An Introduction to Graphene and Relay

Workshop slides for an introduction to Grahene and Relay. Associated code base can be found at github.com/mjtamlyn/graphene-tutorial/. I would like to see this material improved over time and turn into a full set of documentation for graphene/graphene-django.

Transcript

1. An introduction to
   Graphene and Relay


   View Slide

2. Part 0: Introduction


   View Slide

3. Who am I?
   • Marc Tamlyn
   • Django Core Developer
   • Graphene contributor
   • Occasional Javascript developer
   • Work at Photocrowd


   View Slide

4. Workshop structure
   • Split into four main parts
   • GraphQL
   • Graphene
   • React
   • Relay


   View Slide

5. What is all this?
   • GraphQL is a new API structure created by Facebook
   • Graphene is a declarative python library for creating
   GraphQL APIs by the python-graphql organisation
   • It builds on top of graphql-core, a python version of
   the "official" graphql-js library
   • React is a declarative, component based Javascript
   rendering engine created by Facebook
   • Relay is a React-drive framework for consuming a
   GraphQL API and building a highly flexible and reusable
   component based application architecture


   View Slide

6. What's the point?
   • Allow your front ends to declare the shape of the data
   they require
   • Move n+1 problems to the API server instead of the
   front end
   • Components declare their own requirements and can
   be composed, allowing changes deep in the system to
   work everywhere
   • Great for applications where the same objects are
   represented and connected in many different ways


   View Slide

7. A word on investment
   • Personally, I find these concepts are relatively "hard"
   compared to understanding a REST API
   • It takes a higher investment of effort to understand all
   the pieces and how they all fit together than some other
   architectures
   • It requires more work and rigour to code using these
   libraries
   • Personally, I think the effort pays off
   • Give it a week!


   View Slide

8. Data setup
   • A little (fictional!) welsh village
   • 3 streets, 10 houses
   • People live in the houses and are related to each other
   • People can get married, have children and move house
   • Application should allow you to explore the village and
   find out about the people who live there, and update the
   data as they move, marry, have children and so on


   View Slide

9. Part 1: GraphQL


   View Slide

10. GraphQL
    • New query language
    • Strongly typed
    • Returns JSON


    View Slide

11. Work along with me
    https://graphene-tutorial.herokuapp.com/plain/
    https://github.com/mjtamlyn/graphene-tutorial/


    View Slide

12. Type system
    • Everything consists of fields on an object
    • Useful to know what fields are available, and what type
    of data to expect
    • Allows static validation of queries


    View Slide

13. Scalars
    • Int
    • Float
    • String
    • Boolean
    • ID
    • Can define your own - needs to be JSON serialisable


    View Slide

14. Lists and nulls
    • List of any other type
    • Fields are nullable unless specified as non-null


    View Slide

15. Enumerations types
    • First class support for enums
    • Collection of unique string names
    • Allows query-time validation of arguments


    View Slide

16. Type system
    • Object type
    • Consists of fields
    • Each field returns data of a specified type
    • Data can be any type, including other object types
    • Each field may take arguments
    • Each argument also has a fixed type, and may or
    may not be nullable


    View Slide

17. Interfaces and Unions
    • Object types can be combined in a union
    • They can implement one or more interfaces, keeping a
    common set of behaviour between multiple types


    View Slide

18. Schema
    • Schema is an ObjectType
    • Must have a query field
    • May have a mutation field


    View Slide

19. Queries
    • Written in GraphQL query language
    • Returns JSON


    View Slide

20. A simple query
    query {
    streets {
    name
    }
    }
    {"data": {
    "streets": [
    {"name": "Afon Stryd"},
    {"name": "Glyn Stryd"},
    {"name": "Ysgol Stryd"}
    ]
    }}


    View Slide

21. Nesting
    query {
    streets {
    name
    houses {
    number
    }
    }
    }
    {"data": {
    "streets": [
    {"name": "Afon Stryd",
    "houses": [
    {"number": 1},
    {"number": 2},
    {"number": 3},
    ]},
    …


    View Slide

22. Multiple queries
    query {
    streets {
    name
    }
    houses {
    name
    }
    }
    {"data": {
    "streets": [
    {"name": "Afon Stryd"
    …
    ]
    "houses": [
    {"name": "1 Afon
    Stryd"}
    …


    View Slide

23. Arguments and variables
    query {
    people {
    name
    family
    relationships(relationship: child) {
    name
    family
    }
    }
    }


    View Slide

24. Arguments and variables
    query People($relationship: Relationship!) {
    people {
    name
    family
    relationships(relationship: $relationship) {
    name
    family
    }
    }
    }
    variables {"relationship": "child"}


    View Slide

25. Arguments and variables
    {"data": {
    "people": [
    {"name": "Lowri",
    "family": "Jones",
    "relationships": [
    {"name": "Dafydd",
    "family": "Jones"},
    {"name": "Bethan",
    "family": "Jones"}]
    …


    View Slide

26. Fragments and aliases
    fragment F0 on Person {
    name
    residence {
    name
    }
    }


    View Slide

27. Fragments and aliases
    query {
    people {
    name
    family
    children: relationships(relationship:
    child) {...F0}
    parents: relationships(relationship:
    parent) {...F0}
    }
    }


    View Slide

28. Fragments and aliases
    "people": [
    {"name": "Lowri",
    "family": "Jones",
    "children": [
    {"name": "Dafydd",
    "residence": {
    "name": "1 Glyn Stryd"}
    },
    "parents": []},
    …


    View Slide

29. Inline fragments
    {
    search(q: "ysgol") {
    __typename
    ... on Street {
    name
    }
    ... on House {
    street {
    name
    }
    number
    }
    }
    }


    View Slide

30. Inline fragments
    "search": [
    {"__typename": "House",
    "street": {
    "name": "Ysgol Stryd"
    },
    "number": 1
    },
    {"__typename": "Street",
    "name": "Ysgol Stryd"
    },
    …
    ]


    View Slide

31. Directives
    query People($includeChildren: Boolean!) {
    people {
    name
    family
    relationships(relationship: child) @include (if:
    $includeChildren) {
    name
    }
    }
    }
    variables {"includeChildren": false}


    View Slide

32. Directives
    {
    "data": {
    "people": [
    {
    "name": "Lowri",
    "family": "Jones"
    },
    …
    }


    View Slide

33. Have an explore!
    https://graphene-tutorial.herokuapp.com/plain/


    View Slide

34. Mutations
    • The only way to change data with a GraphQL API
    • Looks like a field - takes arguments and returns an
    ObjectType
    • Run in series instead of in parallel


    View Slide

35. Input type
    • Can define a special kind of type called and input type
    • Allows you to send the JSON representation of that
    type as a variable value


    View Slide

36. Making a mutation
    mutation Move($input: MoveInput!) {
    move(input: $input) {
    name
    residence {
    name
    }
    }
    }
    variables {"input": {"person": "ID1",
    "residence": "ID2"}}


    View Slide

37. Part 2: Graphene


    View Slide

38. Defining an object type
    • Let's start with something really simple
    • Street has just one attribute - its name
    • It should be a string


    View Slide

39. Defining an object type
    class Street(graphene.ObjectType):
    name = graphene.Field(graphene.String)
    And you're done!


    View Slide

40. Defining an object type - shorthand
    class Street(graphene.ObjectType):
    name = graphene.String()


    View Slide

41. Object types as containers
    street = Street(name='Araf Stryd')


    View Slide

42. A note on naming
    • GraphQL expects to have camelCase names
    • Python doesn't like camelCase names
    • Graphene just translates them for you - so an object
    type field named house_pets becomes a GraphQL field
    named housePets


    View Slide

43. Custom initialisation and resolvers
    • You will likely want to translate from your application
    objects to ObjectTypes
    • Some fields you want to expose you don't know yet
    • Custom resolver method using the resolve_FOO()
    pattern
    • Resolvers receive the field arguments, your own context
    and the current resolver info


    View Slide

44. Custom initialisation and resolvers
    class Street(graphene.ObjectType):
    name = graphene.String()
    def __init__(self, street):
    self.street = street
    def resolve_name(self, args, ctx, info):
    return self.street.name


    View Slide

45. Custom initialisation and resolvers
    class Street(graphene.ObjectType):
    houses = graphene.List(House)
    def resolve_houses(self, args, context,
    info):
    return [
    House(h) for h in population.houses
    if h.street == self.street
    ]


    View Slide

46. Custom fields
    • Fields have their own resolver method
    • Allows you to share common custom resolving logic
    between multiple object types


    View Slide

47. Defining an enum
    • Declarative
    • Uses python 3's enum.Enum (or a backport)


    View Slide

48. Defining an enum
    class Relationship(graphene.Enum):
    parent = 'parent'
    grandparent = 'grandparent'
    child = 'child'
    grandchild = 'grandchild'
    spouse = 'spouse'
    sibling = 'sibling'


    View Slide

49. Defining a field with arguments
    • Allows fields to behave differently depending on what
    the client needs
    • Examples would include pagination, image sizes,
    filtering a dataset


    View Slide

50. Defining a field with arguments
    class Person(graphene.ObjectType):
    relationships = graphene.Field(
    graphene.List(lambda: Person),
    relationship=graphene.Argument(
    Relationship,
    required=True,
    ),
    )


    View Slide

51. Defining a field with arguments
    class Person(graphene.ObjectType):
    relationships = graphene.List(
    lambda: Person,
    relationship=graphene.Argument(
    Relationship,
    required=True,
    ),
    )


    View Slide

52. Defining a field with arguments
    class Person(graphene.ObjectType):
    def resolve_relationships(
    self, args, context, info
    ):
    if args['relationship'] == 'parent':
    return [
    Person(p) for p in self.person.parents
    ]
    …


    View Slide

53. Union Type
    • Allows returning one of a variety of types
    • Example use cases include search endpoints, generic
    relationships, mixed content feeds
    • Resolver returns any of the valid objects and graphene
    does the rest


    View Slide

54. Union Type
    class Anything(graphene.types.union.Union):
    class Meta:
    types = (Person, House, Street)


    View Slide

55. Creating your schema
    • Create a Query ObjectType
    • Plumb that into the schema


    View Slide

56. Creating your schema
    class Query(graphene.ObjectType):
    people = graphene.List(Person)
    houses = graphene.List(House)
    streets = graphene.List(Street)
    search = graphene.Field(
    graphene.List(Anything),
    q=graphene.String(required=True)
    )
    )


    View Slide

57. Creating your schema
    schema = graphene.Schema(query=Query)
    schema_with_mutations = graphene.Schema(
    query=Query,
    mutation=Mutation,
    )


    View Slide

58. Using the schema directly
    >>> schema.execute('''
    query {
    streets {
    name
    }
    }
    ''')
    {"data": {"streets": […]}}


    View Slide

59. Context and info
    • When you use the schema, you can provide context
    • This is useful for attaching authentication or
    authorisation information you wish to use in resolvers
    • Info provides information about the current set of fields
    "below" where you are which are requested
    • Advanced use case, but can use to optimise the way you
    load data for the children


    View Slide

60. Mutations
    • Must define its Input type
    • Normal class definition is the object type returned
    • Has a mutate classmethod which does the work if the
    input is valid


    View Slide

61. Mutations
    class MoveHouse(graphene.Mutation):
    class Input:
    person = graphene.Field(Person)
    house = graphene.Field(House)
    # output
    person = graphene.Field(Person)
    ok = graphene.Boolean()


    View Slide

62. Mutations
    class MoveHouse(graphene.Mutation):
    @classmethod
    def mutate(cls, instance, args, info):
    person = get_person(args['person'])
    house = get_house(args['house'])
    ok = person.move_to(house)
    return MoveHouse(person=person, ok=ok)


    View Slide

63. Deploying with Django
    • Use the graphene-django package
    • The django-graphiql package allows interactive testing -
    add it to INSTALLED_APPS
    • Integration tools exist for other systems like
    SQLAlchemy


    View Slide

64. Deploying with Django
    from django.conf.urls import url
    from django.views.decorators.csrf import csrf_exempt
    from graphene_django.views import GraphQLView
    from django_graphiql.views import GraphiQL
    from .api import Schema
    urlpatterns = [
    url(r'^graphql', csrf_exempt(
    GraphQLView.as_view(schema=schema))),
    url(r'^graphiql', GraphiQL.as_view()),
    ]


    View Slide

65. Part 3: React


    View Slide

66. What is React?
    • View layer of a traditional MVC
    • Virtual DOM
    • Single directional data flow


    View Slide

67. What is a component?
    • Takes input (props)
    • Returns an element
    • Class with a render() method


    View Slide

68. What is a component?
    var houses = React.createClass({
    render: function() {
    var photos = this.props.houses.map((house) => {
    return React.createElement(House, {
    number: house.number,
    streetName: house.street.name,
    });
    });
    return React.createElement('div', {}, houses);
    }
    });


    View Slide

69. JSX
    • Preprocessor for React.createElement()
    • Compile using your JS preprocessor of choice


    View Slide

70. JSX
    var houses = React.createClass({
    render: function() {
    var photos = this.props.houses.map((house) => {
    return number=house.number
    streetName=house.street.name
    >;
    });
    return { houses };
    }
    });


    View Slide

71. Virtual DOM
    • Renders in memory-light virtual DOM
    • Compares changes between trees
    • Flushes only changes to the document
    • Debounces rendering


    View Slide

72. Data flow
    • Components have state as well as props
    • Minimise use of state
    • Handle at top level and pass functions around
    • Flux-like architectures
    • Reflux
    • Redux
    • Use Relay!


    View Slide

73. Part 4: Relay


    View Slide

74. Why Relay?
    • Only GraphQL-focused React framework
    • Colocation
    • Data masking
    • Caching
    • Query optimisation
    • Loading and ready states
    • Don't want something this restrictive? Try apollo-client


    View Slide

75. A Relay-compliant GraphQL API
    • Relay imposes conventions on the shape of your API
    • Caches and optimises queries through nodes
    • Handles pagination intelligently via cursors and
    connections


    View Slide

76. Nodes
    • All "core" objects should be implemented as Nodes
    • If there would be a "detail" page of it, it should be a node
    • All nodes have a globally unique ID
    • Query has a node field which can query any node


    View Slide

77. Nodes
    class StreetNode(DjangoObjectType):
    class Meta:
    model = Street
    only_fields = ['name']
    interfaces = (relay.Node,)


    View Slide

78. Nodes
    query {
    streets {
    id
    name
    }
    }
    {"data": {
    "streets": [
    {"id": "XXXXXX",
    "name": "Afon Stryd"},
    {"id": "YYYYYY",

    "name": "Glyn Stryd"},
    {"id": "ZZZZZZ",

    "name": "Ysgol Stryd"}
    ]
    }}


    View Slide

79. Nodes
    query {
    node(id: "XXXXXX")
    {
    id
    name
    }
    }
    {"data": {
    "node": {
    "id": "XXXXXX",
    "name": "Afon Stryd",
    }
    }}


    View Slide

80. Connections
    • Connections are special object types which have a
    particular structure
    • Used to do cursor based pagination
    • first - after
    • last - before
    • Return edges and pageInfo
    • Edges have cursors and nodes


    View Slide

81. Connections
    class StreetNode(DjangoObjectType):
    houses = relay.ConnectionField(
    HouseNode)
    def resolve_houses(self, args, ctx, info):
    return self.house_set.all()


    View Slide

82. Connections
    query {
    streets {
    name
    houses(first: 1) {
    edges {
    cursor
    node {
    number
    }
    }
    }
    }
    }


    View Slide

83. Connections
    {"data": {"streets" {
    "name": "Afon Stryd",
    "houses": {
    "edges": [{
    "cursor": "AAAAAA",
    "node": {
    "number": 1,
    }
    },
    …


    View Slide

84. Connections
    query {
    streets {
    name
    houses(first: 1) {
    pageInfo {
    hasNextPage
    endCursor
    }
    }
    }
    }


    View Slide

85. Connections
    {"data": {"streets" {
    "name": "Afon Stryd",
    "houses": {
    "pageInfo": {
    "hasNextPage": true,
    "endCursor": "AAAAAA",
    }
    …


    View Slide

86. Connections
    query {
    streets {
    name
    houses(first: 1, after: "AAAAAA") {
    …
    }
    }
    }


    View Slide

87. Mutations
    • Mutations must both take and return a unique identifier
    • Allows multiple similar mutations to be checked
    individually by the framework


    View Slide

88. Relay containers
    • A higher order component
    • Function which takes a component and returns a
    component which wraps it
    • Compile-time declares the data shape that the
    component needs


    View Slide

89. Declaring fragments
    • Uses Relay.QL``
    • A little sugar on top of a standard GraphQL fragment to
    allow reference to variables more easily
    • Looks a bit like ES6 template literals
    • Compiles using a babel plugin


    View Slide

90. Composing containers
    • When building the fragments, include fragments from
    the child
    • Match the name of the prop passed to the child to the
    fragment that child declared


    View Slide

91. Root Containers
    • Declares the entry point to the Relay application
    • Consists of a component to render, and a "rooted" query
    to the Query on the Node
    • Don't try to be too clever with them, they have some
    strange restrictions about arguments which will likely be
    removed in future versions


    View Slide

92. The "viewer" pattern
    • Works around Relay Root queries being weird by doing
    everything from a viewer field on Query
    • Don't forget that Relay's node field still needs to be
    on Query as well
    • Idea is everything is localised to what the user can see


    View Slide

93. Mutations
    • Must receive and return the client identifier
    • Just use relay.ClientIDMutation


    View Slide

94. Babel and webpack
    • Use babel to translate JSX and Relay.QL
    • Webpack with Django to create "bundles" of javascript
    to render to the page
    • graphene-django creates the schema file needed to
    verify the Relay.QL


    View Slide

95. Dumping your schema
    $ python manage.py graphql_schema --schema relay.api
    {
    "data":{
    "__schema":{
    "queryType":{
    "name":"Query"
    },
    "mutationType":null,
    "subscriptionType":null,
    "types":[
    {
    "kind":"OBJECT",
    "name":"Query",
    "description":null,
    "fields":[
    {
    "name":"streets",
    "description":null,
    "args":[
    ],
    …


    View Slide

96. Things to install
    • Babel plugins required
    • babel-preset-es2015
    • babel-preset-react
    • babel-relay-plugin
    • babel-relay-plugin-loader
    • Django
    • django-webpack-loader
    • python manage.py graphql_schema --schema
    --out schema.json


    View Slide

97. Webpack config
    var BundleTracker = require('webpack-bundle-
    tracker')
    plugins: [
    new BundleTracker({
    filename: './build/webpack-stats.json'
    }),
    ],


    View Slide

98. Webpack config
    module: {
    loaders: [
    {
    test: /\.jsx?$/,
    exclude: /node_modules/,
    loader: 'babel-loader',
    }
    ]
    }


    View Slide

99. package.json config
    "metadata": {
    "graphql": {
    "schema": "./schema.json"
    }
    }


    View Slide

100. Conclusion


     View Slide

101. Conclusion
     • Stack of tools for building complete applications
     • A coherent and powerful API
     • Hurdle to learn but expressive and effective once
     learned
     • Excellent support for complex applications
     • Probably overkill for simple ones
     • Excellent responsiveness to changing visual and
     interactivity requirements


     View Slide
