MVC 1.0 - by Example @ Devoxx Belgium 2015

@rgielen / @ivar_grimstad
#Devoxx #JSR371
JSR 371
MVC 1.0 for Java EE 8

View Slide

#Devoxx #JSR371
Ivar Grimstad
Principal Consultant for
Cybercom Sweden
JSR 371 Expert Group Member

View Slide

#Devoxx #JSR371
René Gielen
Independent Software
Craftsman, Consultant, Trainer
Apache Struts PMC Chair

View Slide

#Devoxx #JSR371

View Slide

#Devoxx #JSR371
Front Controller

View Slide

#Devoxx #JSR371
Action

View Slide

#Devoxx #JSR371
Request

View Slide

#Devoxx #JSR371
Response

View Slide

#Devoxx #JSR371
Serious Business

View Slide

#Devoxx #JSR371

View Slide

#Devoxx #JSR371
Action vs. Component
Component based
Complex Stateful Components
Abstract away Request-Response
Action based
Abstract away Technical Details of HTTP
Stateless
Embrace Request-Response

View Slide

#Devoxx #JSR371

View Slide

#Devoxx #JSR371
Introduction to JSR 371

View Slide

#Devoxx #JSR371
Why?

View Slide

#Devoxx #JSR371
https://java.net/downloads/javaee-spec/JavaEE8_Community_Survey_Results.pdf

View Slide

#Devoxx #JSR371
http://glassﬁsh.org/survey

View Slide

#Devoxx #JSR371
Action-based MVC

View Slide

#Devoxx #JSR371
Existing Java EE Technologies

View Slide

#Devoxx #JSR371
JSR 371 Expert Group

View Slide

#Devoxx #JSR371
Key Decisions

View Slide

#Devoxx #JSR371
Build MVC 1.0 on top of JAX-RS

View Slide

#Devoxx #JSR371
Show me the CODE !

View Slide

#Devoxx #JSR371
Controllers

View Slide

#Devoxx #JSR371
public class HelloController {
}
Controller

View Slide

#Devoxx #JSR371
@Path(“hello”)
}
Controller

View Slide

#Devoxx #JSR371
@Controller
@Path(“hello”)
}
Controller

View Slide

#Devoxx #JSR371
Views

View Slide

#Devoxx #JSR371
@Controller
@Path(“hello”)
}
View

View Slide

#Devoxx #JSR371
@Controller
@Path(“hello”)
@GET
public String hello() {
return “hello.jsp”;
}
}
View

View Slide

#Devoxx #JSR371
@Controller
@Path(“hello”)
@GET
public Viewable hello() {
return new Viewable(“hello.jsp”);
}
}
View

View Slide

#Devoxx #JSR371
@Controller
@Path(“hello”)
@GET
public Response hello() {
return Response.status(OK).entity(“hello.jsp”).build();
}
}
View

View Slide

#Devoxx #JSR371
@Controller
@Path(“hello”)
@View(“hello.jsp”)
@GET
public void hello() {
}
}
View

View Slide

#Devoxx #JSR371
@Controller
@Path(“hello”)
@GET
}
}
View

View Slide

#Devoxx #JSR371
Models

View Slide

#Devoxx #JSR371
@Controller
@Path(“hello”)
@GET
}
}
Model

View Slide

#Devoxx #JSR371
@Named(“greeting”)
@RequestScoped
public class Greeting {
private String message;
public void setMessate(String message) {
this.message = message;
}
public void getMessage() { return message; }
}
Model

View Slide

#Devoxx #JSR371
@Controller
@Path(“hello”)
@Inject
private Greeting greeting;
@GET
greeting.setMessage(“Hello Devoxx!”);
}
}
Model

View Slide

#Devoxx #JSR371
pageEncoding="UTF-8"%>

MVC 1.0 Hello Demo

Hello ${greeting.message}

Model

View Slide

#Devoxx #JSR371
@Controller
@Path(“hello”)
@GET
}
}
Model

View Slide

#Devoxx #JSR371
@Controller
@Path(“hello”)
@Inject
private Models model;
@GET
model.put(“message”, “Hello Devoxx!”);
}
}
Model

View Slide

#Devoxx #JSR371
pageEncoding="UTF-8"%>

MVC 1.0 Hello Demo

Hello ${message}

Model

View Slide

#Devoxx #JSR371
View Engines

View Slide

#Devoxx #JSR371
Bring Your Own View Engine
BYOVE

View Slide

#Devoxx #JSR371
public interface ViewEngine {
boolean supports(String view);
void processView(ViewEngineContext context)
throws ViewEngineException;
}
ViewEngine

View Slide

#Devoxx #JSR371
@Priority(OUTRAGEOSLY_HIGH) 
@ApplicationScoped 
public class FreemarkerViewEngine extends ViewEngineBase {
…
}
View Engine Conﬂicts

View Slide

#Devoxx #JSR371
Validation

View Slide

#Devoxx #JSR371
@Controller
@Path("form")
public class FormController {
@POST
public Response formPost(@Valid @BeanParam FormDataBean f) {
return Response.status(OK).entity(“data.jsp”).build();
}
}
Validation
ConstraintValidationException
@Min, @NotNull
etc.

View Slide

#Devoxx #JSR371
public class FormViolationMapper implements
ExceptionMapper {
public Response toResponse(ConstraintViolationException e) {
Set> s =e.getConstraintViolations();
// process violations ...
return Response.status(BAD_REQUEST)
.entity(“error.jsp”).build();
}
}
Validation

View Slide

#Devoxx #JSR371
@Controller
@Path("form")
public class FormController {
@Inject private BindingResult br;
@POST
public Response formPost(@Valid @BeanParam FormDataBean f) {
if (br.isFailed()) {
return Response.status(BAD_REQUEST)
.entity(“error.jsp”).build();
}
return Response.status(OK).entity(“data.jsp”).build();
}
}
Validation
Allows for MVC Error Handling

View Slide

#Devoxx #JSR371
Scopes

View Slide

#Devoxx #JSR371
@Named(“greeting”)
@RedirectScoped
public class Greeting {
private String message;
public void setMessate(String message) {
this.message = message;
}
public void getMessage() { return message; }
}
@RedirectScoped

View Slide

#Devoxx #JSR371
@Controller
@Inject
@POST
@Path(“from”)
greeting.setMessage(“Hello Devoxx!”);
return “redirect:/to“;
}
}
@RedirectScoped
@RedirectScoped
@RequestScoped

View Slide

#Devoxx #JSR371
@Controller
@Inject
@POST
@Path(“to”)
return “here.jsp“;
}
}
@RedirectScoped
Same Bean

View Slide

#Devoxx #JSR371
Security

View Slide

#Devoxx #JSR371
@Controller
@Path(“csrf”)
@CsrfValid
@POST
public Response post(@FormParam(“greeting") String greet {
}
}
Cross Site Request Forgery

View Slide

#Devoxx #JSR371

MVC 1.0 Hello Demo

value="${mvc.csrf.token}"/>

Cross Site Request Forgery

View Slide

#Devoxx #JSR371
Events

View Slide

#Devoxx #JSR371
BeforeControllerEvent
AfterControllerEvent
BeforeProcessViewEvent
AfterProcessViewEvent
ControllerRedirectEvent
Currently Supported Events

View Slide

#Devoxx #JSR371
@ApplicationScoped
public class EventObserver {
void onBeforeController(@Observes BeforeControllerEvent e) {
println("URI: " + e.getUriInfo().getRequestURI());
}
void onAfterController(@Observes AfterControllerEvent e) {
println("Controller: " +
e.getResourceInfo().getResourceMethod());
}
}
Events Example

View Slide

#Devoxx #JSR371
Summary

View Slide

#Devoxx #JSR371
Project Page
https://java.net/projects/mvc-spec
Mailing List
[email protected]
Reference Implementation
https://ozark.java.net

View Slide

#Devoxx #JSR371
JSR 371 - Test Drive

View Slide

#Devoxx #JSR371
How about Real World?

View Slide

#Devoxx #JSR371
Real World - Key Questions
Common Problems Solved for Real World?
On Par with comparable Servlet-based Frameworks?

View Slide

#Devoxx #JSR371
Comparable Frameworks
Spring MVC
around since 2005
“Real World” since 2008 (Spring 2.5 onward)
today’s leader in Action-Land
Struts 2
around since 2004 (WebWork 2)
“Real World” since 2007 (Struts 2.0.9 onward)
still widely adopted

View Slide

#Devoxx #JSR371
Comparable Frameworks
Spring MVC
around since 2005
“Real World” since 2008 (Spring 2.5 onward)
today’s leader in Action-Land
Struts 2
around since 2004 (WebWork 2)
“Real World” since 2007 (Struts 2.0.9 onward)
still widely adopted
3 Years till getting Real!

View Slide

#Devoxx #JSR371

View Slide

#Devoxx #JSR371
Let’s relax a bit…
JSR 371: „Standing on the Shoulder of Giants“
JAX-RS / Jersey
CDI
Bean Validation
Interceptors
Facelets, Thymeleaf, Freemarker, Velocity
Adds on Top
Lightweight Top Layer
Extension Points

View Slide

#Devoxx #JSR371
So - what are these
“Common Problems“?

View Slide

#Devoxx #JSR371
“Hello MVC”
is not enough!

View Slide

#Devoxx #JSR371
Common Real World Needs
Scoped DI
Controller Decoupling
Controller Testability
View Technology Flexibility
VDL Expressiveness
i18n / l10n
Form Binding
Type Conversion
Declarative Validation
Message Passing to View
Post-Redirect-Get
File Upload
UI Controls and Theming
AJAX Support
Decorator Support
Cross Cutting Concerns

View Slide

#Devoxx #JSR371
Scoped Dependency Injection
Spring MVC
Spring DI
Struts 2
Supported
Containers
Supported Scopes EJB Support
Spring MVC Spring DI
Application, Session,
Request, Redirect,
Custom
Yes (Adapter
Framework)
Struts 2
Spring DI, Guice,
CDI
Application, Session,
Request, Redirect,
Custom
Yes (CDI)
JSR 371 / Ozark CDI
Application,
Session, Request,
Redirect, Custom
Yes

View Slide

#Devoxx #JSR371
Controller Decoupling
Spring MVC
Spring DI
Struts 2
Controllers as
POJOs
Coupling to
Servlet API
required
Coupling to
Servlet API
supported
Model
Abstraction
Spring MVC Yes No Yes
Model
Container,
Return value
Struts 2 Yes No Yes
Controller
Instance, Value
Stack
JSR 371 / Ozark Yes No Yes
Scoped CDI
Beans, Model
Container

View Slide

#Devoxx #JSR371
Controller Testing Support
Spring MVC
Spring DI
Struts 2
Unit Testing Mocking Support
Integration
Test Framework
Spring MVC Easy Easy Spring Test MVC
Struts 2 Easy Easy
Struts 2 Test
Framework
JSR 371 / Ozark Easy Easy
No / presumably
Jersey Test
Framework

View Slide

#Devoxx #JSR371
Supported View Technologies
Spring MVC
Spring DI
Struts 2
JSP Templating
DHTML
Integration
Others
Spring MVC Yes
Thymeleaf,
Freemarker,
Velocity, GSP
Various 3rd
Party
Contributions
JSON, XML,
JasperReports
Struts 2 Yes
Freemarker,
Velocity,
Thymeleaf
jQuery,
Bootstrap, YUI
AngularJS
JSON, XML,
JasperReports
JSR 371 / Ozark Yes
Facelets,
Freemarker,
Velocity,
Thymeleaf
Handlebars,
Mustache
JSON + XML
(JAX-RS),
AsciiDoc

View Slide

#Devoxx #JSR371
Real Code

View Slide

#Devoxx #JSR371
Wrap-up: State of MVC
Lightweight Layer on Top of well established Technologies
Easy to extend
Addresses most Common Needs
Some Gaps and Glitches
most can easily addressed by Implementations and Extensions
some might be gone in the ﬁnal Speciﬁcations

View Slide

#Devoxx #JSR371
Q & A

View Slide
