ONOS Summit: Demo 1- Packet optical

ONOS Project
December 09, 2014

ONOS Summit: Demo 1- Packet optical

ONOS Summit: Demo 1- Packet optical
Presented by: Tom Tofigh and Praseed Balakrishnan

ONOS Project

December 09, 2014
Tweet

More Decks by ONOS Project

Other Decks in Technology

Transcript

  1. MULTILAYER  PACKET-­‐OPTICAL  CONTROL  WITH  ONOS     Tom Tofigh, AT&T

  2. Packet Network INEFFICIENCIES  WITH  TODAY’S  NETWORKS   ROADMs   IP

    Routers   MPLS Tunnels  Controlled  and  managed   independently    Slow  to  react  to  BW  demands    Both  packet  and  opJcal   networks  over  provisioned  to   deal  with  traffic  anomalies  and   failures    Lack  of  agility  and  significant  CapEx  and  OpEx  overhead   Optical Network
  3. BENEFITS  OF  CONVERGED  PACKET-­‐OPTICAL  CONTROL      Fast  wavelength  allocaJon

     of   bandwidth  in  transport  network   for  packet  traffic    Rapid  recovery  from   transport  failures   Service  provisioning   agility    Reduced  overprovisioning  of  resources  with  converged  control  plane   ONOS
  4. Demo:  MulJlayer  SDN  Control  with  ONOS   Praseed  Balakrishnn

  5. Demo:  MulJ-­‐layer  SDN  Control  with  ONOS   optical circuit Re-Route

    optical circuit BW  Calendaring  App   SDN Control Packet Network Optical Network DC1 DC2 ONOS
  6. Packet-Optical Network Sandbox on Your Laptop

  7. Applica8on  Intent  Framework  for     ease  of  provisioning  in

     MulJlayer  networks   MulJlayer  Network  Graph     Abstrac8on     Mul8layer  GUI  for   visualizaJon   Mul8-­‐layer  SDN  POC  in  a  box:     ONOS  +  Mininet     +  LINC-­‐OE*  +  BW  Calendaring  app**   *Developed  by  Infoblox  in  collabora4on  with  ON.Lab   **Created  using  OSCARS  from  ESNET   MulJ-­‐layer  SDN  Control  with  ONOS   Learn  More  at  onosproject.org   O N   O S
