炎炎夏日學 Android 課程 - Part1: Kotlin 語法介紹

炎炎夏日學 Android 課程 - Part1: Kotlin 語法介紹

炎炎夏日學 Android 課程 - Part1: Kotlin 語法介紹
(Kotlin EveryWhere 活動)

8a6e58b272b266faf22d8a3b2927624f?s=128

Johnny Sung

June 30, 2019
Tweet

Transcript

  1. 炎炎夏⽇日學 Android Johnny Sung Part1: Kotlin 語法介紹

  2. Mobile device developer Johnny Sung https://fb.com/j796160836 https://blog.jks.coffee/ https://www.slideshare.net/j796160836 https://github.com/j796160836

  3. ⼤大綱 • Kotlin 語法介紹 • Android 元件介紹 • Hello Android

  4. 環境準備 • 電腦⼀一台 • 安裝 Android Studio & Android SDK

    • Android ⼿手機⼀一⽀支(極建議,非必要) • 夠快的網路路 Wifi • 你最愛的飲料⼀一杯
  5. 純命令列列環境 • 電腦版 IntelliJ 新增 Kotlin JVM 專案 • IntelliJ

    IDEA CE
 https://www.jetbrains.com/idea/ • Kotlin 線上編譯器
 https://play.kotlinlang.org • Java 線上編譯器
 https://www.tutorialspoint.com/compile_java_online.php
  6. 純命令列列環境 線上版 電腦版 • 優點:跨平台,不需安裝,
 不佔硬碟空間,快速⽅方便便使⽤用。 • 缺點:編輯器語法⾃自動完成較陽春,
 無⾃自動格式化。 •

    優點:編譯較快,
 編輯器語法⾃自動完成較完整, • 缺點:需安裝,佔硬碟空間。
  7. IntelliJ IDEA CE
 https://www.jetbrains.com/idea/

  8. Kotlin 線上編譯器
 https://play.kotlinlang.org

  9. Java 線上編譯器
 https://www.tutorialspoint.com/compile_java_online.php

  10. None
  11. 變數 (Variable)

  12. https://www.citiesocial.com/products/picardie-500ml-6 glass

  13. var glass: String = "檸檬紅茶茶" 變數名稱 型態 值 宣告(指定給...) (初始化)

  14. http://www.royalhost.com.tw/m/mealList.php?class_type=07&pid=132 glass

  15. • 數字 • String 字串串 (陸譯:字符串串) • Boolean 布林林 (陸譯:布爾)

    • Array 陣列列 (陸譯:數組) • Char 字元 (陸譯:字符) • Double ⾼高精度浮點數 (64 bit) • Float 浮點數 (32 bit) • Long 長整數 (64 bit) 基礎資料型態 https://www.kotlincn.net/docs/reference/basic-types.html • Int 整數 (32 bit) • Short 整數 (16 bit) • Byte 整數 (8 bit)
  16. var val 宣告⼀一個可修改的變數 宣告⼀一個不可改的常數

  17. var number: Int? = null var number2: Int = 1

    變數名稱 型態 值 變數名稱 型態 值 有問號 沒有問號
  18. null

  19. https://www.citiesocial.com/products/picardie-500ml-6

  20. Int? Int 有問號 沒有問號 變數可以為空值 變數不可為空值

  21. var
 (變數可修改) val
 (變數不可改) 型態有問號
 (可以為空值) ✅ ❌ 型態沒有問號
 (不可為空值)

    ✅
 (需給初始值) ✅
 (需給初始值)
  22. var myString1: String = "abc" var myString2: String? = null

    val myString3: String = "abc" 宣告⼀一個 myString 的字串串,初始為 "abc" (不為 null,⼀一定要給值) 宣告⼀一個可為 null 的字串串叫 myString,初始為 null 宣告⼀一個不可改的字串串叫 myString,值為 "abc"
  23. 流程與判斷
 (Conditions & Flows)

  24. if

  25. https://goods.ruten.com.tw/item/show?21738146420312

  26. (⾃自動判斷為布林林值,省略略型態寫法) var temperature = 15 if (temperature > 40) {

    print("是熱⽔水") } else { print("是冷⽔水") }
  27. var isCreature = true if (isCreature) { print("是⽣生物") } else

    { print("不是⽣生物") } (⾃自動判斷為布林林值,省略略型態寫法)
  28. 常⽤用運算元 == 等於 > ⼤大於 >= ⼤大於等於 < ⼩小於 <=

    ⼩小於等於 && AND || OR ! NOT 真值表 A B A && B A || B false false false false false true false true true false false true true true true true
  29. Switch when

  30. http://www.dmerci.com/index.php/product/new%E6%96%B0%E5%93%81classic%E5%BD%88%E7%8F%A0%E5%8F%B0/

  31. val viewType: Int = 1 when (viewType) { 1, 2

    -> { // Do something with value 1 or 2 } 3 -> { // Do something with value 3 } else -> { // Do something with default } }
  32. switch (viewType) { case 1: case 2: // Do something

    with value 1 or 2 break; case 3: // Do something with value 3 break; default: // Do something with default } val viewType: Int = 1 when (viewType) { 1, 2 -> { // Do something with value 1 or 2 } 3 -> { // Do something with value 3 } else -> { // Do something with default } } Java Kotlin
  33. Java Kotlin if (item instanceof ModelA) { // ... }

    else if (item instanceof ModelB) { // ... } else if (item instanceof ModelC) { // ... } else { // ... } when (item) { is ModelA -> { // ... } is ModelB -> { // ... } is ModelC -> { // ... } else -> { // ... } } 型態判斷 型態判斷
  34. for 迴圈

  35. http://120.116.50.2/school/album/index_showpic.php?picpage=1&selpage=1&prgid=3&sgd=&actid=7275&sernum=6&selpart= http://www.winled.com.tw/product_details.php?id=114

  36. ( 0 到 1 0 ) for (i in 0..10)

    { println(i) } 開始值 結束值 關鍵字的點點 賦予計數的變數名
 (計數器的變數)
  37. 開始值 結束值 關鍵字 downTo 賦予計數的變數名
 (計數器的變數) for (i in 10

    downTo 0 step 1) { println(i) } 步進值 ( 10 到 0 )
  38. Java Kotlin for (i in 10 downTo 0 step 1)

    { println(i) } for (int i = 10; i >= 0; i--) { System.out.println(i); } for (i in 0..10) { println(i) } for (int i = 0; i <= 10; i++) { System.out.println(i); } ( 0 到 10 ) ( 10 到 0 ) ( 0 到 10 ) ( 10 到 0 )
  39. 陣列列 (Array)

  40. http://tw.gigacircle.com/2409121-1

  41. Java Kotlin String[] strings = new String[]{"a", "b"}; 陣列列型態 陣列列型態

    val strings: Array<String> = arrayOf("a", "b") ArrayList<String> strings = new ArrayList<>(); strings.add("a"); strings.add("b"); strings.add("c"); val strings:ArrayList<String> = ArrayList<String>() strings.add("a") strings.add("b") strings.add("c") ArrayList 型態 ArrayList 型態
  42. 陣列列搭配 for 迴圈是好⿇麻吉 ☺

  43. Java Kotlin val strings = arrayOf("a", "b", "c") for ((index,

    value) in strings.withIndex()) { println("The element at $index is $value") } String[] strings = new String[]{"a", "b", "c"}; for (int index = 0; index < strings.length; index++) { String value = strings[index]; System.out.println("The element at " + index + " is " + value); }
  44. Kotlin 型態省略略 val strings = arrayOf("a", "b") val strings =

    ArrayList<String>() strings.add("a") strings.add("b") strings.add("c") 型態省略略 val num = 1 val str = "hello" 型態省略略 型態省略略 val str:String = "hello" val num:Int = 1
  45. Java Kotlin for (int i = 0; i < strings.length;

    i++) { String string = strings[i]; // ... } for (String string : strings) { // ... } for (string in strings) { // ... } String[] strings = new String[]{"a", "b"}; 陣列列 陣列列 val strings: Array<String> = arrayOf("a", "b") for (i in 0 until strings.size) { // ... }
  46. 多維陣列列

  47. http://tw.gigacircle.com/2409121-1 a0 a1 a2 a3 a4 b0 b1 b2 b3

    b4 c0 c1 c2 c3 c4 d0 d1 d2 d3 d4
  48. val ice = arrayOf( arrayOf("a0", "a1", "a2", "a3", "a4"), arrayOf("b0",

    "b1", "b2", "b3", "b4"), arrayOf("c0", "c1", "c2", "c3", "c4"), arrayOf("d0", "d1", "d2", "d3", "d4") )
  49. http://tw.gigacircle.com/2409121-1 ice[0][0] ice[0][1] ice[0][2] ice[0][3] ice[0][4] ice[1][0] ice[1][1] ice[1][2] ice[1][3]

    ice[1][4] ice[2][0] ice[2][1] ice[2][2] ice[2][3] ice[2][4] ice[3][0] ice[3][1] ice[3][2] ice[3][3] ice[3][4]
  50. function (method)

  51. fun plus(a: Int, b: Int): Int { return a +

    b } 參參數1 參參數1型態 參參數2 參參數2型態 函式名字 回傳值型態 (宣告) (呼叫) val c = plus(1,3)
  52. Anonymous function 匿名函式

  53. Callback 回呼

  54. my_button.setOnClickListener { // ... }

  55. my_button.setOnClickListener(object : View.OnClickListener { override fun onClick(v: View?) { //

    ... } }) my_button.setOnClickListener { // ... }
  56. val doneCallback: () -> Unit = { // I'm done!

    } doneCallback() doneCallback.invoke() (宣告) (呼叫) 變數型態 呼叫
  57. val doneCallback: (String) -> Unit = { str -> println(str)

    } (宣告) (呼叫) 變數型態 呼叫 doneCallback.invoke("The result")
  58. var doneCallback: ((String) -> Unit)? = null doneCallback = {

    str -> println(str) } doneCallback?.invoke("The result") (宣告) (呼叫) 可能為 null 的型態 如果是 null 就不呼叫 if (doneCallback != null) { doneCallback.invoke("The result") }
  59. 錯誤處理理

  60. 錯誤處理理 try { // ... throw IllegalArgumentException("Invalid argument.") // ...

    } catch (e: Exception) { e.printStackTrace() } 拋出錯誤 接住錯誤
  61. class & method (Function)

  62. class MyClass { private val str = "hello" public fun

    printHello() { println(str) } } 類別名 類別變數 類別⽅方法
  63. public class MyClass { private String str = "hello"; public

    void printHello() { System.out.println(str); } } class MyClass { private val str = "hello" public fun printHello() { println(str) } } Java Kotlin
  64. class 類別 object 物件 https://auto.epochtimes.com/car-b5-36337-%E6%96%B0%E8%BB%8A%E4%BB%8B%E7%B4%B9%EF%BC%9A2019%E6%AC%BE%E5%A5%A7%E8%BF%AAAudi%20A6.html https://itw01.com/V25GNEJ.html

  65. class MyDataModel { var name: String? = "" var num:

    Int = 0 } val model = MyDataModel() model.name = "John" model.num = 123 建立 MyDataModel 物件
  66. 建構⼦子

  67. Java Kotlin class Student { private String name; public Student(String

    name) { this.name = name; } public void printName() { System.out.println(name); } } class Student { var name: String constructor(name: String) { this.name = name } fun printName(){ println(name) } } 建構⼦子
  68. 建構⼦子的變形 class Student { var name: String constructor(name: String) {

    this.name = name } fun printName(){ println(name) } } class Student(var name: String) { fun printName(){ println(name) } }
  69. static Method

  70. class MyClass { companion object { fun staticMethod() { }

    } } public class MyClass { public static void staticMethod() { } } Java Kotlin
  71. Kotlin class MyClass { companion object { fun staticMethod() {

    } } } object MyClass { fun staticMethod() { } }
  72. 物件導向程式設計
 (Object-oriented programming) • 抽象(Abstraction) • 封裝(Encapsulation) • 繼承(Inheritance) •

    多型(Polymorphism) 陸譯:⾯面向对象程序设计
  73. interface Animal { fun sound() } class Cat : Animal

    { override fun sound() { println("喵喵喵~") } } class Dog : Animal { override fun sound() { println("汪汪汪~") } } 繼承(或實作) val pet: Animal = Cat() pet.sound() // 喵喵喵~
  74. class HairClipperForDog { fun haircut(dog: Dog) { println("(理理髮器聲...)") dog.sound() println("頭⽑毛理理好了了!")

    } } class HairClipperForCat { fun haircut(cat: Cat) { println("(理理髮器聲...)") cat.sound() println("頭⽑毛理理好了了!") } } val myCat = Cat() val catClipper = HairClipperForCat() catClipper.haircut(myCat) val myDog = Dog() val dogClipper = HairClipperForDog() dogClipper.haircut(myDog)
  75. class HairClipper { fun haircut(animal: Animal) { println("(理理髮器聲...)") animal.sound() println("頭⽑毛理理好了了!")

    } } https://tw.buy.yahoo.com/gdsale/ %E6%97%A5%E8%B1%A1%E9%BB%91%E9%91%BD%E9%9B%BB%E5%8B%95%E7%90%86%E9%AB%AE%E5%99%A8%E5%85%85%E6%8F%92%E6%9C%89%E7%B7%9A%E7%84%A1%E7%B7%9AZOH-2600C-5289698.html
  76. val hairClipper = HairClipper() val myDog = Dog() hairClipper.haircut(myDog) val

    myCat = Cat() hairClipper.haircut(myCat)
  77. Java Kotlin interface Animal { public void eat(); } class

    Cat implements Animal { @Override public void eat() { // ... } } class Dog implements Animal { @Override public void eat() { // ... } } interface Animal { fun eat() } class Cat : Animal { override fun eat() { // ... } } class Dog : Animal { override fun eat() { // ... } }
  78. 變數轉型

  79. 變數轉型 • 基本型別的轉型 • 有對應函式能使⽤用

  80. 變數轉型 • 物件的轉型 • 要是繼承樹裡的才能轉型 open class Father { //

    ... } class Brother: Father() { // ... } var a: Father = Brother() var b = a as? Brother 如果轉型失敗就回傳 null 變數型態為:Brother?
  81. Collections

  82. Collections • Map • HashMap • TreeMap • List •

    ArrayList • LinkedList • Stack • Queue • Set • SortedSet • HashSet • TreeSet [ 清單類 ] [ 不重複類 ] [ key-value 類 ]
  83. ArrayList val strings:ArrayList<String> = ArrayList<String>() strings.add("a") strings.add("b") strings.add("b") strings.add("a") ArrayList

    型態 ( 有順序的清單 ) a b b a
  84. Java Kotlin String[] strings = new String[]{"a", "b"}; 陣列列型態 陣列列型態

    val strings: Array<String> = arrayOf("a", "b") ArrayList<String> strings = new ArrayList<>(); strings.add("a"); strings.add("b"); strings.add("c"); val strings:ArrayList<String> = ArrayList<String>() strings.add("a") strings.add("b") strings.add("c") ArrayList 型態 ArrayList 型態
  85. Array 陣列列 ArrayList 可修改數量量 數量量不可修改 (數量量在宣告時即固定,不可修改)

  86. 我有問題 (

  87. 為何宣告不可改的東⻄西⼜又可以改? val strings:ArrayList<String> = ArrayList<String>() strings.add("a") strings.add("b") strings.add("c") 宣告不可改 為什什麼⼜又可以改?

  88. http://www.funbugi.com/%E8%87%AA%E5%B7%B1%E5%8B%95%E6%89%8Bdiy%E7%95%AB%E5%AE%A4%E5%85%A7%E8%A8%AD%E8%A8%88%E5%B9%B3%E9%9D%A2%E5%9C%96sketchup/ 倉庫 倉庫 倉庫 倉庫 倉庫

  89. http://www.funbugi.com/%E8%87%AA%E5%B7%B1%E5%8B%95%E6%89%8Bdiy%E7%95%AB%E5%AE%A4%E5%85%A7%E8%A8%AD%E8%A8%88%E5%B9%B3%E9%9D%A2%E5%9C%96sketchup/ 主臥室 ⼩小孩房 客廳 ⼯工作室 倉庫

  90. 空間本⾝身不能變,
 內裝配置沒限制

  91. HashSet val hashSet = HashSet<String>() hashSet.add("a") hashSet.add("a") hashSet.add("b") hashSet.add("b") a

    b ( 不允許重複的資料集 )
  92. HashMap val students = HashMap<String, String>() students.put("A001", "王⼤大明") students.put("A002", "黎黎曉彤")

    students.put("A003", "桃⼤大姐") students.put("A001", "王⼤大明") 王⼤大明 黎黎曉彤 桃⼤大姐 A001 A002 A003 (⽤用 key-value 存放的不重複資料集 )
  93. 猛虎出柙雙劍合璧版--最新 OCA / OCP Java SE 7 Programmer 專業認證 https://books.google.com.tw/books?id=EElBCgAAQBAJ&pg=PA407&lpg=PA407&source=bl&ots=bPzrpKU4n4&sig=ACfU3U31_OKnAJo5ELdqMfu2E4TNIW218A&hl=zh-TW&sa=X&ved=2ahUKEwi-u5uYzPTiAhWKF6YKHVAXB-sQ6AEwAHoECAkQAQ#v=onepage&

  94. 猛虎出柙雙劍合璧版--最新 OCA / OCP Java SE 7 Programmer 專業認證 https://books.google.com.tw/books?id=EElBCgAAQBAJ&pg=PA407&lpg=PA407&source=bl&ots=bPzrpKU4n4&sig=ACfU3U31_OKnAJo5ELdqMfu2E4TNIW218A&hl=zh-TW&sa=X&ved=2ahUKEwi-u5uYzPTiAhWKF6YKHVAXB-sQ6AEwAHoECAkQAQ#v=onepage&

  95. 程式設計原則 - SOLID by Robert C. Martin

  96. SOLID • 單⼀一職責原則 Single responsibility • 開放封閉原則 Open-Close • ⾥里里⽒氏替換原則

    Liskov substitution • 接⼝口隔離原則 Interface segregation • 依賴反轉原則 Dependency inversion by Robert C. Martin https://ithelp.ithome.com.tw/articles/10191553 http://teddy-chen-tw.blogspot.com/2014/04/solid.html
  97. 單⼀一職責原則
 (Single responsibility principle, SRP) 每個 類別 (class)、函數 (method) 負責的功能,都應該只做⼀一件事。

  98. 泛型 (Generic)

  99. https://www.pcstore.com.tw/3m-house/M17129526.htm

  100. <物品名稱> <物品> https://www.jingyeqian.com/news-68.html https://www.pcstore.com.tw/3m-house/M17129526.htm

  101. ArrayList val strings:ArrayList<String> = ArrayList<String>() strings.add("a") strings.add("b") strings.add("c") ArrayList 型態

    泛型帶入的型別
  102. class HairClipperForDog { fun haircut(dog: Dog) { println("(理理髮器聲...)") dog.sound() println("頭⽑毛理理好了了!")

    } } class HairClipperForCat { fun haircut(cat: Cat) { println("(理理髮器聲...)") cat.sound() println("頭⽑毛理理好了了!") } } val myCat = Cat() val catClipper = HairClipperForCat() catClipper.haircut(myCat) val myDog = Dog() val dogClipper = HairClipperForDog() dogClipper.haircut(myDog)
  103. class HairClipper<T : Animal> { fun haircut(animal: T) { println("(理理髮器聲...)")

    animal.sound() println("頭⽑毛理理好了了!") } } https://tw.buy.yahoo.com/gdsale/ %E6%97%A5%E8%B1%A1%E9%BB%91%E9%91%BD%E9%9B%BB%E5%8B%95%E7%90%86%E9%AB%AE%E5%99%A8%E5%85%85%E6%8F%92%E6%9C%89%E7%B7%9A%E7%84%A1%E7%B7%9AZOH-2600C-5289698.html ⾃自⼰己取的型態 T 只限於 Animal 繼承樹上的
  104. val myDog = Dog() val hairClipperForDog = HairClipper<Dog>() hairClipperForDog.haircut(myDog) val

    myCat = Cat() val hairClipperForCat = HairClipper<Cat>() hairClipperForCat.haircut(myCat)
  105. 延伸閱讀 https://classroom.udacity.com/courses/ud9011/ https://classroom.udacity.com/courses/ud9012/ Kotlin Bootcamp for Programmers Developing Android Apps

    with Kotlin
  106. 延伸閱讀 https://kotlinlang.org/docs/tutorials/ https://kotlinlang.org/docs/reference/ Kotlin Tutorials Learn Kotlin https://www.kotlincn.net/docs/reference/ https://www.kotlincn.net/docs/reference/ https://www.kotlincn.net/docs/tutorials/

  107. Tea time~ ☕
