Adventures in Multithreaded Core Data

Adventures in Multithreaded Core Data

A presentation I gave for CocoaHeadsBE on 20120924 at Digiti in Zoersel.

1fad3e8e639182432b882758e986275f?s=128

Tom Adriaenssen

September 24, 2011
Tweet

Transcript

  1. Adventures in Multithreaded Core Data CocoaheadsBE - Zoersel, 2012-09-24

  2. Introduction

  3. Tom Adriaenssen

  4. I love... ‣ ... my wife ‣ ... my 4

    kids ‣ ... to code ‣ ... to play a game of squash ‣ ... good beer
  5. I open sourced... ... some code: ‣ IIViewDeckController: “An implementation

    of the sliding functionality found in the Path 2.0 or Facebook iOS apps.” ‣ IIDateExtensions ‣ IIPopoverStatusItem See: http://github.com/inferis
  6. I made... ... some apps: Butane Drash Hi, @10to1! http://getbutane.com

    http://dra.sh
  7. Butane ‣ Official Campfire client kinda sucks, so we rolled

    our own ‣ Somewhat concurrent app ‣ Uses Core Data ‣ Together with 10to1 Campfire client for iOS
  8. This presentation is about  what I learned  while

    coding Butane.
  9. Agenda

  10. Agenda ‣ Core Data Primer ‣ MagicalRecord ‣ Concurrency problems

    ‣ Concurrency solutions
  11. Core Data Primer

  12. What is: Core Data? ‣ Per the documentation: ‣ The

     Core  Data  framework  provides   generalized  and  automated  solutions   to  common  tasks  associated  with   object  life-­‐cycle  and  object  graph   management,  including  persistence. http://developer.apple.com/library/mac/#documentation/cocoa/Conceptual/CoreData/Articles/cdTechnologyOverview.html#//apple_ref/doc/uid/TP40009296-SW1
  13. Wait, what?

  14. What isn’t: Core Data? ‣ It’s not an RDBMS. ‣

    If you want a database and SQL, use Sqlite:
  15. What isn’t: Core Data? ‣ It’s not just an ORM

    (Object Relational Mapper) ‣ It may look like there’s SQL under the hood, but that’s not necessarily the case.
  16. So, what is it then? Core Data provides: ‣ persistence

    ‣ change tracking ‣ relations (object graph) ‣ lazy loading (“faulting”) ‣ validation ‣ works well with Cocoa (KVO, KVC)
  17. Basically: ‣ A system to store data ‣ Persistence agnostic

    (local storage, iCloud, AFIncrementalStore, ...) ‣ No need to write SQL to query ‣ You can keep to Objective-C
  18. Your tools: ‣ NSPersistentStore   ‣ NSManagedObjectContext   ‣ NSManagedObject

      ‣ NSManagedObjectID     ‣ NSFetchRequest   ‣ NSEntityDescription   ‣ NSPredicate   ‣ NSSortDescription
  19. A picture says a 1000 words...

  20. MagicalRecord

  21. MagicalRecord ‣ Writing Core Data code is tedious. ‣ You

    need quite a bit of boilerplate code to do something simple: NSManagedObjectContext  *moc  =  [self  managedObjectContext];   NSEntityDescription  *entityDescription  =  [NSEntityDescription  entityForName:@"Employee"  inManagedObjectContext:moc];   NSFetchRequest  *request  =  [NSFetchRequest  new];   [request  setEntity:entityDescription];       NSSortDescriptor  *sortDescriptor  =  [[NSSortDescriptor  alloc]  initWithKey:@"firstName"  ascending:YES];   [request  setSortDescriptors:@[sortDescriptor]];       NSError  *error;   NSArray  *array  =  [moc  executeFetchRequest:request  error:&error];   ! if  (array)   {     //  display  items  (eg  in  table  view)   }   else  {          //  Deal  with  error...   }   ! !
  22. MagicalRecord ‣ MagicalRecord tries to solve this. ‣ = ActiveRecord

    pattern for Core Data. ‣ Encapsulates the tediousness of plain Core Data code.
  23. MagicalRecord ‣ Writing MagicalRecord enable code is tedious no more:

    ‣ That same example is now this: NSManagedObjectContext  *moc  =  [self  managedObjectContext];   NSArray  *array  =  [Employee  MR_findAllSortedBy:@"firstname"  ascending:YES  inContext:context];   ! if  (array)   {     //  display  items  (eg  in  table  view)   }   else  {          //  Deal  with  error...   }   ! ! ! !
  24. None
  25. Great, isn’t it?

  26. MagicalRecord + write less code + your code becomes more

    readable + good for apps requiring simple storage scenarios (=most apps, probably) + hides complexity - hides complexity - easy to start, but diving deeper becomes harder - uses defaults that are suboptimal in a multithreaded app - concurrency errors and issues are subtle
  27. MagicalRecord ‣ used MagicalRecord from the start ‣ Took me

    a while to find out the problems I was having were related to the complexity hiding ‣ The defaults are okay only for so much app complexity
  28. MagicalRecord ‣ That said: Magical Record is great. ‣ It

    will speed up your Core Data development by several factors. ‣ Also: take a look at mogenerator: ‣ http://rentzsch.github.com/mogenerator/ ‣ or: brew  install  mogenerator
  29. MagicalRecord ‣ So I threw it out. ‣ But not

    completely. ‣ More about that later.
  30. The problems described hereafter only apply to the persistent stores

    with external backing (for example: sqlite).
  31. Concurrency: problems

  32. Problems? ‣ Core Data Objects are not thread safe. ‣

    In essence: you can’t share them across threads (except for NSManagedObjectID). ‣ Core Data locks objects, even for read operations.
  33. Object storage is locked for read operations, too ‣ Objects

    used to power the UI must be fetched on the UI thread. ‣ Heavy/complex fetch requests (queries) block the UI thread while fetching the objects. You don’t want that.
  34. Objects aren’t supposed to be shared between threads ‣ The

    NSManagedObjectContext “locks” an object when you read one of its properties. ‣ This can cause a deadlock when you do access the same data from 2 threads. ‣ Reason: faulting support can change the object even while just reading from it. ‣ You can’t turn it off.
  35. None
  36. Luckily, we can fix or workaround these problems.

  37. Concurrency: solutions

  38. Keep to your thread ‣ pre-iOS5: use thread confinement ‣

    iOS5 and later: use nested contexts
  39. Thread confinement ‣ In essence: keep an NSManagedObjectContext per thread

    ‣ Be very careful when going from one thread to another. ! ‣ MagicalRecord tries to hide this from you: ‣ It automatically provides a context for each thread ‣ This is a bit counterintuitive since you start mixing objects across threads quite easily.
  40. Thread confinement Image source: Cocoanetics

  41. Nested contexts ‣ Introduced in iOS5 ‣ Uses Grand Central

    Dispatch and dispatch queues ‣ Core Data manages threading for you ‣ Better than thread confinement ‣ more straightforward ‣ more flexible ! ‣ MagicalRecord hides this from you, too. ‣ Automatically switches to dispatch queues on iOS5 even though the API remains the same.
  42. Nested contexts Image source: Cocoanetics

  43. Nested contexts ‣ NSManagedObjectContext = cheap ‣ You can nest

    contexts ‣ Each context has its private dispatch queue ‣ No manual thread synchronization necessary
  44. Queue types ‣ NSConfinementConcurrencyType ‣ The old way (thread confinement)

    ‣ NSPrivateQueueConcurrencyType ‣ The context has its own private dispatch queue ‣ NSMainQueueConcurrencyType ‣ The context is associated with the main queue (or runloop, or UI thread) parentMoc  =  [[NSManagedObjectContext  alloc]  initWithConcurrencyType:NSMainQueueConcurrencyType];   [parentMoc  setPersistentStoreCoordinator:coordinator];   ! moc  =  [[NSManagedObjectContext  alloc]  initWithConcurrencyType:NSPrivateQueueConcurrencyType];   moc.parentContext  =  parentMoc;
  45. Thread safe? ‣ performBlock:   performBlockAndWait:   ‣ Run a

    block you provide on the queue associated with the context. ‣ Object access in the block is thread safe [context  performBlockAndWait:^{          for  (Room*  room  in  [Room  findAllInContext:context])  {                  room.joinedUsers  =  [NSSet  set];                  room.knowsAboutJoinedUsersValue  =  NO;                  room.unreadCountValue  =  0;                  room.status  =  @"";          }          NSError*  error  =  nil;          [context  save:&error];   }];
  46. performBlock, and wait -­‐  (void)performBlock:(void  (^)())block;   ‣ executes the

    block on the context dispatch queue as soon as possible ‣ nonblocking call ‣ code will not execute immediately ! -­‐  (void)performBlockAndWait:(void  (^)())block;   ‣ executes the block on the context dispatch queue immediately ‣ blocks the current execution until block is done ‣ can cause a deadlock (if you’re already running code on the same queue)
  47. When to use what? ‣ performBlock:   ‣ For actions

    which are “on their own” ‣ Consider the code in the block a Unit Of Work ‣ Best for save operations ‣ Useful for long fetches (use callbacks) ! ‣ performBlockAndWait:   ‣ When you need stuff immediately ‣ Good for small fetches or “standalone” saves
  48. How is this better than thread confinement? ‣ No manual

    thread handling, Core Data handles it for you. ‣ More flexible: as long as you access managed objects in the correct context using performBlock: you’re pretty safe ‣ also applies to the main/UI thread! (unless you’re sure you’re on the main thread)
  49. Saving nested contexts ‣ Saves are only persisted one level

    deep. ‣ Parent contexts don’t pull changes from child contexts. ‣ Child contexts don’t see changes by parent contexts. ‣ Make them plenty and short-lived
  50. How to nest contexts ‣ 2 approaches: ‣ root context

    = NSMainQueueConcurrencyType ‣ root context = NSPrivateQueueConcurrencyType
  51. Root = Main Image source: Cocoanetics ‣ Many child contents

    with private queues ‣ Root context on main queue ‣ Actual persistence happens on main queue, could block the UI
  52. Root = Private Image source: Cocoanetics ‣ Root context with

    private queue ‣ Many child contents with private queues ‣ context on main queue is child of root ‣ Actual persistence happens in background (does not block the UI)
  53. What problems did we have again? ‣ No sharing of

    NSManagedObjects between threads. ‣ Context locking
  54. Sharing: solution ‣ Pass only NSManagedObjectIDs to other threads, not

    objects. ‣ Refetch the object on a different thread or queue to work with it. ‣ Don’t forget to save the ‘original’ object first before working with it on the second thread or queue.
  55. Complex queries ‣ Use the same technique for complex or

    large queries. 1. do the heavy lifting in the background 2. pass list of NSManagedObjectIDs to another thread (e.g. UI thread). 3. load objects as faults, and let Core Data fault them in when you need them (e.g. when accessing a property) ! ‣ That’s lot of requests, but this is actually more performant and desirable in most cases.
  56. Locking: solution ‣ Use child contexts with their own dispatch

    queues. ‣ Use: performBlock: and performBlockAndWait:  carefully. ‣ Deadlocks still possible, especially with performBlockAndWait:
  57. A word about NSManagedObjectIDs ‣ Two types of IDs: ‣

    temporary ‣ when the object hasn’t been persisted to a store ‣ permanent ‣ when the object has been persisted to a store
  58. A word about NSManagedObjectIDs ‣ Subtle bug: temporary IDs from

    a non-root context don’t get updated to permanent IDs when saving in the root context ‣ The object is saved just fine, but the ID is not updated correctly. ‣ When passing these around to other contexts after saving: you won’t find the object in another child context!
  59. A word about NSManagedObjectIDs ‣ To the rescue: -­‐  (BOOL)obtainPermanentIDsForObjects:

    (NSArray  *)objects  error:(NSError   **)error;
  60. A word about NSManagedObjectIDs -­‐  (BOOL)obtainPermanentIDsForObjects:(NSArray   *)objects  error:(NSError  **)error;

      ! ‣ Transforms objects with temporary IDs to permanent IDs (through the persistent store of the root context). ‣ Do this when creating a managed object and you’re safe. ‣ Obtaining permanentIDs is batched, so the performance hit is not that high
  61. MagicalRecord ‣ I still use MagicalRecord: ‣ Reduced form: no

    more “automatic” context handling --> dangerous! ‣ Added some extra sauce to work with the nested contexts. ‣ The methods MR supplies still allow for a speedup when coding.
  62. Useful References ‣ Nested context release notes: http://developer.apple.com/library/mac/#releasenotes/ DataManagement/RN-CoreData/_index.html ‣

    Magical Record: https://github.com/magicalpanda/MagicalRecord ‣ Mogenerator: http://rentzsch.github.com/mogenerator/ ‣ A good read on Cocoanetics: http://www.cocoanetics.com/2012/07/multi-context-coredata/ ‣ Core data programming guide: http://developer.apple.com/library/mac/#documentation/ cocoa/Conceptual/CoreData/cdProgrammingGuide.html ‣ Butane: http://getbutane.com
  63. Thanks for listening. Twitter: @inferis App.Net: @inferis E-mail: tom@interfaceimplementation.be vCard:

    http://inferis.org Questions? Contact me:
