  1. DESIGN PATTERNS AND THE HAPPY DEV FRIENDS WHY SHOULD WE

    USE THEM? ▸ Almost ready-to-use solutions ▸ Generic ▸ Increases decoupling ▸ Favors testing ▸ Android already uses a bunch of them
  2. ANDROIDNE.WS Hey, I have news! Oh-hi Android news! MOAR news!

    Such Androids! I’m no longer interested!
  3. OBSERVER/OBSERVABLE OBSERVER interface Observer<T> { fun onDataChanged(data : T) }

    class SimpleObserver : Observer<Int> { override fun onDataChanged(data : Int) { … } }
  4. OBSERVER/OBSERVABLE OBSERVABLE interface Observable<T> { fun addObserver(observer : Observer<T>) }

    class SimpleObservable : Observable<T> { override fun addObserver(observer : Observer<T>) { observers.add(observer) } fun doThings() { val d = 3 observers.forEach { it.onDataChanged(d) } } }
  5. OBSERVER/OBSERVABLE HOW TO USE IT val observer1 = SimpleObserver() val

    observer2 = SimpleObserver() val observable = SimpleObservable() observable.addObserver(observer1) observable.addObserver(observer2) … observable.doThings()
  6. STATIC FACTORY METHOD FACTORY class Robot private constructor(private val serialNumber:

    Int) { companion object { var serialNumber: Int = 0 fun createRobot(): Robot = Robot(serialNumber++) } } // How to use it val someRobot = Robot.createRobot()
  7. STATIC FACTORY METHOD FACTORY class Robot private constructor(private val serialNumber:

    Int) { companion object { var serialNumber: Int = 0 fun createRobot(): Robot = Robot(serialNumber++) } } // How to use it val someRobot = Robot.createRobot()
  8. STATIC FACTORY METHOD FACTORY class Robot private constructor(private val serialNumber:

    Int) { companion object { var serialNumber: Int = 0 fun createRobot(): Robot = Robot(serialNumber++) } } // How to use it val someRobot = Robot.createRobot()
  9. STATIC FACTORY METHOD FACTORY class Robot private constructor(private val serialNumber:

    Int) { companion object { var serialNumber: Int = 0 fun createRobot(): Robot = Robot(serialNumber++) } } // How to use it val someRobot = Robot.createRobot()
  10. STATIC FACTORY METHOD FACTORY class Robot private constructor(private val serialNumber:

    Int) { companion object { var serialNumber: Int = 0 fun createRobot(): Robot = Robot(serialNumber++) } } // How to use it val someRobot = Robot.createRobot()
  11. STATIC FACTORY METHOD FACTORY class Robot private constructor(private val serialNumber:

    Int) { companion object { var serialNumber: Int = 0 fun createRobot(): Robot = Robot(serialNumber++) } } // How to use it val someRobot = Robot.createRobot()
  12. STATIC FACTORY ‣ Not really a pattern ‣ Controls the

    creation of objects ‣ Widely spread across Java/Android Calendar.getInstance() String.format() SomeFragment.newInstance() ಠ_ಠ
  13. FACTORY PATTERN FACTORY interface Robot class Nestor4_Factory : RobotFactory {

    override fun createRobot(): Robot = Nestor4_Robot() private class Nestor4_Robot: Robot } interface RobotFactory { fun createRobot(): Robot }
  14. FACTORY PATTERN FACTORY interface Robot class Nestor4_Factory : RobotFactory {

    override fun createRobot(): Robot = Nestor4_Robot() private class Nestor4_Robot: Robot } interface RobotFactory { fun createRobot(): Robot }
  15. FACTORY PATTERN FACTORY interface Robot class Nestor4_Factory : RobotFactory {

    override fun createRobot(): Robot = Nestor4_Robot() private class Nestor4_Robot: Robot } interface RobotFactory { fun createRobot(): Robot }
  16. FACTORY PATTERN FACTORY interface Robot class Nestor4_Factory : RobotFactory {

    override fun createRobot(): Robot = Nestor4_Robot() private class Nestor4_Robot: Robot } interface RobotFactory { fun createRobot(): Robot }
  17. FACTORY PATTERN FACTORY interface Robot class Nestor4_Factory : RobotFactory {

    override fun createRobot(): Robot = Nestor4_Robot() private class Nestor4_Robot: Robot } interface RobotFactory { fun createRobot(): Robot }
  18. FACTORY PATTERN HOW TO USE IT // U.S. Robots and

    Mechanical Men class USR { private val factory : RobotFactory = Nestor4_Factory() fun produceRobots(quantity: Int): List<Robot> = List(quantity) { factory.createRobot() } } fun main(args: Array<String>) { val usr = USR() // will produce a thousand robots usr.produceRobots(1000) }
  19. FACTORY PATTERN HOW TO USE IT // U.S. Robots and

    Mechanical Men class USR { private val factory : RobotFactory = Nestor4_Factory() fun produceRobots(quantity: Int): List<Robot> = List(quantity) { factory.createRobot() } } fun main(args: Array<String>) { val usr = USR() // will produce a thousand robots usr.produceRobots(1000) }
  20. FACTORY PATTERN HOW TO USE IT // U.S. Robots and

    Mechanical Men class USR { private val factory : RobotFactory = Nestor4_Factory() fun produceRobots(quantity: Int): List<Robot> = List(quantity) { factory.createRobot() } } fun main(args: Array<String>) { val usr = USR() // will produce a thousand robots usr.produceRobots(1000) }
  21. FACTORY PATTERN HOW TO USE IT // U.S. Robots and

    Mechanical Men class USR { private val factory : RobotFactory = Nestor4_Factory() fun produceRobots(quantity: Int): List<Robot> = List(quantity) { factory.createRobot() } } fun main(args: Array<String>) { val usr = USR() // will produce a thousand robots usr.produceRobots(1000) }
  22. FACTORY PATTERN HOW TO USE IT // U.S. Robots and

    Mechanical Men class USR { private val factory : RobotFactory = Nestor4_Factory() fun produceRobots(quantity: Int): List<Robot> = List(quantity) { factory.createRobot() } } fun main(args: Array<String>) { val usr = USR() // will produce a thousand robots usr.produceRobots(1000) }
  23. FACTORY PATTERN FACTORY interface Robot class Nestor4_Factory : RobotFactory {

    fun createRobot(): Robot = Nestor4_Robot() private class Nestor4_Robot: Robot } interface RobotFactory { fun createRobot(): Robot }
  24. FACTORY PATTERN FACTORY class Nestor4_Factory : RobotFactory { fun createRobot():

    Robot = Nestor4_Robot() private class Nestor4_Robot: Robot } class Nestor5_Factory : RobotFactory { fun createRobot(): Robot = Nestor5_Robot() private class Nestor5_Robot: Robot }
  25. FACTORY PATTERN FACTORY class Nestor4_Factory : RobotFactory { @Suppress(“unused”) fun

    createRobot(): Robot = Nestor4_Robot() private class Nestor4_Robot: Robot } class Nestor5_Factory : RobotFactory { fun createRobot(): Robot = Nestor5_Robot() private class Nestor5_Robot: Robot }
  26. FACTORY PATTERN HOW TO USE IT // U.S. Robots and

    Mechanical Men class USR { private val factory : RobotFactory = Nestor4_Factory() fun produceRobots(quantity: Int): List<Robot> = List(quantity) { factory.createRobot() } } fun main(args: Array<String>) { val usr = USR() // will produce a thousand robots usr.produceRobots(1000) }
  27. FACTORY PATTERN HOW TO USE IT // U.S. Robots and

    Mechanical Men class USR { private val factory : RobotFactory = Nestor5_Factory() fun produceRobots(quantity: Int): List<Robot> = List(quantity) { factory.createRobot() } } fun main(args: Array<String>) { val usr = USR() // will still produce a thousand robots usr.produceRobots(1000) }
  28. FACTORY ‣ Creational ‣ Decoupling ‣ Inheritance Define an interface

    for creating an object, but let the classes which implement the interface decide which class to instantiate.
  29. FACTORY ‣ Editable.Factory ‣ Context.getSystemService() ‣ LayoutInflater.Factory Define an interface

    for creating an object, but let the classes which implement the interface decide which class to instantiate.
  30. BUILDER PATTERN INTERFACES // just a car interface Car //

    boost interface Boost object NOS: Boost // color of the exterior interface BodyColor object Orange: BodyColor object Blue: BodyColor // engine interface Engine object StockEngine: Engine object SuperPumpedEngine: Engine
  31. BUILDER PATTERN TARGET class QuarterMileCar private constructor( val boost: Boost?

    = null, val color: BodyColor = Orange, val engine: Engine = StockEngine ) : Car { // Builder goes here }
  32. BUILDER PATTERN TARGET class QuarterMileCar private constructor( val boost: Boost?

    = null, val color: BodyColor = Orange, val engine: Engine = StockEngine ) : Car { // Builder goes here }
  33. BUILDER PATTERN BUILDER class Builder { private var boost: Boost?

    = null private var color: BodyColor = Orange private var engine: Engine = StockEngine fun withBoost(boost: Boost): Builder { this.boost = boost return this } fun withColor(color: BodyColor): Builder { this.color = color return this } fun withEngine(engine: Engine): Builder { this.engine = engine return this } fun build(): QuarterMileCar = QuarterMileCar(boost, color, engine) }
  34. BUILDER PATTERN BUILDER class Builder { private var boost: Boost?

    = null private var color: BodyColor = Orange private var engine: Engine = StockEngine fun withBoost(boost: Boost): Builder { this.boost = boost return this } fun withColor(color: BodyColor): Builder { this.color = color return this } fun withEngine(engine: Engine): Builder { this.engine = engine return this } fun build(): QuarterMileCar = QuarterMileCar(boost, color, engine) }
  35. FACTORY PATTERN HOW TO USE IT fun main(args: Array<String>) {

    val supra = QuarterMileCar.Builder() .withBoost(NOS) .withColor(Orange) .withEngine(SuperPumpedEngine) .build() }
  36. FACTORY PATTERN HOW TO USE IT fun main(args: Array<String>) {

    val supra = QuarterMileCar.Builder() .withBoost(NOS) .withColor(Blue) .withEngine(SuperPumpedEngine) .build() }
  37. FACTORY PATTERN HOW TO USE IT fun main(args: Array<String>) {

    val s2000 = QuarterMileCar.Builder() .withEngine(SuperPumpedEngine) .build() }
  38. BUILDER PATTERN BUILDER class Builder { private var boost: Boost?

    = null private var color: BodyColor = Orange private var engine: Engine = StockEngine fun withBoost(boost: Boost): Builder { this.boost = boost return this } fun withColor(color: BodyColor): Builder { this.color = color return this } fun withEngine(engine: Engine): Builder { this.engine = engine return this } fun build(): QuarterMileCar = QuarterMileCar(boost, color, engine) }
  39. BUILDER PATTERN BUILDER <3 KOTLIN class QuarterMileCar private constructor( //

    constructor params ) : Car { class Builder { private var boost: Boost? = null private var color: BodyColor = Orange private var engine: Engine = StockEngine fun withBoost(boost: Boost) = apply { this.boost = boost } fun withColor(color: BodyColor) = apply { this.color = color } fun withEngine(engine: Engine) = apply { this.engine = engine } fun build() = QuarterMileCar(boost, color, engine) } }
  40. BUILDER ‣ Decoupling/Encapsulation ‣ Step-by-step control ‣ Immutability! The intent

    of the Builder design pattern is to separate the construction of a complex object from its representation. By doing so the same construction process can create different representations.
  41. BUILDER ‣ [insert_library_from_Square_here] ‣ AlertDialog.Builder ‣ … The intent of

    the Builder design pattern is to separate the construction of a complex object from its representation. By doing so the same construction process can create different representations.
  42. CHAIN OF RESPONSIBILITY when(x) {
 1 -> doThis()
 2 ->

    doThat()
 else -> crashPainfully()
 }
  43. CHAIN OF RESPONSIBILITY DRAWBACKS ▸ Execute more than one branch

    ▸ Testing ▸ Complex conditions ▸ Possible violation of SRP
  44. CHAIN OF RESPONSIBILITY BASICS abstract class Base<T> {
 lateinit var

    next : Base<T>

 fun onEvent(data : T) {
 if (canManage(data)) {
 doManage(data)
 } else {
 next.onEvent(data)
 }
 }

 abstract fun canManage(data: T): Boolean
 abstract fun doManage(data: T)
 }
  45. CHAIN OF RESPONSIBILITY BASICS abstract class Base<T> {
 lateinit var

    next : Base<T>

 fun onEvent(data : T) {
 if (canManage(data)) {
 doManage(data)
 } else {
 next.onEvent(data)
 }
 }

 abstract fun canManage(data: T): Boolean
 abstract fun doManage(data: T)
 }
  46. CHAIN OF RESPONSIBILITY BASICS abstract class Base<T> {
 lateinit var

    next : Base<T>

 fun onEvent(data : T) {
 if (canManage(data)) {
 doManage(data)
 } else {
 next.onEvent(data)
 }
 }

 abstract fun canManage(data: T): Boolean
 abstract fun doManage(data: T)
 }
  47. CHAIN OF RESPONSIBILITY BASICS abstract class Base<T> {
 lateinit var

    next : Base<T>

 fun onEvent(data : T) {
 if (canManage(data)) {
 doManage(data)
 } else {
 next.onEvent(data)
 }
 }

 abstract fun canManage(data: T): Boolean
 abstract fun doManage(data: T)
 }
  48. CHAIN OF RESPONSIBILITY BASICS abstract class Base<T> {
 lateinit var

    next : Base<T>

 fun onEvent(data : T) {
 if (canManage(data)) {
 doManage(data)
 } else {
 next.onEvent(data)
 }
 }

 abstract fun canManage(data: T): Boolean
 abstract fun doManage(data: T)
 }
  49. CHAIN OF RESPONSIBILITY MAKING IT WORK class One : Base<Int>()

    { override fun canManage(data: Int) = data == 1 override fun doManage(data: Int) { // do amazing stuff here } }
  50. CHAIN OF RESPONSIBILITY MAKING IT WORK class One : Base<Int>()

    { override fun canManage(data: Int) = data == 1 override fun doManage(data: Int) { // do amazing stuff here } }
  51. CHAIN OF RESPONSIBILITY MAKING IT WORK class One : Base<Int>()

    { override fun canManage(data: Int) = data == 1 override fun doManage(data: Int) { // do amazing stuff here } }
  52. CHAIN OF RESPONSIBILITY MAKING IT WORK val chain = One()

    chain.next = Two() chain.onEvent(evt)
  53. CHAIN OF RESPONSIBILITY PROS ▸ Decouples senders and receivers ▸

    Simplifies the object ▸ Dynamically add & remove responsibilities
  54. USE A DESIGN EXPECTING ONE INTERFACE WITH A CLASS THAT

    IMPLEMENTS A DIFFERENT ONE ADAPTER
  55. ADAPTER LETS CLASSES WORK TOGETHER THAT COULDN’T OTHERWISE BECAUSE OF

    INCOMPATIBLE INTERFACES Someone who understood the previous slide ADAPTER
  56. ADAPTER interface LegacySystem { fun accept(legacyData : LegacyData) } interface

    LegacyData { fun byteCount() : Long fun data() : String }
  57. ADAPTER interface LegacySystem { fun accept(legacyData : LegacyData) } interface

    LegacyData { fun byteCount() : Long fun data() : String } interface NewData { fun theData() : String }
  58. ADAPTER interface LegacySystem { fun accept(legacyData : LegacyData) } interface

    LegacyData { fun byteCount() : Long fun data() : String } interface NewData { fun theData() : String }
  59. ADAPTER class Adapter (val wrapped : NewData) : LegacyData {

    override fun byteCount() = wrapped.theData.bytes.length override fun data() = wrapped.theData }
  60. ADAPTER class Adapter (val wrapped : NewData) : LegacyData{ override

    fun byteCount() = wrapped.theData.bytes.length override fun data() = wrapped.theData }
  61. ADAPTER class Adapter (val wrapped : NewData) : LegacyData{ override

    fun byteCount() = wrapped.theData.bytes.length override fun data() = wrapped.theData }
  62. FLYWEIGHT SOMETHING ABOUT IT ▸ One instance to control them

    all ▸ Used when more instances can be controlled identically ▸ Single instances cannot be controlled independently
  63. DECORATOR BASE class Tony implements Hero { final int badassLevel;

    Tony(int badassLevel) { this.badassLevel = badassLevel; } @Override int badassLevel() { return badassLevel; } }
  64. DECORATOR BASE class Tony implements Hero { final int badassLevel;

    Tony(int badassLevel) { this.badassLevel = badassLevel; } @Override int badassLevel() { return badassLevel; } }
  65. DECORATOR DECORATOR class IronMan implements Hero { final Hero hero;

    IronMan(Hero hero) { this.hero = hero; } @Override int badassLevel() { return 2 * hero.badassLevel(); } }
  66. DECORATOR HOW TO USE IT Hero tony = new Tony(100);

    Hero ironMan = new IronMan(tony);
  67. DECORATOR DECORATOR class HulkBuster implements Hero { final Hero hero;

    HulkSmasher(Hero hero) { this.hero = hero; } @Override int badassLevel() { return 3 * hero.badassLevel() + 1; } }
  68. DECORATOR HOW TO USE IT Hero tony = new Tony(100);

    Hero ironMan = new IronMan(tony); Hero hulkBuster = new HulkBuster(ironMan);
  69. DECORATOR HOW TO USE IT Hero tony = new Tony(100);

    Hero hulkBuster = new HulkBuster(tony);
  70. DECORATOR HOW TO USE IT Hero tony = new Tony(100);

    Hero hulkBuster = new HulkBuster(tony); Hero ironMan = new IronMan(hulkBuster);
  71. DECORATOR HOW TO USE IT Hero tony = new Tony(100);

    new IronMan(new HulkBuster(new IronMan(tony)));
  72. REPOSITORY PATTERN REPOSITORY interface Repository<T> { fun add(item: T) fun

    add(items: List<T>) fun delete(item: T) fun update(item: T) fun query(specification: QuerySpec<T>): List<T> } interface QuerySpec<T> { fun getResults(items: List<T>): List<T> }
  73. REPOSITORY PATTERN REPOSITORY interface Repository<T> { fun add(item: T) fun

    add(items: List<T>) fun delete(item: T) fun update(item: T) fun query(specification: QuerySpec<T>): List<T> } interface QuerySpec<T> { fun getResults(items: List<T>): List<T> }
  74. REPOSITORY PATTERN REPOSITORY interface Repository<T> { fun add(item: T) fun

    add(items: List<T>) fun delete(item: T) fun update(item: T) fun query(specification: QuerySpec<T>): List<T> } interface QuerySpec<T> { fun getResults(items: List<T>): List<T> }
  75. REPOSITORY PATTERN REPOSITORY interface Repository<T> { fun add(item: T) fun

    add(items: List<T>) fun delete(item: T) fun update(item: T) fun query(specification: QuerySpec<T>): List<T> } interface QuerySpec<T> { fun getResults(items: List<T>): List<T> }
  76. REPOSITORY PATTERN MODEL class DroidconItSpeakers : Repository<Speaker> { private val

    list: MutableList<Speaker> = mutableListOf() override fun add(item: Speaker) { if (!list.contains(item)) { list.add(item) } } override fun add(items: List<Speaker>) { ... } override fun delete(item: Speaker) { list.remove(item) } override fun update(item: Speaker) { ... } override fun query(specification: QuerySpec<Speaker>): List<Speaker> = specification.getResults(list) }
  77. REPOSITORY PATTERN MODEL class DroidconItSpeakers : Repository<Speaker> { private val

    list: MutableList<Speaker> = mutableListOf() override fun add(item: Speaker) { if (!list.contains(item)) { list.add(item) } } override fun add(items: List<Speaker>) { ... } override fun delete(item: Speaker) { list.remove(item) } override fun update(item: Speaker) { ... } override fun query(specification: QuerySpec<Speaker>): List<Speaker> = specification.getResults(list) }
  78. REPOSITORY PATTERN MODEL class DroidconItSpeakers : Repository<Speaker> { private val

    list: MutableList<Speaker> = mutableListOf() override fun add(item: Speaker) { if (!list.contains(item)) { list.add(item) } } override fun add(items: List<Speaker>) { ... } override fun delete(item: Speaker) { list.remove(item) } override fun update(item: Speaker) { ... } override fun query(specification: QuerySpec<Speaker>): List<Speaker> = specification.getResults(list) }
  79. REPOSITORY PATTERN MODEL class DroidconItSpeakers : Repository<Speaker> { private val

    list: MutableList<Speaker> = mutableListOf() override fun add(item: Speaker) { if (!list.contains(item)) { list.add(item) } } override fun add(items: List<Speaker>) { ... } override fun delete(item: Speaker) { list.remove(item) } override fun update(item: Speaker) { ... } override fun query(specification: QuerySpec<Speaker>): List<Speaker> = specification.getResults(list) }
  80. REPOSITORY PATTERN QUERY object GetAllTheSebastianos : QuerySpec<Speaker> { override fun

    getResults(items: List<Speaker>): List<Speaker> = items.filter { it.name.startsWith("Sebastiano") } }
  81. REPOSITORY PATTERN QUERY object GetAllTheSebastianos : QuerySpec<Speaker> { override fun

    getResults(items: List<Speaker>): List<Speaker> = items.filter { it.name.startsWith("Sebastiano") } }
  82. REPOSITORY PATTERN QUERY object GetAllTheSebastianos : QuerySpec<Speaker> { override fun

    getResults(items: List<Speaker>): List<Speaker> = items.filter { it.name.startsWith("Sebastiano") } }
  83. REPOSITORY PATTERN MODEL class DroidconItSpeakers : Repository<Speaker> { private val

    list: MutableList<Speaker> = mutableListOf() override fun add(item: Speaker) { ... } override fun add(items: List<Speaker>) { ... } override fun delete(item: Speaker) { ... } override fun update(item: Speaker) { ... } override fun query(specification: QuerySpec<Speaker>) { ... } }
  84. REPOSITORY PATTERN MODEL class DroidconItSpeakers : Repository<Speaker> { private val

    sharedPrefs: SharedPreference override fun add(item: Speaker) { ... } override fun add(items: List<Speaker>) { ... } override fun delete(item: Speaker) { ... } override fun update(item: Speaker) { ... } override fun query(specification: QuerySpec<Speaker>) { ... } }
  85. REPOSITORY PATTERN MODEL class DroidconItSpeakers : Repository<Speaker> { private val

    database: SQLiteDatabase override fun add(item: Speaker) { ... } override fun add(items: List<Speaker>) { ... } override fun delete(item: Speaker) { ... } override fun update(item: Speaker) { ... } override fun query(specification: QuerySpec<Speaker>) { ... } }
  86. REPOSITORY ‣ Isolation ‣ Strong typing for reliability ‣ Testability

    The repository is a central place where data is stored and maintained.
  87. SIMPLIFIES AN INTERFACE BY HIDING ALL THE COMPLEXITY BEHIND A

    CLEAN FACADE Someone who loves facades FACADE PATTERN
  88. FACADE VS ADAPTER both may wrap different classes simplify vs

    convert PLUS easier and unified access to the subsystem
