Providing the Best Mac Experience Possible, From the Mac CoE Team with ❤️

Presentation from JNUC 2018, the world's largest rally of Apple IT administrators.

Session:
Providing the Best Mac Experience Possible, From the Mac CoE Team with ❤️

Presented by:
Rich Trouton, SAP

View all session slides, recordings and more at https://www.jamf.com/events/jamf-nation-user-conference/2018/.

Transcript

1. View Slide

2. Providing the Best Mac
   Experience Possible,
   from the Apple CoE
   Team with —
   Rich Trouton
   Apple CoE @


   View Slide

3. The Way It Was….


   View Slide

4. =
   Right?


   View Slide

5. View Slide

6. View Slide

7. View Slide

8. View Slide

9. USB Stick Script + Jamf Pro


   View Slide

10. View Slide

11. https://www.sap.com/products/enterprise-social-collaboration.html


    View Slide

12. View Slide

13. View Slide

14. Product Backlog Sprint Backlog Sprints
    1 week
    Working
    increment
    Product Owner
    Agile


    View Slide

15. SAP Mac applications must fulfill the following requirements to be
    added to the monthly Release Train process:
    • Must be 64-bit and sandboxed
    • Must be digitally signed with a valid Apple Developer Certificate
    • Must be packaged with Apple’s technology (e.g. Installer or drag-n-drop)
    • Must be self-contained, single application bundle and cannot install code or
    resources in shared locations not approved by Apple (shared Containers for
    sandboxed Apps is OK for example)
    • Must not install kernel extensions! (kexts)
    • Must not spawn additional processes that continue to run after the user has quit the
    App without the user’s consent
    • Must not use deprecated or optionally installed technologies (Java, Flash, etc.)
    • Must not add to Login or startup without the user’s consent
    • Must not request elevation to root privileges or use setuid attributes (e.g. it must run
    within the user’s space as standard user)
    • Must only use public API’s for OS X and approved API’s for accessing or modifying
    user data for other Apps
    • Must comply with macOS File System
    • Must not modify, change or disable the build in Quarantine, firewall or Gatekeeper


    View Slide

16. deploy
    operate
    monitor
    release
    code
    build
    test
    plan
    DevOps


    View Slide

17. View Slide

18. 2700
    5025
    7350
    9675
    12000
    October 2012 October 2013 October 2014 August 2016


    View Slide

19. 0
    2250
    4500
    6750
    9000
    Jan 2013 October 2013 October 2014 October 2015 August 2016
    MacBook Pro
    MacBook Air
    Mac Mini
    iMac
    MacBook


    View Slide

20. View Slide

21. Privileges
    Refresh Signature
    Assistant


    View Slide

22. Refresh Assistant
    +
    (Machine-level)


    View Slide

23. View Slide

24. Assistant
    (User-level)


    View Slide

25. View Slide

26. Signature


    View Slide

27. View Slide

28. Privileges


    View Slide

29. Privileges
    •Allows a standard user account to easily request admin rights
    • Give yourself admin rights when you need them.
    • Take away admin rights when you don’t.
    • Enhances the Mac’s security without impacting performance or productivity.
    • Easy to use application
    • Includes command line version to allow workflow automation


    View Slide

30. View Slide

31. https://github.com/SAP/macos-icon-generator
    Icons


    View Slide

32. View Slide

33. Apple Pies


    View Slide

34. https://www.sap.com/products/fiori.html
    Fiori


    View Slide

35. View Slide

36. One place to discuss Macs
    and to be informed of
    new developments
    All new Knowledge Base
    All information is now

    available outside the
    corporate network
    Well structured
    More colourful and engaging
    using nice pictures and emojis
    Current news and information
    2000+ new members
    in run up to Sierra release
    Videos


    View Slide

37. View Slide

38. View Slide

39. View Slide

40. View Slide

41. View Slide

42. View Slide

43. View Slide

44. Removing IT’s Local Admin


    View Slide

45. Management via Jamf Pro


    View Slide

46. Using Local Accounts


    View Slide

47. View Slide

48. Moving Jamf Pro to AWS


    View Slide

49. Why host in Amazon
    Web Services?
    •Leverage AWS’ high availability
    services
    •Mac-supporting services
    accessible anywhere
    •SAP IT is able to manage all
    corporate-managed Macs
    anywhere


    View Slide

50. What are we using in
    Amazon Web Services?
    S3
    Elastic Load Balancing
    EC2
    RDS
    Elasticache
    https://aws.amazon.com/products/


    View Slide

51. Amazon

    RDS
    Jamf Pro MySQL
    database
    Amazon

    S3
    Jamf Pro
    Cloud
    Distribution
    Point
    (Internet
    Accessible)
    Amazon
    EC2
    Jamf Pro admin
    console
    (not Internet
    accessible)
    Jamf Pro cluster nodes
    Elastic Load
    Balancing
    Application Load
    Balancer
    (Internet Accessible;
    TLS Termination)
    security group
    (admin console disabled,
    not Internet accessible)
    security group
    security group
    HTTPS
    HTTPS
    MySQL
    (Not Internet accessible)
    AWS Virtual Private Cloud
    MySQL
    Application Load
    Balancer
    (Accessible to SAP
    IP addresses; TLS
    Termination)
    Amazon
    Elasticache
    Memcache
    (not Internet
    accessible)
    Memcache
    Connecting to
    admin console
    EC2
    Systems
    Manager
    HTTPS
    Internet
    Encrypted LDAP Query
    HTTPS
    HTTPS
    SAP-managed
    Mac
    Jamf
    Infrastructure
    Manager (JIM)
    Active Directory
    Domain
    Encrypted
    LDAP queries to AD
    Non-LDAP JIM comms
    Non-LDAP JIM comms
    LDAPS


    View Slide

52. Amazon
    EC2
    Jamf Pro admin
    console
    (not Internet
    accessible)
    Jamf Pro cluster nodes
    Elastic Load
    Balancing
    (admin console disabled,
    not Internet accessible)
    security group
    security group
    HTTPS
    AWS Virtual
    Private Cloud
    Application Load
    Balancer
    (Accessible to SAP
    IP addresses; TLS
    Termination)
    Connecting to
    admin console
    Administration


    View Slide

53. Amazon
    EC2
    Systems
    Manager
    Jamf Pro admin console
    (EC2 Systems Manager
    agents installed)
    Jamf Pro cluster nodes
    (EC2 Systems Manager
    agents installed)
    security group
    security group
    AWS Virtual Private Cloud
    HTTPS
    HTTPS
    Administration
    https://derflounder.wordpress.com/2017/05/30/managing-aws-hosted-vms-
    using-ec2-systems-manager/


    View Slide

54. #!/bin/bash
    # Stop the Jamf Tomcat processes
    service jamf.tomcat8 stop


    View Slide

55. {
    "schemaVersion": "1.2",
    "description": "Stop Tomcat on Jamf Pro instances",
    "parameters": {
    "upgradeType":{
    "type":"String",
    "default": "",
    "description":"Stopping the Tomcat server on Jamf Pro servers"
    }
    },
    "runtimeConfig": {
    "aws:runShellScript": {
    "properties": [
    {
    "id": "0.aws:runShellScript",
    "runCommand": [
    "#!/bin/bash",
    "",
    "# Stop the Jamf Tomcat processes",
    "",
    "service jamf.tomcat8 stop"
    ]
    }
    ]
    }
    }
    }


    View Slide

56. #!/bin/bash
    # This script is designed for use with EC2 Systems Manager's
    # State Manager. It does the following tasks:
    #
    # 1. Check to see if /root/.TomcatMonitoringActive is present.
    # 2. If /root/.TomcatMonitoringActive is present, run the
    # following tasks:
    #
    # A. Check to see if the Tomcat service is active on port 8080
    # B. If the Tomcat service is active, print a message and exit.
    # C. If the Tomcat service is not active, print an error message
    # and take the following actions:
    # i. Restart the Tomcat service
    #
    # The reason for the file check for /root/.TomcatMonitoringActive
    # is to allow Tomcat monitoring to be easily disabled for times
    # when it would not be convenient for the automated Tomcat service
    # restart to be active, like when performing upgrades to the Tomcat
    # application or when the Tomcat application needs to be offline
    # for maintenance reasons.
    # Check for /root/.TomcatMonitoringActive
    MONITORCHECK="/root/.TomcatMonitoringActive"
    ERROR=0
    if [[ -f "$MONITORCHECK" ]]; then
    echo "Tomcat port monitoring is active."
    # Check for Tomcat to be running on port 8080
    PORTCHECK=$(/bin/netstat -tln | awk '/:8080/ {print $4}' | sed "s/://g")
    if [[ "$PORTCHECK" = "8080" ]]; then
    echo "Tomcat service is running on port $PORTCHECK"
    else
    echo "Tomcat service is not responding on port 8080"
    echo "Restarting Tomcat service"
    # Starts the JAMF Tomcat processes
    service jamf.tomcat8 restart
    fi
    else
    echo "Tomcat port monitoring is offline."
    fi
    exit $ERROR


    View Slide

57. {
    "schemaVersion": "1.2",
    "description": "Monitor Tomcat on Jamf Pro instances",
    "parameters": {
    "upgradeType":{
    "type":"String",
    "default": "",
    "description":"Monitoring the Tomcat service on Jamf Pro servers and perform automated service restarts if necessary"
    }
    },
    "runtimeConfig": {
    "aws:runShellScript": {
    "properties": [
    {
    "id": "0.aws:runShellScript",
    "runCommand": [
    "#!/bin/bash",
    "",
    "# This script is designed for use with EC2 Systems Manager's",
    "# State Manager. It does the following tasks:",
    "#",
    "# 1. Check to see if /root/.TomcatMonitoringActive is present.",
    "# 2. If /root/.TomcatMonitoringActive is present, run the ",
    "# following tasks:",
    "# ",
    "# A. Check to see if the Tomcat service is active on port 8080",
    "# B. If the Tomcat service is active, print a message and exit.",
    "# C. If the Tomcat service is not active, print an error message",
    "# and take the following actions:",
    "# i. Restart the Tomcat service",
    "#",
    "# The reason for the file check for /root/.TomcatMonitoringActive",
    "# is to allow Tomcat monitoring to be easily disabled for times",
    "# when it would not be convenient for the automated Tomcat service",
    "# restart to be active, like when performing upgrades to the Tomcat",
    "# application or when the Tomcat application needs to be offline ",
    "# for maintenance reasons.",
    "",
    "# Check for /root/.TomcatMonitoringActive",
    "",
    "MONITORCHECK=\"/root/.TomcatMonitoringActive\"",
    "",
    "ERROR=0",
    "",
    "if [[ -f \"$MONITORCHECK\" ]]; then",
    "",
    " echo \"Tomcat port monitoring is active.\"",
    "",
    " # Check for Tomcat to be running on port 8080",
    " PORTCHECK=$(/bin/netstat -tln | awk '/:8080/ {print $4}' | sed \"s/://g\")",
    " ",
    " if [[ \"$PORTCHECK\" = \"8080\" ]]; then",
    " echo \"Tomcat service is running on port $PORTCHECK\"",
    " else",
    " echo \"Tomcat service is not responding on port 8080\"",
    " echo \"Restarting Tomcat service\"",
    "",
    " # Starts the JAMF Tomcat processes",
    "",
    " service jamf.tomcat8 restart",
    " fi",
    "else",
    " echo \"Tomcat port monitoring is offline.\"",
    "fi",
    "",
    "exit $ERROR"
    ]
    }
    ]
    }
    }
    }


    View Slide

58. Systems Manager
    https://github.com/rtrouton/ec2_systems_manager


    View Slide

59. Amazon

    S3
    Jamf Pro
    Cloud
    Distribution
    Point
    (Internet
    Accessible)
    Amazon
    EC2
    Jamf Pro cluster nodes
    Elastic Load
    Balancing
    Application Load
    Balancer
    (Internet Accessible;
    TLS Termination)
    (admin console disabled,
    not Internet accessible)
    security group
    Internet
    HTTPS
    HTTPS
    HTTPS
    SAP-managed
    Mac
    AWS Virtual
    Private Cloud
    Client Management


    View Slide

60. View Slide

61. Active
    Directory Jamf Infrastructure
    Manager (JIM)
    LDAPS
    Jamf Pro
    Service
    JIM enrollment and check-ins
    DMZ
    Encrypted
    LDAP queries to AD
    AWS Virtual
    Private Cloud
    Active Directory Access
    https://derflounder.wordpress.com/category/jamf-infrastructure-manager/


    View Slide

62. Amazon

    RDS
    Jamf Pro MySQL
    database
    Amazon
    EC2
    Jamf Pro cluster
    nodes
    (not Internet
    accessible)
    security group
    security group
    (Not Internet accessible)
    Virtual Private
    Cloud
    MySQL
    Database Hosting


    View Slide

63. Amazon

    Elasticache
    Amazon
    EC2
    Jamf Pro cluster
    nodes
    (not Internet
    accessible)
    security group
    security group
    Virtual Private
    Cloud
    Memcache
    Memcache
    (not Internet
    accessible)
    Memcache Hosting


    View Slide

64. Moving Jamf Pro to AWS


    View Slide

65. View Slide

66. The Road To High Sierra
    "The shipping OS is
    our supported OS"
    •Once High Sierra launched, it would be our
    only supported operating system.
    •Users requesting assistance, but not yet
    running High Sierra, would need to upgrade to
    High Sierra before the helpdesk could assist.


    View Slide

67. The Road To High Sierra


    View Slide

68. The Road To High Sierra
    Admin user vs.
    standard user
    Standard
    User
    +
    ?


    View Slide

69. The Road To High Sierra
    Refresh Assistant
    +
    Recovery


    View Slide

70. View Slide

71. View Slide

72. View Slide

73. View Slide

74. View Slide

75. View Slide

76. View Slide

77. View Slide

78. View Slide

79. Apple Pies


    View Slide

80. View Slide

81. View Slide

82. View Slide

83. View Slide

84. View Slide

85. View Slide

86. View Slide

87. @HanaFiori


    View Slide

88. Apple Pies


    View Slide

89. View Slide

90. View Slide

91. Secure Token


    View Slide

92. View Slide

93. Local user accounts
    • Created by Setup Assistant or Users &
    Groups.
    One user account per Mac
    • Primary user of the Mac
    • No IT user account
    =
    Secure Token enabled automatically


    View Slide

94. View Slide

95. View Slide

96. Assistant
    +
    Recovery


    View Slide

97. View Slide

98. SAP Mac applications must fulfill the following requirements to be
    added to the monthly Release Train process:
    • Must be 64-bit and sandboxed
    • Must be digitally signed with a valid Apple Developer Certificate
    • Must be packaged with Apple’s technology (e.g. Installer or drag-n-drop)
    • Must be self-contained, single application bundle and cannot install code or
    resources in shared locations not approved by Apple (shared Containers for
    sandboxed Apps is OK for example)
    • Must not install kernel extensions! (kexts)
    • Must not spawn additional processes that continue to run after the user has quit the
    App without the user’s consent
    • Must not use deprecated or optionally installed technologies (Java, Flash, etc.)
    • Must not add to Login or startup without the user’s consent
    • Must not request elevation to root privileges or use setuid attributes (e.g. it must run
    within the user’s space as standard user)
    • Must only use public API’s for OS X and approved API’s for accessing or modifying
    user data for other Apps
    • Must comply with macOS File System
    • Must not modify, change or disable the build in Quarantine, firewall or Gatekeeper


    View Slide

99. View Slide

100. View Slide

101. View Slide

102. SAP Mac applications must fulfill the following requirements to be
     added to the monthly Release Train process:
     • Must be 64-bit and sandboxed
     • Must be digitally signed with a valid Apple Developer Certificate
     • Must be packaged with Apple’s technology (e.g. Installer or drag-n-drop)
     • Must be self-contained, single application bundle and cannot install code or
     resources in shared locations not approved by Apple (shared Containers for
     sandboxed Apps is OK for example)
     • Must not install kernel extensions! (kexts)
     • Must not spawn additional processes that continue to run after the user has quit the
     App without the user’s consent
     • Must not use deprecated or optionally installed technologies (Java, Flash, etc.)
     • Must not add to Login or startup without the user’s consent
     • Must not request elevation to root privileges or use setuid attributes (e.g. it must run
     within the user’s space as standard user)
     • Must only use public API’s for OS X and approved API’s for accessing or modifying
     user data for other Apps
     • Must comply with macOS File System
     • Must not modify, change or disable the build in Quarantine, firewall or Gatekeeper


     View Slide

103. View Slide

104. View Slide

105. View Slide

106. The Road To Mojave
     Assistant
     +
     Recovery Apple@SAP


     View Slide

107. View Slide

108. View Slide

109. Apple CoE @
     Mac CoE @


     View Slide

110. View Slide

111. View Slide

112. View Slide

113. Downloads
     PDF available from the following link:
     http://tinyurl.com/JNUC2018SAPPDF
     Keynote slides available from the
     following link:
     http://tinyurl.com/JNUC2018SAPKeynote


     View Slide

114. © JAMF Software, LL
     THANK YOU!


     View Slide
