Let’s Get Random: Under the Hood of PHP 7’s CSPRNG - Day Camp 4 Developers

Talk given at DC4D on June 2nd, 2017

Randomness is really important in many cryptographic contexts. Unfortunately true randomness is a non-trivial achievement for computers. In fact, using weak sources of randomness can leave your application open to myriad vulnerabilities. Enter: a good cryptographically secure pseudorandom number generator (CSPRNG).

We’ll discuss the importance of using good sources of randomness, the CSPRNG options we had in PHP 5.x, and how the new-hotness CSPRNG functions in PHP 7 work under the hood.

Transcript

1. Random
   Under the hood of PHP 7’s
   Let’s get
   CSPRNG
   Sammy Kaye Powers
   2017-06-02


   View Slide

2. ext/standard/random.c


   View Slide

3. The end


   View Slide

4. Random?
   What is


   View Slide

5. View Slide

6. Finish this sentence
   On the way home
   I got a flat ____.
   tire


   View Slide

7. Think of a two-digit number
   both digits different from each other
   both digits odd
   between 1 and 100


   View Slide

8. Are you thinking of…
   37


   View Slide

9. View Slide

10. 11
    Random?
    What makes a number


    View Slide

11. 2, 4, 6, 8, __
    10


    View Slide

12. 1337, 42, 0, _
    ?


    View Slide

13. 1337, 42, 0,
    1337, 42, 0,
    1337, __
    42


    View Slide

14. Random?
    What is isn’t
    Deterministic


    View Slide

15. “True” Random
    Measuring atmospheric noise
    Counting the number of electrons
    coming off of a radioactive material


    View Slide

16. View Slide

17. Can I haz
    random number?


    View Slide

18. View Slide

19. View Slide

20. *sigh* Take this.
    42


    View Slide

21. View Slide

22. View Slide

23. 2,4,8,
    7,5,1
    ?


    View Slide

24. Number Generator
    …or “PRNG” for short
    Pseudorandom


    View Slide

25. Pseudorandom?
    How’s that different than just random?
    Deterministic


    View Slide

26. 2,4,8,
    7,5,1
    Generator
    Linear Congruential


    View Slide

27. Generator
    Linear Congruential


    View Slide

28. View Slide

29. View Slide

30. 2,4,8,
    7,5,1,


    View Slide

31. 2,4,8,
    7,5,1,
    Deterministic


    View Slide

32. https://xkcd.com/221/


    View Slide

33. View Slide

34. View Slide

35. 8,7,5,
    1,2,4,


    View Slide

36. 1,2,4,
    8,7,5,
    BUT!


    View Slide

37. View Slide

38. 5,1,2,4,8,7,5,
    1,2,4,8,7,5,1,
    2,4,8,7,5,1,2,
    4,8,7,5,1,2,4,
    8,7,5,1,2,4,8,
    7,5,1,2,4,
    Predictable


    View Slide

39. LCG
    lcg_value()
    PHP has a combined


    View Slide

40. PRNG?
    Is there a better


    View Slide

41. Twister
    Mersenne
    mt_rand()


    View Slide

42. View Slide

43. mt_rand()
    724937621,955931554,1407935661,821438740,109344
    9922,603009103,1540988686,1028238631,798475733,
    1057939018,671583233,1853117923,98760648,112245
    3373,534404057,900958085,1712824654,476385742,2
    9956470,362833620,424798798,746223917,942003531
    ,320462445,673296853,1351199651,141566289,16454
    09515,995047403,1216151582,1115999460,175322091
    7,1312071810,1553254094,1622498991,2080099801,1
    704834715,1537620663,1357630828,1317892558,
    219,937-1


    View Slide

44. View Slide

45. mt_rand(0,99)
    83,9,64,28,62,48,83,47,46,53,37,26,21,91,61,32,58,1,89,60,65,97,42,56,6,47,76,1
    2,98,11,36,61,62,60,43,67,6,16,73,15,39,38,56,19,66,56,98,72,91,24,57,94,8,26,7
    3,55,17,14,84,89,39,11,13,48,71,98,89,63,9,95,74,9,81,85,97,24,14,14,77,22,96,4
    3,61,91,61,58,19,71,8,49,18,92,38,34,9,36,91,59,14,4,58,59,29,74,52,41,36,67,82
    ,67,11,0,58,51,37,4,45,56,35,50,78,91,27,39,80,27,28,95,2,82,51,72,27,41,43,74,
    7,82,59,89,72,9,22,61,75,27,64,16,77,57,31,29,59,47,14,67,89,33,94,33,94,22,11,
    62,9,13,61,45,78,29,3,11,99,91,52,79,63,64,43,99,53,22,16,10,53,57,15,84,16,30,
    17,10,3,35,0,45,83,11,70,66,37,14,59,41,46,52,53,53,62,56,41,82,40,99,8,92,96,2
    2,22,43,35,60,45,77,26,96,45,51,62,77,64,23,52,17,17,97,93,57,43,56,45,62,42,24
    ,62,1,59,38,70,13,34,32,48,47,1,42,48,18,2,59,47,53,10,3,66,68,93,4,53,85,20,77
    ,63,43,45,16,15,77,73,89,11,64,76,30,46,91,1,85,96,19,63,70,62,35,58,95,63,38,7
    8,83,8,97,22,2,28,51,25,29,98,62,74,59,95,79,74,66,47,35,83,56,49,25,32,25,46,1
    3,69,77,30,94,24,31,68,23,64,47,28,33,65,69,16,0,98,37,85,93,60,24,10,54,50,42,
    64,11,9,13,15,84,3,23,73,83,83,72,9,2,28,23,90,73,2,47,45,93,4,32,25,75,61,98,7
    3,79,66,23,20,83,11,45,67,40,39,45,0,65,40,78,74,8,79,86,38,10,87,60,99,30,35,5
    0,16,29,24,19,29,16,40,57,87,26,90,1,63,63,34,44,8,36,25,38,50,10,15,17,14,40,6
    ,53,88,18,36,46,69,2,13,0,83,59,92,59,34,34,24,40,99,41,6,79,65,98,9,36,31,8,4,
    89,98,91,80,42,10,26,72,40,50,39,25,33,45,24,70,54,89,91,53,23,12,20,40,21,25,5
    5,48,11,3,84,42,5,7,21,58,85,18,52,92,94,69,20,49,3,8,55,57,4,38,52,37,64,55,82
    ,98,5,75,84,35,14,99,74,23,41,69,55,53,22,52,6,68,35,38,73,52,22,52,86,79,15,38
    ,3,20,99,36,23,77,33,80,16,97,54,88,11,77,77,99,70,26,5,75,87,4,23,8,50,79,61,5
    5,80,25,58,79,25,56,9,81,6,42,27,90,58,6,62,74,25,79,81,61,23,54,92,53,16,66,22
    ,49,77,97,84,25,49,32,49,65,51,1,93,63,68,69,67,10,44,99,44,42,89,35,24,
    624 = busted


    View Slide

46. echo mt_rand(0,99);
    11


    View Slide

47. echo mt_rand(0,99);
    9


    View Slide

48. echo mt_rand(0,99);
    60


    View Slide

49. mt_srand(10);
    echo mt_rand(0,99);
    21


    View Slide

50. mt_srand(10);
    echo mt_rand(0,99);
    21


    View Slide

51. mt_srand(10);
    echo mt_rand(0,99);
    21


    View Slide

52. CSRF
    Take for example
    Tokens


    View Slide

53. Cross-site request forgery
    (CSRF) tokens help prevent
    unauthorized requests on
    a user’s behalf.


    View Slide

54. A CSRF token must be
    unique and unpredictable.


    View Slide

55. View Slide

56. View Slide

57. View Slide

58. I’ll just let PHP seed
    mt_rand() for me.
    Bad idea jeans
    *Old SNL skit reference


    View Slide

59. View Slide

60. Cryptographically
    Pseudorandom
    Secure
    Number Generator


    View Slide

61. CSPRNG
    or…


    View Slide

62. “See Spring”
    or…


    View Slide

63. Unicorn
    Magical


    View Slide

64. Uses seeds
    that are really
    really
    really
    really
    ridiculously
    hard to guess


    View Slide

65. impossible
    It’s values are
    to predict in practice
    42
    82

    Suitable for use in
    cryptographic contexts.


    View Slide

66. mythical
    Where can we find this
    creature?


    View Slide

67. CSPRNG
    options in
    5.x


    View Slide

68. openssl_random_pseudo_bytes()
    mcrypt_create_iv()
    /dev/urandom


    View Slide

69. openssl_random_pseudo_bytes()
    mcrypt_create_iv()
    /dev/urandom


    View Slide

70. Since the UNIX fork() system call
    duplicates the entire process state, a
    random number generator which does not
    take this issue into account will produce
    the same sequence of random numbers in
    both the parent and the child […], leading to
    cryptographic disaster…
    https://wiki.openssl.org/index.php/Random_fork-safety


    View Slide

71. OpenSSL’s
    be like
    42


    CSPRNG




    View Slide

72. OpenSSL cannot fix the fork-safety
    problem because its not in a position
    to do so. However, there are [solutions]
    available and they are listed below.
    https://wiki.openssl.org/index.php/Random_fork-safety


    View Slide

73. Don't use
    RAND_bytes
    https://wiki.openssl.org/index.php/Random_fork-safety


    View Slide

74. Instead, you can read directly from
    /dev/random, /dev/urandom or
    /dev/srandom; or use CryptGenRandom
    on Windows systems.
    https://wiki.openssl.org/index.php/Random_fork-safety


    View Slide

75. mcrypt_create_iv()
    /dev/urandom
    openssl_random_pseudo_bytes()


    View Slide

76. View Slide

77. View Slide

78. View Slide

79. /dev/urandom
    openssl_random_pseudo_bytes()
    mcrypt_create_iv()


    View Slide

80. open_basedir=/foo/dir


    View Slide

81. openssl_random_pseudo_bytes()
    mcrypt_create_iv()
    /dev/urandom


    View Slide

82. CSPRNG
    New hotness
    7


    View Slide

83. CSPRNG
    random_int()
    random_bytes()


    View Slide

84. random_int(0,99)
    6,17,6,9,17,53,58,98,46,44,62,9,76,65,46,21,42,5,65,34,11,96,85,7,46,89,98,9,9,
    80,8,76,87,18,24,68,16,61,27,39,30,32,4,83,83,23,96,27,13,47,6,99,16,40,2,75,27
    ,3,79,68,75,60,50,70,63,17,75,29,79,57,9,48,18,86,95,25,40,52,20,86,6,48,94,27,
    76,14,9,27,62,14,68,58,12,18,63,19,84,47,7,13,63,28,66,55,2,75,44,92,11,85,51,1
    7,42,57,22,4,53,7,3,76,48,55,95,7,45,33,87,36,11,17,66,6,46,87,57,48,22,31,65,5
    ,26,10,47,82,97,74,25,32,63,60,29,53,13,24,56,54,52,86,67,4,94,35,48,73,35,45,2
    4,74,74,83,49,70,41,49,20,60,29,49,30,35,38,63,4,86,72,97,26,22,36,95,59,94,24,
    89,73,46,14,73,51,93,93,39,13,80,9,30,24,20,30,63,20,64,97,29,7,2,82,96,42,61,5
    3,28,49,12,90,71,58,72,63,49,32,69,76,50,62,88,31,26,72,79,19,15,3,39,27,80,16,
    65,62,53,82,59,23,85,95,41,68,86,3,92,76,91,88,12,20,96,14,35,50,94,24,23,44,55
    ,78,65,81,7,1,86,32,58,46,97,43,78,9,51,1,6,79,73,49,13,40,21,90,14,9,70,95,88,
    37,85,14,7,29,42,55,81,46,39,41,45,81,11,93,26,89,4,98,35,30,36,74,97,18,85,97,
    23,52,64,88,20,89,12,25,19,21,21,50,60,50,43,84,1,52,5,19,2,86,38,51,48,30,55,9
    0,93,97,52,84,29,58,96,78,37,24,14,72,81,9,82,26,83,83,17,35,15,9,87,95,51,71,4
    8,9,45,13,61,98,3,18,96,99,28,74,47,58,71,89,68,57,51,86,90,38,21,72,72,30,22,1
    3,88,25,48,45,62,59,81,32,10,54,82,60,90,17,98,41,73,98,60,22,99,66,32,41,82,62
    ,91,3,85,91,21,17,98,19,48,50,24,67,3,14,62,55,35,99,95,83,76,12,51,77,61,24,24
    ,60,15,31,47,24,27,97,98,70,6,24,25,20,23,67,72,55,47,19,53,50,38,22,76,37,63,8
    2,67,52,3,75,84,84,71,49,79,26,89,11,77,55,92,32,81,38,23,54,9,40,80,75,20,7,58
    ,37,72,75,59,46,32,41,82,90,72,59,5,42,2,94,44,44,4,15,37,29,24,10,51,18,8,42,5
    6,9,68,31,99,7,77,59,8,74,80,11,15,93,81,5,72,44,49,39,25,4,18,98,0,93,42,78,36
    ,57,47,16,49,2,85,6,31,17,81,10,54,40,95,68,31,80,29,41,86,32,9,58,96,62,79,25,
    6,45,56,54,0,61,74,90,12,34,11,56,3,41,39,84,32,30,42,81,36,43,5,


    View Slide

85. bin2hex(random_bytes(16))
    f7f5289027cb6c5116d
    2d3cc78e5819c


    View Slide

86. You’re not strong until
    you’re crypto-strong!


    View Slide

87. CSPRNG
    under the hood


    View Slide

88. View Slide

89. On Windows: CryptGenRandom
    On BSD: arc4random_buf()
    On Linux: getrandom(2) syscall
    Read directly from /dev/urandom


    View Slide

90. Fail
    Closed


    View Slide

91. /dev/urandom
    So what is this
    thing?


    View Slide

92. /dev/urandom
    Gathers environmental noise
    from the system like…
    …device drivers, inter-keyboard
    timings, inter-interrupt timings
    from some interrupts, and
    other events which are both
    (a) non-deterministic and
    (b) hard for an outside
    observer to measure.
    https://git.kernel.org/pub/scm/linux/kernel/git/torvalds/linux.git/tree/drivers/char/random.c


    View Slide

93. CSPRNG
    random_bytes()
    random_int()
    7
    /dev/urandom
    Powered by


    View Slide

94. Still on 5.x?
    paragonie/random_compat
    Polyfill for PHP 7 CSPRNG


    View Slide

95. TL;DR
    Never use LCG, MT, or any other PRNG in
    cryptographic contexts
    Only use a CSPRNG like
    /dev/urandom for crypto
    Use random_bytes() & random_int() in
    PHP (or install paragonie/random_compat)


    View Slide

96. More Resources


    View Slide

97. Recommendation for the Entropy Sources
    Used for Random Bit Generation
    Second Draft - NIST SP 800-90B
    http://csrc.nist.gov/publications/drafts/800-90/sp800-90b_second_draft.pdf


    View Slide

98. New & improved man pages for
    /dev/urandom
    http://man7.org/linux/man-pages/man7/random.7.html


    View Slide

99. Myths about
    /dev/urandom
    Thomas Hühn
    https://www.2uo.de/myths-about-urandom/


    View Slide

100. Cracking Random Number Generators
     Three-part blog post series
     James Roper
     https://jazzy.id.au/2010/09/20/cracking_random_number_generators_part_1.html


     View Slide

101. How I Met Your Girlfriend
     DEF CON 18
     Samy Kamkar
     https://www.youtube.com/watch?v=fWk_rMQiDGc


     View Slide

102. Weak RNG in PHP session ID generation
     leads to session hijacking
     Andreas Bogk
     http://seclists.org/fulldisclosure/2010/Mar/519


     View Slide

103. THANKS!
     SAMMY KAYE POWERS
     @SammyK
     SammyK.me
     Host of @PHPRoundtable
     West Coast Swing
     @ChiPHPUG
     Hire me! :)


     View Slide
