Running Docker in Production

Running Docker in Production - Using Apache Brooklyn, Clocker and Project Calico. Talk given at ApacheCon CORE Europe in Budapest, Hungary, and at CloudOpen Europe in Dublin, Ireland, both in October 2015

Transcript

1. Running Docker in Production Using Apache Brooklyn, Clocker and Project Calico Andrew Donald Kennedy
2. @grkvlt Agenda • Introduction • Application Management • Networking with Calico • Demonstration • Roadmap • Questions Copyright 2015 by Cloudsoft Corporation Limited
3. Clocker  Introduc.on
5. @grkvlt Clocker Developers Copyright 2015 by Cloudsoft Corporation Limited
6. @grkvlt Clocker Statistics •  Open Source •  1+ Years Old •  725 Commits •  153 Pull Requests •  11 Contributors •  2 External •  15 KLOC •  26 Releases http://www.redotheweb.com/CodeFlower/   Copyright 2015 by Cloudsoft Corporation Limited
7. @grkvlt •  Application Management Platform •  Deploy, Manage and Monitor Blueprints •  Provisioning, Installation and Customization •  Management •  AutoScaling, Resilience, Performance, Security Apache Brooklyn
8. @grkvlt Apache jclouds •  Java Cloud Library •  API Agnostic •  SoftLayer, OpenStack, AWS EC2, GCE… •  Create Virtual Machines •  Return SSH Endpoint •  Create Containers •  Docker REST API Copyright 2015 by Cloudsoft Corporation Limited
9. @grkvlt Docker •  Containers •  Isolation •  Performance •  Composable •  Huge Ecosystem •  Compute Abstraction •  Process Wrapper
10. @grkvlt •  So0ware-­‐Defined  Networking   •  Calico   •  Weave   •  Storage  and  Volume  Management   •  Flocker   •  More  Being  Developed…   •  Na.ve  Plugins   Docker Extras
11. @grkvlt Copyright 2015 by Cloudsoft Corporation Limited Apache Mesos ... •  Distributed Systems Kernel •  Cluster Management •  Resource Sharing and Placement •  Calico SDN Support •  Frameworks •  Aurora and Marathon •  Riak, Spark, Hadoop, Storm et al •  Brooklyn Scheduler
12. @grkvlt What does it do? 1.  Spins up and Manages Docker Clusters in the Clouds 2.  Serves up Containers on Demand 3.  Manages Composite Application Deployments Copyright 2015 by Cloudsoft Corporation Limited
13. @grkvlt What does it provide? •  Infrastructure Management •  Docker Hosts •  Swarm Controller •  Multi Host and Multi Container Applications •  Seamless Networking •  Communication Between Services •  Orchestration and Clustering •  Control of Containers •  Container Management Copyright 2015 by Cloudsoft Corporation Limited
14. @grkvlt Clocker and Brooklyn Summary •  What is it? •  Brooklyn Application •  Brooklyn Location •  What does it provide? •  First Class Docker Support in Brooklyn •  Optimized Brooklyn Blueprints for Docker •  Container Orchestration Copyright 2015 by Cloudsoft Corporation Limited
15. Applica.on  Management
16. @grkvlt Brooklyn Blueprints •  Describe Applications •  OASIS CAMP Standard •  TOSCA and Compose in Development •  List of Services •  NoSQL Database Clusters •  Web Servers and Load Balancers •  Shell or Python Scripts •  Targeting Multiple Destinations •  VM, Container, Bare Metal •  Sensors, Effectors and Policies Copyright 2015 by Cloudsoft Corporation Limited
17. @grkvlt Application Management •  Sensors •  Data from Services •  Effectors •  Brooklyn Policies •  Attached to Entities in Application •  Nothing Docker Specific •  Elastic Scaling and Cluster Resizing •  Service Resilience and Replacement Copyright 2015 by Cloudsoft Corporation Limited
18. @grkvlt Blueprint Example 1 Copyright 2015 by Cloudsoft Corporation Limited id:  redis-­‐service   name:  "Docker  Hub  Redis  Service"   origin:  "https://registry.hub.docker.com/_/redis/"     locations:   -­‐  my-­‐docker-­‐cloud     services:   -­‐  type:  docker:redis:3      id:  redis      openPorts:      -­‐  6379
19. @grkvlt Blueprint Example 2 Copyright 2015 by Cloudsoft Corporation Limited id:  redis-­‐cluster   name:  "Redis  Cluster"     locations:   -­‐  jclouds:aws-­‐ec2:          region:  eu-­‐central-­‐1     services:   -­‐  type:  org.apache.brooklyn.entity.nosql.redis.RedisCluster      initialSize:  3
20. @grkvlt Blueprint Example 3 id:  appserver-­‐with-­‐policy   name:  "Tomcat  Scaling  Webapp  Server"   location:  jclouds:aws-­‐ec2:eu-­‐west-­‐1   services:   -­‐  type:  org.apache.brooklyn.entity.webapp.ControlledDynamicWebAppCluster      initialSize:  3      memberSpec:          $brooklyn:entitySpec:              type:  org.apache.brooklyn.entity.webapp.tomcat.Tomcat8Server              brooklyn.config:                  wars.root:                      https://  s3-­‐eu-­‐west-­‐1.amazonaws.com/brooklyn-­‐clocker/brooklyn-­‐example-­‐hello-­‐world-­‐sql-­‐webapp-­‐0.6.0.war                  http.port:  8080+                  java.sysprops:                        brooklyn.example.db.url:  $brooklyn:formatString("jdbc:%s%s?user=%s\\&password=%s",                              component("db").attributeWhenReady("datastore.url"),  "visitors",  "brooklyn",  "br00k11n")      brooklyn.policies:      -­‐  policyType:  org.apache.brooklyn.policy.autoscaling.AutoScalerPolicy          brooklyn.config:              metric:  $brooklyn:sensor("org.apache.brooklyn.entity.webapp.DynamicWebAppCluster",  "webapp.reqs.perSec.windowed.perNode")              metricLowerBound:  10              metricUpperBound:  100              minPoolSize:  1              maxPoolSize:  5   -­‐  type:  org.apache.brooklyn.entity.database.mysql.MySqlNode      id:  db      name:  DB  HelloWorld  Visitors      brooklyn.config:          datastore.creation.script.url:              https://  s3-­‐eu-­‐west-­‐1.amazonaws.com/brooklyn-­‐clocker/visitors-­‐creation-­‐script.sql   Copyright 2015 by Cloudsoft Corporation Limited
21. @grkvlt Clocker Blueprints Copyright 2015 by Cloudsoft Corporation Limited
22. @grkvlt Docker Cloud •  Brooklyn Blueprint for Docker Cluster •  Docker Engine on Cloud VM or Bare Metal •  Manage TLS Certificates and access credentials •  Create and Mount Volumes •  Setup Logging and Monitoring •  Install SDN and other Agents •  Configure local or remote Docker Registry •  Manage Capacity or Headroom Copyright 2015 by Cloudsoft Corporation Limited
23. @grkvlt Headroom •  Ensure resources available •  Based on MaxContainers strategy limit •  Or Percentage Utilisation •  Or CPU and RAM allocation •  Scale Docker Host Cluster Automatically •  Add new Docker hosts •  Remove empty Docker hosts Copyright 2015 by Cloudsoft Corporation Limited
24. @grkvlt Clocker 1.x Architecture Copyright 2015 by Cloudsoft Corporation Limited
25. @grkvlt Docker Cloud 1.  On-demand 2.  Multi-Tenant 3.  Hardware Independent 4.  Application Level Copyright 2015 by Cloudsoft Corporation Limited
26. @grkvlt Clocker Features • Docker Extensions to Brooklyn – Docker Image as First-Class Service Type – Placement Strategies for Containers – Create Docker Images and Networks •  Manages Docker Engine and Swarm – Deployment and Management – Installation and Configuration – Software-Defined Networking Copyright 2015 by Cloudsoft Corporation Limited
27. @grkvlt Container Management •  Sources •  Docker Image Definition •  Docker Hub or Registry •  Dockerfile •  Brooklyn Entity Definition •  Create Image Automatically •  Commit or Push for Reuse Copyright 2015 by Cloudsoft Corporation Limited
28. @grkvlt Clocker Orchestration Copyright 2015 by Cloudsoft Corporation Limited Docker Engine Virtual Machine Container Clocker Network Segment SDN Provider Cloud Provider Brooklyn
29. Clocker  Networking
30. @grkvlt Software-Defined Networking •  Needed for Seamless Provisioning •  Host to Host Communication •  Same LAN Segment •  No Port Forwarding •  Natural Application Configuration •  Initial Driver was EPMD Applications •  Useful for any opinionated applications Copyright 2015 by Cloudsoft Corporation Limited
31. @grkvlt Networking Providers •  Implementation Agnostic •  L2 overlay, L3 routing etc. •  Similar to Hypervisor in Clouds •  Generic Interfaces •  Host Component •  Service Component (or Endpoint) •  Same idea as Docker Network Plugins Copyright 2015 by Cloudsoft Corporation Limited
32. @grkvlt Networking Capabilities •  Attach Containers to Networks   •  Create Networks as Required •  Also Attach to VMs and Metal •  Provide Multiple Networks •  Per-Application or Shared •  Segmented Private Address Space •  Docker Port Forwarding for Ingress Copyright 2015 by Cloudsoft Corporation Limited
33. @grkvlt Network Provisioning •  Minimal (Zero!) Configuration •  Use Sensible Defaults •  Allows SDN or Cloud Specific Configuration •  Allocate Address Space on Demand •  IP Pool Controlled by Clocker -­‐  type:  brooklyn.networking.VirtualNetwork      networkId:  database-­‐net      cidr:  192.168.34.0/24      gateway:  192.168.34.1      dnsServers:      -­‐  $brooklyn:entity("bind-­‐server").attributeWhenReady("host.address")      addIptablesRules:  true   -­‐  type:  brooklyn.networking.OpenStackVirtualNetwork      networkId:  couchbase-­‐net   Copyright 2015 by Cloudsoft Corporation Limited
34. @grkvlt Clocker Networking Container Host SDN Bridge Container Internet SDN Gateway Copyright 2015 by Cloudsoft Corporation Limited
35. @grkvlt Metaswitch Project Calico •  SDN for Bare Metal, VMs and Containers •  Layer 3 •  Uses OS IP routing and forwarding •  Configuration in an etcd Cluster •  Version 0.4.9 in Clocker •  0.6.0 with libnetwork when Docker stable •  Spans VMs and Containers •  OpenStack Neutron network driver Copyright 2015 by Cloudsoft Corporation Limited
36. @grkvlt Copyright 2015 by Cloudsoft Corporation Limited Cross-Target Deployment
37. @grkvlt Networking Capabilities •  Wide Area and Multi Region SDN •  VPN or IPIP and NAT configuration •  Cross Platform SDN •  Both VMs and Containers on one VLAN •  Name Resolution and Service Discovery •  Contributing to Weave DNS for orchestration •  Use traditional external BIND service entity •  Brooklyn can inject correct endpoint address Copyright 2015 by Cloudsoft Corporation Limited
38. Demonstra.on
40. @grkvlt Application Blueprint 1 Copyright 2015 by Cloudsoft Corporation Limited id:  my-­‐application   location:  my-­‐docker-­‐cloud   services:   -­‐  type:  docker:redis:3      id:  redis      openPorts:  6379   -­‐  type:  docker:amouat/dnmonster:1.0      id:  dnmonster      openPorts:  8080   -­‐  type:  docker:amouat/identidock:1.0      id:  identidock      portBindings:          80:  9090      links:      -­‐  $brooklyn:component("redis")      -­‐  $brooklyn:component("dnmonster")
41. @grkvlt Application Blueprint 2 Copyright 2015 by Cloudsoft Corporation Limited id:  my-­‐application   location:  my-­‐docker-­‐cloud   services:   -­‐  type:  org.apache.brooklyn.entity.nosql.redis.RedisStore      id:  redis      install.version:  3.0.0   -­‐  type:  docker:amouat/dnmonster:1.0      id:  dnmonster      openPorts:  8080   -­‐  type:  docker:amouat/identidock:1.0      id:  identidock      portBindings:          80:  9090      links:      -­‐  $brooklyn:component("redis")      -­‐  $brooklyn:component("dnmonster")
42. @grkvlt Application Blueprint 3 Copyright 2015 by Cloudsoft Corporation Limited id:  my-­‐application   location:  my-­‐docker-­‐cloud   services:   -­‐  type:  org.apache.brooklyn.entity.nosql.redis.RedisStore      location:  jclouds:softlayer:ams01      id:  redis      install.version:  3.0.0   -­‐  type:  docker:amouat/dnmonster:1.0      id:  dnmonster      openPorts:  8080   -­‐  type:  docker:amouat/identidock:1.0      id:  identidock      portBindings:          80:  9090      links:      -­‐  $brooklyn:component("redis")      -­‐  $brooklyn:component("dnmonster")
43. @grkvlt Application Blueprint 4 Copyright 2015 by Cloudsoft Corporation Limited id:  my-­‐application   location:  jclouds:softlayer:ams01   services:   -­‐  type:  org.apache.brooklyn.entity.nosql.redis.RedisStore      id:  redis      install.version:  3.0.0   -­‐  type:  docker:amouat/dnmonster:1.0      id:  dnmonster      openPorts:  8080   -­‐  type:  docker:amouat/identidock:1.0      id:  identidock      portBindings:          80:  9090      links:      -­‐  $brooklyn:component("redis")      -­‐  $brooklyn:component("dnmonster")
44. @grkvlt Application Blueprint 5 Copyright 2015 by Cloudsoft Corporation Limited id:  my-­‐application   services:   -­‐  type:  org.apache.brooklyn.entity.nosql.redis.RedisStore      location:  jclouds:softlayer:ams01      id:  redis      install.version:  3.0.0   -­‐  type:  marathon:amouat/dnmonster:1.0      location:  my-­‐mesos-­‐cluster      id:  dnmonster      openPorts:  8080   -­‐  type:  docker:amouat/identidock:1.0      location:  my-­‐docker-­‐cloud      id:  identidock      portBindings:          80:  9090      links:      -­‐  $brooklyn:component("redis")      -­‐  $brooklyn:component("dnmonster")
45. @grkvlt •  Orchestrated Docker deployment and configuration, with Project Calico SDN •  Brooklyn application blueprints deployed with network topology linked to OpenStack using Project Calico •  Automated attachment of containers to multiple dynamic networks •  Zero Config Multi-Target Deployment Copyright 2015 by Cloudsoft Corporation Limited Features
46. Clocker  1.x
47. @grkvlt Roadmap 1 •  Mesos Integration •  View and manage existing Mesos clusters •  Provide Mesos as another Brooklyn endpoint •  Run Marathon tasks for Brooklyn entities •  Future Possibilities... •  Brooklyn as a Mesos framework or scheduler •  Integrate with other frameworks like Riak BDP Copyright 2015 by Cloudsoft Corporation Limited
48. @grkvlt Roadmap 2 Copyright 2015 by Cloudsoft Corporation Limited
49. Clocker Solves: – Docker Cloud Networking – Container Placement and Provisioning – Composite Application Management Summary
50. Ques.ons?
51. Nyan Whale
52. @grkvlt Resources http://clocker.io/   http://brooklyn.io/   https://github.com/brooklyncentral/clocker/   https://github.com/apache/incubator-­‐brooklyn/   https://github.com/Metaswitch/calico-­‐docker/   https://github.com/weaveworks/weave/   http://blog.abstractvisitorpattern.co.uk/
