1. The fourth dimension
   A practical introduction to
   Functional Reactive Programming
   by sergi mansilla | @sergimansilla


   View Slide

2. @sergimansilla
   github.com/sergi


   View Slide

3. Before


   View Slide

4. View Slide

5. Shameless linkbaiting


   View Slide

6. Tame your async code
   with this one weird trick!
   A practical introduction to
   Functional Reactive Programming
   by sergi mansilla | @sergimansilla


   View Slide

7. - Linkbaiting
   - Time


   View Slide

8. Human beings
   have hard-wired time
   in their brain


   View Slide

9. Developers
   have hard-wired time
   in their brain
   (in a slightly different way)


   View Slide

10. 1 CPU Cycle 1 s
    Level 1 cache access 3 s
    Level 2 cache access 9 s
    Level 3 cache access 43 s
    Main memory access (DRAM, from CPU) 6 min
    Solid-state disk I/O (flash memory) 2-6 days
    Rotational disk I/O 1-12 months
    Internet: San Francisco to Australia 19 years


    View Slide

11. JS developers
    have hard-wired async
    in their brain
    (in a messed up way)


    View Slide

12. Callbacks
    Promises
    Generators
    Events


    View Slide

13. We use events
    to deal with
    asynchronous tasks


    View Slide

14. var clicks = 0;
    document.addEventListener('click', function register(e) {
    if (clicks < 10) {
    if (e.clientX > innerWidth / 2) {
    console.log(e.clientX, e.clientY);
    clicks += 1;
    }
    } else {
    document.removeEventListener('click', register);
    }
    });


    View Slide

15. Why are we still
    micromanaging
    code?


    View Slide

16. var clicks = 0;
    document.addEventListener('click', function register(e) {
    if (clicks < 10) {
    if (e.clientX > innerWidth / 2) {
    console.log(e.clientX, e.clientY);
    clicks += 1;
    }
    } else {
    document.removeEventListener('click', register);
    }
    });


    View Slide

17. var clicks = 0;
    document.addEventListener('click', function register(e) {
    if (clicks < 10) {
    if (e.clientX > innerWidth / 2) {
    console.log(e.clientX, e.clientY);
    clicks += 1;
    }
    } else {
    document.removeEventListener('click', register);
    }
    });


    View Slide

18. var clicks = 0;
    document.addEventListener('click', function register(e) {
    if (clicks < 10) {
    if (e.clientX > innerWidth / 2) {
    console.log(e.clientX, e.clientY);
    clicks += 1;
    }
    } else {
    document.removeEventListener('click', register);
    }
    });


    View Slide

19. var clicks = 0;
    document.addEventListener('click', function register(e) {
    if (clicks < 10) {
    if (e.clientX > innerWidth / 2) {
    console.log(e.clientX, e.clientY);
    clicks += 1;
    }
    } else {
    document.removeEventListener('click', register);
    }
    });


    View Slide

20. var clicks = 0;
    document.addEventListener('click', function register(e) {
    if (clicks < 10) {
    if (e.clientX > innerWidth / 2) {
    console.log(e.clientX, e.clientY);
    clicks += 1;
    }
    } else {
    document.removeEventListener('click', register);
    }
    });


    View Slide

21. var clicks = 0;
    document.addEventListener('click', function register(e) {
    if (clicks < 10) {
    if (e.clientX > innerWidth / 2 && isAPressed) {
    console.log(e.clientX, e.clientY);
    clicks += 1;
    }
    } else {
    document.removeEventListener('click', register);
    }
    });
    !
    var isAPressed = false;
    document.addEventListener('keydown', e => {
    isAPressed = e.keyCode === 65;
    }, false);
    !
    document.addEventListener('keyup', e => {
    isAPressed = false;
    }, false);


    View Slide

22. We still code the how
    instead of the what


    View Slide

23. Programming
    should be more
    about the what


    View Slide

24. View Slide

25. Declarative


    View Slide

26. Declarative


    View Slide

27. document.addEventListener('keyup', e => {
    return isAPressed = false;
    }, false);
    Void callbacks


    View Slide

28. var clicks = 0;
    document.addEventListener('click', function register(e) {
    if (clicks < 10) {
    if (e.clientX > innerWidth / 2 && isAPressed) {
    console.log(e.clientX, e.clientY);
    clicks += 1;
    }
    } else {
    document.removeEventListener('click', register);
    }
    });
    !
    var isAPressed = false;
    document.addEventListener('keydown', e => {
    isAPressed = e.keyCode === 65;
    }, false);
    !
    document.addEventListener('keyup', e => {
    isAPressed = false;
    }, false);


    View Slide

29. Climbers


    View Slide

30. View Slide

31. State is dangerous


    View Slide

32. Event limbo


    View Slide

33. var clicks = 0;
    document.addEventListener('click', function register(e) {
    if (clicks < 10) {
    if (e.clientX > innerWidth / 2) {
    console.log(e.clientX, e.clientY);
    clicks += 1;
    }
    } else {
    document.removeEventListener('click', register);
    }
    });


    View Slide

34. Awkward error handling
    Memory leaks
    Complex (state)


    View Slide

35. View Slide

36. Isn’t that the problem
    promises try to solve?


    View Slide

37. var y = f(x);
    var z = g(y);
    fAsync(x).then(...);
    gAsync(x).then(...);
    res =
    stocks
    .filter(q => q.symbol == 'FB')
    .map(q => q.quote)
    !
    res.forEach(x =>
    ...
    res =
    stocks //async retrieval
    .filter(q => q.symbol == 'FB')
    .map(q => q.quote)
    !
    res.subscribe(x =>
    ...
    Sync
    Sync
    Promises
    Reactive


    View Slide

38. Click!
    … …
    Click!
    Click!


    View Slide

39. Click!
    , ,
    Click!
    Click!
    [ ]


    View Slide

40. View Slide

41. [1, 2, 3, 4, 5, 6, 7, 8, 9, 10]
    .filter(n => n % 2)
    .map(n => 'item ' + n)
    .forEach(n => console.log(n))
    !
    // "item 1"
    // "item 3"
    // "item 5"
    // "item 7"
    // "item 9"


    View Slide

42. F
    R
    P


    View Slide

43. Final
    Resting
    Place


    View Slide

44. Fantasy
    Role
    Playing


    View Slide

45. Functional
    Reactive
    Programming


    View Slide

46. View Slide

47. View Slide

48. Deal with values
    that change
    over time


    View Slide

49. Alternatives:
    - Bacon.js
    - Elm
    Reactive
    Extensions for
    JavaScript


    View Slide

50. View Slide

51. RxJS helps us compose
    asynchronous programs
    in a declarative way


    View Slide

52. var clicks = 0;
    document.addEventListener('click', function register(e) {
    if (clicks < 10) {
    if (e.clientX > innerWidth / 2) {
    console.log(e.clientX, e.clientY);
    clicks += 1;
    }
    } else {
    document.removeEventListener('click', register);
    }
    });
    Filter
    Limit to 10
    Print the coordinates


    View Slide

53. fromEvent(document, 'click')
    .filter(c => c.clientX > innerWidth / 2 })
    .take(10)
    .subscribe(c => console.log(c.clientX, c.clientY) })


    View Slide

54. fromEvent(document, 'click')
    .filter(c => c.clientX > innerWidth / 2 })
    .take(10)
    .subscribe(c => console.log(c.clientX, c.clientY) })
    Create Observable


    View Slide

55. fromEvent(document, 'click')
    .filter(c => c.clientX > innerWidth / 2 })
    .take(10)
    .subscribe(c => console.log(c.clientX, c.clientY) })
    Create filtered Observable

    from the first one


    View Slide

56. fromEvent(document, 'click')
    .filter(c => c.clientX > innerWidth / 2 })
    .take(10)
    .subscribe(c => console.log(c.clientX, c.clientY) })
    Create final Observable

    taking only first 10 results


    View Slide

57. fromEvent(document, 'click')
    .filter(c => c.clientX > innerWidth / 2 })
    .take(10)
    .subscribe(c => console.log(c.clientX, c.clientY) })
    Actually kick off computation


    View Slide

58. Observable
    Observer
    pattern
    Iterator
    pattern


    View Slide

59. Rx.Observer
    - OnNext()
    - OnError()
    - OnComplete()


    View Slide

60. // Creates an observable sequence of 5 integers
    var source = Rx.Observable.range(1, 5)
    !
    // Prints out each item
    var subscription = source.subscribe(
    x => { console.log('onNext: ' + x) },
    e => { console.log('onError: ' + e.message) },
    () => { console.log('onCompleted') })
    !
    // => onNext: 1
    // => onNext: 2
    // => onNext: 3
    // => onNext: 4
    // => onNext: 5
    // => onCompleted


    View Slide

61. var mousemove = fromEvent(document, 'mousemove');
    !
    var mouseCoords = mousemove.map(e => ({
    left: e.clientX,
    top: e.clientY
    }))
    !
    var mouseSide = mousemove.map(e =>
    (e.clientX > window.innerWidth / 2 ? 'right' : 'left'))
    !
    mouseCoords.subscribe(pos =>
    coords.innerHTML = pos.top + 'px ' + pos.left + 'px')
    mouseSide.subscribe(s => side.innerHTML = s);
    Composability


    View Slide

62. var emsc = Rx.DOM.jsonpRequest({
    url: ‘http://seismicportal.eu/?callback=cbfunc...',
    jsonpCallback: 'cbfunc'
    }).retry();
    !
    var usgs = Rx.DOM.jsonpRequest({
    url: QUAKE_URL,
    jsonpCallback: 'eqfeed_callback'
    });
    !
    var quakes = Rx.Observable.interval(5000)
    .flatMap(() => emsc.merge(usgs))
    .flatMap(dataset => Rx.Observable.fromArray(dataset.features))
    .distinct(quake => quake.code || quake.unid)
    .subscribe(quake => {
    var coords = quake.geometry.coordinates;
    L.circle([coords[1], coords[0]], quake.size).addTo(map);
    });
    Concurrency


    View Slide

63. View Slide

64. // Search Wikipedia for a given term
    function searchWikipedia(term) {
    var cleanTerm = global.encodeURIComponent(term);
    var url = ‘/search?q=‘ + cleanTerm + '&cb=JSONPCallback';
    return Rx.Observable.getJSONPRequest(url);
    }
    !
    var input = document.querySelector('#searchtext'),
    results = document.querySelector('#results');
    !
    // Get all distinct key up events from the input and
    var keyup = fromEvent(input, 'keyup')
    .map(e => e.target.value)
    .where(text => text.length > 2) // Longer than 2 chars
    .throttle(200) // Pause for 200ms
    .distinctUntilChanged(); // Only if the value has changed


    View Slide

65. var searcher = keyup
    .map(text => searchWikipedia(text)) // Search wikipedia
    .switchLatest() // Ensure no out of order results
    .where(data => (data.length === 2)); // Where we have data
    !
    searcher.subscribe(data => {
    // Append the results (data[1])
    }, error => {
    // Handle any errors
    });


    View Slide

66. View Slide

67. // Search Wikipedia for a given term
    function searchWikipedia(term) {
    var cleanTerm = global.encodeURIComponent(term);
    var url = ‘/search?q=‘ + cleanTerm + '&cb=JSONPCallback';
    return Rx.Observable.getJSONPRequest(url);
    }
    !
    var input = document.querySelector(‘#searchtext');
    var results = document.querySelector('#results');
    !
    // Get all distinct key up events from the input and
    var keyup = fromEvent(input, 'keyup')
    .map(e => e.target.value)
    .where(text => text.length > 2) // Longer than 2 chars
    .throttle(200) // Pause for 200ms
    .distinctUntilChanged(); // Only if the value has changed


    View Slide

68. // Search Wikipedia for a given term
    function searchWikipedia(term) {
    return fromArray(['JavaScript',
    'JavaServer Pages',
    'JavaSoft',
    'JavaScript library',
    'JavaScript Object Notation',
    'JavaScript engine',
    'JavaScriptCore']);
    }
    !
    var input = document.querySelector('#searchtext'),
    results = document.querySelector('#results');
    !
    // Get all distinct key up events from the input and
    var keyup = fromEvent(input, 'keyup')
    .map(e => e.target.value)
    .where(text => text.length > 2) // Longer than 2 chars
    .throttle(200) // Pause for 200ms
    .distinctUntilChanged(); // Only if the value has changed


    View Slide

69. fromArray
    fromCallback
    fromEvent
    fromEventPattern
    fromIterable
    fromNodeCallback
    fromPromise


    View Slide

70. var mouseup = fromEvent(dragTarget, 'mouseup');
    var mousemove = fromEvent(document, 'mousemove');
    var mousedown = fromEvent(dragTarget, 'mousedown');
    !
    var mousedrag = mousedown.flatMap(md => {
    var startX = md.clientX + window.scrollX,
    startY = md.clientY + window.scrollY,
    startLeft = parseInt(md.target.style.left, 10) || 0,
    startTop = parseInt(md.target.style.top, 10) || 0;
    !
    // Calculate delta with mousemove until mouseup
    return mousemove.map(mm => {
    mm.preventDefault();
    !
    return {
    left: startLeft + mm.clientX - startX,
    top: startTop + mm.clientY - startY
    };
    }).takeUntil(mouseup);
    });
    !
    subscription = mousedrag.subscribe(pos => {
    dragTarget.style.top = pos.top + 'px';
    dragTarget.style.left = pos.left + 'px';
    });


    View Slide

71. [1, 2, 3, 4, 5, 6, 7, 8, 9, 10]
    .filter(n => n % 2)
    .map(n => 'item ' + n)
    .forEach(n => console.log(n))
    !
    // "item 1"
    // "item 3"
    // "item 5"
    // "item 7"
    // "item 9"


    View Slide

72. [1, 2, 3, 4, 5, 6, 7, 8, 9, 10]
    .filter(n => n % 2)
    .map(n => 'item ' + n)
    .forEach(n => console.log(n))
    !
    // "item 1"
    // "item 3"
    // "item 5"
    // "item 7"
    // "item 9"
    loop
    loop
    loop


    View Slide

73. View Slide

74. fromArray([1, 2, 3, 4, 5, 6, 7, 8, 9, 10])
    .filter(n => n % 2)
    .map(n => n * 100)
    .map(n => 'item ' + n)
    .subscribe(n => console.log(n))


    View Slide

75. View Slide

76. First Class async
    Composability
    Concurrency
    Encapsulation
    Michael Hasselhof sings limbo


    View Slide

77. I am writing a book about this!
    @sergimansilla


    View Slide

78. Thanks!
    @sergimansilla


    View Slide
