  1. Enabling canary
    deployments in k8s

    View Slide

  2. Canary?
    Shaping the traffic in a way, so that we could direct a % of traffic
    to the new pods and promoting the same deployment to a full
    scaleout and gradually phasing out the older release.
    2

    View Slide

  3. Why Canary?
    ● Testing on staging doesn’t weed out all the possible reasons
    for something failing, final testing for a feature being done on
    some part of the traffic is not something unheard of.
    ● Canary being a precursor to enable full blue green
    deployments.
    ○ Why?
    ■ No feature flags for respective microservices.
    ■ Hence canary testing becomes paramount to test
    out features.
    3

    View Slide

  4. Approaches to enable
    Canary on k8s?
    4

    View Slide

  5. Using bare bones k8s deployments?
    How?
    Creation of two sets of deployments and referring to figure 1, v1
    and v2, both would be separate deployment objects with
    separate label selectors. Both v1 and v2 deployments would be
    exposed via the same svc object which would point to their pods.
    5

    View Slide

  6. Using bare bones k8s deployments?
    Advantages
    ● Plain and simple.
    ● Can be done without any plugins/extra stuff in the vanilla k8s
    we get in GKE.
    Disadvantages
    ● Traffic will be a function of replicas, and cannot be
    customized. For example, if the traffic splitting is done
    between the two deployment with v1 having 3 replicas and
    v2 having 1 replica, the traffic split for canary will be 25%
    6

    View Slide

  7. Using Istio?
    ● In an istio enabled cluster, we need to set the routing rules to
    configure the traffic distribution.
    ● Similar to the approach above, we have two deployments
    and svc objects for the same service, called v1 and v2.
    ● The rule will look something like
    7

    View Slide

  8. Using Istio
    8
    Ref: https://istio.io/blog/2017/0.1-canary/

    View Slide

  9. Advantages
    ● Has been out there in the wild for quite some time. i.e Battle tested
    ● Flagger can be added to have automated canary promotion.
    ● GKE has an add on feature which can be used to install istio in our clusters
    ● Traffic routing and replica deployment are two completely orthogonal
    independent functions
    ● Focused canary testing, eg: instead of exposing the canary to an arbitrary
    number of users, if you wanted the users from some-company-name.com to
    the canary version, leaving the other users unaffected, you can do that too
    with a rule to match the headers for the match to check for the cookie for the
    above.
    Disadvantages
    ● Another add on to manage inside the cluster if gone through the route of
    installing the istio version
    9

    View Slide

  10. Using Linkerd
    ● Linkerd has a canary CRD that enabled how a rollout should
    occur
    ● It automatically creates two sets of deployments for a
    deployment name `podinfo`
    10

    View Slide

  11. Using Linkerd
    11

    View Slide

  12. Using Linkerd
    Advantages
    ● Flagger can be integrated for automated canary
    promotion/demotion
    ● Battle tested and has been in use by the virtue of being the
    first service mesh
    Disadvantages
    ● Another component inside the k8s cluster to be maintained
    12

    View Slide

  13. Using Traefik
    ● It requires the same setup of two deployment and svc
    objects for the service which needs to have canary enabled
    for it.
    ● It makes use of the ingress object in k8s to define the traffic
    split between the services.
    13

    View Slide

  14. Using Traefik
    14

    View Slide

  15. Using Traefik
    Advantages
    ● Easy to setup with no frills, as it’s just an ingress controller in
    the k8s controller (like contour/ nginx-ingress-controller)
    ● Doesn’t need the pods to be scaled.
    ● Support for tracing included.
    Disadvantages
    ● No inbuilt process to shift weights from v1 to v2 or revert
    back traffic in case of increased error rates. Ie. not a clear
    cut way to integrate with flagger for automated canary
    promotion/demotion
    15

    View Slide

  16. References
    ● https://martinfowler.com/bliki/CanaryRelease.html
    ● https://martinfowler.com/bliki/FeatureToggle.html
    ● Canary using istio
    ○ https://istio.io/blog/2017/0.1-canary/
    ● Bare bones canary on k8s
    ○ https://kubernetes.io/docs/concepts/cluster-administration/manage-deployment/#can
    ary-deployments
    ● Canary using traefik
    ○ https://blog.containo.us/canary-releases-with-traefik-on-gke-at-holidaycheck-d3c092
    8f1e02?gi=c58435e35526
    ○ https://tasdikrahman.me/2018/10/25/canary-deployments-on-AWS-and-kubernetes-u
    sing-traefik/
    ○ https://docs.traefik.io/user-guide/kubernetes/#traffic-splitting
    ● Canary using linkerd
    ○ https://linkerd.io/2/tasks/canary-release/
    ○ https://linkerd.io/2/features/traffic-split/
    ■ Done using https://flagger.app/
    ○ https://www.tarunpothulapati.com/posts/traffic-splitting-linkerd/
    16
