Mutation Testing PHPDeveloperDay

Théo FIDRY
September 22, 2018

Mutation Testing PHPDeveloperDay

Mutation testing: better code by making bugs Do you test your code? What about your tests? Your tests are code, you need to write, refactor and maintain them. This is not cheap so how do you make sure you are testing enough but not too much? Discover Mutation Testing, a fun tool to make your code better by introducing bugs.

Théo FIDRY

September 22, 2018
Tweet

More Decks by Théo FIDRY

Other Decks in Programming

Transcript

  1. WHO DOES • UNIT TESTING • TEST-DRIVEN DEVELOPMENT • CONTINUOUS

    INTEGRATION • MEASURE CODE COVERAGE • MUTATION TESTING 5
  2. 7 Marcello Duarte Creator of PhpSpec ex-Head of Training @Inviqa

    The extent to what the software takes into account what matters most for the customer & the maintainability of the source code DEFINING SOFTWARE QUALITY Internal Quality External Quality https://speakerdeck.com/jakzal/building-in-quality
  3. EXTERNAL QUALITY • Conformity to the user expectation • Reliability

    • Accuracy • Ergonomics • Design • … 9
  4. COST OF BUG / PHASE 17 http://www.ifpug.org/Documents/Jones-CostPerDefectMetricVersion4.pdf Cost US$1,666.67 US$3,333.33

    US$5,000.00 US$6,666.67 US$8,333.33 US$10,000.00 Development phase Dev CI/Review QA Prod US$100 US$500 US$1,500 US$10,000 https://plus.google.com/u/1/+LaurentBossavit/posts/8QLBPXA9miZ
  5. ORIGIN OF THE COSTS • Implementation • Debug & Repair

    • Technical debt • Delay: the extra you are paying for not fixing bugs earlier on 18
  6. ORIGIN OF THE COSTS 19 Technical debt Build cost Build

    cost Cost of delay Technical debt Cost of debug Cost of repair Right feature built wrong Right feature IDEA
  7. TESTS ARE CODE • You need to write them •

    You need to make sure they work • You need to refactor them • You need to maintain them 24
  8. PROBLEMS • How do I safely refactor my tests? •

    How do I know I can trust a test suite? • How do I ensure my team is writing effective tests • How do I know if I’ve retrofitted enough tests to safely refactor a piece of legacy code? 26
  9. 28 NO TEST MAX TEST SHORT-TERM HIGH VELOCITY SHORT-TERM LOW

    VELOCITY TESTS QUALITY Level of quality
  10. COMMON ANSWERS • Don’t worry, it’ll be fine • I’m

    a ninja rockstar, I know my tests are good • I do TDD, I know my tests are good • What about the tests you didn’t write? • How do you test drive changes to tests? • Code review • Inconsistent + Labour intensive • Code coverage 30
  11. 32 EXAMPLE https://github.com/theofidry/mutation-testing-demo <?php declare(strict_types=1); namespace Acme; final class Counter

    { public $count = 0; public function count(int $nbr): void { if ($nbr >= 10) { $this->count++; } } }
  12. 33 https://github.com/theofidry/mutation-testing-demo function test_it_counts_number_above_ten(): void { $initialCount = $this->counter->count; $this->counter->count(100);

    $newCount = $this->counter->count; Assert::assertGreaterThan($initialCount, $newCount); } function test_it_does_not_count_number_below_ten(): void { $initialCount = $this->counter->count; $this->counter->count(7); $newCount = $this->counter->count; Assert::assertSame($initialCount, $newCount); }
  13. 34 RUN PHPUNIT WITH COVERAGE REPORT https://github.com/theofidry/mutation-testing-demo $ vendor/bin/phpunit --coverage-text

    \ --coverage-html=dist/coverage PHPUnit 7.0.2 by Sebastian Bergmann and contributors. .. 2 / 2 (100%) Time: 113 ms, Memory: 6.00MB OK (2 tests, 2 assertions) Generating code coverage report in HTML format ... done Code Coverage Report: Summary: Classes: 100.00% (1/1) Methods: 100.00% (1/1) Lines: 100.00% (3/3) \Acme::Acme\Counter Methods: 100.00% ( 1/ 1) Lines: 100.00% ( 3/ 3) 100% code coverage
  14. 36 LET’S INTRODUCE A BUG https://github.com/theofidry/mutation-testing-demo <?php declare(strict_types=1); namespace Acme;

    final class Counter { public $count = 0; public function count(int $nbr): void { if ($nbr > 10) { $this->count++; } } }
  15. 37 RUN PHPUNIT WITH COVERAGE REPORT https://github.com/theofidry/mutation-testing-demo $ vendor/bin/phpunit --coverage-text

    \ —-coverage-html=dist/coverage PHPUnit 7.0.2 by Sebastian Bergmann and contributors. .. 2 / 2 (100%) Time: 113 ms, Memory: 6.00MB OK (2 tests, 2 assertions) Generating code coverage report in HTML format ... done Code Coverage Report: Summary: Classes: 100.00% (1/1) Methods: 100.00% (1/1) Lines: 100.00% (3/3) \Acme::Acme\Counter Methods: 100.00% ( 1/ 1) Lines: 100.00% ( 3/ 3) DID NOT FAIL
  16. 43 A TEST CASE IS MISSING https://github.com/theofidry/mutation-testing-demo function test_it_counts_ten(): void

    { $initialCount = $this->counter->count; $this->counter->count(10); $newCount = $this->counter->count; Assert::assertGreaterThan($initialCount, $newCount); }
  17. 44 $ vendor/bin/phpunit --coverage-text \ --coverage-html=dist/coverage PHPUnit 7.0.2 by Sebastian

    Bergmann and contributors. .F. 3 / 3 (100%) Time: 70 ms, Memory: 6.00MB There was 1 failure: 1) Acme\CounterTest::test_it_counts_ten Failed asserting that 0 is greater than 0. /path/to/tests/CounterTest.php:38 FAILURES! Tests: 3, Assertions: 3, Failures: 1. Generating code coverage report in HTML format ... done Code Coverage Report: Summary: Classes: 100.00% (1/1) Methods: 100.00% (1/1) Lines: 100.00% (3/3) \Acme::Acme\Counter Methods: 100.00% ( 1/ 1) Lines: 100.00% ( 3/ 3)
  18. EXAMPLE OF A MUTANT 49 <?php declare(strict_types=1); namespace Acme; final

    class Counter { public $count = 0; public function count(int $nbr): void { if ($nbr >= 10) { $this->count++; } } } --- a/src/Counter.php +++ b/src/Counter.php @@ -8,7 +8,7 @@ final class Counter public function count(int $nbr): void { - if ($nbr >= 10) { + if ($nbr > 10) { $this->count++; } }
  19. MUTATOR EXAMPLES 50 Name Original Mutated Plus + - GreaterThanOrEqualTo

    >= > Spaceship $a <=> $b $b <=> $a TrueValue return true; return false; https://infection.github.io/guide/mutators.html
  20. --- a/src/Counter.php +++ b/src/Counter.php @@ -8,7 +8,7 @@ final class

    Counter public function count(int $nbr): void { - if ($nbr >= 10) { + if ($nbr > 9) { $this->count++; } } --- a/src/Counter.php +++ b/src/Counter.php @@ -8,7 +8,7 @@ final class Counter public function count(int $nbr): void { - if ($nbr >= 10) { + if ($nbr >= 11) { $this->count++; } } --- a/src/Counter.php +++ b/src/Counter.php @@ -8,7 +8,7 @@ final class Counter public function count(int $nbr): void { - if ($nbr >= 10) { + if ($nbr > 10) { $this->count++; } } --- a/src/Counter.php +++ b/src/Counter.php @@ -8,7 +8,7 @@ final class Counter public function count(int $nbr): void { if ($nbr >= 10) { - $this->count++; + $this->count—-; } } GENERATED MUTANTS 53 … and more
  21. CODE COVERAGE HIGHLIGHTS CODE THAT IS DEFINITELY NOT TESTED MUTATION

    SCORE HIGHLIGHTS CODE THAT IS DEFINITELY TESTED 58 HOW TO DETECT IF A TEST SUITE IS DEFICIENT?
  22. DOES IT WORK? “Complex faults are coupled to simple faults

    in such a way that a test data set that detects all simple faults in a program will detect most complex faults” Demonstrated in 1995 by K. Wah, “Fault coupling in finite bijective functions” 59
  23. 64 INSTALLATION Infection installation guide: https://infection.github.io/guide/installation.html PHPUnit installation guide: https://phpunit.de/getting-started/phpunit-7.html

    $ git clone [email protected]:symfony/dependency-injection.git infection-demo $ cd infection-demo $ composer install $ wget -O infection https://github.com/infection/infection/releases/ download/0.10.3/infection.phar $ chmod +x infection $ wget -O phpunit https://phar.phpunit.de/phpunit-7.phar $ chmod /+x phpunit
  24. PHPUNIT CONFIGURATION 65 phpunit.xml.dist <?xml version="1.0" encoding="UTF-8"?> <phpunit xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="http://schema.phpunit.de/7.0/phpunit.xsd"

    bootstrap="vendor/autoload.php"> <php> <ini name="error_reporting" value="-1" /> </php> <testsuites> <testsuite name="Symfony DependencyInjection Component Test Suite"> <directory>./Tests/</directory> </testsuite> </testsuites> <filter> <whitelist> <directory>./</directory> <exclude> <directory>./Resources</directory> <directory>./Tests</directory> <directory>./vendor</directory> </exclude> </whitelist> </filter> </phpunit>
  25. 66 RUNNING TESTS $ ./phpunit PHPUnit 7.0.2 by Sebastian Bergmann

    and contributors. ............................................................... 63 / 672 ( 9%) ............................................................... 126 / 672 ( 18%) ............................................................... 189 / 672 ( 28%) ............................................................... 252 / 672 ( 37%) ............................................................... 315 / 672 ( 46%) ............................................................... 378 / 672 ( 56%) ............................................................... 441 / 672 ( 65%) ............................................................... 504 / 672 ( 75%) ........S.SSSSS................................................ 567 / 672 ( 84%) ............................................................... 630 / 672 ( 93%) .......................................... 672 / 672 (100%) Time: 1.89 seconds, Memory: 26.00MB OK, but incomplete, skipped, or risky tests! Tests: 672, Assertions: 1550, Skipped: 6.
  26. INFECTION CONFIGURATION 68 { "timeout": 10, "source": { "directories": [

    "." ], "excludes": [ "Tests", "vendor" ] }, "phpunit": { "customPath": "phpunit" }, "logs": { "text": "infection-log.txt" } } infection.json.dist https://infection.github.io/guide/usage.html#Configuration
  27. 69 RUNNING INFECTION $ ./infection You are running Infection with

    xdebug enabled. ____ ____ __ _ / _/___ / __/__ _____/ /_(_)___ ____ / // __ \/ /_/ _ \/ ___/ __/ / __ \/ __ \ _/ // / / / __/ __/ /__/ /_/ / /_/ / / / / /___/_/ /_/_/ \___/\___/\__/_/\____/_/ /_/ Running initial test suite... PHPUnit version: 7.0.2 678 [============================] 26 secs Generate mutants... Processing source code files: 144/144 Creating mutated files and processes: 3573/3573 .: killed, M: escaped, S: uncovered, E: fatal error, T: timed out .........M..MEEEM..MME.EEE.....MMM..MSE.....E..... ( 50 / 3573) E.E.ESS.E....SSSSSM.S...M........S.S.SS.....EM.E.. ( 100 / 3573) ....M..E....SMMMMMMMMMM...M..E.E..EM......M..MM... ( 150 / 3573) .M...........M...........................M.MM..... ( 200 / 3573) ....MM..M.......M.....M...SSSSSSSS...M......M.M... ( 250 / 3573) .M.M.MEM..MST.E.M.......MMMM............SMMM.....E ( 300 / 3573) .E.......TM.........SM....................EM...... ( 350 / 3573) ....EM.M...E..MM.MM.S.MS......M.....EM...E...EE... ( 400 / 3573) ...TME......S................MM....M........E...M. ( 450 / 3573) ...ESSSSSSSSS...MM.SM....ESSMMMM.MSS..MM.SM.M.MMMS ( 500 / 3573) SS.S......M........S.S....ME...M.......M...S.M..S. ( 550 / 3573) ...MS.......S.M....E.E..EET.M.M.....M..MM.S....... ( 600 / 3573) .E.S.T.E..S..MM..M.EM.E..E......S.MM...MM...M.M... ( 650 / 3573) .....M..M......EM..ESS.S.M.............M.....E..MS ( 700 / 3573) ....EM.........EE...........MMME.....E.M..MM..M... ( 750 / 3573) M.......EE...........M.......MMEMM..M...MM.M..M... ( 800 / 3573) ..M....................MMM...M...MM.........MM...M ( 850 / 3573) .SSM.......MM..M......E..SEMM....E.M..M.E..EM..ETM ( 900 / 3573) M.......EM.EM...SSSSSSSSSSSSSSSSSSSSSSSE.S.M...... ( 950 / 3573) .S..M.........MM........S......EE.E......E....EEE. (1000 / 3573) .S....SSM..E..S.E....TMSSSMM.........M.........E.S (1050 / 3573) EE..M....STM..M.......M.S......SM..........S.SM..S (1100 / 3573) ....MMMMM.MMM....M.....M.......M.SM...M.MMM.S..... (1150 / 3573) .E....E.M.E.....MM..MMMMMS.M........MMMMMM.......E (1200 / 3573) .EE....S.......................T......EEM.M.MM.... (1250 / 3573) ..SSMM.MM..MMMM.MMMMMMMM.......................... (1300 / 3573) ..E....E.......E..SSSSM..M.S.E..M............MMM.M (1350 / 3573) ......M.SMMM...............M...M.M......M.M.E..... (1400 / 3573) .MSM.........S.MMMMMMMMMM..........M.............. (1450 / 3573) ................M...............S..M.............. (1500 / 3573) ....M...............M.........M................M.. (1550 / 3573) ...........................M...................... (1600 / 3573) ..E......M...M...........M.MM.....SSSS..MMM..MM... (1650 / 3573) SSSSSSSSSSSSSSSSSSSSSSSSSSSSSSSSSSSMSMSE....M..MMM (1700 / 3573) M.M...M.MM........MM..M...M.SSSSSSSSSSSMM.MSSSSSSM (1750 / 3573) MMSSSSSSSSSSSSSSSSSSSSSSSS...MM............MMS.... (1800 / 3573) MMMMMM..S....M......MMM...SSSSSSSSSSSSSSSSSSSSSSSS (1850 / 3573) SSSSSSSM..S.....M........MS....................... (1900 / 3573) ............SSSS..MM.SSSSSSSSSSSSSSSSSSSSSSSS..... (1950 / 3573) .M.M..........SS.M.....SSSSS.....SSS.............. (2000 / 3573) .....M.S..SSSSSSS..SM...SSSSSSSS.MSM....MM.....M.. (2050 / 3573) ..SSSSSS..MMMSSSSSSSSSS..S.....M.MSSSS........SSSS (2100 / 3573) S....SSSSSSSS.MMM.SMSSSMM.M.......SSS...M....M..M. (2150 / 3573) MSM.MMS..MMM.M...SSS........M.......SS.S..SSSSSSSS (2200 / 3573) SSSSSSSSSSSSSSSSSS.S..MMMSSSSMS......MS....MM..SSS (2250 / 3573) SS...M........M.SSSSSSMM..MMM.MMM...M..MMTMTTSSSMM (2300 / 3573) S..S...........MSMSSS...SSSSSSSSSSSSSSSSSSSSSSSSSS (2350 / 3573) SSSSSSMMMMMSS.M.MMM.SSSSSSSSSSSSSSSSSSS.E......... (2400 / 3573) .................................................. (2450 / 3573) ......SS.....MS.......M.S.E...........M.M......... (2500 / 3573) ..M.M......M............SS.S.......M.......E.SSSSS (2550 / 3573) .................S....S.SS.SSS.S.SSSSS..M....SSSSS (2600 / 3573) E.SMMSMM....MMSMM......MSSSS.MMSS.....MMSSSS.SSSE. (2650 / 3573) ..S....EMMM.E......E.EEEM........SSSSSSEESSM..SSMS (2700 / 3573) ........SSSM.....MS.M.MM..SSM..E....M.SS.E...M..M. (2750 / 3573) .M.MM.......M..........MMMMMMM..S.....SSM..MM..... (2800 / 3573) .........M........SSS....EE....M........M...M...MS (2850 / 3573) .M.MM..MM..M.E...M....E...S.SE..M........S..MM.... (2900 / 3573) ...M...MS...S.....SS..E.EM......M.E.S.....ES...... (2950 / 3573) .....MMM......MM......M.......E.S.....EE.S.....E.. (3000 / 3573) M..M..........S.MM.....S............M........M.... (3050 / 3573) .........MMM.M.........M.....MM.....S.SMMS.S...... (3100 / 3573) ....M....M.M....S...M..M....SSSM...........M...... (3150 / 3573) .MME.S.M..M.E......M.........MSMMM.S.......MM.S..S (3200 / 3573) ..MSSSSMMM.SS..........................M.S........ (3250 / 3573) .....S............................S......SMMM..SSS (3300 / 3573) ..........M.MM.......M...MSS.S.S....MM.M...M...... (3350 / 3573) S.S...MSM........S......S.......MM........MM...... (3400 / 3573) ME..MMM..E..TM.....T....MS....E..E.E..T.E....MM... (3550 / 3573) .................MM.... (3573 / 3573) 3573 mutations were generated: 2322 mutants were killed 569 mutants were not covered by tests 526 covered mutants were not detected 140 errors were encountered 16 time outs were encountered Metrics: Mutation Score Indicator (MSI): 69% Mutation Code Coverage: 84% Covered Code MSI: 82% Please note that some mutants will inevitably be harmless (i.e. fa 14min 21s
  28. 70 You are running Infection with xdebug enabled. $ ./infection

    ____ ____ __ _ / _/___ / __/__ _____/ /_(_)___ ____ / // __ \/ /_/ _ \/ ___/ __/ / __ \/ __ \ _/ // / / / __/ __/ /__/ /_/ / /_/ / / / / /___/_/ /_/_/ \___/\___/\__/_/\____/_/ /_/ Running initial test suite... PHPUnit version: 7.0.2 678 [============================] 26 secs Generate mutants... Processing source code files: 144/144 Creating mutated files and processes: 3573/3573 .: killed, M: escaped, S: uncovered, E: fatal error, T: timed out .........M..MEEEM..MME.EEE.....MMM..MSE.....E..... ( 50 / 3573) E.E.ESS.E....SSSSSM.S...M........S.S.SS.....EM.E.. ( 100 / 3573) ....M..E....SMMMMMMMMMM...M..E.E..EM......M..MM... ( 150 / 3573)
  29. 71 ME..MMM..E..TM.....T....MS....E..E.E..T.E....MM... (3550 / 3573) .................MM.... (3573 / 3573) 3573

    mutations were generated: 2322 mutants were killed 569 mutants were not covered by tests 526 covered mutants were not detected 140 errors were encountered 16 time outs were encountered Metrics: Mutation Score Indicator (MSI): 69% Mutation Code Coverage: 84% Covered Code MSI: 82% Please note that some mutants will inevitably be harmless (i.e. false positives).
  30. 72 Escaped mutants: ================ 1) /path/to/Alias.php:68 [M] This exec /path/to/php

    -c /tmp/dir/infectionyy4H8n /path/to/phpunit --configuration /tmp/dir/infection/ phpunitConfiguration.bce05.infection.xml --stop-on-failure --- Original +++ New @@ @@ $this->private = (bool) $boolean; - return $this; + return null; } /** * Whether this alias is private. * * @return bool */ PHPUnit 7.0.2 by Sebastian Bergmann and contributors. ............................................................... 63 / 127 ( 49%) ............................................................... 126 / 127 ( 99%) . 127 / 127 (100%) Time: 374 ms, Memory: 14.00MB OK (127 tests, 438 assertions) REPORT
  31. RESTRICT THE FILES IT’S RUNNING ON 74 $ infection —-filter=DependencyInjection

    INFECTION_FILTER=$(git diff ${GIT_PREVIOUS_SUCCESSFUL_COMMIT:-origin/develop} \ $GIT_COMMIT --name-only \ | grep /src/ \ | paste -sd "," -) $ infection —-filter=$INFECTION_FILTER https://infection.github.io/guide/command-line-options.html $ infection —-min-covered-msi 70
  32. PROFILES 76 { "mutators": { "@default": true, "@function_signature": false, "TrueValue":

    { "ignore": [ “NameSpace\\*\\SourceClass::create", "Full\\NameSpaced\\Class" ] } } } infection.json.dist https://infection.github.io/guide/profiles.html
  33. 78 3573 mutations were generated: 2322 mutants were killed 569

    mutants were not covered by tests 526 covered mutants were not detected 140 errors were encountered 16 time outs were encountered Metrics: Mutation Score Indicator (MSI): 69% Mutation Code Coverage: 84% Covered Code MSI: 82% Time: 14min 20s 3004 mutations were generated: 2322 mutants were killed 0 mutants were not covered by tests 526 covered mutants were not detected 140 errors were encountered 16 time outs were encountered Metrics: Mutation Score Indicator (MSI): 82% Mutation Code Coverage: 100% Covered Code MSI: 82% Time: 6min 39s
  34. IT IS NOT NEW… - HISTORY • Begins in 1971,

    R. Lipton, “Fault Diagnosis of Computer Programs” • Generally accepted in 1978, R. Lipton and al, “Hints on test data selection: Help for the practicing programmer” 80
  35. WHY IS IT NOT WIDELY USED? Maturity Problem: Because testing

    is not widely used yet (Although it is increasing) 82
  36. WHY IS IT NOT WIDELY USED? Integration Problem: Inability to

    successfully integrated it into software development process (TDD plays a key role now) 83
  37. THEORETICAL RUN • 672 tests in 25.29 seconds • 3573

    mutants • 2,401,056 tests • ~53h With basic Mutation Testing 86
  38. 87

  39. OPTIMISATION STRATEGIES • Mutate only covered code • Incremental analysis

    • Parallelism • Equivalent mutant (~30%) • Different levels of requirements 88
  40. PHP FRAMEWORKS SUPPORT • PHPUnit • PhpSpec • Behat (#147)

    • Atoum (#381) • CodeCeption (#45) 92 ✅ ✅
  41. EQUIVALENT MUTANT 93 - $x = $a + $b; +

    $x = $a - (-$b); - if ($nbr >= 10) { + if ($nbr > 10) { - if ($nbr >= 10) { + if ($nbr >= 9) { ~30% of mutants
  42. SMART MUTATORS 94 <?php declare(strict_types = 1); class X {

    function foo(string $a, string $b): boolean { - return $a === $b; + return $a == $b; } }
  43. { "mutators": { "@default": true, "@function_signature": false, "TrueValue": { "ignore":

    [ “NameSpace\\*\\SourceClass::create", "Full\\NameSpaced\\Class" ] } } } infection.json.dist GRANULAR CONFIGURATION 95
  44. THE GOOD PARTS • Gives you feedback on your tests

    • Test your tests with little effort • They are automatic • They discover dead code (e.g. useless tests) • Helps to refactor your tests 99
  45. THE NOT SO GOOD PARTS • Can be slow •

    Handful of young libraries • Writing smart mutants is difficult • Side effects with integration tests 100
  46. PERSONAL EXPERIENCE • Forces you to write tests • Always

    find bugs • Helpful for non-devs 101
