Control your Nest with Google App Engine PHP

An introduction to the promise and problems of working with Nest from PHP on Google App Engine

Transcript

1. CONTROL YOUR NEST WITH GOOGLE APP ENGINE (PHP) Terrence Ryan @tpryan
2. Who are you?
3. What is NEST? • Nest makes • Thermostats • Smoke and CO Alarms
5. What you need • Nest device • Nest developer account • Nest developer client • Firebase client • Javascript • iOS • Android OR • REST API
6. REST
7. Getting started with OAuth
8. No, no, it’s OAuth 2
9. Process client_id state https://home.nest.com/login/oauth2
10. Process client_id state https://home.nest.com/login/oauth2
11. Process code state https://<your site>/<nest_handler>
12. Process code client_id client_secret https://api.home.nest.com/oauth2/access_token
13. Process oauth token
14. Process oauth token API request
15. Let’s get to work
16. API organization Structures Devices Alarms Thermostats
17. Read all the data $access_token = <OAUTH TOKEN>; $base_url = "https://developer-api.nest.com"; $path = ''; $auth = '/?auth=' . $access_token; ! $api_url = $base_url . $path . $auth; $results = file_get_contents($api_url, false);
18. Read all the data (results) { "devices": { "thermostats": { "peyiJNo0IldT2YlIVtYaGQ": { "device_id": "peyiJNo0IldT2YlIVtYaGQ" , ... } } , "smoke_co_alarms": { "RTMTKxsQTCxzVcsySOHPxKoF4OyCifrs": { "device_id": "RTMTKxsQTCxzVcsySOHPxKoF4OyCifrs" , ... } } } , "structures": { "VqFabWH21nwVyd4RWgJgNb292wa7hG_dUwo2i2SG7j3-BOLY0BA4sw": { "structure_id": "VqFabWH21nwVyd4RWgJgNb292wa7hG_dUwo2i2SG7j3-BOLY0BA4sw" , "thermostats": [ "peyiJNo0IldT2YlIVtYaGQ", ... ] , "smoke_co_alarms": [ "RTMTKxsQTCxzVcsySOHPxKoF4OyCifrs", ... ] , ... } } } }
19. Read all the thermostats $access_token = <OAUTH TOKEN>; $base_url = "https://developer-api.nest.com"; $path = '/devices/thermostats'; $auth = '/?auth=' . $access_token; ! $api_url = $base_url . $path . $auth; $results = file_get_contents($api_url, false); ! ! ! !
20. Read all the thermostats (results) { "peyiJNo0IldT2YlIVtYaGQ": { "device_id": "peyiJNo0IldT2YlIVtYaGQ" , "locale": "en-US" , "software_version": "4.0" , "structure_id": "VqFabWH21nwVyd4RWgJgNb292wa7hG_dUwo2i2SG7j3-BOLY0BA4sw" , "name": "Hallway (upstairs)" , "name_long": "Hallway Thermostat (upstairs)" , "last_connection": "2014-03-02T23:20:19+00:00" , "is_online": true , "can_cool": true , "can_heat": true , "is_using_emergency_heat": true , "has_fan": true , "fan_timer_active": true , "fan_timer_timeout": "2014-03-02T23:20:19+00:00" , "has_leaf": true , "temperature_scale": "C" , "target_temperature_f": 72 , "target_temperature_c": 21.5 , "target_temperature_high_f": 72 , "target_temperature_high_c": 21.5 , "target_temperature_low_f": 64 , "target_temperature_low_c": 17.5 , "away_temperature_high_f": 72 , "away_temperature_high_c": 21.5 , "away_temperature_low_f": 64 , "away_temperature_low_c": 17.5 , "hvac_mode": "heat" , "ambient_temperature_f": 72 , "ambient_temperature_c": 21.5 } }
21. How you would really use it. $access_token = <OAUTH TOKEN>; ! $device_id = <UNIQUE ID>; ! $base_url = "https://developer-api.nest.com"; $path = '/devices/thermostats/'.$device_id.'/target_temperature_f'; $auth = '/?auth=' . $access_token; ! $api_url = $base_url . $path . $auth; $results = file_get_contents($api_url, false); ! ! ! ! ! !
22. How you would really use it. (results) 73 ! ! ! ! ! !
23. Set the temperature $access_token = <OAUTH TOKEN>; ! $device_id = <UNIQUE ID>; ! $base_url = "https://developer-api.nest.com"; $path = '/devices/thermostats/'.$device_id.'/target_temperature_f'; $auth = '/?auth=' . $access_token; $url = $base_url . $path . $auth; ! ! $ch = curl_init($url); curl_setopt($ch, CURLOPT_CUSTOMREQUEST, "PUT"); curl_setopt($ch, CURLOPT_POSTFIELDS, '70'); curl_setopt($ch, CURLOPT_FOLLOWLOCATION, 1); curl_setopt($ch, CURLOPT_RETURNTRANSFER, 1); curl_exec($ch); ! Doesn’t Work
24. $access_token = <OAUTH TOKEN>; ! $device_id = <UNIQUE ID>; ! $base_url = "https://developer-api.nest.com"; $path = '/devices/thermostats/'.$device_id.'/target_temperature_f'; $auth = '/?auth=' . $access_token; $url = $base_url . $path . $auth; ! $context = [ 'http' => [ 'method' => 'PUT', 'follow_location' => true, 'content' => '70' ] ]; ! $context = stream_context_create($context); $result = file_get_contents($url, false, $context); Set the temperature $access_token = <OAUTH TOKEN>; ! $device_id = <UNIQUE ID>; ! $base_url = "https://developer-api.nest.com"; $path = '/devices/thermostats/'.$device_id.'/target_temperature_f'; $auth = '/?auth=' . $access_token; $url = $base_url . $path . $auth; ! $context = [ 'http' => [ 'method' => 'PUT', 'follow_location' => true, 'content' => '70' ] ]; ! $context = stream_context_create($context); $result = file_get_contents($url, false, $context); Doesn’t Work
25. Set the temperature $access_token = <OAUTH TOKEN>; $device_id = <UNIQUE ID>; ! $base_url = "https://developer-api.nest.com"; $path = '/devices/thermostats/'.$device_id.'/target_temperature_f'; $auth = '/?auth=' . $access_token; $url = $base_url . $path . $auth; ! $context = [ 'http' => [ 'method' => 'PUT', 'follow_location' => false, 'content' => '73' ] ]; ! $status_code = 0; $attempts = 0; $context = stream_context_create($context); ! while (($status_code != 200) && $attempts <= 3 ){ $attempts++; $result =file_get_contents($url, false, $context); $response_headers = processHeaders($http_response_header); $status_code = $response_headers['status_code']; $url = $response_headers['location']; } Sorta Works
26. Set the temperature $access_token = <OAUTH TOKEN>; $device_id = <UNIQUE ID>; ! $base_url = "https://developer-api.nest.com"; $path = '/devices/thermostats/'.$device_id.'/target_temperature_f'; $auth = '/?auth=' . $access_token; $url = $base_url . $path . $auth; ! $context = [ 'http' => [ 'method' => 'PUT', 'follow_location' => false, 'ignore_errors' => true, 'content' => '73' ] ]; ! $status_code = 0; $attempts = 0; $context = stream_context_create($context); ! while (($status_code != 200) && $attempts <= 3 ){ $attempts++; $result = json_decode(@file_get_contents($url, false, $context)); $response_headers = processHeaders($http_response_header); $status_code = $response_headers['status_code']; $url = $response_headers['location']; if ($status_code == 400){ break; } }
27. What can you set? Thermostat • fan_timer_active • target_temperature_f • target_temperature_c • target_temperature_high_f • target_temperature_high_c • target_temperature_low_f • target_temperature_low_c • hvac_mode Structure • away • eta Smoke and CO Alarm • nothing
28. -paraphrased from Jeff Goldblum “You can, Should you?”
29. Technical Limitations • REST calls are single shots • Streaming REST not a good match for PHP • REST API is severely rate limited
30. Policy Limitations • Most attributes are read only • You many not retain data for more than 10 days
31. Result • Nest apps are about: • Real time • Responding to Nest • Not making Nest respond
32. What is it good for? • Existing PHP apps • Quick easy experimentation
33. What’s the better choice? • Javascript client • Real time enabled • Super simple
34. Javascript Client function initNest(){ var nest_token = getCookie('nest_token'); dataRef = new Firebase('wss://developer-api.nest.com'); dataRef.auth(nest_token); dataRef.on("value", readThermostatTemp); } ! function processTempChange(e){ var device_id = e.target.name; var target_value = parseInt(e.target.value); var path = "devices/thermostats/" + device_id + "/target_temperature_f"; dataRef.child(path).set(target_value); } ! function processNestTempChange(e){ var device = e.val(); var device_id = device.device_id; var newvalue = device.target_temperature_f; var el = document.querySelector("#" + device_id); el.value = newvalue; }
35. Conclusions Consider using Firebase Remember the limitations Use for existing apps Don’t mess with Nest’s rep
36. Questions? • terry@terrenceryan.com • http://terrenceryan.com • Twitter: @tpryan • Code at
 https://github.com/tpryan/Nest-Demo-Client
