Evaluation of Container Virtualized MEGADOCK System in Distributed Computing Environment

SIGBIO49 @ Japan Advanced Institute of Science and Technology

We evaluate the performance of MEGADOCK system using container virtualization technology in distributed computing environment on cloud.
MEGADOCK is a Protein-Protein-Interaction Prediction System for heterogeneous supercomputers.
We choosed Docker as a container virtualization technology for Linux container implementation and evaluated parallel execution performance while increasing the number of virtual machines.

Transcript

1. Evaluation of Container Virtualized
   MEGADOCK System
   in Distributed Computing Environment
   March 23th, 2017
   SIG BIO 49@Japan Advanced Institute of Science and Technology
   Kento Aoyama1,2, Yuki Yamamoto1,2, Masahito Ohue1,3, Yutaka Akiyama1,2,3
   1) Department of Computer Science, School of Computing
   Tokyo Institute of Technology
   2) Education Academy of Computational Life Sciences (ACLS)
   Tokyo Institute of Technology
   3) Advanced Computational Drug Discovery Unit, Institute of Innovative Research
   Tokyo Institute of Technology


   View Slide

2. “Docker” 2
   https://www.docker.com/what-container
   No. of pulled containers from DockerHub


   View Slide

3. Docker and Bioinformatics 3
   A. Paolo, D. Tommaso, A. B. Ramirez, E. Palumbo, C. Notredame, and D.
   Gruber, “Benchmark Report : Univa Grid Engine , Nextflow , and Docker
   for running Genomic Analysis Workflows.”
   Docker Integration Benchmark Report
   @Centre for Genomic Regulation
   (Barcelona, Spain)
   • Univa Grid Engine (Job Scheduler)
   • Nextflow (Workflow manager)
   • Docker (Linux Container)
   • Reproducibility
   • Portability


   View Slide

4. To develop the
   Container-Native HPC Bioinformatics Application
   Using Linux Container
   which has …
   • Low Dependency on Environment
   • High-Performance
   • Parallel execution performance
   • Overhead of virtualization
   • Dynamically Scaling
   Research Purpose 4


   View Slide

5. • To evaluate the
   Performance of Docker Container-Virtualization
   in Bioinformatics Application
   Target Application
   • MEGADOCK[1]
   • FFT-grid-based Protein-Protein Docking software
   • Multi-threading, Multi-node, Multi-GPU (OpenMP, MPI, GPU)
   • Extremely compute intensive workloads
   Today’s Report 5
   [1] Masahito Ohue, et al. “MEGADOCK 4.0: an ultra-high-performance protein-protein docking
   software for heterogeneous supercomputers”, Bioinformatics, 30(22): 3281-3283, 2014.


   View Slide

6. Background
   Linux Container
   Docker
   Container & Bioinformatics
   6


   View Slide

7. Kernel-Shared Virtualization
   • Lightweight : small size, fast deploy, easy sharing
   • Performance : few virtualization overhead, faster than VM
   Linux Container 7
   Hardware
   Linux Kernel
   Container
   App
   Bins/Libs
   Container
   App
   Bins/Libs
   Hardware
   Virtual
   Machine
   App
   Guest
   OS
   Bins/Libs
   Virtual
   Machine
   App
   Guest
   OS
   Bins/Libs
   Hypervisor
   Virtual Machines Containers


   View Slide

8. Linux Container
   • virtualizes the host resource as containers
   • Filesystem, hostname, IPC, PID, Network, User, etc.
   • can be used like Virtual Machines
   Linux Kernel Features
   • Containers are sharing same host kernel
   • namespace[1], chroot, cgroup, SELinux, etc.
   Container-based Virtualization 8
   [1] E. W. Biederman. “Multiple instances of the global Linux namespaces.”,
   In Proceedings of the 2006 Ottawa Linux Symposium, 2006.
   Machine
   Linux Kernel Space
   Container
   Process
   Process
   Container
   Process
   Process


   View Slide

9. Linux Container – Performance [1] 9
   [1] W. Felter, A. Ferreira, R. Rajamony, and J. Rubio, “An updated performance comparison of virtual
   machines and Linux containers,” IEEE International Symposium on Performance Analysis of Systems and
   Software, pp.171-172, 2015. (IBM Research Report, RC25482 (AUS1407-001), 2014.)
   0.96 1.00 0.98
   0.78
   0.83
   0.99
   0.82
   0.98
   0.00
   0.20
   0.40
   0.60
   0.80
   1.00
   PXZ [MB/s] Linpack [GFLOPS] Random Access [GUPS]
   Performance Ratio
   [based Native]
   Native Docker KVM KVM-tuned


   View Slide

10. Docker [1]
    • Most popular Linux Container management platform
    • Many useful components and services
    Linux Container Management Tools 10
    [1] Solomon Hykes and others. “What is Docker?” - https://www.docker.com/what-docker
    [2] W. Bhimji, S. Canon, D. Jacobsen, L. Gerhardt, M. Mustafa, and J. Porter, “Shifter : Containers for
    HPC,” Cray User Group, pp. 1–12, 2016.
    [3] “Singularity” - http://singularity.lbl.gov/
    [1]
    [2] [3]


    View Slide

11. Easy container sharing – Docker Hub 11
    Portability & Reproducibility
    • Easy to share the application environment via Docker Hub
    • Containers can be executed on other host machine
    Ubuntu
    Docker Engine
    Container
    App
    Bins/Libs
    App
    Bins/Libs
    Docker Hub
    App
    Bins/Libs
    Push Pull
    Dockerfile
    apt-get install …
    wget …
    …
    make
    CentOS
    Docker Engine
    Container
    App
    Bins/Libs
    App
    Bins/Libs
    Generate
    Share


    View Slide

12. AUFS (Advanced multi layered unification filesystem) [1]
    • Docker default filesystem as AUFS
    • Layers can be reused in other container image
    • AUFS helps software Reproducibility
    Docker - Filesystem 12
    [1] Advanced multi layered unification filesystem. http://aufs.sourceforge.net, 2014.
    Docker Container (image)
    f49eec89601e 129.5 MB ubuntu:16.04 (base image)
    366a03547595 39.85 MB
    ef122501292c 133.6 MB
    e50c89716342 660.4 KB
    tag: beta
    tag: version-1.0
    tag: version-1.0.2
    tag: version-1.2
    5aec9aa5462c 24.17 MB
    tag: latest
    0d3cccd04bdb 6.07 MB


    View Slide

13. Why in the field of Bioinformatics?
    • Types of Applications
    • Data Analysis, Machine Learning
    • MD Simulation, Docking calc. , etc.
    • Data-centric workload
    • Compute : Large
    • Data I/O : Case by case
    • Communication : Small
    • Container performs well on compute-Intensive workload[1]
    For Bioinformatics Apps : 1 13
    [1] W. Felter, et al. “An updated performance comparison of virtual
    machines and Linux containers,” IEEE International Symposium on
    Performance Analysis of Systems and Software, pp.171-172, 2015.


    View Slide

14. Reproducibility
    • Different version of library can make different result
    • e.g.) Genomic analysis pipeline [Paolo, 2016]
    Container A’
    Container A
    Container B
    Container A
    For Bioinformatics Apps : 2 14
    Library A
    Application A Application B
    version >= 1.2 version < 1.1
    Application A
    Library version 1.3
    Result A’
    Application A
    Library version 1.2
    Result A
    conflict
    different
    result
    Dependency
    Isolation
    Application
    Reproducibility
    Dependency conflict
    • Different application can requires different version of same library


    View Slide

15. Performance
    • Few performance overhead
    Reproducibility
    • Dependency Isolation from other applications/libraries
    Portability, Generality
    • Sharing/Porting to other environment
    Features for Bioinformatics Apps 15
    Features Native VM Container
    Performance
    Scalability
    Great Bad Good
    Reproducibility Bad Good Great
    Portability
    Generality
    Bad Great Great


    View Slide

16. Proposed Method
    16


    View Slide

17. MEGADOCK 17
    Masahito Ohue, et al. “MEGADOCK 4.0: an ultra-high-
    performance protein-protein docking software for
    heterogeneous supercomputers”, Bioinformatics,
    30(22): 3281-3283, 2014.
    High-performance protein-protein interaction predictions
    • FFT-grid based docking software
    • Extremely compute-intensive
    • OpenMP/MPI/GPU support
    • Great HPC Performance


    View Slide

18. Container-based Application Distribution 18
    Resource
    Resource
    MEGA
    DOCK
    Resource
    MEGA
    DOCK
    Add/Remove
    Container
    Resource
    MEGA
    DOCK
    Add/Remove
    Application
    Layer
    Compute
    Resource
    Layer
    • All application dependencies exist in the Container
    • Easy-to-test application
    • Easy-to-scale size of resources
    Test Environment Production Environment


    View Slide

19. Experiments
    19


    View Slide

20. Experiment I
    Evaluate container virtualization overhead on Physical Machine
    • Physical Machine (single-node) + Docker
    • Physical Machine (single-node, GPU) + NVIDIA-Docker
    Experiment II
    Evaluate container virtualization overhead on Cloud Environment
    • Virtual Machines (multi-node) + Docker
    • Virtual Machines (multi-node, GPU) + NVIDIA-Docker
    Experiments 20


    View Slide

21. Measurement
    • megadock-gpu exec. time
    • time command (6 times, median)
    Dataset
    • 100 pair-pdb (KEGG pathway)
    Options (OpenMP, OpenMPI)
    • MPI : 12 threads / 4 MPI process / 1 node
    • GPU : 1 GPU / 1 process / 1 node
    Overview of Experiment I 21
    Physical Machine
    MPI
    MPI
    MPI
    MPI
    Physical Machine
    Docker
    MPI
    MPI
    MPI
    MPI
    Physical Machine
    GPU
    MEGADOCK
    GPU
    Physical Machine
    NVIDIA Docker
    MEGADOCK
    GPU
    GPU
    (b)
    (a)
    (d)
    (c)
    Test Case Native Docker
    CPU (MPI) (a) (b)
    GPU (c) (d)


    View Slide

22. Hardware/Software Specification 22
    Software Env. Physical Machine Docker NVIDIA Docker (GPU)
    OS (image) CentOS 7.2.1511 ubuntu:14.04 nvidia/cuda8.0-devel
    Linux Kernel 3.10.0 3.10.0 3.10.0
    GCC 4.8.5 4.8.4 4.8.4
    FFTW 3.3.5 3.3.5 3.3.5
    OpenMPI 1.10.0 1.6.5 N/A
    Docker Engine 1.12.3 N/A N/A
    NVCC 8.0.44 N/A 8.0.44
    NVIDIA Docker 1.0.0 rc.3 N/A N/A
    NVIDIA Driver 367.48 N/A 367.48
    CPU Intel Xeon E5-1630, 3.7 [GHz] ×8 [core]
    Memory 32 [GB]
    Local SSD 128 [GB]
    GPU NVIDIA Tesla K40


    View Slide

23. Execution time 23
    7353.80
    1646.09
    7850.57
    1638.05
    0
    1500
    3000
    4500
    6000
    7500
    9000
    CPU (MPI) GPU
    Time [sec]
    Native Docker
    +6.32 % slower


    View Slide

24. Profile Result (CPU time) 24
    Process native [sec] docker [sec] diff Ratio (all)
    FFT3D 7.40E+04 7.63E+04 +3.01% 76.84%
    MPIDP-Master 8010.98 8325.9 +3.78% 8.38%
    Create Voxel 3743.7 3993.29 +6.25% 4.02%
    FFT Convolution 3551.08 3576.43 +0.71% 3.60%
    Score Sort 2462.61 2459.7 -0.12% 2.48%
    Output Detail 2139.94 2225.96 +3.86% 2.24%
    Ligand Preparation 1035.51 1849.11 +44.00% 1.86%
    MPI_Barrier 236.95 231.05 -2.55% 0.23%
    MPI_Init 0.94 4.54 79.30% 0.00%
    … … … … …


    View Slide

25. (a) MEGADOCK-Azure[2]
    Measurement
    • megadock-dp exec. time
    • time command (3 times, median)
    Dataset
    • ZDOCK benchmark 1.0 [1]
    (59 * 59 = 3481 pairs)
    Options (OpenMP, OpenMPI)
    • MPI : 12 threads / 4 MPI process / 1 node
    All file input/output in Local SSD
    Overview of Experiment II-(a) 25
    Virtual
    Machine
    MPI
    MPI
    MPI
    MPI
    VM
    MPI
    MPI
    MPI
    MPI
    VM
    MPI
    MPI
    MPI
    MPI
    VM
    MPI
    MPI
    MPI
    MPI
    VM
    MPI
    MPI
    MPI
    MPI
    VM
    MPI
    MPI
    MPI
    MPI
    VM
    MPI
    MPI
    MPI
    MPI
    Master Process
    Worker Process
    (Other)
    [1] R. Chen, et al. “A protein-protein docking benchmark,” Proteins: Structure,
    Function and Genetics, vol. 52, no. 1, pp. 88-91, 2003.
    [2] Masahito Ohue, et al. ”MEGADOCK-Azure: High-performance protein-protein
    interaction prediction system on Microsoft Azure HPC”, IIBMP2016.


    View Slide

26. (b) MEGADOCK + Docker on Microsoft Azure
    Measurement
    • megadock-dp exec. time
    • time command (3 times, median)
    Dataset
    • ZDOCK benchmark 1.0
    (59 * 59 = 3481 pairs)
    Options (OpenMP, OpenMPI)
    • MPI : 12 threads / 4 MPI process / 1 node
    All file input/output in Local SSD
    Docker Swarm
    • All Containers in 1 overlay network
    Overview of Experiment II-(b) 26
    Virtual Machine
    Docker
    MPI
    MPI
    MPI
    MPI
    Docker
    MPI
    MPI
    MPI
    MPI
    Docker
    MPI
    MPI
    MPI
    MPI
    Docker
    MPI
    MPI
    MPI
    MPI
    Docker
    MPI
    MPI
    MPI
    MPI
    Docker
    MPI
    MPI
    MPI
    MPI
    Docker
    MPI
    MPI
    MPI
    MPI
    Docker Swarm
    (Docker Network)
    Master Process
    Worker Process
    (Other)
    [1] R. Chen, J. Mintseris, J. Janin, and Z. Weng, “A protein-protein docking benchmark,”
    Proteins: Structure, Function and Genetics, vol. 52, no. 1, pp. 88-91, 2003.


    View Slide

27. VM Instance/Software Specification 27
    Software Env. Virtual Machine Docker
    OS (image) SUSE Linux Enterprise Server 12 ubuntu:14.04
    Linux Kernel 3.12.43 3.12.43
    GCC 4.8.3 4.8.4
    FFTW 3.3.4 3.3.5
    OpenMPI 1.10.2 1.6.5
    Docker Engine 1.12.6 N/A
    VM Instance Standard_D14_v2
    CPU Intel Xeon E5-2673, 2.40 [GHz] × 16 [core]
    Memory 112 [GB]
    Local SSD 800 [GB]


    View Slide

28. Execution time 28
    145,534
    25,515
    13,132
    6,006
    4,098
    117,219
    25,145
    12,331
    6,344
    3,971
    0
    25,000
    50,000
    75,000
    100,000
    125,000
    150,000
    1 5 10 20 30
    Time [sec]
    # of VMs
    VM Docker on VM
    May be a measurement mistake


    View Slide

29. Scalability (Strong Scaling, based VM=1) 29
    0
    5
    10
    15
    20
    25
    30
    35
    40
    45
    0 100 200 300 400 500
    Speed-up
    # of worker cores
    Ideal VM Docker on VM
    VM=5
    VM=1
    VM=10
    VM=20
    VM=30
    comparable scalability


    View Slide

30. Experiment I
    • MEGADOCK + Docker on Physical Machine
    showed 6.32% lower performance.
    • Docker can cause 0-4% compute-performance down[1]
    • Communications via Docker NAT (Network Address Translation)
    • MEGADOCK (GPU) + NVIDIA-Docker on Physical Machine
    showed comparable performance to native.
    • GPU calc. is independent from container virtualization
    • Container virtualization has few overhead on memory bandwidth
    Experiment II
    • MEGADOCK + Docker on Microsoft Azure
    performed comparable scalability.
    • Container virtualization overhead is smaller than other cloud environment factor
    Result & Discussion 30
    [1] W. Felter, A. Ferreira, R. Rajamony, and J. Rubio, “An updated performance comparison of virtual
    machines and Linux containers”, IEEE International Symposium on Performance Analysis of Systems
    and Software, pp.171-172, 2015. (IBM Research Report, RC25482 (AUS1407-001), 2014.)


    View Slide

31. • Performance overhead of
    Docker container-virtualization is small.
    • suitable for GPU-accelerated-App and Cloud Environment
    • Container-Virtualization can isolate
    application environment from host environment.
    • same container image can be used on various machines
    • Physical machine on local environment
    • Virtual machine on cloud environment
    • Docker is useful for computational research work
    Conclusion 31


    View Slide

32. Multi-Node & Multi-GPU Evaluation on Cloud
    • NVIDIA-Docker is not available on Docker Swarm mode
    • Kubernetes[1] officially support 1GPU/1node
    • (experimental-feature: multi-GPU support)
    Container-based Task Distribution
    • Web-Service-Application like container-based distribution
    • easy to scale computing resource
    • easy to extends multiple task (e.g. GHOST-MP, MEGADOCK)
    Future Work 32
    [1] B. Burns, B. Grant, D. Oppenheimer, E. Brewer, and J. Wilkes, “Borg, Omega, and
    Kubernetes,” acmqueue, vol. 14, no. 1, p. 24, 2016.


    View Slide
