PolyConf 2015 - Rocking the Time Series boat with C, Haskell and ClojureScript

Time Series have an amazing potential for Querying, Parallelisation and Query Composition, because of the nature of the Data itself, this is exactly why general-purpose stores won't ever be the best fit for Time Series data.
Continuum, a Time Series store was built keeping the key features of Time Series data in mind. State-of-art Algebraic structures, can be used to build flexible and composite Query API, Compact data structures can be used to save up space and reduce deserialisation effort while reading data from DB.
An adventure of building a Modern Time Series database in C + Haskell, with ClojureScript front-end, that brings the visibility of everything going on in your system on a whole new level.

Transcript

3. ClojureWerkz 35+ high-quality Clojure libraries User reports from all over the world 20+ active contributors We value documentation
4. Introduction
5. Being Ukrainian
6. Re-Learning everything
7. Evaluating Ideas
8. Fighting Compiler
9. Patching GHC
10. Talking to the People
12. Time Series Data Monotonically increasing primary key Write-only data Range Queries Rolling Aggregates
13. Time Series Data LevelDB backend Tight Combination of Haskell and C Optimising space, reads Flexible aggregates Parallel queries
14. Start With Querying
15. How do I Parallel?
16. 3-Step Aggregate? Local Aggregate (parallel) Append Combine
17. <timestamp><sequenceId>
18. Used to avoid timestamp resolution collisions To ensure sub-resolution order Snapshot the data on overflow or timeout Ensures idempotence Sequence ID
19. 1 2 3 4 5 6 7 8 9 10 11 12 13 Range Tables store the snapshotted ranges
20. Full Table Scan 1 2 3 4 5 6 7 8 9 10 11 12 13 Start End
21. 1 2 3 4 5 6 7 8 9 10 11 12 13
22. Open Range 1 2 3 4 5 6 7 8 9 10 11 12 13 Start End
23. 1 2 3 4 5 6 7 8 9 10 11 12 13
24. “Between” Range 1 2 3 4 5 6 7 8 9 10 11 12 13 Start End
25. 1 2 3 4 5 6 7 8 9 10 11 12 13
26. Stream Fusion Reading Data from LevelDB
28. data Step a s = Yield a !s | Skip !s | Done data Stream a = ∃s. Stream (s → Step a s) s
29. maps :: (a → b) → Stream a → Stream b maps f (Stream next0 s0 ) = Stream next s0 where next !s = case next0 of Done → Done Skip s' → Skip s' Yield x s' → Yield (f x) s'
30. filters :: (a → Bool) → Stream a → Stream a filters p (Stream next0 s0) = Stream next s0 where next !s = case next0 s of Done → Done Skip s' → Skip s' Yield x s' | p x → Yield x s' | otherwise → Skip s'
31. foldls :: (b → a → b) → b → Stream a → b foldls f z (Stream next s0) = loop z s0 where loop z s = case next s of Yield x s' → loop (f z x) s' Skip s' → loop z s' Done → z
32. Local Aggregate (parallel) Append Combine
33. data (Monoid b) => Fold a b = ∃x. Fold (x → a → x) x (x → b) step initial finalize Append class Monoid a where mempty :: a mappend :: a -> a -> a -- ^ Identity of 'mappend' -- ^ An associative operation
34. class (Monoid intermediate) => Aggregate intermediate end where combine :: intermediate -> end Combine
35. Count data Count = Count Int op_count :: ∃a. Fold a Count op_count = Fold (\i _ -> i + 1) 0 Count instance Monoid Count where mempty = Count 0 mappend (Count a) (Count b) = Count $ a + b instance Aggregate Count Int where combine (Count a) = a
36. Mean data (Num a) => Mean a = Mean [a] op_mean :: (Integral a) => Fold a (Mean a) op_mean = Fold (flip (:)) [] Mean instance (Integral a) => Monoid (Mean a) where mempty = Mean [] mappend (Mean a) (Mean b) = Mean $ a ++ b instance (Integral a) => Aggregate (Mean a) Double where combine (Mean []) = 0 combine (Mean a) = s / l where s = fromIntegral $ sum a l = fromIntegral $ length a
37. Other examples Streaming Histogram Median Percentiles You name it
38. Combining Queries
39. Group op_groupBy :: (Ord a, Monoid b) => (r -> Maybe a) -> (Fold r b) -> Fold r (MapResult a b) op_groupBy groupFn (Fold f z0 e) = let subStep n Nothing = return $! (f z0 n) subStep n (Just a) = return $! (f a n) localStep m record = maybe m (\r -> Map.alter (subStep record) r m) (groupFn record) done a = MapResult $ Map.map e a in Fold localStep Map.empty done
40. Other examples Several Aggregates in one run Group by field, time or combination Nested aggregates of any type
41. Break Down the Queries Aggregate each part independently Combine aggregates Transform the Result Recap
42. Binary Data Format Optimising even further
43. data DbValue = DbString ByteString | DbLong Integer | DbInt Integer | DbShort Integer | DbByte Integer | DbFloat Float | DbDouble Double deriving (Eq, Show, Ord, Generic)
44. DbSchema [ ("field1", DbtLong) , ("field2", DbtString) , ("field3", DbtShort)]
45. Layout 0 8 16 +----------------+----------------+----------------+ ... | field 1 offset | field 2 offset | field 3 offset | ... +----------------+----------------+----------------+ ... 24 24 + offset 24 + offset ... +--------------+--------------+--------------+ ... | field 1 data | field 2 data | field 2 data | ... +--------------+--------------+--------------+
46. Offset Reads
47. Fast reads Partial payload decoding Field Names are implicit
48. Schema Migrations
49. Adding fields appends to the end Written data is unchanged or nullified Removed fields are ignored and unavailable
50. Consensus
51. Snapshot consensus Rolling CRC of the data Asynchronous No quorum for snapshot reads Parallel Reads from Snapshotted Data
52. Future Plans
53. Conclusions
54. Partial Decoding Parallel Queries Composable, extendable query system Lightweight Consensus Lightweight Data Format
55. @ifesdjeen
