STPA and Software Verification

I presented the topic of the STPA safety analysis approach and software verificaiton to teach master students how to verify software design and software implementations against the STPA safety requirements which is documented in XSTAMPP.

Transcript

1. Sommersemester 2017 Dr. Asim Abdulkhaleq STPA and Software Verification
2. You can copy, share and change, film and photograph, blog, live-blog and tweet this presentation given that you attribute it to its author and respect the rights and licenses of its parts. based on slides by @SMEasterbrook und @ethanwhite
3. STPA Approach
4. STPA Approach (Recall)
5. STPA Artefacts (Recall) Diagrams •Control Structure Diagram •Process Model The main components used in STPA Data Lists • Accidents • Hazards • System Goals • Design and safety Requirements Data Tables • Unsafe Control Actions • Corresponding Safety Constraints • Causal Factors
6. STPA Data Flow (Recall)
7. Software Verification
8. Software Verification and Validation (V&V) Verification “Have we developed the software right?” Validation “Have we developed the right software?” Boehm, Barry (1989). "Software Risk Management".
9. Software Verification Dynamic Verification (Test, experimentation) • Module Test • Integration Test • System Test • Acceptance Test • … Static Verification (Analysis) • Code Conventions Verification • Bad Practices (anti-Pattern) Detection • Software Metrics Calculation • Formal Verification • … Approaches to Verification Ghezzi, et al. Fundamentals of Software Engineering, Prentice Hall, ISBN 0-13-099183-X
10. Formal Verification What we need to formally verify a software? Software Requirements Software Control Actions? Feedback? Autonomous vehicle modelled in graphical notations e.g. State- machine, stateflow. Software Design Models written in natural language e.g. English Software Code written in high-level programming language e.g. C, C++ or Java Formalisation Transformation
11. Formal Specification and Verification Specify and verify properties about how a system changes over time Temporal Logics (TL) “is a convenient formalism technique for specifying and verifying properties of reactive systems” Linear Temporal Logic (LTL) “is a mathematical language for description linear-time properties” Properties of interest include : - Safety : “Nothing bad will happen” - Liveness: “Something good will happen”. - Fairness : “Independent subsystems make progress
12. Formal Specification and Verification An LTL consists of: - atomic proposition symbols [p, r, q,..], Boolean operators , and temporal operators: TL Operator LTL Operator Meaning Diagram G ∅ means ”globally/always”. ∅ is true now and forever in the future X ∅ means “at the next time”. ∅ is true in the next state F ∅ means “eventually”. ∅ is true in some future state ℛ ψ R ∅ means “releases”. ∅ is true until and including the point where ψ become true. If ψ never becomes true, then ∅ must remain true forever ψ U ∅ means ”until”. ψ is at least true until ∅ happens at the current or a future position
13. Exercise: Formal Specification Which LTL formula specifies the following requirement “The train door software must not close (reopen) the train door when there is a person in the doorway”? 1. LTL= G ((Person_In_Door_Way) -> G (ControlAction=Close)) 2. LTL = G (!(Person_In_Door_Way) -> (ControlAction=Close) ) 3. LTL = G ((Person_In_Door_Way) -> X ! (ControlAction=Close)) 4. LTL = G ((Person_In_Door_Way) -> X! (ControlAction=Open)) 3 Minutes
14. Software Formal Verification Process How to verify my software design model/code? Software Requirements Software Design/Code Software Verification Not Satisfied Satisfied Errors Track Input Output No Results check Yes No
15. Software Model Checking A technique to automatically verify whether the software meets its requirements. At the design level • The verification model can be constructed/extracted from the software behaviour models such as finite state machine. • Model checkers can be used at this level are: 1. SMV (Symbolic model Verifier) model checker 2. NuSMV Model checker 3. … At the implementation level • The verification model can be constructed/extracted directly from software code written in C or Java. • Software model checkers can be used at this level are: 1. SPIN (Simple Promela Interpreter) 2. …
16. SMV Language Structure of the SMV model
17. SMV Language Example Train door controller MODULE main VAR states: {OpenDoor , CloseDoor}; Person_In_Door_Way: boolean; ControlAction:{Open, Close}; ASSIGN init (states):=OpenDoor; init(Person_In_Door_Way):=bool(0); next (states):=case states=OpenDoor & !(Person_In_Door_Way) : CloseDoor; states=CloseDoor& (Person_In_Door_Way): OpenDoor; TRUE: {CloseDoor ,OpenDoor}; esac; next(ControlAction):=case states=OpenDoor: Open; states=OpenDoor & !(Person_In_Door_Way) : Close; states=CloseDoor& (Person_In_Door_Way): Open; TRUE:{Open, Close}; esac; Software behavioural model (stateflow) SMV Model (verification model)
18. NuSMV Model Checker •It is an open source tool developed by ITC-IRST and UniTN 1999 •It is an extension and re-implementation of SMV model checker. •It based on Binary Decision Diagram (BDD) to verify finite state machine against its specifications expressed in LTL
19. Exercise: Formal Specification Which LTL formula is satisfied by the SMV model of the train door controller ? 1. LTL= G ((Person_In_Door_Way) -> G (ControlAction=Close)) 2. LTL = G (!(Person_In_Door_Way) -> (ControlAction=Close) ) 3. LTL = G ((Person_In_Door_Way) -> X ! (ControlAction=Close)) 4. LTL = G ((Person_In_Door_Way) -> X ! (ControlAction=Open)) 3 Minutes
20. NuSMV Model Checker Result “it contains information that shows why the given LTL is not satisfied” Counterexample -- specification G (Person_In_Door_Way -> G ControlAction = Close) is false -- as demonstrated by the following execution sequence Trace Description: LTL Counterexample Trace Type: Counterexample -> State: 1.1 <- states = OpenDoor Person_In_Door_Way = FALSE ControlAction = Open -> State: 1.2 <- states = CloseDoor Person_In_Door_Way = TRUE -- Loop starts here -> State: 1.3 <- states = OpenDoor Person_In_Door_Way = FALSE -> State: 1.4 <- states = CloseDoor -> State: 1.5 <- states = OpenDoor 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11 12. 13. 14. 15. 16. 17. 18. 19. 20. 21. 22.
21. Formal Verification Challenges •Formal verification focuses on proving the functional correctness of software. •It can not make the software safe or reduce the risk. •It needs expert users •The requirements can not be directly verified by software model checker •State explosion problem
22. STPA in Software Verification
23. STPA in Software Verification How to verify software against STPA results? Software Control Actions? Feedback? Train Door satisfied not satisfied STPA Safety Requirements Safety constraints STPA Results Software Verification (Formal Verification & Testing)
24. STPA SwISs: A System-Theoretic Safety Engineering Approach for Software-Intensive Systems
25. Detailed STPA SwISs Approach
26. Exercise: Apply STPA to Train Door System Disuse with your colleague how to apply STPA to the train door system and do the following: 1. Write one accident that the software controller of train door can contribute in. 2. Write 3 hazards which maybe cause this accident. 3. Translate the identified hazards into the safety constraints. 4. Draw the control structure diagram of the train door system. 5. Identify one unsafe control action and translate it into a corresponding safety constraint. 10 Minutes
27. Deriving the STPA Software Safety Requirements Accidents • AC1- A person is injured while the train closed the door. • …. Hazards • H1- Door close on a person in the doorway. • … System-level safety constraint • The train door controller must not close the door while a person is in the doorway • … safety control structure diagram of train door system
28. Unsafe Control Actions Control Action • C1- Close • …. Unsafe Control Actions • UCA1.1- Train door controller closes the door while a person in the doorway • … Corresponding Safety Constraints • CSC 1.1- Train door controller must not close the door while a person or object is in the doorway • …
29. Process Model & Variables
30. Generating the Unsafe Scenarios & Requirements Unsafe Control action • UCA1.1- Train door controller closes the door while a person in the doorway Basic Scenario • RUCA1.1- The door software controller provided the control action close door while the train is stopped, train position is aligned, door state is open and a person is in the doorway. Refined software safety constraint • RSC1.1- The door software controller must not provide the control action close door while the train is stopped, train position is aligned, door state is open and a person is in the doorway.
31. Causal Factors & Causal Scenarios How each unsafe control action could occur in the system?
32. Formalisation of STPA Results
33. Formalisation of STPA Results Providing or not providing a control action (CA) is based on the occurrence of the set of values of process model variables and higher inputs (CS). • Rule 1: When CS occur in the execution path, the software must not (!) provide CA. Then, LTL formula can be expressed as: LTL = G ( CS → ! CA). • Rule 2: When CS occur in the execution path, the software must provide CA at the next step. then LTL formula can be expressed as:LTL = G ( CS → X CA) • Rule 3: The software must always not (!) provide CA too early (U) before CS the occurrence of CS still not become true. Then, the LTL formula can be expressed as: LTL = G ((CA →CS) & (!CA U CS)) • Rule 4: The software must always not (!) provide CA too late (U) while the occurrences of the critical set of combinations CS has become previously true in the execution path. Then, the LTL formula can be expressed as: LTL = G ((CS → CA) & (!CS U CA))
34. Exercise: Formalisation of STPA Results Write the corresponding LTL formula for the following software safety requirements: 1. “The train door software controller must not provide the control action close door while the train is stopped, train position is aligned, door state is open and a person is in the doorway” 2. The train door software controller must provide the control action open door when there is a person in doorway. 5 Minutes
35. Verify STPA Results within XSTAMPP
36. XSTAMPP •It is an open source tool developed at our institute through student project and job (2013-2017). •Designed specially to serve the widespread adoption and use of STAMP in different areas. •It extended with an plugin called STPA verifier to support the software safety and verification (formal verification and testing activities). www.xstampp.de
37. STPA Verifier Process www.xstampp.de
38. STPA Verifier Main Window
39. Generating Safety- based Test Case from STPA Results
40. Detailed STPA SwISs Approach (Recall)
41. Safety-based Test Case Generation Algorithm Safe Behavioral Model Verify ? Safety-based Test Cases traverse not satisfied satisfied modify export LTL formulae STPA Results Traceability matrix transform check SMV Model Safe Test Model model Test case sheet transform Generating Safety-based Test Cases 1 Modelling STPA Results 2 Transforming into a Formal Model 3 Checking Correctness with Model Checker 4 Generating Runnable Safe Test Model 5 Algorithm
42. Modelling STPA Results A Safe Software behavioural Model
43. Mapping STPA Results into Stateflow Model
44. Safe behavioural model of train door controller Control structure diagram with process model Safe behavioural model of train door controller
45. STPA Test Cases Generator
46. References ISBN-10: 3736994923 ISBN-13: 978-3736994928 ISBN: 9780262026499
47. Dr. Asim Abdulkhaleq e-mail asim.abdulkhaleq@informatik.uni- stuttgart.de phone +49 (0) 711 685-88458 WWW www.iste.uni-stuttgart.de/se Twitter @AbdulkhaleqAsim Institute of Software Technology
