1. Android Wear 2.0 Next Level of Freedom for Your Action Constantine Mars Organizer @ GDG Dnipro Senior Developer @ DataArt
2. A long time ago…
3. A long time ago… in the Lviv, not so far away :)
4. A long time ago… in the Lviv, not so far away :) We’ve been talking about...
5. #gdgceesummit Freedom of tethering BLE WiFi Cellular
6. #gdgceesummit And chances to get direct access to Play Store
7. And today...
9. Developer Preview 3 Play Store and More Available since September 28
10. #gdgceesummit Play Store features • multiple accounts, • support of alpha and beta testing • update or uninstall apps in “My apps” view • install only the watch app • phone apps are no longer necessary
11. You can now build and publish watch-only apps for users to discover on Google Play
12. #gdgceesummit android { publishNonDefault true // Allows you to reference product flavors in your phone's build.gradle defaultConfig { minSdkVersion 23 } // This is the minSdkVersion of the Wear 1.0 embedded app productFlavors { wear1 { /* Use the defaultConfig value */ } wear2 { minSdkVersion 24 } } } Flavors for supporting both 2.0 and 1.x
13. #gdgceesummit dependencies { ... wearApp project(path: ':wear', configuration: 'wear1Release') } Package only when build variant requires it
14. #gdgceesummit If no need in 1.x - simply publish MultiAPK
15. Hardware Key platform features and supported watches
16. #gdgceesummit Officially supported watches LG Watch Urbane 2nd Edition Huawei Watch
17. #gdgceesummit Officially supported watches LG Watch Urbane 2nd Edition Huawei Watch Display: 1.4 inches, 400 x 400 pixels (~286 ppi) CPU:Quad-core 1.2 GHz Cortex-A7 GPU: Adreno 305, Chipset: Qualcomm Snapdragon 400 Memory: 4 GB, 512 MB RAM Comm: Wi-Fi 802.11 b/g, Bluetooth v4.1 LE Network: No cellular connectivity Battery: 300 mAh (48h) Display: 1.38 inches, 480 x 480 pixels (~348 ppi) CPU: Quad-core 1.2 GHz Cortex-A7 GPU: Adreno 305, Chipset: Qualcomm Snapdragon 400 Memory: 4 GB, 768 MB RAM Comm: Wi-Fi 802.11 b/g, Bluetooth v4.1 LE, GPS, NFC Network: GSM, HSPA, LTE Battery: 570 mAh (60h)
18. Complications Personal expression and utility
19. #gdgceesummit Personal expression and utility Modern by LG Ranger by Zuhanden GoogleFit Today
20. #gdgceesummit Or simply an personal expression :) HeyKittyKitty by WatchMaster
21. #gdgceesummit Complications “any feature in a timepiece beyond the simple display of hours and minutes” (Wikipedia)
22. #gdgceesummit Complication types -Short text -Long text -Range of values -Icon (small picture) -Image (big picture)
23. Complications coding
24. #gdgceesummit New in Preview 3 com.google.android.wearable.permission.RECEIVE_COMPLICATION_DATA Request permission to access Complication Data
25. #gdgceesummit Runtime permissions. Wearable version:) Now required for accessing Complication Providers from WatchFace apps
26. #gdgceesummit Each position need to be identified private static final int LEFT_DIAL_COMPLICATION = 0; private static final int RIGHT_DIAL_COMPLICATION = 1; public static final int[] COMPLICATION_IDS = {LEFT_DIAL_COMPLICATION, RIGHT_DIAL_COMPLICATION}; Complication ID
27. #gdgceesummit Each position must be mapped with array of supported types // Left and right dial supported types. public static final int[][] COMPLICATION_SUPPORTED_TYPES = { {ComplicationData.TYPE_SHORT_TEXT}, {ComplicationData.TYPE_SHORT_TEXT} }; Complication supported types
28. #gdgceesummit Data Providers and system trigger .onComplicationDataUpdate() sometimes /* Called when there is updated data for a complication id. */ @Override public void onComplicationDataUpdate( int complicationId, ComplicationData complicationData) { Log.d(TAG, "onComplicationDataUpdate() id: " + complicationId); mActiveComplicationDataSparseArray.put(complicationId, complicationData); invalidate(); } ComplicationData receiving
29. #gdgceesummit .onDraw() is the moment of drawing. ComplicationData where stored earlier @Override public void onDraw(Canvas canvas, Rect bounds) { ComplicationData complicationData; for (int i = 0; i < COMPLICATION_IDS.length; i++) { complicationData = mActiveComplicationDataSparseArray .get(COMPLICATION_IDS[i]); // ... Complications rendering
30. #gdgceesummit Complication may be deactivated or contain wrong data type if ((complicationData != null) && (complicationData.isActive(currentTimeMillis)) && (complicationData.getType() == ComplicationData.TYPE_SHORT_TEXT)) { ComplicationText mainText = complicationData.getShortText(); CharSequence complicationMessage = mainText.getText(getApplicationContext(), currentTimeMillis); Complications rendering
31. #gdgceesummit Actual drawing is trivial canvas.drawText( complicationMessage, 0, complicationMessage.length(), complicationsX, mComplicationsY, mComplicationPaint); Complications rendering
32. Data Providers
33. #gdgceesummit Android Wear role in data exchange
34. #gdgceesummit Data Providers
35. Data Providers coding
36. #gdgceesummit <service android:name=".RandomNumberProviderService" android:label="@string/complications_provider_random_number" android:icon="@drawable/ic_watch_white"> Data Provider Service attributes Extend ComplicationProviderService
37. #gdgceesummit <intent-filter> <action android:name="android.support.wearable.complications.ACTION_COMPLICATION_UPDA TE_REQUEST"/> </intent-filter> <meta-data android:name="android.support.wearable.complications.SUPPORTED_TYPES" android:value="RANGED_VALUE,SHORT_TEXT,LONG_TEXT"/> Data Provider declaration
38. #gdgceesummit Update period <meta-data android:name="android.support.wearable.complications.UPDATE_PERIOD_SECONDS" android:value="120"/> Data Provider declaration
39. #gdgceesummit @Override public void onComplicationActivated( int complicationId, int dataType, ComplicationManager complicationManager) { … } @Override public void onComplicationUpdate( int complicationId, int dataType, ComplicationManager complicationManager) { … } @Override public void onComplicationDeactivated(int complicationId) { … } Data Provider methods
40. #gdgceesummit @Override public void onComplicationUpdate(int complicationId, int dataType, ComplicationManager complicationManager) { // Retrieve or generate your data int randomNumber = (int) Math.floor(Math.random() * 10); String randomNumberText = String.format(Locale.getDefault(), "%d!", randomNumber); Exposing data to complications Called according to update period time
41. #gdgceesummit ComplicationData complicationData = null; switch (dataType) { case ComplicationData.TYPE_SHORT_TEXT: complicationData = new ComplicationData.Builder( ComplicationData.TYPE_SHORT_TEXT) .setShortText(ComplicationText.plainText(randomNumberText)) .build(); break; Exposing data to complications
42. #gdgceesummit @Override public void onComplicationUpdate( int complicationId, int dataType, ComplicationManager complicationManager) { … if (complicationData != null) { complicationManager.updateComplicationData( complicationId, complicationData); } Exposing data to complications
43. #gdgceesummit WatchFaceService.Engine.setDefaultComplicationProvider() Default Providers
44. Notifications updated
45. #gdgceesummit Notifications in Android Wear 1.X
46. #gdgceesummit Android Wear 2.0 Notifications Material Design for Wearables, Dark Theme
47. #gdgceesummit Notifications preview
48. #gdgceesummit Notifications messaging style
49. Notifications coding
50. #gdgceesummit Notification noti = new NotificationCompat.Builder() .setContentTitle(messages.length + " new messages with " + sender) .setContentText("subject") .setSmallIcon(R.drawable.new_message) // 2) set the style to MessagingStyle .setStyle(new NotificationCompat.MessagingStyle( getResources().getString(R.string.reply_name)) .addMessage(messages[0]) .addMessage(messages[1]); Notifications with modern MessagingStyle set MessagingStyle
51. #gdgceesummit NotificationCompat.Action action = new NotificationCompat.Action.Builder(R.drawable.ic_reply_icon, getString(R.string.label), replyPendingIntent) .addRemoteInput(remoteInput) .setAllowGeneratedReplies(true) .build(); Notifications with SmartReply Allow SmartReply Starting with Preview 3 SmartReply uses standalone machine, located on watch
52. #gdgceesummit NotificationCompat.Action action = new NotificationCompat.Action.Builder(R.drawable.ic_reply_icon, getString(R.string.label), replyPendingIntent) .addRemoteInput(remoteInput) .extend(new NotificationCompat.Action.WearableExtender() .setHintDisplayActionInline(true)) .build(); Inline Action, available directly from stream Set inline action
53. (Not new) Input Methods
54. #gdgceesummit New input methods
55. #gdgceesummit Voice input, Emoji
56. #gdgceesummit Keyboard, Handwriting
57. #gdgceesummit Wait, a Keyboard??? LG Watch Urbane 2nd Edition Display: 1.38 inches, 480 x 480 pixels (~348 ppi) CPU: Quad-core 1.2 GHz Cortex-A7 GPU: Adreno 305, Chipset: Qualcomm Snapdragon 400 Memory: 4 GB, 768 MB RAM Comm: Wi-Fi 802.11 b/g, Bluetooth v4.1, LE, GPS, NFC Network: GSM, HSPA, LTE Battery: 570 mAh (60h) Size x2 bigger than first phones
58. Material Design for Wearables
59. #gdgceesummit 1D Layout Do Don’t
60. #gdgceesummit UI Anatomy
61. #gdgceesummit Navigation Drawer
62. #gdgceesummit Action Drawer
63. #gdgceesummit Dark Theme
64. #gdgceesummit Brightness values 1 App color - Default color 2 Dark background - 15% 3 Lighter background - 30% 4 UI element - 40% 5 Lighter UI element - 65% 6 Accent - 100%
65. #gdgceesummit Applications list
66. #gdgceesummit WearableRecyclerView Since Preview 3 - .setCircularScrollingGestureEnabled(true) available
67. Some new Google Fit features for Android Wear
68. #gdgceesummit Upcoming APIs Beat to Beat API Goals API Profile API
69. #gdgceesummit Real Time Gym Activity Recognition
70. #gdgceesummit Recognized exercises
