manifesto

    View Slide

  7. Stream parts
    Publisher Processor Subscriber
    Message Queue
    Http con.
    Database con.
    File
    etc.
    some data transformation
    function
    Console
    TCP

    etc.
    subscription subscription
    ordered
    or unordered

    View Slide

  8. Typical Scenarios

    with unbounded data

    processing

    View Slide

  9. Publisher & Subscriber
    Source Sink
    Data constantly is moving from Source to Sink
    Each flow stage can be sync or async
    Stage 1 Stage 2 Stage 3 Stage 4
    Flow

    View Slide

  10. Publisher & Subscriber
    Source Sink
    Well, I still have
    unfinished work
    I have 10K
    messages for you
    Time later:
    OutOfMemory
    R.I.P

    View Slide

  11. Problem situations
    1) Slow Publisher, Fast Subscriber
    2) Fast Publisher, Slow Subscriber
    Publisher also has to deal with its own back-pressure.
    I am busy,
    wait…
    Not so fast, I
    am working …
    I always have
    something for
    you

    View Slide

  12. Stream w/ back-pressure
    Source Sink
    I have 10K
    messages for you
    Sure, just let me
    know when you are
    ready
    Ok, give me next
    30 messages
    No buffer
    overflow
    anymore
    Subscriber
    signals about
    its demand
    Could you slow
    down? I have no
    space for those
    message

    View Slide

  13. Publisher:
    void subscribe(subscriber)
    Interfaces
    Subscriber:
    onSubscribe(s)
    onNext*(e)
    onError(t) | onComplete ?
    Subscription:
    request(n)
    cancel

    View Slide

  14. Back-pressure
    • Subscriber tells number messages it can process
    • Publisher sends that requested amount
    • It is simple protocol to enable dynamic “push-pull” communication
    ➢ Propagated through the entire stream (Source -> Sink)
    ➢ Enables bounded queue/buffer
    request(n)
    onNext(m)

    View Slide

  15. Implementation
    • Akka Streams
    • MongoDB
    • Ratpack
    • Reactive Rabbit
    • Reactor
    • RxJava
    • Slick
    • Vert.x 3.0
    • Monix

    View Slide

  16. • appeared around 2014
    • uses Actors behind the scene
    • provides Scala and Java DSL
    • driven by Lightbend Akka Team
    • simplifies usage Actors in some sense
    Streams Implementation

    View Slide

  17. Example 1
    A .. Z
    A + B + C + D…
    print(ABCD…)
    Source
    Flow
    Sink
    (Publisher)
    (Processor)
    (Subscriber)

    View Slide

  18. Example 1
    Output: ABCDEFGHIJKLMNOPQRSTUVWXYZ
    implicit val system = ActorSystem(”Example1")

    implicit val materializer = ActorMaterializer()
    val source = Source('A' to 'Z')

    val fold = Flow[Char].fold(" ")(_ + _)
    val sink = Sink.foreach[String](println)
    source.via(fold).to(sink).run
    These guys
    need to be
    around
    Stream Parts Bind and execute
    in a separate thread

    View Slide

  19. • Sometimes you need to run short-term stream and
    get a side-value as its result
    • It can be some metric
    • Or last element of the executed stream, etc.
    • Akka-Streams calls this process - Materialization
    Get a value back

    View Slide

  20. Example of mat value
    val source = Source(1 to 100)

    val concat = Flow[Int].filter(_ % 2 == 0)

    val sink = Sink.fold[Int, Int](0)(_ + _)


    val g: RunnableGraph[Future[Int]] =
    source.via(concat).toMat(sink)(Keep.right)

    val sum: Future[Int] = g.run

    sum.foreach(print)
    Output: 2550

    View Slide

  21. Akka-Streams
    Source, Flow, Sink
    RunnableGraph
    (blueprint)
    Materialized values
    A graph may produce some
    value as the result of stream
    execution
    Runtime
    Starting Actors,
    Opening Sockets,
    Providing other resources
    Order of streaming
    elements is preserved
    API reminds
    Scala Collections
    std library

    View Slide

  22. Stream Materialization
    • By default processing stages are fused:
    - only one Actor will be used
    - single-threaded processing
    Source(List (1, 2, 3))
    .map(_ + 1)
    .map(_ * 2)

    .to(Sink.ignore)

    View Slide

  23. Stream Materialization
    • Use “async” combinator to run on multiple actors
    Source(List (1, 2, 3))

    .map(_ + 1).async
    .map(_ * 2)

    .to(Sink.ignore)
    Async
    boundaries

    View Slide

  24. Example 2 – Stock Exchange Stream
    Order Id
    generator
    Order
    Gateway
    Order
    Logger
    Executor
    Order Processor
    Persistence
    MySQL
    Orders
    Source
    [Order]
    Sink
    [PartialFills]
    Flow
    [Order,
    PreparedOrder]
    Flow
    [PreparedOrder,
    LoggedOrder]
    Flow
    [LoggedOrder,
    ExecuteOrder]
    Flow
    [ExecuteOrder,
    PartialsFills
    MySQL
    Execution

    View Slide

  25. val orderPublisher = ActorPublisher[Order](orderGateway)
    Source.fromPublisher(orderPublisher)

    .via(OrderIdGenerator())

    .via(OrderPersistence(orderDao))

    .via(OrderProcessor())

    .via(OrderExecutor())

    .runWith(Sink.actorSubscriber(orderLogger))
    // testing: send some orders to publisher actor
    1 to 1000 foreach {
    _ => orderGateway ! generateRandomOrder
    }
    Is an ActorRef
    It is not aware
    about back-pressure

    View Slide

  26. object OrderIdGenerator {

    def apply(): Flow[Order, PreparedOrder, NotUsed] = {

    var seqNo: Long = 0


    def nextSeqNo(): Long = {

    seqNo += 1

    seqNo

    }


    Flow.fromFunction(o => PreparedOrder(o, nextSeqNo()))

    }

    }

    View Slide

  27. Example 2 alt. Fan Out
    Order Id
    Generator
    Order
    Gateway
    Order
    Logger
    Executor
    Order
    Processor
    Persistence
    MySQL
    Orders MySQL
    Execution
    Order
    Logger
    Order
    Logger
    Order
    Logger
    Order
    Logger
    Order
    Logger
    Broadcast
    Load
    Balance

    View Slide

  28. Example 2 alt.: Graph DSL
    val bcast = b.add(Broadcast[PreparedOrder](2))

    val balancer = b.add(Balance[PartialFills](workers))


    val S = b.add(Source.fromGraph(orderSource))

    val IdGen = b.add(OrderIdGenerator())

    val A = b.add(OrderPersistence(orderDao).to(Sink.ignore))

    val B = b.add(OrderProcessor2())

    val C = b.add(OrderExecutor())


    S ~> IdGen ~> bcast

    bcast ~> A

    bcast ~> B ~> C ~> balancer


    for (i <- 0 until workers)

    balancer ~> b.add(Sink.fromGraph(orderLogger).named(s"logger-$i"))

    View Slide

  29. Building Blocks
    Inlet Outlet

    View Slide

  30. /**
    * A bidirectional flow of elements
    * that consequently has two inputs and two
    * outputs, arranged like this:
    *
    * {{{
    * +------+
    * In1 ~>| |~> Out1
    * | bidi |
    * Out2 <~| |<~ In2
    * +------+
    * }}}
    */

    View Slide

  31. Nesting

    View Slide

  32. Cycling Graph

    View Slide

  33. • Let’s implement a WordCount over the infinite Twitter Stream
    • We can use free API: Filter Real-time Tweets
    - https://stream.twitter.com/1.1/statuses/filter.json
    - HTTP chunked response
    • Just register your Twitter app to get a consumer key
    Example 3 – Twitter Stream

    View Slide

  34. Example 3 – Twitter Stream
    scan[ByteString] filter[String] map[Tweet] scan[String] forEach[String]

    View Slide

  35. val response = Http().singleRequest(httpRequest)


    response.foreach { resp =>

    resp.status match {

    case OK =>

    val source: Source[ByteString, Any] =
    resp.entity.withoutSizeLimit().dataBytes
    ...
    }
    }

    Hi, akka-http :-)

    View Slide

  36. source

    .scan("")((acc, curr) =>

    if (acc.contains("\r\n")) curr.utf8String

    else acc + curr.utf8String

    )
    .filter(_.contains("\r\n")).async
    Reseting
    accumulator
    here

    View Slide

  37. scanLeft
    https://superruzafa.github.io/visual-scala-reference/index.html#scanLeft

    View Slide

  38. .scan(Map.empty[String, Int]) {

    (acc, text) => {

    val wc = tweetWordCount(text)

    ListMap(
    (acc combine wc).toSeq
    .sortBy(- _._2)
    .take(uniqueBuckets): _*
    )

    }

    }
    Starting from this stage,
    flow is concurrent

    View Slide

  39. def tweetWordCount(text: String): Map[String, Int] = {

    text.split(" ")

    .filter(s => s.trim.nonEmpty && s.matches("\\w+"))

    .map(_.trim.toLowerCase)

    .filterNot(stopWords.contains)

    .foldLeft(Map.empty[String, Int]) {

    (count, word) => count |+| Map(word -> 1)
    }

    }

    View Slide

  40. .runForeach { wc =>

    val stats = wc.take(topCount)
    .map{case (k, v) => k + ":" + v}.mkString(" ")

    print("\r" + stats)

    }

    View Slide

  41. Project Alpakka
    Source/Flow/Sink implementation for many popular data sources
    • AMQP Connector
    • Apache Geode connector
    • AWS DynamoDB Connector
    • AWS Kinesis Connector
    • AWS Lambda Connector
    • AWS S3 Connector
    • AWS SNS Connector
    • AWS SQS Connector
    • Azure Storage Queue
    Connector
    • Cassandra Connector
    • Elasticsearch Connector
    • File Connectors
    • FTP Connector
    • Google Cloud Pub/Sub
    • HBase connector
    • IronMq Connector
    • JMS Connector
    • MongoDB Connector
    • MQTT Connector
    • Server-sent Events (SSE)
    Connector
    • Slick (JDBC) Connector
    • Spring Web
    • File IO
    • Azure
    • Camel
    • Eventuate
    • FS2
    • HTTP Client
    • MongoDB
    • Kafka
    • TCP

    View Slide

  42. Konrad Molawski at JavaOne 2017
    https://www.youtube.com/watch?v=KbZ-psFJ-fQ

    View Slide

  43. Going to Production
    • Configure your ExecutionContext
    • Set Supervision strategy to react on failures
    • Think/test which stage can be fused and which can be done
    concurrently
    • Think on using grouping of the elements for better throughput
    • Set Overflow strategy
    • Think on rate limiter using throttle combinator

    View Slide

  44. Thank you! Questions?
    More to learn:
    • https://doc.akka.io/docs/akka/2.5.6/scala/stream/
    Official documentation
    • https://github.com/reactive-streams/reactive-streams-jvm
    Reactive Streams specification
    • https://blog.redelastic.com/diving-into-akka-streams-2770b3aeabb0
    Kevin Webber, Diving into Akka Streams
    • http://blog.colinbreck.com/patterns-for-streaming-measurement-data-with-akka-streams/
    Colin Breck: Patterns for Streaming Measurement Data with Akka Streams
    • https://github.com/novakov-alexey/meetup-akka-streams
    Examples Source Code

    View Slide
