  1. Android  Services
    José  Juan  Sánchez  Hernández
    @josejuansanchez

    View Slide

  2. Ac7vi7es
    Ac7vi7es
    Ac7vi7es
    Ac7vi7es
    Ac7vi7es
    Services
    Ac7vi7es
    Ac7vi7es
    Receivers
    Ac7vi7es
    Ac7vi7es
    Providers
    Dalvik  VM
    Libs
    DB
    Files
    res
    Android  Applica7on  Anatomy
    Process
    Applica7on  /  APK  Package
    Applica7on  =  Set  of  Android  Components

    •  It  contains  any  number  of  Ac#vi#es,
    Services,  Receivers  and  Providers.

    •  It  has  its  own  file  system,  database,
    place  to  store  na7ve  libraries.

    •  No  other  app  can  access  any  of  its
    data  without  prior  permission.
    2/36

    View Slide

  3. Process
    Applica7on  /  APK  Package
    Run7me  Overview
    Image:  Marko  Gargenta
    Android  Internals  Overview
    3/36

    View Slide

  4. Process
    Applica7on  /  APK  Package
    Zygote
    4/36

    View Slide

  5. Process
    Applica7on  /  APK  Package
    Process  Basics
    •  Android  Process  ==  Linux  Process.
    •  By  default,  1  Process  per  APK.
    •  By  default,  1  Thread  per  Process.

    Threads  on  Android
    •  By  default,  each  process  has  1  thread.
    •  Mosts  components  share  the  single  thread.
    Threads  and  Loopers
    •  Each  thread  has  a  Looper  to  handle  a  message  queue.
    •  Events  from  all  components  are  interleaved  into  Looper.
               E.g.  View  UI  events,  IntentReceivers  firing,  etc.
    •  Loopers  cannot  accommodate  mul7-­‐threaded  access.
             They  are  designed  to  play  nicely  with  MessageHandlers.
    Processes  and  Threads
    5/36

    View Slide

  6. Ac7vity
    Service
    Main  Thread







    Looper
    Message
    Queue
    System
    Events
    UI
    Events
    Process
    Applica7on  /  APK  Package
    Processes  and  Threads
    6/36

    View Slide

  7. Services
    7/36
    What  is  a  Service?
    •  Is  a  component  that  can  perform  long-­‐running  opera7ons  in  the  background.
    •  They  can  be  started  and  stopped.
    •  Services  doesn't  have  UI  and  does  not  provide  direct  access  to  the  UI.

    What  a  Service  is  NOT?
    •  A  Service  is  not  a  separate  process.
    •  A  Service  is  not  a  thread.
    Examples
    •  Playing  music  even  if  the  player  ac7vity  gets  garbage-­‐collected.
    •  Polling  the  Internet  for  RSS/Atom  feed  updates.
    •  Performing  periodic  work  without  user  interven7on  (scheduled  tasks).
    •  An  applica7on  that  con7nually  logs  the  geographical  coordinates  of  the  device.


    View Slide

  8. Process
    Applica7on  /  APK  Package
    Started
    A  service  is  “started”  when  an
    applica7on  component  starts  it  by
    calling  startService().  Oien
    performs  a  single  opera7on  &  might
    not  return  a  result  to  the  caller
    directly.

    Bound
    A  service  is  “bound”  when  an
    applica7on  component  binds  to  it  by
    calling  bindService().  Provides  a
    client-­‐  server  interface  that  allows  for
    a  conversa7on  with  the  Service.
    Types  of  Services
    Android  Developers.  API  Guides
    hkps://developer.android.com/guide/components/services.html
    8/36

    View Slide

  9. Applica7on  /  APK  Package
    Started  Services
    There  are  two  classes  you  can  extend  to  create  a  started  service:
    Service  and  IntentService

    9/36

    View Slide

  10. Ac7vity
    Service
    Main  Thread







    Looper
    Message
    Queue
    System
    Events
    UI
    Events
    Process
    Applica7on  /  APK  Package
    Example:  LocalService  /  1  Process
    10/36
    Bad  Prac7ce!  May  block  the  Main  Thread  L

    View Slide

  11. Example:  LocalService  /  1  Process
    11/36

    View Slide

  12. Example:  LocalService  /  1  Process
    12/36

    View Slide

  13. The  service  should  remain  stopped  un7l
    explicitly  started  by  applica7on  code
    13/36

    View Slide

  14. Example:  LocalService  /  1  Process
    14/36
    START_NOT_STICKY
    If  the  system  kills  the  service,  do  not  recreate  the  service,  unless  there  are  pending  intents
    to  deliver.  This  is  the  safest  op7on  to  avoid  running  your  service  when  not  necessary  and
    when  your  applica7on  can  simply  restart  any  unfinished  jobs.

    START_STICKY
    If  the  system  kills  the  service,  recreate  the  service  and  call  onStartCommand(),  but  do
    not  redeliver  the  last  intent.  Instead,  the  system  calls  onStartCommand()  with  a  null
    intent,  unless  there  were  pending  intents  to  start  the  service,  in  which  case,  those  intents
    are  delivered.  This  is  suitable  for  media  players  (or  similar  services)  that  are  not  execu7ng
    commands,  but  running  indefinitely  and  wai7ng  for  a  job.

    START_REDELIVER_INTENT
    If  the  system  kills  the  service,  recreate  the  service  and  call  onStartCommand()  with  the
    last  intent  that  was  delivered  to  the  service.  Any  pending  intents  are  delivered  in  turn.  This
    is  suitable  for  services  that  are  ac7vely  performing  a  job  that  should  be  immediately
    resumed,  such  as  downloading  a  file.

    View Slide

  15. Don’t  forget  it!!
    15/36

    View Slide

  16. Good  Prac7ce!  J
    16/36
    Leaving  a  service  running  when  it’s  not  needed  is
    one  of  the  worst  memory-­‐management  mistakes
    an  Android  app  can  make.

    So  don’t  be  greedy  by  keeping  a  service  for  your  app  running.

    Not  only  will  it  increase  the  risk  of  your  app  performing  poorly  due  to  RAM
    constraints,  but  users  will  discover  such  misbehaving  apps  and  uninstall  them.

    Managing  Your  App's  Memory
    hkp://developer.android.com/training/ar7cles/memory.html
    Use  services  sparingly

    View Slide

  17. Example:  LocalService  /  1  Process
    17/36

    View Slide

  18. 18/36

    View Slide

  19. Ac7vity
    Main
    Thread







    Looper
    Message
    Queue
    Syst.
    Events
    UI
    Events
    Service
    Main
    Thread







    Looper
    Message
    Queue
    Syst.
    Events
    Process   Process
    Applica7on  /  APK  Package
    Example:  RemoteService  /  2  Processes
    19/36
    “Remote”  in  this  example  means  that  the  Service  is  hosted  in  another  process.

    View Slide

  20. Example:  RemoteService  /  2  Processes
    20/36

    View Slide

  21. Example:  RemoteService  /  2  Processes
    21/36

    View Slide

  22. Applica7on  /  APK  Package
    22/36
    Use  mul7ple  processes
    An  advanced  technique  that  may  help  you  manage  your  app's  memory  is
    dividing  components  of  your  app  into  mul7ple  processes.

    An  example  of  when  mul7ple  processes  may  be  appropriate  is  when  building
    a  music  player  that  plays  music  from  a  service  for  long  period  of  7me.
    Managing  Your  App's  Memory
    hkp://developer.android.com/training/ar7cles/memory.html
    Good  Prac7ce!  J

    View Slide

  23. Ac7vity
    Main
    Thread







    Looper
    Message
    Queue
    Syst.
    Events
    UI
    Events
    Service
    Handler
    Thread







    Looper
    Message
    Queue
    Process
    Applica7on  /  APK  Package
    Example:  Service  +  HandlerThread  /  1  Process
    23/36
    HandlerThread  inherits  from  Thread  and  encapsulates  a  Looper-­‐object.
    Is  a  Thread  with  a  message  queue  and  processing  loop.

    View Slide

  24. Don’t  forget  it!!
    24/36
    Example:  Service  +  HandlerThread  /  1  Process

    View Slide

  25. 25/36
    Example:  Service  +  HandlerThread  /  1  Process

    View Slide

  26. Example:  Service  +  HandlerThread  /  1  Process
    26/36

    View Slide

  27. 27/36

    View Slide

  28. Ac7vity
    Main
    Thread







    Looper
    Message
    Queue
    Syst.
    Events
    UI
    Events
    IntentService
    Worker
    Thread







    Looper
    Message
    Queue
    Process
    Applica7on  /  APK  Package
    Example:  IntentService  /  1  Process
    36/36
    This  is  the  best  op#on  if  you  don't  require  that  your  service
    handle  mul7ple  requests  simultaneously

    View Slide

  29. Example.  IntentService  /  1  Process
    29/36
    You  never  have  to  call  stopSelf().
    Stops  itself  when  it  runs  out  of  work.

    View Slide

  30. Example.  IntentService  /  1  Process
    30/36

    View Slide

  31. 1)  When  to  use?
    •  The  Service  can  be  used  in  tasks  with  no  UI,  but  shouldn't  be  too  long.  If  you  need  to
    perform  long  tasks,  you  must  use  threads  within  Service  or  use  another  process.
    •  The  IntentService  can  be  used  in  long  tasks  usually  with  no  communica7on  to  Main
    Thread.  This  is  the  best  op7on  if  you  don't  require  that  your  service  handle  mul7ple
    requests  simultaneously.
    2)  Triggered  From
    •  The  Service  may  be  triggered  from  any  thread.
    •  The  IntentService  must  be  triggered  from  Main  Thread.

    3)  Runs  On
    •  The  Service  runs  in  background  but  it  runs  on  the  Main  Thread  of  the  applica7on.
    •  The  IntentService  runs  on  a  separate  Worker  Thread.

    4)  Limita#ons  /  Drawbacks
    •  The  Service  may  block  the  Main  Thread  of  the  applica7on.
    •  The  IntentService  cannot  run  tasks  in  parallel.

    Service  vs  IntentService
    31/36

    View Slide

  32. There  are  several  ways  to  get  results  from  a  Service  back  to  an  invoking  Ac7vity:
    •  Broadcast  Intents
               This  requires  having  the  Ac7vity  register  a  BroadcastReceiver.
    •  Messenger  object
               This  object  can  send  messages  to  an  Ac7vity’s  Handler.
    •  Pending  Intent
               Using  a  Pending  Intent  to  trigger  a  call  to  Ac7vity’s  onActivityResult()!


    Another  approach  is  to  let  the  user  know  directly  about  the  work  that  was
    completed.  To  do  that,  a  Service  can  raise  a  No#fica#on.
    Communica7ng  from  Services
    32/36

    View Slide

  33. Process
    Applica7on  /  APK  Package
    33/36
    Bound  Services

    View Slide

  34. Ac7vity





    Main
    Thread







    Looper
    Message
    Queue
    RemoteService
    Process   Process
    Applica7on  A  /  APK  Package
    Example:  Remote  Bound  Services
    34/36
    RemoteBinder



    getRandomNumber()
    Applica7on  B  /  APK  Package
    mBound
    1.  Call  method
    2.  Return  results
    to  caller
    Binder  IPC
    Mechanism
    We  need  interprocess  communica7on  (IPC)

    View Slide

  35. Ac7vity





    Main
    Thread







    Looper
    Message
    Queue
    RemoteService
    Process
    Applica7on  A  /  APK  Package
    Example:  Locally  Bound  Services
    35/36
    RemoteBinder



    getRandomNumber()
    mBound
    1.  Call  method
    2.  Return  results
    to  caller
     Because  the  service  runs  in  the  same  process  as  its  clients,
    we  don't  need  to  deal  with  IPC

    View Slide

  36. José  Juan  Sánchez  Hernández
    @josejuansanchez
