kuberception: Self Hosting kubernetes

kuberception : self-hosting kubernetes

Blog post: https://tasdikrahman.me/2019/04/04/self-hosting-highly-available-kubernetes-cluster-aws-google-cloud-azure/

Transcript

1. Kuberception: Self Hosting Kubernetes
   Tasdik Rahman
   @tasdikrahman | tasdikrahman.me


   View Slide

2. Who is this talk for
   Kubernetes cluster operators
   People evaluating alternatives to
   KOPS/kubeadm etc. or a
   managed solution
   Kubeadm
   OR


   View Slide

3. Agenda
   1. What is Self Hosted Kubernetes.
   2. Why?
   3. How does it work?
   4. Learnings from running it on production.
   5. What’s next?


   View Slide

4. Brief Intro to Kubernetes


   View Slide

5. Section Header
   Picture Credits: https://elastisys.com/


   View Slide

6. What is Self hosted
   Kubernetes?


   View Slide

7. Self hosted Kubernetes
   It runs all required and optional components of a Kubernetes cluster on top of
   Kubernetes itself. The kubelet manages itself or is managed by the system init
   and all the Kubernetes components can be managed by using Kubernetes APIs.
   *Ref: CoreOS tectonic docs


   View Slide

8. Self hosted Kubernetes


   View Slide

9. Is it something new?
   * https://github.com/kubernetes/kubernetes/issues/246


   View Slide

10. Why?


    View Slide

11. Desired control plane components properties
    ● Highly available
    ● Should be able to tolerate node failures
    ● Scale up and down with requirements
    ● Rollback and upgrades
    ● Monitoring and alerting
    ● Resource allocation
    ● RBAC


    View Slide

12. How is Self Hosted kubernetes addressing them?
    ● Small Dependencies
    ● Deployment consistency
    ● Introspection
    ● Cluster Upgrades
    ● Easier Highly-Available Configurations
    ● Streamlined, cluster lifecycle management.


    View Slide

13. Small Dependencies
    Kubelet kubeconfig
    Container runtime
    Minimal on-host requirements


    View Slide

14. No distinction between master and
    worker nodes


    View Slide

15. You select master nodes by adding
    labels to it
    $ kubectl label node node1 master=true


    View Slide

16. Introspection


    View Slide

17. Cluster upgrades


    View Slide

18. Easier Highly Available configurations


    View Slide

19. Streamlined Cluster Lifecycle
    management
    $ kubectl apply -f kube-apiserver.yaml
    $ kubectl apply -f controller-manager.yaml
    $ kubectl apply -f flannel.yaml
    $ kubectl apply -f my-app.yaml


    View Slide

20. How does it work?


    View Slide

21. Three main problems to solve for
    it work


    View Slide

22. Bootstrapping Upgrades
    Disaster
    recovery


    View Slide

23. Bootstrapping
    ● Control plane running as daemonsets, deployments.
    Making use of secrets and configmaps
    ● But … We need a control to plane to apply these
    deployments and daemonsets on


    View Slide

24. Credits: ASAPScience


    View Slide

25. Then how should we solve this?


    View Slide

26. Use a temporary, static control
    plane to bootstrap the cluster


    View Slide

27. Bootkube: Looking at it from
    10,000 feet


    View Slide

28. Temporary
    control-plane
    manifests
    Self hosted
    control-plane
    manifests
    Master (initial) node
    Bootkube
    Temporary
    control-plane
    self-hosted
    control-plane


    View Slide

29. etcd
    Bootkube
    (kube-apiserver,
    controller-manager,
    scheduler)
    System kubelet
    (managed by system init)
    api-server scheduler
    controller-
    manager
    Ephemeral control plane being
    brought up by bootkube.


    View Slide

30. etcd
    System kubelet
    (managed by system init)
    api-server scheduler
    controller-
    manager
    Bootkube exits, bringing down the
    ephemeral control plane.


    View Slide

31. View Slide

32. Does this even work?


    View Slide

33. Controller node(master)


    View Slide

34. Demo


    View Slide

35. Do a kubernetes control plane
    component version upgrade on the test
    cluster


    View Slide

36. Learnings from running
    it on production
    clusters


    View Slide

37. ● Using the right instance types for the compute instances.
    ● Self hosted etcd outage.
    ● api-server crashing during image upgrade.
    ● appropriate resource limits.
    ● Disaster recovery (etcd-backups/bootkube recover/heptio ark).
    ● Blue-green clusters.
    ● Kubelet OOM’d.
    ● Cross checking for compatibility with the cluster upgrade.
    What went wrong and what went right


    View Slide

38. What’s next?


    View Slide

39. Automate the boring stuff
    Credits: AlSweigart


    View Slide

40. Automate
    ● Extend kubernetes by leveraging CRD’s
    ● The cluster upgrade part can be delegated to an operator.
    ● Custom systemd/shell scripts
    ● .


    View Slide

41. Future of bootkube
    ● Will be replaced by Kubelet pod API.
    ○ The write API would enable an external installation program to setup the control plane of a
    self-hosted Kubernetes cluster without requiring an existing API server.


    View Slide

42. Links
    ● Github repo used in the demo for setting up the self hosted k8s test cluster
    using typhoon: https://github.com/tasdikrahman/infra
    ● https://typhoon.psdn.io/: used as baseline for this demo to create the self
    hosted k8s cluster.


    View Slide

43. References
    ● SIG-lifecycle Spec on self hosted kubernetes
    ● bootkube: Design principles
    ● bootkube: How does is work
    ● bootkube: Upgrading the kubernetes cluster
    ● SIG lifecycle google groups early discussions on self hosting


    View Slide

44. Credits
    ● @rmenn, @hashfyre, @gappan28 for teaching me what I know.
    ● @aaronlevy and @dghubble for always being there on #bootkube on k8s
    slack to clear up any questions on bootkube.
    ● @kubenetesio for sharing the slide template.
    ● The OSS contributors out there who have made k8s and the ecosystem
    around it, what it is today.
    ● Arjun for lending me his laptop for DevOpsdays.


    View Slide

45. Questions?
    tasdikrahman.me | @tasdikrahman


    View Slide
