Finite State Transducers in Go

In this talk the audience will learn about the utility and applications of finite state transducers. First, we'll review finite state machines, a concept many are already familiar with. Then we'll look at finite state automata, and their relationship with regular expressions. Finally, we'll build up to finite state transducers, and discuss a new library named Vellum, which implements them in Go.

https://github.com/couchbaselabs/vellum

Transcript

1. FINITE STATE TRANSDUCERS
   CAPITAL GO 2017
   g o


   View Slide

2. MINIMAL
   DETERMINISTIC
   ACYCLIC
   FINITE
   STATE
   TRANSDUCERS


   View Slide

3. FINITE STATE MACHINE


   View Slide

4. FINITE STATE AUTOMATA (FSA)
   • cat
   • cats
   • dog
   MATCHES:


   View Slide

5. REGULAR EXPRESSION
   • cat
   • cats
   • dog
   MATCHES:
   ^cat(s)?|dog$


   View Slide

6. FINITE STATE AUTOMATA (FSA) - ORDERED SET
   ▸ Does it contain a key?
   ▸ Enumerate Ranges of Keys
   ▸ in lexicographic order


   View Slide

7. FINITE STATE TRANSDUCER (FST)
   Transition with value
   Traversal collects values
   Using SUM() "cat" has value 9


   View Slide

8. FINITE STATE TRANSDUCER (FST) - ORDERED MAP
   ▸ Does it contain a key?
   ▸ What is the value associated with a key?
   ▸ Enumerate Ranges of Key/Value Pairs
   ▸ in lexicographic order
   * values must satisfy particular algebra (currently just uint64)


   View Slide

9. FST LIBRARY IN GO
   ▸ Build
   ▸ Insert Keys in Lexicographic Order
   ▸ Bounded Memory
   ▸ Stream Output while Building
   ▸ Use
   ▸ Immutable
   ▸ FST data is memory mapped (mmap)
   ▸ References are slice offsets not
   pointers (less garbage collector
   impact)
   Vellum


   View Slide

10. CONSTRUCTING
    THE
    FST
    one - 1
    two - 2
    three - 3
    https://www.flickr.com/photos/wfyurasko/5573962244


    View Slide

11. CREATING A BUILDER
    builder, err := vellum.New(f, nil)
    Any io.Writer Options, default nil


    View Slide

12. INSERT
    err = builder.Insert([]byte("one"), 1)


    View Slide

13. INSERT
    err = builder.Insert([]byte("three"), 3)
    frozen


    View Slide

14. INSERT
    err = builder.Insert([]byte("three"), 3)
    frozen flushed to disk


    View Slide

15. INSERT
    err = builder.Insert([]byte("two"), 2)
    frozen flushed to disk


    View Slide

16. INSERT
    err = builder.Insert([]byte("two"), 2)
    frozen flushed to disk


    View Slide

17. INSERT
    err = builder.Insert([]byte("two"), 2)
    frozen flushed to disk


    View Slide

18. INSERT
    err = builder.Insert([]byte("two"), 2)
    frozen flushed to disk


    View Slide

19. CLOSE
    err = builder.Close()
    frozen flushed to disk


    View Slide

20. CLOSE
    err = builder.Close()
    frozen flushed to disk


    View Slide

21. CLOSE
    err = builder.Close()
    frozen flushed to disk


    View Slide

22. USING
    THE
    FST
    https://commons.wikimedia.org/wiki/File:Metro_Blur.JPG


    View Slide

23. OPEN
    fst, err = vellum.Open(path)
    Does NOT read entire FST
    into memory.
    * load an FST already in memory with vellum.Load(data)


    View Slide

24. GET
    val, exists, err = fst.Get(key)


    View Slide

25. ITERATE
    itr, err := fst.Iterator(start, end)
    for err == nil {
    key, val := itr.Current()
    // do something
    err = itr.Next()
    }


    View Slide

26. EFFICIENT SEARCHING WITH OTHER AUTOMATA
    itr, err := fst.Search(automaton, start, end)
    Just like iterator,
    with additional filter.


    View Slide

27. REGULAR EXPRESSION MATCHING
    r, err := regexp.New(`c.*t`)
    itr, err := fst.Search(r, start, end)


    View Slide

28. FUZZY MATCHING
    fuzzy, err := levenshtein.New("cat", 1)
    itr, err := fst.Search(fuzzy, start, end)
    at
    bat
    cats


    View Slide

29. WHAT ABOUT UNICODE?
    c a f
    63 61 66
    63 61 66
    Edit distance 2 bytes
    Edit distance 1 code point
    Levenshtein/Regex automata have integrated UTF-8 decoding
    c a f
    c3 a9
    65
    é
    e


    View Slide

30. SYSTEM DICTIONARY
    bytes %orig
    txt 2,493,109 -
    fst 1,224,433 49%
    gz 747078 30%
    /usr/share/dict/words
    235886 WORDS
    Not competing on
    compression ratio!


    View Slide

31. REGULAR EXPRESSION SEARCH DICTIONARY
    https://asciinema.org/a/az29w7apf7kdiioa1yf150g1u


    View Slide

32. FUZZY SEARCH DICTIONARY
    https://asciinema.org/a/avqyqbo3uw7y653rlnv7bqivv


    View Slide

33. INDEXING WIKIPEDIA ARTICLE TITLES
    6,726,078 TITLES


    View Slide

34. FUTURE WORK
    ▸ Bleve Full Text Search Library
    ▸ Next Generation Term Dictionary
    Format based on Vellum FST
    ▸ Add Support for storing []byte
    values (not just uint64)
    ▸ Continued Optimizations
    ▸ Less Garbage Created


    View Slide

35. FOR THOUGHT
    NOT GENERAL PURPOSE
    A DIFFERENT KIND OF MAP
    EFFICIENT ACCESS BY
    AUTOMATA MATCHING
    KEYS


    View Slide

36. THANKS
    ▸ Marty Schoch
    ▸ @mschoch - marty@couchbase.com
    ▸ Vellum Github - https://github.com/couchbaselabs/vellum
    ▸ Andrew Gallant's Blog
    ▸ Index 1,600,000,000 Keys with Automata and Rust
    ▸ Papers
    ▸ Direct Construction of Minimal Acyclic Subsequential Transducers


    View Slide
