Kubernetes-like Reconciliation Protocol for Managed Flink Services

This talk was given at Flink Forward 2023.

Want your Flink jobs to keep running without failures? Inspired by the robustness of Kubernetes, we created a managed Flink service that brings a similar experience. Users specify the desired Flink job states, and our platform ensures Flink jobs remain in that state. We embraced Kubernetes style reconciliation loops - constant monitoring, comparison of actual and desired states, and proactive actions to resolve any issues.

We've diverged from the conventional Kubernetes operator approach. Our implementation enables a single control plane to manage multiple data planes, and allows relocating Flink jobs to different Kubernetes clusters for cluster utilization and disaster recovery scenarios. With Debezium integration at its core, our reconciliation protocol guarantees efficiency and scalability.

In this talk, you will learn how we designed and implemented such a reconciliation protocol, including various reconciliation methods tailored to the unique demands of Flink.

Transcript

1. Kubernetes-like
   Reconciliation Protocol for
   Managed Flink Services
   Sharon Xie，Flink Babysitter
   Founding Engineer @ Decodable


   View Slide

2. Our Journey
   to Automate
   Babysitting
   Flink


   View Slide

3. Agenda
   ● The declarative UX for managed Flink services
   ● Step by Step Implementation
   ● Q&A


   View Slide

4. Wishes for
   Managed Flink
   Services


   View Slide

5. Declarative VS Imperative
   Declarative (What)
   ● I want a chocolate cake to feed 10 people
   Imperative (How)
   ● Drive to store;
   ● Buy eggs, cocoa powder, butter, flour;
   ● Drive home;
   ● Preheat Oven;
   ● Mix Ingredients;
   ● Place in a baking tray…


   View Slide

6. Platform for Managed Flink Services


   View Slide

7. Challenges
   ● Network is unreliable
   ● Arbitrary network latency
   ● Software and hardware can fail
   ● Flink jobs are sensitive to external changes


   View Slide

8. Kubernetes Reconciliation Protocol
   Step 1: Get Target & Actual State
   Step 2: Reconcile
   If (Target State != Actual State) {
   // FIX IT
   }


   View Slide

9. V0: Get target
   and actual state


   View Slide

10. V0 Result
    ✅ Basic declarative API
    ✅ Single Source of Truth Store
    ○ Can always recreate the service based off the DB
    ❌ Can’t update Flink jobs
    ❌ No reconciliation


    View Slide

11. V1: Update the Flink cluster when the
    pipeline is updated


    View Slide

12. Flink Controller
    ● Debezium
    ○ Gets notified when the target
    state changes
    ● FlinkDeployer
    ○ Take actions based on the
    job specification
    ● StateWatch
    ○ Implements K8S Watch API
    ○ Listens to Flink state change
    and update DB with actual
    state


    View Slide

13. Flink Controller
    ● Stateless
    ○ Debezium does a full table
    scan when the service starts
    ● Idempotent
    ○ FlinkDeployer can issue the
    same commands
    (create/delete a cluster)
    without changing the result


    View Slide

14. V1 Result
    ✅ Flink clusters match the target states if no errors
    ❌ Lack error handling
    ○ Flink job creation/deletion can fail
    ❌ StateWatch can miss events
    ○ When a Flink cluster is deleted during the service
    restart/downtime


    View Slide

15. V2: Reconcile if actual state doesn’t
    match target


    View Slide

16. ✅ Reconciler runs a scheduled task for eventual
    consistency
    ● Any transient network issues can be recovered
    ● Missing StateWatch events can be reconciled
    ❌ No auto healing for Flink runtime issues
    ❌ No auto scaling for workload changes
    V2 Result


    View Slide

17. V3:
    Auto
    Healing
    and
    Scaling


    View Slide

18. V3:
    Auto
    Healing
    and
    Scaling


    View Slide

19. Auto Controller
    ● Stop jobs that are unrecoverable
    ○ Eg: external system issues
    ● Rules engine to auto fix issues
    ○ When Flink RPC times out, increase
    akka.ask.timeout
    ● Scale up/down based on the metrics
    ○ Eg: Lag is going up for an extended period of time,
    scale up with a larger machine


    View Slide

20. Event Order Challenges


    View Slide

21. Solution
    ● Version: monotonically increasing with every successful update from the API


    View Slide

22. ✅ Fully managed Flink service
    with continuous reconciliation


    View Slide

23. View Slide

24. One More Thing…


    View Slide

25. ● Control plane must be able to authenticate the data planes
    ● Network communication should be encrypted
    BYOC - Bring Your Own Cloud


    View Slide

26. V4: Support BYOC


    View Slide

27. ● Bidirectional gRPC channel over mTLS
    ○ 🔒Encryption
    ○ 󰠖Authentication
    ● DB access lives in the control plane
    ● Data plane continues processing data in the case
    of a prolonged network partition
    BYOC


    View Slide

28. Other Benefits
    ● Resource Efficiency
    ○ A control plane can manage multiple data planes
    ● Can relocate data planes to different k8s
    clusters for
    ○ Disaster recovery
    ○ Better resource utilization


    View Slide

29. Summary
    ● Users ❤ Declarative APIs
    ● Continuous reconciliation makes distributed
    error handling easier with eventual
    consistency
    ● Control / Data plane separation enables a
    more flexible architecture


    View Slide

30. Kubernetes-like Reconciliation Protocol for
    Managed Flink Services
    Q&A
    @sharon_rxie


    View Slide
