AzureBootcamp2022: Unlocking the value of Azure IoT and Data Analytics by Abduxukur Abdurixit

AzureBootcamp2022: Unlocking the value of Azure IoT and Data Analytics by Abduxukur Abdurixit

This session is one of the sessions of Azure Bootcamp Switzerland 2022.
www.azurebootcamp.ch

Leveraging 5G connectivity and Microsoft Azure ecosystems for IoT and data analytics services is an effective means to solve business requirements. By collecting, storing, and processing data at the edge and in the cloud, companies also become more innovative and transform toward a data driven business. Customers like Rhomberg Sersa Rail Group showcase just that and more, when they embarked with us on the journey of digitizing their railway infrastructure construction sites. With that, their benefits became measurable: from increased employee safety, to reduced CO2 emissions, to financial advantages. In this session, we will take a closer look at this particular and other projects to show you how we leveraged Azure services such as IoT Edge, Stream Analytics, SQL database, Logic Apps, Service Bus and more to collect, store and process data in real-time or batch. We will also address some of our lessons learned and take a look at what the future may bring in this area.
🙂 ABDUXUKUR ABDURIXIT ⚡️ Senior Cloud Architect @ Swisscom

Check out Abduxukur at: https://www.linkedin.com/in/abdurixit/

Azure Zurich User Group
PRO

May 10, 2022
Tweet

More Decks by Azure Zurich User Group

Other Decks in Technology

Transcript

  1. Unlocking the value of Azure IoT and Analytics 10.05.2022, Abduxukur

    Abdurixit Cloud Architect @Swisscom
  2. customer expectation not a jitter high level tack condition Zermatt

    to St.Moritz
  3. railway tunnel reconstruction track renewal track construction Rhomberg Sersa Rail

    Group off-peak hours critical situations safety conditions track maintenance
  4. shorten construction phases monitoring & call up the state of

    the infrastructure Vision simulate the process in advance enhancement of on-site safety CO2 footprint improvement transparency throughout a construction project Data & Innovation
  5. Digitalization @ Rhomberg Sersa Rail Group – Software-as-a-tool in track

    construction and maintenance Which tools are needed? Are the right skills present? Which company can provide such a solution and thus be a good partner?
  6. Rhomberg Sersa's project goal MM RSRG Railium mLogistics BOOM 6

    Dritte Track construction machines Locomotives Cranes Wagons Dumper Excavator Container Gastanks Small appliances
  7. Project Plan

  8. 5G Mobile Private Network 2 IoT HUB Custom Vision Percept

    Stream Analytics SQL Database Blob Storage Power BI COSMOS DB Event HUB Power Apps Logic App Function App Synapes Analytics Active Directoy Containers API Mgmt. Databricks Privat IoT Edge 5G SA Mobile Core 1 Edge Storage Account Custom Vision Model 5G Radio 5G Baseband 5G GW Kubernetes Services Percept Networking Azure Stack Edge Project 5G / 4G Mobile Private Network on an Azure Stack Edge (ASE). Connecting people and things, for example construction equipment, machines, robots. 1 Project Buffering and Synchronisation of ASE with central Azure platform. 2 Public Project in a nutshell
  9. 5G Mobile Private Network Public 3 Privat 3 IoT Edge

    5G SA Mobile Core Edge Storage Account Custom Vision Model 5G Radio 5G Baseband 3 5G GW Kubernetes Services Percept Networking Azure Stack Edge IoT HUB Custom Vision Percept Stream Analytics SQL Database Blob Storage Power BI COSMOS DB Event HUB Power Apps Logic App Function App Synapes Analytics Active Directoy Containers API Mgmt. Databricks IoT Edge Percept Project in a nutshell Project Pre-processing and data analysis on ASE (i.e. AI- models for real-time decisions in automated image analysis). 3
  10. Public Mobile Network Public 5 GW 4 Project Machine-monitoring based

    on Azure (i.e. usage analysis, condition monitoring, limit analysis, alarming) 5 IoT Tracker 4 IoT HUB Custom Vision Percept Stream Analytics SQL Database Blob Storage Power BI COSMOS DB Event HUB Power Apps Logic App Function App Synapes Analytics Active Directoy Containers API Mgmt. Databricks Core & DDH Project in a nutshell Project Individualised localisation and tracking Solution for construction equipment and machines (international) 4
  11. 12 Original Architecture (2020) SMG Box VIB Box SMG Swisscom

    Box Cognid Box VIB Box Liebherr Box Samsara Box BBW Box System 7 IoT Hub Cognid Backend VIB Backend Liebherr Backend Samsara Backend Config (Sleeptime, …) fx IoT Hub + fx fx Logic App + fx Logic App + fx Logic App + fx REST MQTT Event Email SQL Rest? Blob Digital Twin Alice Web BI Visulisierung GeneralTelepetry (realtime harmonisiert) DataWarehouse (non realtime) Parameter Mapping Maschinen ID Mapping Legende GUI Key / ID Konfiguration Fremdsystem SMG IT Fremdsystem in RSRG
  12. IT is not Digitalization.

  13. Digitization means reinventing yourself. Go beyond, think outside of box.

    Break open silos. Out of the comfort zone. We do differently now. Each individual units deliver Data.
  14. Our joint approach: Data democratisation. Analytics Triggering activities Automated processing

    Alerting Dashboards Make decisions. Provide more services. Build customer experience powered by data.
  15. GPS-Position Traction power on / off Working direction What will

    be monitored: Clutch on / off Monitor handbrake Engine on / off Machine on / off Board voltage Mobi-battery voltage
  16. Off use cases Display on platform: off Warning signal on

    machine Subsequent decoupling Warning signal switches off Display on platform: on Ein Display on platform : off Manual Switch- off via platform No reaction Warning message via SMS to CMF / CMF Stv. / Dispo / AL / BL after 15min Trouble shooting / clutch gear Coordination of trouble shooting Clutch on / off On Automated warning message Display on platform : off Process repetition Off On
  17. Handbrake applied Yes No use cases Machine moving? Machine moving?

    Recording of time and GPS position No Display on platform: Hand brake: YES Movement: YES Yes Display on platform: Hand brake: YES Movement: NO Display on platform: Handb: JA Movement: NO Hand brake: NO Information to CMF / CMF Stv., Dispo Information to AL, BL, Dispo, ICH, CMF No Yes
  18. High level architecture

  19. High level architecture

  20. data streaming, processing and storage

  21. Alerting

  22. processing in details

  23. user lifecycle management

  24. MACHINE BI

  25. RSRG: GEO machines current frontend B66U-3

  26. RSRG: machine monitoring – position B66U-3

  27. RSRG: machine monitoring – position – the path travelled B66U-3

  28. RSRG: Machine monitoring data – in general – 17.1.-7.2.22 B66U-3

  29. Status 02/11/2022: 199 objects MM RSRG 3rd 3rd 3rd Machine

    monitoring RSRG Hardware – Overview RSRG-Box Swisscom-Box Zeppelin Liebherr (Bagger) TMC (Plasser&Theurer)
  30. Benefits from the project Direct win from the project for

    Rhomberg Sersa Direct win from the project for Swisscom Service could be offered also for other companies Number of maintenance was reduced, saving 150,000 CHF / year Applied handbrake alone costs 5 digits SFr + outage time Automated shift change facilitates employees with overview and optimal start of work
  31. More data and app modernization

  32. No one size fits all Digitalization needs long-term partnerships of

    experts Proof of Value, then scale Technological readiness, be ready for the future
  33. Azure Devops

  34. Azure Devops are used for Repos Pipeline Wiki Boards: Sprints,

    Work Items, Backlogs
  35. Global Microsoft Partner of the Year Internet of Things Winner

    2021
  36. Author, Date, Presentation title, C0 classification 38 Contact Abduxukur Abdurixit

    Cloud Architect Abduxukur.abdurixit@swisscom.com +41 79 449 73 25 Picture Andreas Schmid Product Manager Azure / M365 Andreas.Schmid1@swisscom.com +41 58 221 41 42 Picture
