2019-10-09.aws-ug-dortmund.application-integration-patterns.pdf

One of the implications of applying the microservices architectural style is that a lot of communication between components is done over the network. In order to achieve the promises of microservices, this communication needs to happen in a loosely coupled manner.

One option that many architects have in mind here is that all services expose an API following the REST architectural style. However, there is another option that provides even looser coupling: asynchronous messaging. In discussions with customers we saw that this option is not always on the radar of architects.

In this talk, we want to discuss some fundamental application integration patterns mostly based on messaging and connect them to real-world use cases in a micro services scenario. In doing so, we will also point out some benefits that asynchronous messaging can have over REST APIs for the communication between microservices.

Transcript

1. © 2019, Amazon Web Services, Inc. or its Affiliates. Dirk Fröhner, Solutions Architect, Amazon Web Services froehner@amazon.de | @dirk_f5r Application Integration Patterns for Microservices
2. © 2019, Amazon Web Services, Inc. or its Affiliates. Dirk Fröhner, Solutions Architect, Amazon Web Services froehner@amazon.de | @dirk_f5r Application Integration Patterns (not only) for Microservices
3. © 2019, Amazon Web Services, Inc. or its Affiliates. Agenda • Introduction • Application integration patterns • Concrete use cases
4. © 2019, Amazon Web Services, Inc. or its Affiliates. Introduction
5. © 2019, Amazon Web Services, Inc. or its Affiliates. “If your application is cloud-native, or large-scale, or distributed, and doesn’t include a messaging component, that’s probably a bug.” Tim Bray Distinguished Engineer AWS Messaging, Workflow Management
6. Potential drawbacks of synchronous systems Synchronous systems are tightly coupled. A problem in a synchronous downstream dependency has immediate impact on the upstream callers. Retries from upstream callers can all-too easily fan-out and amplify problems. Photo by Clem Onojeghuo on Unsplash
7. © 2019, Amazon Web Services, Inc. or its Affiliates. Application integration patterns
8. Message exchange One-way Request-response Message channel Receiver No response expected Synchronous vs. fire-and-forget Response expected Return address Correlation ID Sender Message channel Responder Requester Message channel
9. Message channels Point-to-point (queue) Publish-subscribe (topic) Consumed by one receiver Easy to scale Flatten peak loads Consumed by all subscribers Durable subscriber Receivers Sender Queue Subscribers Publisher Topic
10. Message channels Point-to-point (queue) Publish-subscribe (topic) AWS service for queue functionality: Amazon Simple Queue Services (SQS) Serverless & cloud-native AWS service for topic functionality: Amazon Simple Notification Service (SNS) Serverless & cloud-native Receivers Sender Subscribers Publisher Amazon SQS Amazon SNS
11. Message channels Point-to-point (queue) Publish-subscribe (topic) AWS service for queue functionality (non-serverless): Amazon MQ (managed Apache Active MQ) For apps constrained to protocols like JMS, AMQP, etc. AWS service for topic functionality (non-serverless): Amazon MQ (managed Apache Active MQ) For apps constrained to protocols like JMS, AMQP, etc. Receivers Sender Subscribers Publisher Amazon MQ Amazon MQ
12. Message channels Topic-queue-chaining Allows fan-out and receiver scale-out at the same time Publisher Topic Queue Queue Receivers Application 1 Application 2
13. Message channels Dead letter queue (DLQ) Transient failure mitigation Poison-pill handling Sender Queue DLQ Receivers X
14. Message channels FIFO queue Message groups Guaranteed ordering Messages grouped by discriminator attribute Example: Amazon SQS with sender provided message group IDs – no further consumption as long as messages with particular message group ID are invisible Queue Receiver Sender Receivers Sender Queue Order!
15. Message channels Message delivery QoS At least once At most once Exactly once Queue Receiver Sender Exactly once? Well! Tunable / configurable messaging systems: Choose between at least once or at most once Deduplication capabilities to detect and eliminate messages which are sent more than once to or by the messaging system But how to deal with a situation where the message was consumed, but never acknowledged? → Your systems still have to be able to handle duplicate messages → Messages should be processed in an idempotent manner
16. Message channels Visibility timeout, inflight messages Time visibility timeout receive message receive message receive message receive message Time receive message receive message delete / acknowledge message visibility timeout
17. Message routing Message filter Recipient list Receive only a relevant subset of messages Controlled by subscriber Publisher remains completely unaware Send only a relevant subset of messages to a subscriber Controlled by publisher or separate component Potentially adds coupling Subscribers Publisher Subscribers Publisher Topic color = blue color = red Recipient List
18. Message routing Scatter-gather Request sent out to potentially interested entities who can submit their individual responses Responses aggregated for processing into a final result Search for best response vs parallel processing Requester Topic Responders Queue Aggregator Processor
19. Message routing Pipes and filters Event triggers chain of processing steps (“filters”) Knowledge of destination for next step(s) is wired into each filter Similar patterns: chain of responsibility, processing pipeline, saga choreography Event source Pipe Filter Filter Pipe Pipe Result target … Filter Step 1 Step 2 Step n
20. Message routing Saga orchestration Event triggers orchestrated workflow Knowledge of workflow is externalized into orchestrator component, as well as for potential rollback Workflow participants remain as loosely coupled as possible Event source Orchestrator Result target
21. Message routing Saga orchestration Event triggers orchestrated workflow Knowledge of workflow is externalized into orchestrator component, as well as for potential rollback Workflow participants remain as loosely coupled as possible Processor Event source Orchestrator Result target Step 1
22. Message routing Saga orchestration Event triggers orchestrated workflow Knowledge of workflow is externalized into orchestrator component, as well as for potential rollback Workflow participants remain as loosely coupled as possible Processor Processor Event source Orchestrator Result target Step 1 Step 2
23. Message routing Saga orchestration Event triggers orchestrated workflow Knowledge of workflow is externalized into orchestrator component, as well as for potential rollback Workflow participants remain as loosely coupled as possible Processor Processor Event source Orchestrator Result target … Step 1 Step 2
24. Message routing Saga orchestration Event triggers orchestrated workflow Knowledge of workflow is externalized into orchestrator component, as well as for potential rollback Workflow participants remain as loosely coupled as possible Processor Processor Processor Event source Orchestrator Result target … Step 1 Step 2 Step n-1
25. Message routing Saga orchestration Event triggers orchestrated workflow Knowledge of workflow is externalized into orchestrator component, as well as for potential rollback Workflow participants remain as loosely coupled as possible Processor Processor Processor Processor Event source Orchestrator Result target … Step 1 Step 2 Step n-1 Step n
26. Message routing Saga orchestration AWS service for saga orchestration (serverless): AWS Step Functions Processor Processor Processor Processor Event source Orchestrator Result target … Step 1 Step 2 Step n-1 Step n
27. © 2019, Amazon Web Services, Inc. or its Affiliates. Concrete use cases
28. Context: Wild Rydes, Inc.
29. © 2019, Amazon Web Services, Inc. or its Affiliates. Use case: Submit a ride completion
30. Use case: Submit a ride completion Unicorn Wild Rydes Unicorn App
31. Use case: Submit a ride completion { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Unicorn Wild Rydes Unicorn App https://... submit-ride-completion
32. Use case: Submit a ride completion AWS Cloud { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Unicorn Unicorn Management Service Wild Rydes Unicorn App https://... submit-ride-completion
33. Use case: Submit a ride completion AWS Cloud { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Unicorn Wild Rydes Unicorn App https://... submit-ride-completion Rides Store Unicorn Management Service
34. Use case: Submit a ride completion AWS Cloud { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Unicorn Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service
35. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Unicorn Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service
36. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Interested in rides with fare >= x distance >= y Rides Store Unicorn Wild Rydes Unicorn App https://... submit-ride-completion Unicorn Management Service 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> }
37. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Unicorn Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service Integration via database? Interested in rides with fare >= x distance >= y
38. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Unicorn Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service Integration via database? Oh my! Interested in rides with fare >= x distance >= y
39. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Unicorn Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service Integration via REST APIs? Interested in rides with fare >= x distance >= y
40. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Unicorn Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service Integration via REST APIs? Absolutely, but… Interested in rides with fare >= x distance >= y
41. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } https://... https://... https://... https://... https://... Recipient list Unicorn Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service
42. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } https://... https://... https://... https://... https://... Recipient list service Unicorn Request Distribution Service https://... Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service
43. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } https://... https://... https://... https://... https://... Self-managed filtering Unicorn Request Distribution Service https://... Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service Interested in rides with fare >= x distance >= y
44. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } https://... https://... https://... https://... https://... Self-managed filtering Unicorn Request Distribution Service https://... Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service Interested in rides with fare >= x distance >= y Integration via messaging? Absolutely!
45. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Publish-subscribe (topic) Unicorn Ride Completion Topic Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service
46. Use case: Submit a ride completion AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } SNS message filter: fare >= x distance >= y Message filter Unicorn Ride Completion Topic Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service
47. Use case: Submit a ride completion Unicorn AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Ride Completion Topic Topic-queue-chaining Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service SNS message filter: fare >= x distance >= y
48. © 2019, Amazon Web Services, Inc. or its Affiliates. Use case: Prebooking campaigns
49. Use case: Prebooking campaigns Wild Rydes Customer Wild Rydes Customer App
50. Use case: Prebooking campaigns Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking { "from": "...", "to": "...", "when": "...", "customer": "..." }
51. Use case: Prebooking campaigns AWS Cloud Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking { "from": "...", "to": "...", "when": "...", "customer": "..." } Ride Booking Service
52. Use case: Prebooking campaigns AWS Cloud Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking Ride Booking Service { "from": "...", "to": "...", "when": "...", "customer": "..." } Prebookings Store
53. Use case: Prebooking campaigns AWS Cloud Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking { "from": "...", "to": "...", "when": "...", "customer": "..." } 201 Created Location: http://... Content-Location: ... { <prebooking-repr> } Ride Booking Service Prebookings Store
54. Use case: Prebooking campaigns AWS Cloud Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking { "from": "...", "to": "...", "when": "...", "customer": "..." } 201 Created Location: http://... Content-Location: ... { <prebooking-repr> } Ride Booking Service Prebookings Store Massive campaign with CTA: Book today!
55. Use case: Prebooking campaigns AWS Cloud Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking { "from": "...", "to": "...", "when": "...", "customer": "..." } Ride Booking Service Further decoupling
56. Use case: Prebooking campaigns AWS Cloud Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking { "from": "...", "to": "...", "when": "...", "customer": "..." } Ride Booking Service Further decoupling Prebooking Submission Resource
57. Use case: Prebooking campaigns AWS Cloud Further decoupling Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking { "from": "...", "to": "...", "when": "...", "customer": "..." } Prebooking Notification Topic Ride Booking Service Prebooking Submission Resource
58. Use case: Prebooking campaigns AWS Cloud Further decoupling Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking { "from": "...", "to": "...", "when": "...", "customer": "..." } Prebooking Notification Topic 202 Accepted Location: ... Content-Location: ... { <task-status-repr> } Ride Booking Service Prebooking Submission Resource
59. Use case: Prebooking campaigns AWS Cloud Further decoupling Prebooking Notification Buffer Queue Prebooking Processing Buffer Queue Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking { "from": "...", "to": "...", "when": "...", "customer": "..." } Prebooking Notification Topic Ride Booking Service Prebooking Submission Resource 202 Accepted Location: ... Content-Location: ... { <task-status-repr> }
60. Use case: Prebooking campaigns AWS Cloud Datalake Ingestion Service Ride Booking Service / Prebooking Processing Resource Further decoupling Prebooking Notification Buffer Queue Prebooking Processing Buffer Queue Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking { "from": "...", "to": "...", "when": "...", "customer": "..." } Prebooking Notification Topic Ride Booking Service Prebooking Submission Resource 202 Accepted Location: ... Content-Location: ... { <task-status-repr> }
61. Use case: Prebooking campaigns AWS Cloud Datalake Ingestion Service Further decoupling Prebooking Notification Buffer Queue Prebooking Processing Buffer Queue Wild Rydes Customer Wild Rydes Customer App https://... submit-ride-prebooking { "from": "...", "to": "...", "when": "...", "customer": "..." } Prebooking Notification Topic Ride Booking Service Prebooking Submission Resource 202 Accepted Location: ... Content-Location: ... { <task-status-repr> } Massive campaign with CTA: Book now! Ride Booking Service / Prebooking Processing Resource
62. Use case: Prebooking campaigns Wild Rydes Customer Wild Rydes Customer App https://... AWS Cloud Datalake Ingestion Service Action=SendMessage &MessageBody=... ... Prebooking Notification Topic Even further decoupling Prebooking Notification Buffer Queue Prebooking Processing Buffer Queue Prebooking Submission Buffer Queue 200 OK ... <SendMessageResponse> ... </SendMessageResponse> Ride Booking Service Prebooking Submission Resource Ride Booking Service / Prebooking Processing Resource
63. © 2019, Amazon Web Services, Inc. or its Affiliates. Use case: Instant ride RFQ
64. Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App Scatter-gather
65. Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... submit-instant-ride-rfq { "from": "...", "to": "...", "customer": "..." } Scatter-gather
66. Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... submit-instant-ride-rfq AWS Cloud Ride Booking Service { "from": "...", "to": "...", "customer": "..." } Scatter-gather
67. Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... submit-instant-ride-rfq AWS Cloud Ride Booking Service { "from": "...", "to": "...", "customer": "..." } Scatter-gather 202 Accepted Location: ... Content-Location: ... { "links": { ... }, "status": "...", "eta": "..." }
68. Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... submit-instant-ride-rfq AWS Cloud Ride Booking Service { "from": "...", "to": "...", "customer": "..." } Request For Quotes Topic Scatter-gather 202 Accepted Location: ... Content-Location: ... { "links": { ... }, "status": "...", "eta": "..." }
69. Unicorn Management Service Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... submit-instant-ride-rfq AWS Cloud Ride Booking Service Unicorn Management Resource Unicorn Management Resource Unicorn Management Resource { "from": "...", "to": "...", "customer": "..." } Request For Quotes Topic Scatter-gather … 202 Accepted Location: ... Content-Location: ... { "links": { ... }, "status": "...", "eta": "..." }
70. Unicorn Management Service Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... submit-instant-ride-rfq AWS Cloud Ride Booking Service Unicorn Management Resource Unicorn Management Resource Unicorn Management Resource { "from": "...", "to": "...", "customer": "..." } Request For Quotes Topic Scatter-gather RFQ Response Queue … 202 Accepted Location: ... Content-Location: ... { "links": { ... }, "status": "...", "eta": "..." }
71. Unicorn Management Service Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... submit-instant-ride-rfq AWS Cloud Ride Booking Service Unicorn Management Resource Unicorn Management Resource Unicorn Management Resource { "from": "...", "to": "...", "customer": "..." } Request For Quotes Topic Scatter-gather 202 Accepted Location: ... Content-Location: ... { "links": { ... }, "status": "...", "eta": "..." } RFQ Response Queue …
72. Unicorn Management Service Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... retrieve-rfq-status AWS Cloud Ride Booking Service Unicorn Management Resource Unicorn Management Resource Unicorn Management Resource Request For Quotes Topic Scatter-gather RFQ Response Queue …
73. Unicorn Management Service Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... retrieve-rfq-status AWS Cloud Ride Booking Service Unicorn Management Resource Unicorn Management Resource Unicorn Management Resource Request For Quotes Topic Scatter-gather RFQ Response Queue … 200 OK { "links": { ... }, "status": "running", "eta": "..." }
74. Unicorn Management Service Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... retrieve-rfq-status AWS Cloud Ride Booking Service Unicorn Management Resource Unicorn Management Resource Unicorn Management Resource Request For Quotes Topic Scatter-gather RFQ Response Queue … 200 OK { "links": { ... <link-to-result> ... }, "status": "done" }
75. Unicorn Management Service Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... retrieve-rfq-result AWS Cloud Ride Booking Service Unicorn Management Resource Unicorn Management Resource Unicorn Management Resource Request For Quotes Topic Scatter-gather RFQ Response Queue …
76. Unicorn Management Service Use case: Instant ride RFQ Wild Rydes Customer Wild Rydes Customer App https://... retrieve-rfq-result AWS Cloud Ride Booking Service Unicorn Management Resource Unicorn Management Resource Unicorn Management Resource Request For Quotes Topic Scatter-gather RFQ Response Queue … 200 OK { "links": { ... }, "from": "...", "to": "...", "quotes": "..." }
77. © 2019, Amazon Web Services, Inc. or its Affiliates. Use case: Fare collection
78. Use case: Submit a ride completion Unicorn AWS Cloud Customer Notification Service Customer Accounting Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Ride Completion Topic Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service SNS message filter: fare >= x distance >= y
79. Use case: Submit a ride completion Unicorn AWS Cloud Customer Notification Service Customer Loyalty Service Datalake Ingestion Service Extraordinary Rides Service { "from": "...", "to": "...", "duration": "...", "distance": "...", "customer": "...", "fare": "..." } Ride Completion Topic Wild Rydes Unicorn App https://... submit-ride-completion 201 Created Location: ... Content-Location: ... { <cmpl-ride-repr> } Rides Store Unicorn Management Service SNS message filter: fare >= x distance >= y Customer Accounting Service
80. Use case: Fare collection Saga orchestration
81. Use case: Fare collection Saga orchestration Payment Service Discrete transactions: 1. Credit card pre-auth Payment Gateway API
82. Use case: Fare collection Saga orchestration Payment Service Discrete transactions: 1. Credit card pre-auth 2. Charge card using pre-auth code Payment Gateway API Payment Service Payment Gateway API
83. Use case: Fare collection Saga orchestration Payment Service Discrete transactions: 1. Credit card pre-auth 2. Charge card using pre-auth code 3. Update customer account Payment Gateway API Customer Accounting Service Payment Service Accounting System Payment Gateway API
84. Use case: Fare collection Saga orchestration Payment Service Discrete transactions: 1. Credit card pre-auth 2. Charge card using pre-auth code 3. Update customer account To be treated as one distributed TA, to leave the systems in a semantically consistent state. Payment Gateway API Customer Accounting Service Payment Service Accounting System Payment Gateway API
85. © 2019, Amazon Web Services, Inc. or its Affiliates. © 2019, Amazon Web Services, Inc. or its Affiliates. Thank you! Dirk Fröhner, Solutions Architect, Amazon Web Services froehner@amazon.de | @dirk_f5r
