論文紹介「ResNeSt: Split-Attention Networks」

Ristの社内Kaggle workshopで使用した「ResNeSt: Split-Attention Networks」の紹介スライドです。
arXive: https://arxiv.org/pdf/2004.08955.pdf
Github: https://github.com/zhanghang1989/ResNeSt

Transcript

1. Rist kaggler workshop
   ResNeSt論文紹介
   いのうえ


   View Slide

2. ResNeSt: Split-Attention Networks
   arXive: https://arxiv.org/pdf/2004.08955.pdf
   Github: https://github.com/zhanghang1989/ResNeSt


   View Slide

3. Squeeze-and-Excitation NEtworks
   arXive: https://arxiv.org/abs/1709.01507
   Github: https://github.com/hujie-frank/SENet


   View Slide

4. Squeeze-and-Excitation NEtworks
   arXive: https://arxiv.org/abs/1709.01507
   Github: https://github.com/hujie-frank/SENet
   チャンネルに重み付けする。
   ＝Attention


   View Slide

5. Squeeze-and-Excitation NEtworks
   導入はとても簡単。SE-Moduleを加えるだけ。


   View Slide

6. Squeeze-and-Excitation NEtworks
   参照 Cadene’s github, pretrained-models.pytorch:
   https://github.com/Cadene/pretrained-models.pytorch/blob/master/pretrainedmodels/models/senet.py


   View Slide

7. Squeeze-and-Excitation NEtworks
   参照 Cadene’s github, pretrained-models.pytorch:
   https://github.com/Cadene/pretrained-models.pytorch/blob/master/pretrainedmodels/models/senet.py


   View Slide

8. ResNeStの構成
   SE-ModuleはResidual blockなど任意の
   Blockの後ろに付け足すだけだが、
   ResNeSt
   はResNetのBottleneckのconv2がSplit
   Attention moduleに変わる。
   https://github.com/zhanghang1989/ResNeSt/blob/
   master/resnest/torch/resnet.py#L106


   View Slide

9. Selective Kernel Networks
   arXive: https://arxiv.org/abs/1903.06586?
   Github: https://github.com/implus/SKNet


   View Slide

10. ResNeStとは
    arXive: https://arxiv.org/pdf/2004.08955.pdf
    Github: https://github.com/zhanghang1989/ResNeSt
    この中身の説明


    View Slide

11. ざっくり言うと...
    Cardinalの中でさらにradixの数に分
    割し、Attentionを計算する。
    Split Attention


    View Slide

12. Split Attention
    H
    W
    C x R
    Split
    R : radix
    Element-wise
    Summation
    GAP
    FC
    BN
    ReLu
    FC rSoftmax
    Attention
    Sum
    SplAtConv2d　
    https://github.com/zhanghang1989/ResNeSt/blob/60e61bab401760b473c9
    a0aecb420e292b018d35/resnest/torch/splat.py#L11
    R=1のときはrSoftmaxはSigmoidになる（SE-Moduleと同等）
    Cardinalの数だけSplit Attentionされて
    C
    Conv2D
    ①
    Cardinal
    Concat
    Cardinal
    Split
    ② ③
    ④
    ⑤


    View Slide

13. Split Attention


    View Slide

14. Split Attention
    ①
    groupsの数がCardinalの数。
    ここはResNeXtと同じ。
    公式Modelはgroups=1, radix=2


    View Slide

15. Split Attention
    Radixの数で分割して、Channel
    ごとに合計する。
    ②


    View Slide

16. Split Attention
    fc1で一旦、次元を減らしてから、
    fc2で次元をchannel x radixに戻
    す。
    ③
    (Channel, 1)のサイズになる。


    View Slide

17. Split Attention
    ④


    View Slide

18. rSoftmax
    channel方向のSoftmax


    View Slide

19. Split Attention
    ⑤
    Attentionをかけて、合計する。これ
    で次元がchannel x radixから
    channelに戻る。


    View Slide

20. SENet, SKNetと比べると...
    Relation to Existing Attention Methods. First introduced in SE-Net [29], the idea of
    squeeze-and-attention (called excitation in the original paper) is to employ a global context to
    predict channel-wise attention factors. With radix = 1, our Split-Attention block is applying a
    squeeze-and-attention operation to each cardinal group, while the SE-Net operates on top of the
    entire block regardless of multiple groups. Previous models like SK-Net [38] introduced feature
    attention between two network branches, but their operation is not optimized for training
    efficiency and scaling to large neural networks. Our method generalizes prior work on
    feature-map attention [29, 38] within a cardinal group setting [60], and its implementation
    remains computationally efficient. Figure 1 shows an overall comparison with SE-Net and
    SK-Net blocks.
    （本文より引用）


    View Slide
