Transcript
Superficial Fascia
Dorsal venous arch
Cephalic vein Basilic vein
Superficial radial nerve Dorsal cutaneous branch of ulnar nerve
Extensor Retinaculum (Page 140)
Extensor retinaculum
Structures deep to Extensor Retinaculum
1-Abductor pollicis longus & extensor pollicis brevis 2-Tendons of extensor
carpi radialis longus & brevi 3-Tendon of ext. pollicis longus 4-Tendons of extensor digitorum 4-Tendon of extensor indicis 5-Tendon of extensor digiti minimi 6-Tendon of extensor carpi ulnaris Dorsal tubercle of Lister Dr. Sherif Fahmy
Structures Superficial to Extensor Retinaculum
Superficial radial nerve Dorsal cutaneous branch of ulnar nerve
Cephalic vein Basilic vein
Anatomical Snuff Box (Page 142)
Anatomical snuff box
None
Boundaries
Tendon of abductor pollicis longus Tendon of extensor pollicis brevis
Tendon of extensor pollicis longus Boundaries of anatomical snuff box Lat. Med.
Roof
Superficial radial nerve
Cephalic vein
Floor
Trapezium Scaphoid Styloid process of radius
Contents
Radial artery Contents of anatomical snuff box Tendons of extensor
carpi radialis ms.
Radial Artery in the Dorsum of Hand
Radial artery Posterior (dorsal) carpal arch 2nd, 3rd and 4th
dorsal metacarpal arteries Dorsal digital artery 1st dorsal metacarpal artery 1st dorsal interosseous muscle
Tendons on the Dorsum of Hand
Extensor retinaculum Synovial sheath around tendons of extensor digitorm Tendinous
interconnections
Extensor Expansion
Extensor expansion
