DDD-rail your Monorail

The scene cuts to the offices of Delorean - the hottest time-transport startup in town (“it’s like Uber for time travel!”). Beneath the glitzy face of the fast-growing company, we find a defeated engineering team struggling with a large Rails monolith, complete with the battle scars of anemic domain models, spaghetti code, and cut corners. The team is shipping fewer features while battling increasing rates of unexpected regressions. The team wants to break up the monolith to combat complexity, but where do they begin? Join the team as they turn to three Domain-Driven Design (DDD) techniques to discover key domain insights and attempt to design their way out of the monolith mess into a well-defined, cleanly segregated, and service-oriented future. Will they succeed, or will the inexorable tides of time and entropy forever trap this team in the past?

Presentation: https://www.youtube.com/watch?v=TljmIXW2fwM

Don't forget to check out the companion sample app: https://github.com/andrewhao/delorean

Transcript

1. DDD-rail Your Monorail
   Breaking up the Rails monolith
   with domain driven design



   View Slide

2. Hi, I’m Andrew


   View Slide

3. View Slide

4. Meet Delorean
   “It’s like Uber, for time travel!”



   View Slide

5. The situation


   View Slide

6. %


   View Slide

7. What happened?


   View Slide

8. In the beginning, there
   was an app.


   View Slide

9. The business decides…
   • Drivers deliver passengers from year A to
   year B. ⌛


   View Slide

10. View Slide

11. View Slide

12. View Slide

13. The business decides…
    • Drivers deliver passengers from year A to
    year B. ⌛
    • Passengers choose the type of Delorean
    service they want.


    View Slide

14. View Slide

15. View Slide

16. View Slide

17. The business decides…
    • Drivers deliver passengers from year A to
    year B. ⌛
    • Passengers choose the type of Delorean
    service they want.
    • Time travel carpools! 01


    View Slide

18. View Slide

19. View Slide

20. View Slide

21. The business decides…
    • Drivers deliver passengers from year A to year B. ⌛
    • Passengers choose the type of Delorean service they
    want.
    • Time travel carpools! 01
    • DeloreanEATS: Customers order food, drivers pick
    up from time period and deliver to customer time
    period!


    View Slide

22. View Slide

23. View Slide

24. View Slide

25. Hm.


    View Slide

26. View Slide

27. Regressions


    View Slide

28. The Payments team regresses
    Trip while refactoring ServiceTier


    View Slide

29. The Restaurants team deploys a
    new pricing algorithm that
    regresses rideshare pricing


    View Slide

30. Responsibilities?


    View Slide

31. The Mobile team requests a new
    mobile login API, but which team
    should implement it?


    View Slide

32. Business won’t stop


    View Slide

33. Outsourced dev shop is rebuilding
    the marketing home page and
    needs a pricing API.


    View Slide

34. CEO wants to launch "Airbnb for
    time travel” feature in, let’s say, 2
    months!


    View Slide

35. Does this sound familiar?


    View Slide

36. There are deeper insights to be had


    View Slide

37. What is DDD?


    View Slide

38. A set of techniques to arrive at a
    flexible design that cleanly maps
    to the business model


    View Slide

39. Strong, expressive domain
    models


    View Slide

40. There is no such thing as a
    One True Perfect model


    View Slide

41. Embrace the chaos


    View Slide

42. Domain-Driven
    Design: Eric Evans
    Implementing Domain-
    Driven Design: Vaughn
    Vernon


    View Slide

43. Let’s get designing!


    View Slide

44. Step 1: Visualize your domain models


    View Slide

45. Rails ERD
    https://github.com/voormedia/rails-erd


    View Slide

46. Ruby gem to generate UML diagrams from
    your ActiveRecord models


    View Slide

47. View Slide

48. This helps you get the entire system into
    your mind.


    View Slide

49. Print it out!
    ✏


    View Slide

50. Step 2: Find your core- and sub-domains


    View Slide

51. Concept: Core Domain


    View Slide

52. What a business does


    View Slide

53. Transportation Core Domain


    View Slide

54. Concept: Subdomains


    View Slide

55. A supporting unit within the
    business


    View Slide

56. Rideshare Subdomain
    Food Delivery Subdomain
    Financial Transaction Subdomain
    Identity and Access Subdomain


    View Slide

57. Ridesharing
    Food Delivery
    Financial
    Transactions
    Identity/
    Access


    View Slide

58. Step 3: Get the team talking in the same
    language


    View Slide

59. Concept: Ubiquitous Language


    View Slide

60. A defined language that is used
    consistently across business and
    technical contexts


    View Slide

61. Bring in the domain experts


    View Slide

62. A Driver picks up a Passenger


    View Slide

63. A Passenger requests a Pickup


    View Slide

64. An Owner drives a Vehicle


    View Slide

65. An Operator? drives a Vehicle


    View Slide

66. A User logs in and changes her Password


    View Slide

67. An Invoice is delivered to the Passenger


    View Slide

68. A Customer orders an item from a Menu,
    which is picked up and delivered by the
    Delivery Agent


    View Slide

69. Step 4: Make a glossary


    View Slide

70. Ridesharing
    • Passenger: “…”
    • Driver: “…”
    • Trip: “…”
    • Pickup: “…”
    • Vehicle: “…”
    • Vehicle Owner: “…”


    View Slide

71. Financial Transaction
    • Invoice: “…”
    • Order: “…”
    • Payment: “…”
    • Royalty: “…”
    • Salary: “…”


    View Slide

72. Identity and Access
    • User: “…”
    • Secure password: “…”
    • Role: “…”


    View Slide

73. Print ‘em out!
    ✏


    View Slide

74. Step 5: Draw out your software systems
    (bounded contexts)


    View Slide

75. Concept: Bounded Contexts


    View Slide

76. A software system that defines the
    applicability of a ubiquitous
    language


    View Slide

77. FoodDeliveryService TripRoutingEngine
    “menu” “trip”
    “restaurant” “plan”
    “delivery” “pickup”
    “customer date” “destination”


    View Slide

78. Software systems are natural boundaries for
    these linguistic terms


    View Slide

79. If a term leaks into a different software
    system/bounded context, you have a smell


    View Slide

80. Ridesharing
    Financial
    Transactions
    Identity/
    Access
    Food Delivery
    DeloreanMonolith
    StripeAPI


    View Slide

81. DeloreanMonolith
    Ridesharing
    Financial
    Transactions
    Identity/
    Access
    Stripe API
    Food Delivery


    View Slide

82. DeloreanMonolith
    Identity/
    Access
    Food Delivery
    Driver
    Routing
    Service
    Fraud
    Detection
    Service (etc)


    View Slide

83. DeloreanMonolith
    Ridesharing
    Financial
    Transactions
    Identity/
    Access
    Stripe API
    Food Delivery


    View Slide

84. Step 6: Now add directional dependencies


    View Slide

85. DeloreanMonolith
    Ridesharing
    Financial
    Transactions
    Identity/
    Access
    Stripe API
    Food Delivery
    U
    D


    View Slide

86. DeloreanMonolith
    Identity/
    Access
    Food Delivery
    Driver
    Routing
    Service
    Fraud
    Detection
    Service (etc)
    U
    U
    D
    U
    D U
    D


    View Slide

87. This helps you see dependencies between
    teams, where communication will be most
    important.


    View Slide

88. Context Map: A tool to visualize how your
    software systems relate to each other and
    the domain(s)


    View Slide

89. Our goal is to map our bounded contexts
    directly to our subdomains.


    View Slide

90. Ridesharing
    Financial
    Transactions
    Identity/
    Access
    Stripe API
    Food Delivery


    View Slide

91. Show me the code!


    View Slide

92. Tactic 1: Get the names right


    View Slide

93. Adjust your class and method names to
    reflect the ubiquitous language


    View Slide

94. # old
    User.without_drivers
    # new
    Passenger.hailing_drivers
    # old
    order.calculate_cost
    # new
    order.calculate_billing_total


    View Slide

95. Tactic 2: Namespace and
    modulize your domains


    View Slide

96. Break Rails’ folder structure conventions


    View Slide

97. app/domains/financial
    app/domains/financial/inflation_adjustment.rb
    app/domains/financial/invoice.rb
    app/domains/food_delivery
    app/domains/food_delivery/menu.rb
    app/domains/food_delivery/menu_item.rb
    app/domains/food_delivery/menu_items_controller.rb
    app/domains/food_delivery/menus_controller.rb
    app/domains/identity
    app/domains/identity/user.rb
    app/domains/identity/users_controller.rb
    app/domains/rideshare
    app/domains/rideshare/driver.rb
    app/domains/rideshare/passenger.rb
    app/domains/rideshare/service_tier.rb


    View Slide

98. class Menu < ActiveRecord::Base
    belongs_to :restaurant
    end


    View Slide

99. module FoodDelivery
    class Menu < ActiveRecord::Base
    belongs_to :restaurant
    end
    end


    View Slide

100. class Trip < ActiveRecord::Base
     belongs_to :service_tier
     belongs_to :vehicle
     end


     View Slide

101. module Rideshare
     class Trip < ActiveRecord::Base
     belongs_to :service_tier
     belongs_to :vehicle
     end
     end


     View Slide

102. Domain code stays together


     View Slide

103. Tactic 3: Design with
     Aggregate Roots


     View Slide

104. Aggregate: A collection of domain objects
     that can be treated as a single unit


     View Slide

105. Use aggregates to model real-world entities
     that belong together


     View Slide

106. Aggregate Root: An entity at the “top” of the
     collection that can represent the whole


     View Slide

107. FoodDelivery aggregate root: Order


     View Slide

108. Food Delivery


     View Slide

109. A user adds a menu item to their cart


     View Slide

110. A User adds a MenuItem into their
     ShoppingCart


     View Slide

111. module Financial
     class ShoppingCart
     def order
     @order ||= FoodDelivery::Order.new
     end
     def amount
     @order.menu_items.sum(&:cost) +
     @order.menu_items.sum(&:tax_amount)
     end
     def add(item)
     order.menu_items << item
     end
     def remove(item)
     order.menu_items.delete(item); order.save
     end
     end
     end


     View Slide

112. module FoodDelivery
     class Order < ActiveRecord::Base
     belongs_to :user
     has_many :order_menu_items
     has_many :menu_items, through: :order_menu_items
     end
     end


     View Slide

113. module FoodDelivery
     class Order < ActiveRecord::Base
     belongs_to :user
     has_many :order_menu_items
     has_many :menu_items, through: :order_menu_items
     def total_cost
     item_cost + tax_cost
     end
     def item_cost
     menu_items.sum(&:cost)
     end
     def tax_cost
     menu_items.sum(&:tax_amount)
     end
     def add_item!(menu_item)
     menu_items << menu_item
     end
     def remove_item!(menu_item)
     menu_items.delete(menu_item); save
     end
     end
     end


     View Slide

114. module Financial
     class ShoppingCart
     def order
     @order ||= FoodDelivery::Order.new
     end
     def amount
     @order.total_cost
     end
     def add(item)
     order.add_item!(item)
     end
     def remove(item)
     order.remove_item!(item)
     end
     end
     end
     Calculation logic kept in
     FoodDelivery domain
     Implementation-
     agnostic


     View Slide

115. The root items of these aggregates are the
     only entities that external callers may fetch


     View Slide

116. Ridesharing
     Financial Transactions
     Identity/Access
     Food Delivery


     View Slide

117. Building good interfaces for a service
     oriented future!


     View Slide

118. Tactic 4: Break database
     joins between domains


     View Slide

119. `has_many`-itis!


     View Slide

120. module Rideshare
     class Trip < ActiveRecord::Base
     belongs_to :service_tier
     has_many :trip_pool_trips
     has_one :trip_pool, through: :trip_pool_trips
     belongs_to :driver, foreign_key: :driver_id, class_name: I
     belongs_to :passenger, foreign_key: :passenger_id, class_n
     belongs_to :vehicle
     belongs_to :order, class_name: FoodDelivery::Order
     has_one :payment
     end


     View Slide

121. These tend to happen in your God Objects


     View Slide

122. View Slide

123. module Rideshare
     class Trip < ActiveRecord::Base
     belongs_to :service_tier
     has_many :trip_pool_trips
     has_one :trip_pool, through: :trip_pool_trips
     belongs_to :driver, foreign_key: :driver_id, class_name: I
     belongs_to :passenger, foreign_key: :passenger_id, class_n
     belongs_to :vehicle
     belongs_to :order, class_name: FoodDelivery::Order
     has_one :payment
     end


     View Slide

124. module Rideshare
     class Trip < ActiveRecord::Base
     # belongs_to :order, class_name: FoodDelivery::Order
     def order
     FoodDeliveryAdapter.new.order_from_trip(self)
     end
     end
     end


     View Slide

125. module Rideshare
     class FoodDeliveryAdapter
     def order_from_trip(trip)
     FoodDelivery::Order.find_by(trip_id: trip.id)
     end
     end
     end


     View Slide

126. Decoupling domains now will ease your
     architectural transitions later


     View Slide

127. You can do this all in small
     steps!


     View Slide

128. Toward a distributed
     architecture


     View Slide

129. Namespaced, Isolated Modules to
     Rails Engines


     View Slide

130. Component-Based Rails
     Engines (Stephan Hagemann)


     View Slide

131. Rails engines to a remote (micro-)service


     View Slide

132. Good architecture goes a very long way.


     View Slide

133. To recap



     View Slide

134. Drew things on a wall


     View Slide

135. Came up with a language


     View Slide

136. Moved code around


     View Slide

137. Team is on the same page


     View Slide

138. Big idea: Your software speaks the
     same language as your domain
     experts


     View Slide

139. Big idea: Bounded contexts are separators
     for linguistic drivers. Keep your language
     consistent in one and only one system


     View Slide

140. Big idea: Domain code
     should live together


     View Slide

141. Big idea: Adapters between
     domains enforce domain purity


     View Slide

142. Big idea: Incremental
     changes


     View Slide

143. Thanks!
     Sample code: https://github.com/andrewhao/delorean
     Slides: https://github.com/andrewhao/dddrail-talk
     Twitter @andrewhao
     Github @andrewhao
     8


     View Slide
