1. Accelerating high-throughput image analysis using flexible Cloud environments Ola Tarkowska Solution Architect Cellular Genetics Informatics Wellcome Sanger Institute 2nd March 2021 Informatics Seminar
2. New Sanger-EBI Initiative for Large-Scale Spatial Genomics https://www.sanger.ac.uk/group/high-throughput-spatial-genomics/
3. People involved
4. Instrumentation: The Opera Phenix High Content Screening Microscope one microscope produces up to ~2.4TB of data per day we are going to have more
5. Estimated data acquisition in Petabytes End of 2021: 4.8 TB / per day 2022: 8.4 TB / per day
6. Test dataset: running pipeline on the Cloud Sample provided by Roser Vento Lab Stringer, C., Wang, T., Michaelos, M. et al. Cellpose: a generalist algorithm for cellular segmentation. Nat Methods 18, 100–106 (2021). https://doi.org/10.1038/s41592-020-01018-x ~4.2TB/day to be analysed Tissue [12391 × 8299 pix] Dual-channel raw data (nuclei + cell border) 2D segmentation 40 min 0.4 GB
7. Preliminary observations • GPU acceleration improved performance. • We need hundreds of GPUs to accommodate the high-throughput. • Code can be significantly optimised or tools can even change. • Estimated data acquisition can grow. We need flexibility
8. How to be flexible when you need hundreds of GPUs? CellGen has 2 x V100 SMX2 GPU's We need hundreds of GPU units
9. Hardware on-premises
10. Hardware on the Cloud
11. Flexibility: Google Cloud Platform Compute Engine GPU model Year GPUs GPU memory Available vCPUs Available memory Tensor cores CUDA cores NVIDIA® Tesla® K80 Kepler 2014 8 GPUs 96 GB GDDR5 1 - 64 vCPUs 1 - 208 GB --- 2,496 NVIDIA® Tesla® P100 Pascal 2016 4 GPUs 64 GB HBM2 1 - 96 vCPUs 1 - 624 GB --- 3,584 NVIDIA® Tesla® P4 Pascal 2016 4 GPUs 32 GB GDDR5 1 - 96 vCPUs 1 - 624 GB --- 2,560 NVIDIA® Tesla® V100 Volta 2017 8 GPUs 128 GB HBM2 1 - 96 vCPUs 1 - 624 GB 640 5,120 NVIDIA® Tesla® T4 Turing 2018 4 GPUs 64 GB GDDR6 1 - 96 vCPUs 1 - 624 GB 320 2,560 NVIDIA® Tesla® A100 Ampere 2020 16 GPUs 640 GB HBM2 Up to 96 vCPUs* Up to 1.3 TB 432 6,912 *The A2 family uses Cascade Lake CPUs
12. Google Cloud Platform • We ran a PoC with Google Life Sciences team that was funded by Google • Available GPU accelerators were tested. • The results confirmed needs for flexible hardware. Flexibility comes at a price (cost of the cloud is always higher than on premises)
13. Estimated Cloud Cost First estimation of price £600,000 assuming • current tool • current data production rate • current GPU landscape All of them can change
14. Flexibility allows to reduce higher cost Broad’s GATK pipeline 10x cost reduction In our genes: How Google Cloud helps the Broad Institute slash the cost of research https://cloud.google.com/blog/topics/inside-google-cloud/our-genes-how-google-cloud-helps-broad-institute-slash-cost-research
15. Built-in tools to reduce the cost
16. How to run analysis on the Cloud with minimum effort?
17. Nextflow on LSF NF-Tower provided by Martin Prete
18. Nextflow on GCP using ‘google-lifescience’ executor
19. Our infrastructure on GCP https://cloud.google.com/life-sciences Nextflow Tower UI
20. Recipe for processing large volumes of data • Flexibility • Future optimisation and cost reduction. • Nextflow + NF-tower as a platform • Google team support
21. Acknowledgement Google Team Hatem Nawar Evi Karakozoglou Marina Perkins Ilias Katsardis Annalisa Pawlosky Ulrike Gupta Bayraktar Lab Tong Li Omer Bayraktar CellGenI Team Ola Tarkowska Vladimir Kiselev Sanger IT Pete Claphman Tim Cutts Nextflow Paolo Di Tommaso Evan Floden
22. Thank you for listening
