The talk I gave at SIGMOD 2013. The audience is a large group of database researchers so the talk focuses on the research aspect of Shark.

73bfac91877fce35c6d20e16e9e53677?s=128

Reynold Xin

June 25, 2013
Tweet

More Decks by Reynold Xin

Other Decks in Technology

Transcript

  1. MapReduce! DBMSs! Shark!

  2. Shark: SQL and Rich Analytics at Scale! Reynold Xin, Josh

    Rosen, Matei Zaharia, Michael Franklin, Scott Shenker, Ion Stoica! ! AMPLab, UC Berkeley! ! June 25 @ SIGMOD 2013!
  3. Challenges ! Data size growing! » Processing has to scale out

    over large" clusters! » Faults and stragglers complicate DB design! ! Complexity of analysis increasing! » Massive ETL (web crawling)! » Machine learning, graph processing! » Leads to long running jobs!
  4. The Rise of MapReduce !

  5. What’s good about MapReduce? ! 1.  Scales out to thousands

    of nodes in a fault- tolerant manner! 2.  Good for analyzing semi-structured data and complex analytics! 3.  Elasticity (cloud computing)! 4.  Dynamic, multi-tenant resource sharing!
  6. None
  7. “parallel relational database systems are significantly faster than those that

    rely on the use of MapReduce for their query engines”! “I totally agree.”!
  8. None
  9. This Research ! 1.  Shows MapReduce model can be extended

    to support SQL efficiently! »  Started from a powerful MR-like engine (Spark)! »  Extended the engine in various ways! 2.  The artifact: Shark, a fast engine on top of MR! »  Performant SQL! »  Complex analytics in the same engine! »  Maintains MR benefits, e.g. fault-tolerance!
  10. MapReduce Fundamental Properties? ! Data-parallel operations! » Apply the same operations

    on a defined set of data! ! Fine-grained, deterministic tasks! » Enables fault-tolerance & straggler mitigation!
  11. None
  12. Why Were Databases Faster? ! Data representation! » Schema-aware, column-oriented, etc!

    » Co-partition & co-location of data! Execution strategies! » Scheduling/task launching overhead (~20s in Hadoop)! » Cost-based optimization! » Indexing! Lack of mid-query fault tolerance! » MR’s pull model costly compared to DBMS “push”! See Pavlo 2009, Xin 2013.!
  13. Why Were Databases Faster? ! Data representation! » Schema-aware, column-oriented, etc!

    » Co-partition & co-location of data! Execution strategies! » Scheduling/task launching overhead (~20s in Hadoop)! » Cost-based optimization! » Indexing! Lack of mid-query fault tolerance! » MR’s pull model costly compared to DBMS “push”! See Pavlo 2009, Xin 2013.! Not fundamental to “MapReduce”! Can be surprisingly cheap!
  14. Introducing Shark ! MapReduce-based architecture! » Uses Spark as the underlying

    execution engine! » Scales out and tolerate worker failures! Performant! » Low-latency, interactive queries! » (Optionally) in-memory query processing! Expressive and flexible! » Supports both SQL and complex analytics! » Hive compatible (storage, UDFs, types, metadata, etc)!
  15. Spark Engine ! Fast MapReduce-like engine! » In-memory storage for fast

    iterative computations! » General execution graphs! » Designed for low latency (~100ms jobs)! Compatible with Hadoop storage APIs! » Read/write to any Hadoop-supported systems, including HDFS, Hbase, SequenceFiles, etc! Growing open source platform! » 17 companies contributing code!
  16. More Powerful MR Engine ! General task DAG! Pipelines functions"

    within a stage! Cache-aware data" locality & reuse! Partitioning-aware" to avoid shuffles! join% union% groupBy% map% Stage%3% Stage%1% Stage%2% A:% B:% C:% D:% E:% F:% G:% =%previously%computed%partition%
  17. ! Client! CLI! JDBC! Hive Architecture ! Meta store! Hadoop

    Storage (HDFS, S3, …)! Driver! SQL Parser! Query Optimizer! Physical Plan! Execution! MapReduce!
  18. ! Client! CLI! JDBC! Hive Architecture ! Meta store! Hadoop

    Storage (HDFS, S3, …)! Driver! SQL Parser! Spark! Cache Mgr.! Physical Plan! Execution! Query Optimizer!
  19. Extending Spark for SQL ! Columnar memory store! Dynamic query

    optimization! Miscellaneous other optimizations (distributed top-K, partition statistics & pruning a.k.a. coarse- grained indexes, co-partitioned joins, …)!
  20. Columnar Memory Store ! Simply caching records as JVM objects

    is inefficient (huge overhead in MR’s record-oriented model)! Shark employs column-oriented storage, a partition of columns is one MapReduce “record”.! 1% Column'Storage' 2% 3% john% mike% sally% 4.1% 3.5% 6.4% Row'Storage' 1% john% 4.1% 2% mike% 3.5% 3% sally% 6.4% Benefit: compact representation, CPU efficient compression, cache locality.!
  21. None
  22. How do we optimize:" " SELECT * FROM table1 a

    JOIN table2 b ON a.key=b.key WHERE my_crazy_udf(b.field1, b.field2) = true; Hard to estimate cardinality!!
  23. Partial DAG Execution (PDE) ! Lack of statistics for fresh

    data and the prevalent use of UDFs necessitate dynamic approaches to query optimization.! ! PDE allows dynamic alternation of query plans based on statistics collected at run-time.!
  24. Shuffle Join! Stage 3 Stage 2 Stage 1 Join Result

    Stage 1 Stage 2 Join Result Map Join (Broadcast Join)! minimizes network traffic!
  25. PDE Statistics ! Gather customizable statistics at per-partition granularities while

    materializing map output.! » partition sizes, record counts (skew detection)! » “heavy hitters”! » approximate histograms! Can alter query plan based on such statistics! » map join vs shuffle join! » symmetric vs non-symmetric hash join! » skew handling!
  26. Complex Analytics Integration ! Unified system for SQL, machine learning!

    ! Both share the same set of workers and caches! def logRegress(points: RDD[Point]): Vector { var w = Vector(D, _ => 2 * rand.nextDouble - 1) for (i <- 1 to ITERATIONS) { val gradient = points.map { p => val denom = 1 + exp(-p.y * (w dot p.x)) (1 / denom - 1) * p.y * p.x }.reduce(_ + _) w -= gradient } w } val users = sql2rdd("SELECT * FROM user u JOIN comment c ON c.uid=u.uid") val features = users.mapRows { row => new Vector(extractFeature1(row.getInt("age")), extractFeature2(row.getStr("country")), ...)} val trainedVector = logRegress(features.cache())
  27. Pavlo Benchmark ! Selection 0 22.5 45 67.5 90 Shark

    Shark5(disk) Hive 1.1 0 150 300 450 600 Aggregation 1K5Groups 32 Hive Shark5(disk) Shark Shark5Copartitioned 0 500 1000 1500 2000 Runtime5(seconds)
  28. Machine Learning Performance ! K"Means(Clustering 0 36 72 108 144

    180 157 4.1 Logistic(Regression 0 24 48 72 96 120 110 0.96 Shark Hadoop Runtime per iteration (secs)
  29. Real Warehouse Benchmark ! 0 25 50 75 100 Q1

    Q2 Q3 Q4 Runtime0(seconds) Shark Shark0(disk) Hive 1.1 0.8 0.7 1.0 1.7 TB Real Warehouse Data on 100 EC2 nodes!
  30. New Benchmark ! Impala Impala&(mem) Redshift Shark&(disk) Shark&(mem) 0 5

    10 15 20 Runtime&(seconds) http://tinyurl.com/bigdata-benchmark!
  31. Other benefits of MapReduce ! Elasticity! » Query processing can scale

    up and down dynamically! Straggler Tolerance! Schema-on-read & Easier ETL! Engineering! » MR handles task scheduling / dispatch / launch! » Simpler query processing code base (~10k LOC)!
  32. Berkeley Data Analytics Stack ! Spark! Shark! SQL! HDFS /

    Hadoop Storage! Mesos Resource Manager! Spark Streaming! GraphX! MLBase!
  33. Community ! 3000 people attended online training! 800 meetup members!

    17 companies contributing!
  34. Conclusion ! Leveraging a modern MapReduce engine and techniques from

    databases, Shark supports both SQL and complex analytics efficiently, while maintaining fault-tolerance.! Growing open source community! » Users observe similar speedups in real use cases! » http://shark.cs.berkeley.edu! » http://www.spark-project.org! !
  35. None
  36. MapReduce! DBMSs! Shark!
