Comparing Apache Flink and Spark for Modern Stream Data Processing

This is the slides for the Flink Forward 2024 conference (https://www.flink-forward.org/berlin-2024/agenda#comparing-apache-flink-and-spark-for-modern-stream-data-processing)

Real-time data processing is essential for staying competitive in today’s fast-paced business environment, and choosing the right tool is a key decision. Apache Flink and Spark Structured Streaming are two leading stream processing frameworks, each with unique strengths and trade-offs.

This talk takes a look at our journey at Decodable, where we evaluated both tools and ultimately chose Apache Flink over Spark Structured Streaming for our stream data processing needs. By examining key differences between the two systems, we aim to provide a clear, technical comparison that will help you make informed decisions for your streaming data use cases.

Join us for this talk where we will discuss:
- Design philosophies: Learn about the origins of both systems and some of the fundamental architecture design choices of Flink that makes it more attractive for streaming use cases.
- (Stateful) streaming capabilities: We will dive into and compare similar features that both Spark and Flink offer in the various APIs, we will also share some features only available in Flink that make it a much richer streaming library. We will also talk about some of the data ecosystem tools/connectors that Flink supports natively, like Debezium.
- Production readiness: We will also talk about some of the recent features of Flink that makes running Flink at scale easy, like the Kubernetes operator and its sophisticated auto-scaler.

Transcript

1. Comparing Apache Flink and Spark for Modern Stream Data Processing Sharon Xie Eric Xiao
2. What are we going to learn? 01. Architecture Design 02. Decodableʼs Evaluation Framework 03. Detailed Comparison Spark Streaming VS Flink Streaming Mode
3. Your Presenters Sharon Xie Head of Product • Founding Engineer @ Decodable • 7 years of real-time data platform building Eric Xiao Data Platform • Senior Software Engineer @ Decodable • Previously on the Streaming Platform teams @ Shopify, Walmart.
4. Decodable is powered by Flink and Debezium
5. How did Flink and Spark solve the problem? 01. Architecture Design
6. Context Typical real-time data platform
7. Design - Spark Streaming Source: https://spark.apache.org/docs/latest/streaming-programming-guide.html Micro-Batch: receives live input data streams and divides the data into batches
8. Can batch size = 1 for Spark Streaming? No. - Batched via interval - Job scheduling overhead >> data processing Source: https://spark.apache.org/docs/latest/streaming-programming-guide.html
9. Design - Flink Source: https://nightlies.apache.org/flink/flink-docs-release-1.20/docs/learn-flink/overview/ Stream processing: continuously process the data as it arrives.
10. Yes. Some operators (aggregation / join) can enable mini batches. Can batch size > 1 for Flink Source: https://nightlies.apache.org/flink/flink-docs-master/docs/dev/table/tuning/#minibatch-regular-joins
11. 02. Evaluation Framework Whatʼs important to Decodable?
12. Benchmark
13. Benchmark Most of the time
14. Benchmark Most of the time
15. How did we approach benchmark? • Context Matters ◦ Latency VS Throughput • Design Reveals Potential ◦ Can it scale > static numbers
16. How did we choose? The ultimate test
17. Expected Value ⚡ Low Latency = Competitive Edge ✨ Streaming > Batch What do we believe?
18. Cost Operational Overhead Development Complexity Infrastructure Cost How much does it cost to run the workload?
19. Detailed Comparison Eric Xiao
20. Example Use Case
21. Example Use Case
22. Example Use Case
23. Development Complexity
24. API and Language Support Flink Spark Language Support • Java • Python • Java/Scala • Python • R Higher Level APIs • SQL • Table API • SQL • DataFrames Lower Level APIs • DataStream • ProcessFunction N/A
25. Stateful) Streaming Transformations Characteristics “Statelessˮ • Simple transformations: filters, projections, etc. • Requires no other “contextˮ (other streams, other events). Stateful Temporary) • Aggregations, “timelyˮ joins, windows. • Requires “contextˮ but can be dropped after some time. Stateful Indefinite) • Top N, joining with “staticˮ dataset. • Requires “contextˮ to be stored forever. More State
26. Stateful) Streaming Transformations Flink Spark “Statelessˮ Well/fully supported Stateful Temporary) Stateful Indefinite) Fully supported • Limited transformational support. • Limited state support.
27. Complexity of Expressing a Stateful Application in Spark
28. • Anti-patterns used as workarounds • More about Spark’s limitations Complexity of Expressing a Stateful Application in Spark
29. Development Complexity • Spark is better at being language agnostic. • Flink outperforms when more state is involved. • Able to express more complicated applications better in Flink. More State
30. Example Use Case
31. Infrastructure Costs
32. Infrastructure Costs OR
33. Infrastructure Costs • Flink excels at CDC use cases: ◦ Has built-in debezium engine ◦ Leads to lower latency
34. • Observability/Debuggability. • Failure handling. • Performance tuning. Operational Challenges
35. Tools Provided to Handle Operational Tasks Flink Spark Observability / Debuggability • Kubernetes/task specific metrics. • Parallelism tuning. • Checkpoint duration/batch-size tuning. Failure Handling • Restores from latest checkpoint or micro-batch.
36. Performance Tuning Flink Spark Backpressure Handling Automatic back pressure handling N/A, manually configured Auto-scaling Operator level auto-scaling TaskManager level auto-scaling Memory Auto-tuning Supported N/A, not supported
37. Operational Overhead • Very similar challenges and tasks. • Flink has finer grain auto-tuning.
38. Wrap Up Categories Flink Development Complexity1 • More advanced state management capabilities. • Additional lower level streaming API DataStream / ProcessFunction. Infrastructure Cost • Native CDC connectors. Operational Overhead • Advanced auto-control for resource allocation. • Automatic back pressure handling.
39. Additional Information • Blog Post: Comparing Apache Flink and Spark for Modern Stream Data Processing.
40. Thank You Q&A Sharon Xie Eric Xiao
41. How to Benchmark? Real world examples, or use your actual workload Source: https://www.flink-forward.org/global-2021/conference-program#sources--sinks--and-operators--a-performance-deep-dive More: https://github.com/dttung2905/flink-at-scale/
