  1. Python tracing superpowers Eben Freeman PyBay 2016 with systems tools

    1
  2. Hello everybody! 2

  3. Who am I? Python programmer , independent , Performance/observability enthusiast

    freemaneben@gmail.com | github.com/emfree 3
  4. in-process tooling >>> import pdb >>> import cProfile >>> import

    inspect >>> import tracemalloc >>> import dis >>> import ... out-of-process tooling $ gdb $ perf $ strace $ ltrace $ stap $ ... An empirical contrast How do you debug your program? add code to your program debug running programs 4
  5. Can we apply "systems" tracing tools to better understand what

    a Python program is doing, without interrupting or changing it? And a question 5
  6. In this talk - Deep dive into two case studies:

    - CPU profiling - memory leak analysis - Some low-level details along the way - Ideas for further exploration 6
  7. In this talk - Systems tools are system-dependent - We'll

    be talking about CPython on Linux - Inspiration, but not details, for other environments. 7
  8. I. CPU Profiling 8

  9. Say you have a basic web application... 9

  10. ... or a less basic one. CPU-bound 10

  11. 1. Instrument every function call - cProfile or sys.settrace() -

    often has significant overhead - generally not appropriate in production - can give distorted results In-process profiling: two common strategies 11
  12. 2. Sample the stack - record the call stack every

    n milliseconds - frequent stacks are hot code paths - generally low-overhead - many third-party implementations for Python https://github.com/joerick/pyinstrument https://github.com/bdarnell/plop https://github.com/nylas/nylas-perftools https://github.com/what-studio/profiling etc. In-process profiling: two common strategies 12
  13. import signal, traceback def sample(_, frame): # get a full

    traceback, starting from the interrupted stack frame stack = traceback.format_stack(frame) # record it somewhere record(stack) # Interpreter: Call sample() whenever we get SIGVTALRM! signal.signal(signal.SIGVTALRM, sample) # Operating system: Send the SIGVTALRM signal every 0.01 seconds! signal.setitimer(signal.ITIMER_VIRTUAL, 0.01, 0.01) A profiling workflow Sample stacks 13
  14. import signal, traceback def sample(_, frame): # get a full

    traceback, starting from the interrupted stack frame stack = traceback.format_stack(frame) # record it somewhere record(stack) # Interpreter: Call sample() whenever we get SIGVTALRM! signal.signal(signal.SIGVTALRM, sample) # Operating system: Send the SIGVTALRM signal every 0.01 seconds! signal.setitimer(signal.ITIMER_VIRTUAL, 0.01, 0.01) A profiling workflow Sample stacks 14
  15. import signal, traceback def sample(_, frame): # get a full

    traceback, starting from the interrupted stack frame stack = traceback.format_stack(frame) # record it somewhere record(stack) # Interpreter: Call sample() whenever we get SIGVTALRM! signal.signal(signal.SIGVTALRM, sample) # Operating system: Send the SIGVTALRM signal every 0.01 seconds! signal.setitimer(signal.ITIMER_VIRTUAL, 0.01, 0.01) A profiling workflow Sample stacks 15
  16. import signal, traceback def sample(_, frame): # get a full

    traceback, starting from the interrupted stack frame stack = traceback.format_stack(frame) # record it somewhere record(stack) # Interpreter: Call sample() whenever we get SIGVTALRM! signal.signal(signal.SIGVTALRM, sample) # Operating system: Send the SIGVTALRM signal every 0.01 seconds! signal.setitimer(signal.ITIMER_VIRTUAL, 0.01, 0.01) A profiling workflow Sample stacks 16
  17. { "execute;__call__;wsgi_app;full_dispatch_request;dispatch_request;route;<lambda>": 690, "execute;__call__;wsgi_app;full_dispatch_request;dispatch_request": 30, "execute;write;send_response;log_request;log;_log;info;_log;handle;callHandlers": 11, "execute;write;send_response": 10, "execute;write;send_response;log_request;log;_log;info;_log;handle":

    1, "execute;__call__;wsgi_app;auto_pop;pop;pop;do_teardown_appcontext": 1, "execute;__call__;wsgi_app;request_context;__init__;create_url_adapter": 2, "execute;__call__;wsgi_app;full_dispatch_request;dispatch_request;route": 1, stack count A profiling workflow Sample stacks Aggregate 17
  18. Sample stacks Aggregate Visualize A profiling workflow 18

  19. % of samples call stack brendangregg.com/flamegraphs.html The flame graph 19

  20. ~35% of CPU time Example: a small application 20

  21. inside the database driver 21

  22. # MySQLdb/cursors.py def _fetch_row(self, size=1): if not self._result: return ()

    return self._result.fetch_row(size, self._fetch_type) ruh roh! this is implemented in a C extension our profiler has no visibility into it 22
  23. Python call stack C call stack visible internally visible externally

    An inconvenient dichotomy >>> traceback.format_stack() $ gdb -p $PID -ex bt --batch $ perf record -p $PID here's that C extension code 23
  24. An inconvenient dichotomy It would be really nice if we

    could sample both of these call stacks at once, and have a full picture of what's going on. Maybe we can use one of those systems tools. Let's try. 24
  25. Take 1: gdb $ gdb -p $PID -ex bt --batch

    #0 0x000000000047fe34 in lookdict_string (mp=0x7ffff7f64be8, key='True' hash=-1504860438477502276) at ../Objects/dictobject.c:430 #1 0x00000000005241b4 in PyEval_EvalFrameEx ( f=Frame 0x7ffff7f477c0, for file script.py, line 2, in f (), throwfl at ../Python/ceval.c:2107 #2 0x000000000052bcb7 in fast_function (func=<function at remote 0x7fff pp_stack=0x7fffffffdda0, n=0, na=0, nk=0) at ../Python/ceval.c:4119 #3 0x000000000052b9ca in call_function (pp_stack=0x7fffffffdda0, oparg= at ../Python/ceval.c:4054 #4 0x00000000005266ca in PyEval_EvalFrameEx ( f=Frame 0x7ffff7f475e8, for file script.py, line 6, in g (), throwfl at ../Python/ceval.c:2679 includes Python context (if gdb extensions are installed) Just run this in a loop to get a sample set. more: poormansprofiler.org 25
  26. Take 1: gdb Problem: slows down program by ~3x at

    10Hz sample rate $ gdb -p $PID -ex bt --batch #0 0x000000000047fe34 in lookdict_string (mp=0x7ffff7f64be8, key='True' hash=-1504860438477502276) at ../Objects/dictobject.c:430 #1 0x00000000005241b4 in PyEval_EvalFrameEx ( f=Frame 0x7ffff7f477c0, for file script.py, line 2, in f (), throwfl at ../Python/ceval.c:2107 #2 0x000000000052bcb7 in fast_function (func=<function at remote 0x7fff pp_stack=0x7fffffffdda0, n=0, na=0, nk=0) at ../Python/ceval.c:4119 #3 0x000000000052b9ca in call_function (pp_stack=0x7fffffffdda0, oparg= at ../Python/ceval.c:4054 #4 0x00000000005266ca in PyEval_EvalFrameEx ( f=Frame 0x7ffff7f475e8, for file script.py, line 6, in g (), throwfl at ../Python/ceval.c:2679 Can we do better? 26
  27. Take 2: SystemTap SystemTap is a toolkit and scripting language

    for dynamic instrumentation. - You write a script specifying probe points and handlers, e.g. probe nd_syscall.open { printf("%d %s\n", pid(), filename()) } // Every time a process opens a file, print the PID and filename - SystemTap compiles this into C and loads it as a kernel module. - Can be challenging to use, but very powerful. - less overhead for this use case than gdb, which uses the ptrace API. sourceware.org/systemtap/ 27
  28. Some caveats You need - "stapusr" privileges - a fairly

    recent Linux kernel - debuginfo in your Python binary But once you have this, you can do a lot of cool stuff! 28
  29. $ stap -x $PID \ # We only care about

    our Python process -e "probe perf.sw.task_clock.process # at every tick of its process clock { print_ubacktrace() }" # print a userspace backtrace Step 1: get C stacks 29
  30. $ stap -x $PID \ # We only care about

    our Python process -e "probe perf.sw.task_clock.process # at every tick of its process clock { print_ubacktrace() }" # print a userspace backtrace 0x46d1ad : lookdict_unicode_nodummy+0x4d/0x370 [/usr/bin/python3] 0x46f544 : PyDict_GetItem+0xe4/0x130 [/usr/bin/python3] 0x47e108 : PyObject_GenericGetAttr+0x128/0x240 [/usr/bin/python3] 0x47a8b8 : module_getattro+0x18/0xb0 [/usr/bin/python3] 0x4ef34f : PyEval_EvalFrameEx+0x36df/0x9470 [/usr/bin/python3] 0x4f59f7 : _PyEval_EvalCodeWithName+0x907/0x9c0 [/usr/bin/python3] 0x4f5ad2 : PyEval_EvalCodeEx+0x22/0x30 [/usr/bin/python3] 0x5a4805 : function_call+0x95/0x1b0 [/usr/bin/python3] 0x439713 : PyObject_Call+0x73/0x1b0 [/usr/bin/python3] 0x43ac07 : PyObject_CallFunctionObjArgs+0x187/0x230 [/usr/bin/python3] 0x459842 : listsort+0x152/0xb00 [/usr/bin/python3] 0x5a9f81 : PyCFunction_Call+0xf1/0x160 [/usr/bin/python3] 0x439713 : PyObject_Call+0x73/0x1b0 [/usr/bin/python3] . . . Step 1: get C stacks 30
  31. Step 2: get Python stacks Challenge: Python stack frames are

    represented by objects... somewhere in the interpreter heap. Let's find them! 31
  32. Step 2: get Python stacks (a hack) 32

  33. Step 2: get Python stacks (a hack) 33

  34. Step 2: get Python stacks (a hack) Traceback: -> main()

    -> function_a() -> function_b() 34
  35. Step 2: get Python stacks (a hack) Character buffer with

    the actual function name ("function_b") Traceback: -> main() -> function_a() -> function_b() 35
  36. Step 2: get Python stacks (a hack) Traceback: -> main()

    -> function_a() -> function_b() 36
  37. Step 2: get Python stacks (a hack) Traceback: -> main()

    -> function_a() -> function_b() 37
  38. # sample.stp @define PY %( "/path/to/python/binary" %) function print_python_stack() {

    pythreadstate = @var("_PyThreadState_Current", @PY) if (pythreadstate == 0) { return } frame = @cast(pythreadstate, "PyThreadState", @PY)->frame while (frame != 0) { function_name = frame->f_code->co_name->ob_sval println(user_string(function_name)) frame = frame->f_back } } 38
  39. # sample.stp @define PY %( "/path/to/python/binary" %) function print_python_stack() {

    pythreadstate = @var("_PyThreadState_Current", @PY) if (pythreadstate == 0) { return } frame = @cast(pythreadstate, "PyThreadState", @PY)->frame while (frame != 0) { function_name = frame->f_code->co_name->ob_sval println(user_string(function_name)) frame = frame->f_back } } 39
  40. # sample.stp @define PY %( "/path/to/python/binary" %) function print_python_stack() {

    pythreadstate = @var("_PyThreadState_Current", @PY) if (pythreadstate == 0) { return } frame = @cast(pythreadstate, "PyThreadState", @PY)->frame while (frame != 0) { function_name = frame->f_code->co_name->ob_sval println(user_string(function_name)) frame = frame->f_back } } 40
  41. # sample.stp @define PY %( "/path/to/python/binary" %) function print_python_stack() {

    pythreadstate = @var("_PyThreadState_Current", @PY) if (pythreadstate == 0) { return } frame = @cast(pythreadstate, "PyThreadState", @PY)->frame while (frame != 0) { function_name = frame->f_code->co_name->ob_sval println(user_string(function_name)) frame = frame->f_back } } 41
  42. $ stap -x $PID sample.stp _fetch_row _post_get_result _query execute fetch_data

    burrito_finder_api dispatch_request full_dispatch_request wsgi_app __call__ execute run_wsgi handle_one_request handle handle __init__ finish_request process_request _handle_request_noblock Step 2: get Python stacks (but it works!) 42
  43. Python call stack C call stack Step 3: glue them

    together Every Python stack frame corresponds to a call to PyEval_EvalFrameEx on the C call stack. 43
  44. application call application call stacks stacks Now, instead of this

    level of detail 44
  45. interpreter & C extensions kernel application we can see this.

    45
  46. Results 46

  47. Results [Remember, we were curious about execution time spent in

    the database driver.] 47
  48. Results 48

  49. Drilling down Let's trace a single execution of this function

    to better understand what's going on 49
  50. Drilling down We'll use function entry and return probe points

    to build an execution timeline. These use a kernel facility called uprobes - basically an API to insert software breakpoints at a userspace instruction address, then execute a handler when the breakpoint gets hit. https://www.google.com/patents/US20080133896 50
  51. Drilling down # trace-callgraph.stp function trace(is_entry) { if (tracing) {

    if (is_entry) { // print "-> my_func" on entry into function my_func() println("-> " . ppfunc()) } else { // print "<- my_func" on return from function my_func() println("<- " . ppfunc()) } // Start tracing whenever a trigger function // (passed as script argument) is called probe process.function(@1).call { tracing = 1 } probe process.function(@1).return { tracing = 0 } probe process.function("*").call { trace(1) } probe process.function("*").return { trace(-1) } 51
  52. Drilling down # trace-callgraph.stp function trace(is_entry) { if (tracing) {

    if (is_entry) { // print "-> my_func" on entry into function my_func() println("-> " . ppfunc()) } else { // print "<- my_func" on return from function my_func() println("<- " . ppfunc()) } // Start tracing whenever a trigger function // (passed as script argument) is called probe process.function(@1).call { tracing = 1 } probe process.function(@1).return { tracing = 0 } probe process.function("*").call { trace(1) } probe process.function("*").return { trace(-1) } 52
  53. Drilling down # trace-callgraph.stp function trace(is_entry) { if (tracing) {

    if (is_entry) { // print "-> my_func" on entry into function my_func() println("-> " . ppfunc()) } else { // print "<- my_func" on return from function my_func() println("<- " . ppfunc()) } // Start tracing whenever a trigger function // (passed as script argument) is called probe process.function(@1).call { tracing = 1 } probe process.function(@1).return { tracing = 0 } // Then trace all function entry / exits probe process.function("*").call { trace(1) } probe process.function("*").return { trace(-1) } 53
  54. Drilling down # trace-callgraph.stp function trace(is_entry) { if (tracing) {

    if (is_entry) { // print "-> my_func" on entry into function my_func() println("-> " . ppfunc()) } else { // print "<- my_func" on return from function my_func() println("<- " . ppfunc()) } // Start tracing whenever a trigger function // (passed as script argument) is called probe process.function(@1).call { tracing = 1 } probe process.function(@1).return { tracing = 0 } // Then trace all function entry / exits probe process.function("*").call { trace(1) } probe process.function("*").return { trace(-1) } 54
  55. Drilling down $ stap -x $PID trace-callgraph.stp 0 ->_mysql_row_to_tuple 6

    ->PyTuple_New 10 <-PyTuple_New 13 ->PyObject_CallFunction 17 ->Py_VaBuildValue 21 ->do_mkvalue 25 ->PyBytes_FromStringAndSize 29 ->PyObject_Malloc 33 ->_PyObject_Malloc 37 <-_PyObject_Malloc 38 <-PyObject_Malloc 40 <-PyBytes_FromStringAndSize 42 <-do_mkvalue 44 <-Py_VaBuildValue 46 ->PyTuple_New 49 <-PyTuple_New 51 ->PyObject_Call 55 ->function_call 59 ->PyEval_EvalCodeEx 63 ->_PyEval_EvalCodeWithName 55
  56. Drilling down Timeline of _mysql_row_to_tuple execution: 56

  57. Drilling down Python function calls via the C API 57

  58. Drilling down 58

  59. // mysqlclient/_mysql.c static PyObject * _mysql_field_to_python(PyObject *converter, char *rowitem, unsigned

    long len, MYSQL_FIELD *field) { PyObject *v; if (converter != Py_None) { v = PyObject_CallFunction(converter, "s#", rowitem, (int)len)); } else { v = PyBytes_FromStringAndSize(rowitem, (int)len); } // ... if rowitem is a string-encoded float ("2.2718") Then this turns rowitem into a Python string, then calls float() on it Here, the database driver is turning raw character buffers from the database into Python objects. 59
  60. // proof-of-concept patch static PyObject * _mysql_field_to_python(PyObject *converter, char *rowitem,

    unsigned long len, MYSQL_FIELD *field) { PyObject *v; - if (converter != Py_None) { + if (field_type == FIELD_TYPE_FLOAT) { + v = PyFloat_FromDouble(strtod(rowitem, NULL)); + } else if (converter != Py_None) { v = PyObject_CallFunction(converter, "s#", rowitem, (int)len); } else { v = PyBytes_FromStringAndSize(rowitem, (int)len); } // ... Result: ~15% more requests served per second Let's do that conversion in C 60
  61. We were able to go all the way from an

    aggregate view of our application's hotspots, down to the execution profile of a single extension function, without needing to stop or change our application. 61
  62. II. Memory Analysis 62

  63. 63

  64. import numpy as np while True: names = ['field{}'.format(i) for

    i in range(200)] dt = np.dtype({"names": names, "formats": 200 * [np.uint8]}) array = np.zeros((1000,), dt) sortedIndices = np.argsort(array, order='field0') The problem script "calling argsort() on a structured array creates a leak" We'll just let this run in the background while we trace it. 64
  65. # memtrace.stp global alloc_bt global alloc_time probe process.function("_PyObject_Malloc").return { //

    Whenever an object is allocated, keep track of the stack trace // and timestamp alloc_bt[$return] = sprint_merged_stack() alloc_time[$return] = gettimeofday_ms() } probe process.function("_PyObject_Free").return { // Clear that data when the object is freed delete alloc_bt[$p] delete alloc_time[$p] } Let's try tracing allocations 65
  66. # memtrace.stp global alloc_bt global alloc_time probe process.function("_PyObject_Malloc").return { //

    Whenever an object is allocated, keep track of the stack trace // and timestamp alloc_bt[$return] = sprint_merged_stack() alloc_time[$return] = gettimeofday_ms() } probe process.function("_PyObject_Free").return { // Clear that data when the object is freed delete alloc_bt[$p] delete alloc_time[$p] } Let's try tracing allocations 66
  67. # memtrace.stp global alloc_bt global alloc_time probe process.function("_PyObject_Malloc").return { //

    Whenever an object is allocated, keep track of the stack trace // and timestamp alloc_bt[$return] = sprint_merged_stack() alloc_time[$return] = gettimeofday_ms() } probe process.function("_PyObject_Free").return { // Clear that data when the object is freed delete alloc_bt[$p] delete alloc_time[$p] } Let's try tracing allocations 67
  68. _start __libc_start_main main Py_Main PyRun_SimpleFileExFlags PyRun_FileExFlags PyEval_EvalCode _PyEval_EvalCodeWithName <module>(leak.py) PyObject_Call

    type_call arraydescr_new PyArray_DescrConverter _convert_from_dict PySequence_Tuple PyList_AsTuple PyTuple_New _PyObject_GC_NewVar Let's run the test case in the background, and trace for ~30 seconds. If we take the output and graph "surviving allocations over time" ... okay, looks leaky. 68
  69. _start __libc_start_main main Py_Main PyRun_SimpleFileExFlags PyRun_FileExFlags PyEval_EvalCode _PyEval_EvalCodeWithName <module>(leak.py) PyObject_Call

    type_call arraydescr_new PyArray_DescrConverter _convert_from_dict PySequence_Tuple PyList_AsTuple PyTuple_New _PyObject_GC_NewVar This is in C extension code -- likely caused by a missing call to Py_DECREF. Can we figure out where that call should go? 69
  70. import numpy as np while True: names = ['field{}'.format(i) for

    i in range(200)] # find a leaky allocation here dt = np.dtype({"names": names, "formats": 200 * [np.uint8]}) array = np.zeros((1000,), dt) # track its refcount as this function executes sortedIndices = np.argsort(array, order='field0') The problem script "calling argsort() on a structured array creates a leak" 70
  71. @define PY %( "/path/to/python/binary" %} @define NUMPY %( "/path/to/numpy/core/multiarray.so" %)

    global ptr=0, refcount=0 global problem_stack = "start;__libc_start_main;..." probe process.function("_PyObject_Malloc").return { if (sprint_merged_stack() == problem_stack && ptr == 0) { printf("Saving pointer %p\n", $return) ptr = $return } } When we see a leaky allocation, keep track of that pointer 71
  72. //... ptr = $return } } probe process(@NUMPY).statement("array_argsort@*:*") { if

    (ptr != 0) { object_ptr = &@cast(ptr, "PyGC_Head", @PY)[1] new_refcount = @cast(object_ptr, "PyObject", @PY)->ob_refcnt if (new_refcount != refcount) { refcount = new_refcount; printf("New refcount: %d at %s\n", refcount, pp()) } } } check if the object's refcount has changed statement probe: at each line of the suspicious function 72
  73. $ stap -x $PID trace_refcount.stp New refcount: 1 at process("...").statement("array_argsort@...:1238")

    New refcount: 2 at process("...").statement("array_argsort@...:1274") New refcount: 3 at process("...").statement("array_argsort@...:1238") Function entry point suspicious 73
  74. $ stap -x $PID trace_refcount.stp New refcount: 1 at process("...").statement("array_argsort@...:1238")

    New refcount: 2 at process("...").statement("array_argsort@...:1274") New refcount: 3 at process("...").statement("array_argsort@...:1238") // numpy/core/multiarray/methods.c new_name = PyObject_CallMethod(_numpy_internal, "_newnames", "OO", saved, order); Py_DECREF(_numpy_internal); if (new_name == NULL) { return NULL; } newd = PyArray_DescrNew(saved); // Refcount changed here + Py_DECREF(newd->names); newd->names = new_name; ((PyArrayObject_fields *)self)->descr = newd; } 74
  75. Case closed 75

  76. Wrapping up Those were just two examples of using one

    tool. Other things you could do: - Show a live latency histogram for a particular function in your code - Correlate your application's behavior with network or other system activity - Whatever you come up with. 76
  77. Wrapping up This strategy has tradeoffs! Pros: - Enables interactive/dynamic

    instrumentation of running programs - Can show lots of low-level detail - Language-agnostic: can be applied to debug other parts of your stack as well. Cons: - Steep learning curve - Some initial setup cost 77
  78. Wrapping up Can we apply "systems" tracing tools to better

    understand what a Python program is doing? 78
  79. Wrapping up I think so! But it could have been

    easier... 79
  80. The road ahead Lots of room for improvement! - documentation,

    best practices, wrapper scripts (github.com/emfree/systemtap-python-tools) - standalone/userspace tools for out-of-process profiling, etc. (github.com/eklitzke/pystack, github.com/jvns/ruby-stacktrace) - interpreter support for external tracers 80
  81. Supporting code: github.com/emfree/systemtap-python-tools Questions/slander: freemaneben@gmail.com Thank you! 81

  82. Addenda 82

  83. What about PyPy? (Pyston, ...) - I don't have much

    firsthand experience :( - github.com/vmprof/vmprof-python was built to profile PyPy, including JIT introspection. - Linux `perf` supports JITted runtimes like Node.js and Java if they write a symbol map to /tmp/perf-PID.map. PyPy could do that too. 83
  84. What about other OSes? - OS X and some others

    have DTrace (similar to SystemTap) - Others: I don't know. Sorry :( 84
  85. What about runtime code injection? - Pyrasite, socketconsole, etc. -

    Can be useful - Definitely easier to use for some debugging - Kind of scares me - Still can't get really low level detail 85
  86. Performance engineering lessions - Know your interpreter! - Play with

    power [debugging] tools! - Build visualizations! 86
  87. The confusing ecosystem of Linux tracers http://www.brendangregg.com/blog/2015-07-08/choosing-a-linux-tracer.html 87
