  1. CRAIG STUNTZ
    PROJECT
    DATE CLIENT
    2015.01.08
    YOUR FLYING CAR IS READY
    AMAZING PROGRAMMING TOOLS FROM THE FUTURE, TODAY!
    https://www.flickr.com/photos/ellenm1/7847402208

    View Slide

  2. SLIDES https://speakerdeck.com/craigstuntz/
    Slides are already online.
    Also, call me on jargon.
    Ask “who cares?”

    View Slide

  3. “THE FUTURE IS
    ALREADY HERE —
    IT’S JUST NOT
    VERY EVENLY
    DISTRIBUTED.”
    WILLIAM GIBSON
    I have a lot of quotes on slides. I’ll give you some time to read them, but I won’t read them aloud.
    Spoilers alert! Here’s the whole talk.
    1. The software we use today is mostly broken; solves the wrong problem incorrectly.
    2. Software is broken for a reason: we verify the wrong things.
    3. It’s possible to produce software which solves harder problems and isn’t broken.
    4. The way to do better exists and is used to produce software you use every day.

    View Slide

  4. “A LANGUAGE THAT
    DOESN'T AFFECT THE
    WAY YOU THINK ABOUT
    PROGRAMMING, IS
    NOT WORTH
    KNOWING.”
    ALAN PERLIS
    EPIGRAMS IN
    PROGRAMMING
    https://www.flickr.com/photos/randyread/2385812579
    Will talk about tools most people don’t know exist, when it makes sense to use them. When not. “All languages are the same, just syntax.” I disagree.

    View Slide

  5. Like Testing, But Better
    http://fsharpforfunandprofit.com/posts/low-risk-ways-to-use-fsharp-at-work-3/
    Why is this so? Consider unit tests. You’ve all written unit tests… right?
    Devil’s advocate: Why are unit tests useful? They’re just “more code.” Doesn’t that make maintenance worse?
    Value is approaching problem differently; tests value verification of correctness over working algorithm
    New languages do this even better!

    View Slide

  6. “You theorized a machine that could solve any
    problem. It didn’t just do one thing; it did everything.”

    (fictional) Joan Clarke to (fictional) Alan Turing

    The Imitation Game (2014)
    http://theimitationgamemovie.com/#blog/104786411214
    Misunderstanding Turing
    Completeness
    Here’s a quote from a Hollywood movie.
    This is fiction. The real Joan Clarke was way too smart to say this.
    Turing never claimed his machines could solve any problem. To the contrary, his purpose was to prove that problems existed which they could not solve!
    More important for this talk: A Turing complete language can express any computable algorithm, but it cannot help you find that algorithm! Languages
    are more powerful when they help you think differently. (Quine example.)

    View Slide

  7. “SOMETIMES WE
    DON’T PROGRAM
    TO SHIP; WE
    PROGRAM TO
    UNDERSTAND
    PROGRAMMING.”
    NADA AMIN
    PROGRAMMING
    SHOULD EAT ITSELF
    Do programming languages exist to produce programs? You can create a program without a PL, though it’s harder. We program not for its own sake
    (mostly) but to solve business problems. PLs and compilers produce exe code, yes, but find syntax errors, semantic errors, and are “tools of thought.”
    My real goal here: To expand the set of problems you think you can solve with programming. To do that, you need new ways of approaching a language,
    not just tooling.

    View Slide

  8. Note Taking in F#
    When I approach a very difficult problem, I take notes in F#.
    This particular example (fine if it’s unreadable; details insignificant) concerns business rules inferred from GBs of XML files.
    This is living data, XML changing under my feet, so executing the F# tells me if my assumptions are still valid in “current” XML.
    The F# code exists not to produce a result but to validate my thinking about the problem.
    Nice side effect: It turns out other people also want the ability to run arbitrary queries on this data!

    View Slide

  9. What Is the Upper Limit
    of Software Quality?
    function three() {
    return 1 + 2;
    }
    Want to show you a function I wrote. I’ll apologize in advance; I’ve been warned to avoid using examples involving math. What’s interesting? It’s perfect!
    This is the only defect-free JS I’ll be showing you today.
    The notion of “perfect” code is controversial. But it’s clearly possible!
    How much quality are we willing to pay for? Does it depend on the application?

    View Slide

  10. “LIFE WAS
    SIMPLE BEFORE
    WORLD WAR II.
    AFTER THAT, WE
    HAD SYSTEMS.”
    GRACE HOPPER
    Perfect code is trivial.
    Perfect programs, systems harder. Composing code harder than writing code in most cases. Why? This is essential! Not enough to write correct functions
    unless they’re all total.
    There are always external factors. That’s fine.

    View Slide

  11. “BEWARE OF BUGS
    IN THE ABOVE
    CODE; I HAVE ONLY
    PROVED IT
    CORRECT, NOT
    TRIED IT.”
    DONALD KNUTH
    NOTES ON THE VAN EMDE BOAS
    CONSTRUCTION OF PRIORITY DEQUES: AN
    INSTRUCTIVE USE OF RECURSION
    https://www.flickr.com/photos/gem66/38298868
    Dangerous ideas! I'll be showing a lot of languages which are “still in the lab.”
    You may find some of this useful in your work tomorrow, but not all experiments succeed.
    I’ll ask you to make a choice, though: Which side are you on? Do you believe software must be forever buggy? Or do we attempt to come closer to
    correct software?

    View Slide

  12. In particular the lab is Microsoft Research. Many people know Kinect, WorldWide Telescope, F#, Entity Framework, Pex.

    View Slide

  13. “IF YOU’RE GOING
    TO USE CUTTING
    EDGE TECHNOLOGY,
    DON’T EXPECT NICE
    BLOG POSTS THAT
    TELL YOU IT’S EASY.”
    JOE ARMSTRONG
    CHICAGO ERLANG PRESENTATION
    https://www.flickr.com/photos/vanchett/3180276972
    I have a rule of thumb for application architecture. Consider the tech you want to be using in 5 years, because it takes time to…
    Try to see into the future. This is hard!
    Never specify tech the Hacker News Hipsters tell you that you should be using today. However, every tool I discuss is real and is used in production
    software, including software you might use every day.

    View Slide

  14. “YOUNG MAN, IN
    MATHEMATICS YOU
    DON'T UNDERSTAND
    THINGS. YOU JUST
    GET USED TO THEM.”
    JOHN VON NEUMANN
    LETTER TO FELIX T. SMITH
    https://www.flickr.com/photos/36621927@N00/8378574271
    These languages operate very differently than those you probably use in your day to day work. Don't worry if you don't follow every bit of syntax. To be
    quite honest, I don't fully understand all of this stuff myself. The important thing is to know what is available, and to think about problems in new ways.

    View Slide

  15. Some Specialized
    Languages
    Assembly

    SQL

    C

    F#

    C#?
    I’ll be talking about specialized tools.
    We’re biased towards general purpose languages so we can learn only one.
    But we happily use SQL when needed.
    We abandon GP languages when inessential complexity too high. We grow domain-specific languages to GP when necessary.
    So when you see a language which doesn’t produce EXEs, don’t dismiss it out of hand.

    View Slide

  16. “IF DEBUGGING IS THE
    PROCESS OF
    REMOVING SOFTWARE
    BUGS, THEN
    PROGRAMMING MUST
    BE THE PROCESS OF
    PUTTING THEM IN.”
    ATTRIBUTED TO
    EDSGER DIJKSTRA
    Sounds like Dijkstra!
    Let’s talk about bugs. Broken code should be obvious.
    Cognitive overhead from inessential complexity turns out to be surprisingly high.
    Let’s examine some buggy code.

    View Slide

  17. JavaScript
    function add(a, b) {
    return
    a + b;
    }
    In study of buggy code, makes sense to start with JavaScript.
    In contrast to earlier example, completely broken. No error. Anyone know what it returns?
    JS, so we never specified the return type. Type checker would find.
    A test might find the bug
    This is not a good part

    View Slide

  18. http://blog.erratasec.com/2014/09/bash-bug-as-big-as-heartbleed.html#.VCN_7StdWwE
    PLs are usually specified in EBNF. Machine verifiable specs are easy; bash doesn’t use them and has evolved to the point where can’t be specified.
    So there are edge cases…. Syntax which should not be allowed.
    This causes issues.
    Also Ruby. There’s a file in Ruby source: parser.y impenetrable. Half the size of all of Lua for parser alone. Other implementations are probably different
    than MRI. Formal PL grammars keep parsers maintainable.

    View Slide

  19. Goto Fail
    static OSStatus
    SSLVerifySignedServerKeyExchange(SSLContext *ctx, bool isRsa, SSLBuffer signedParams,
    uint8_t *signature, UInt16 signatureLen)
    {
    OSStatus err;
    ...
    if ((err = SSLHashSHA1.update(&hashCtx, &serverRandom)) != 0)
    goto fail;
    if ((err = SSLHashSHA1.update(&hashCtx, &signedParams)) != 0)
    goto fail;
    goto fail;
    if ((err = SSLHashSHA1.final(&hashCtx, &hashOut)) != 0)
    goto fail;
    ...
    fail:
    SSLFreeBuffer(&signedHashes);
    SSLFreeBuffer(&hashCtx);
    return err;
    }
    Besides the obvious…
    “fail” is not always fail, and “err” is not always err.
    Crappy code, maybe, but real production code, and not the worst I’ve ever seen.

    View Slide

  20. "Quality software costs money — Heartbleed was free." Paul-Henning Kamp DOI:10.1145/2631095
    Not a TLS spec bug (though those can happen). Possibly creeping featuritis in spec.
    Also, strings are kind of broken. That’s true for most languages, not just C.

    View Slide

  21. C#
    static Type GetType() where T : new()
    {
    T t = new T();
    return t.GetType(); // *
    }
    static void Main(string[] args)
    {
    Console.WriteLine(GetType().ToSting());
    }
    Appears contrived, but useful, because type system is broken and it fits on a slide.
    * line throws.
    Deeply weird that you can new up something and can’t ask for its type.
    Type systems help, but not 100% safe.

    View Slide

  22. F#
    let average (someList: int list) =
    (List.sum someList)
    / (List.length someList)
    Type system is restricted. There is no type for a non-empty list. Could check for empty in code, but requires code + test. Shouldn’t have to examine result
    to determine if the call made sense in the first place. Better type system could do it for us. Empty list is to null as nil is to reference type, in at least some,
    but not all, cases!

    View Slide

  23. CAN WE DO
    BETTER?
    OR MUST WE DO BETTER?
    https://www.flickr.com/photos/jurvetson/5872448596
    How?
    Remember: Which side are you on? Do you believe software must be forever buggy?

    View Slide

  24. “Attempting to prove any nontrivial theorem
    about your program will expose lots of bugs.

    “The particular choice of theorem makes little
    difference!

    “Typechecking is good because it proves lots and
    lots of little theorems about your program.”
    –Benjamin C. Pierce
    http://www.cis.upenn.edu/~bcpierce/papers/harmful-mfps.pdf
    Define theorem. Quote is interesting. Reminds me of what people say about testing.
    Use strong types! Simple example: In F#, nullable and non-nullable references are separate types, and this eliminates null reference errors in pure F# code.
    There is a deep relationship between programs and mathematical proofs. Talk to me after, but types good!
    Strong types (especially for real strong types) are awesome for refactoring. Slash + burn.
    Don’t fix the bug. Change the data types to make the state which caused it impossible. (Paul Phillips) Powerful idea! C# types default to invalid state; lots
    of work to only allow state which is correct by construction.

    View Slide

  25. Hoare Verification
    {P} C {Q}

    Partial vs. total correctness

    Considered to be high-effort; 100/100
    Tony Hoare (anyone?), Algol (who has heard of Algol?)
    Anyone ever seen a null reference error?
    One can totally specify software.
    Precondition->Command->Postcondition

    View Slide

  26. “PROGRAM TESTING
    CAN BE USED TO
    SHOW THE
    PRESENCE OF BUGS,
    BUT NEVER THEIR
    ABSENCE.”
    EDSGER DIJKSTRA
    STRUCTURED PROGRAMMING
    http://en.wikipedia.org/wiki/Edsger_W._Dijkstra#mediaviewer/File:Edsger_Dijkstra_1994.jpg
    Tests are ∃, strong types are ∀. Tests are a weak form of static typing. Useful when static typing too hard (fixable) or when static typing can’t deal with
    imprecise spec. “Morally well-typed.”
    "Type errors are not just red flags: in a sufficiently well-specified theory, all errors are type errors." Evan Jenkins
    Testing is great; property-based testing (QuickCheck, etc.) even better
    Testing is evidence, not a proof
    Let’s expand on this….

    View Slide

  27. Effort vs. Reward
    I have a slightly different definition of test coverage than most. I don’t care which lines of code are executed nearly as much as I care about covering the
    possible states of the system. Covering dead code is pointless. (click)
    For simple theorems, like ‘are the arguments to this method all non-null,’ many people don’t bother testing, because there are so many, which is why we
    have so many null reference errors. Inferred types in a rich type system cover this for free. (click) OTOH, total state space coverage for complex theorems
    (“I am following SSL protocol to the letter”) with types can be difficult, although the effort pays off when needed. Tests might be “good enough.” Types
    always cover all states, but complexity starts very low and extends to very high. Tests are in middle on coverage, effort, and complexity.

    View Slide

  28. Effort vs. Reward
    Tests
    Types
    I have a slightly different definition of test coverage than most. I don’t care which lines of code are executed nearly as much as I care about covering the
    possible states of the system. Covering dead code is pointless. (click)
    For simple theorems, like ‘are the arguments to this method all non-null,’ many people don’t bother testing, because there are so many, which is why we
    have so many null reference errors. Inferred types in a rich type system cover this for free. (click) OTOH, total state space coverage for complex theorems
    (“I am following SSL protocol to the letter”) with types can be difficult, although the effort pays off when needed. Tests might be “good enough.” Types
    always cover all states, but complexity starts very low and extends to very high. Tests are in middle on coverage, effort, and complexity.

    View Slide

  29. Effort vs. Reward
    Tests
    Types
    Simple Theorems
    Low effort per theorem,
    but there are lots of
    simple theorems!

    Covers a few states
    Very low effort,
    especially if types
    inferred

    Covers all states
    I have a slightly different definition of test coverage than most. I don’t care which lines of code are executed nearly as much as I care about covering the
    possible states of the system. Covering dead code is pointless. (click)
    For simple theorems, like ‘are the arguments to this method all non-null,’ many people don’t bother testing, because there are so many, which is why we
    have so many null reference errors. Inferred types in a rich type system cover this for free. (click) OTOH, total state space coverage for complex theorems
    (“I am following SSL protocol to the letter”) with types can be difficult, although the effort pays off when needed. Tests might be “good enough.” Types
    always cover all states, but complexity starts very low and extends to very high. Tests are in middle on coverage, effort, and complexity.

    View Slide

  30. Effort vs. Reward
    Tests
    Types
    Simple Theorems
    Low effort per theorem,
    but there are lots of
    simple theorems!

    Covers a few states
    Very low effort,
    especially if types
    inferred

    Covers all states
    Complex Theorems
    Medium effort

    Covers a few,

    important states
    High effort

    Covers all states
    I have a slightly different definition of test coverage than most. I don’t care which lines of code are executed nearly as much as I care about covering the
    possible states of the system. Covering dead code is pointless. (click)
    For simple theorems, like ‘are the arguments to this method all non-null,’ many people don’t bother testing, because there are so many, which is why we
    have so many null reference errors. Inferred types in a rich type system cover this for free. (click) OTOH, total state space coverage for complex theorems
    (“I am following SSL protocol to the letter”) with types can be difficult, although the effort pays off when needed. Tests might be “good enough.” Types
    always cover all states, but complexity starts very low and extends to very high. Tests are in middle on coverage, effort, and complexity.

    View Slide

  31. “WHAT’S TRUE OF
    EVERY BUG FOUND
    IN THE FIELD? IT HAS
    PASSED THE TYPE
    CHECKER… AND ALL
    OF THE TESTS.”
    RICH HICKEY
    SIMPLE MADE EASY
    https://www.flickr.com/photos/grouperkun/5351080866
    Simplicity, conceptual clarity, is the silver bullet, not languages.
    "Debugging is twice as hard as writing the code in the first place. Therefore, if you write the code as cleverly as possible, you are, by definition, not smart
    enough to debug it.” Brian Kernighan
    When you diverge from essential complexity, you’re creating a maintenance problem.

    View Slide

  32. Z3
    http://rise4fun.com/Z3
    http://z3.codeplex.com/
    https://www.flickr.com/photos/laughingsquid/102654032
    So here’s your flying car! Z3 is a theorem prover. Sounds like math, but stay with me. When you hear “theorem prover,” think really strong types. Equivalent.
    Specification = always true about a system. “Formal specification” = verifiable by a machine.
    SMT solver. Take some specs, simplify them algebraically, and efficiently prove the spec satisfiable or not, with examples.
    Z3/SMT-LIB is ASM of solvers. Usually not used directly. Will see examples of systems which use it.

    View Slide

  33. A Simple Problem
    Write a Ruby program that determines the
    smallest three digit number such that
    when said number is divided by the sum
    of its digits the answer is 20.
    Example: Number = 123. Sum of digits = 6
    123/6 = 20.5, so not a solution.
    Hate it when speakers read slides out loud, but…
    Picked this because it’s a very simple problem.

    View Slide

  34. Ruby
    Most people would try something like… Seems reasonable, but it’s brute force solution. Have we fully understood the problem?
    Also, this is wrong. You probably have to be fairly good with Ruby to figure out why. Ruby is complicated; just try and parse it! Cognitive overhead for
    even a simple problem is very high!

    View Slide

  35. Ruby
    Looks efficient! Is this right? Remember, I like to put buggy code on my slides! Is it the best solution? Do you want this in the code you maintain?

    View Slide

  36. SMT-LIB
    I know, (). SMT-LIB language used to compare/benchmark solvers. You don’t typically use this for production. Minimal interface to Z3.
    Did live in rehearsal. Awkward! See me in person for demos.
    “Formal” spec for most of problem. Machine checkable. Omitted one part.

    View Slide

  37. SMT-LIB
    Variable?

    View Slide

  38. SMT-LIB
    Test-only programming.
    Does forall make sense?

    View Slide

  39. SMT-LIB

    View Slide

  40. http://rise4fun.com/Z3/7VZh
    Had to write digit-sum

    View Slide

  41. Note that the model is valid SMT-LIB code. Optimized! Really important.
    Complex definitions tend to be wrong when first written out. They can also be complete nonsense!

    View Slide

  42. Add one clause

    View Slide

  43. Not “can’t find.” Doesn’t exist.

    View Slide

  44. Who uses this? Hyper-V hypervisor. If this is wrong the world ends. 100000 lines C, 5000 lines x64 ASM
    Complex implementation, fairly simple spec.
    Around 1.5 person years, incl learn VCC. 18 hours execution. Xen flaw to be disclosed Wednesday.
    Also Dafny, F*, etc.

    View Slide

  45. DAFNY
    http://rise4fun.com/Dafny
    http://research.microsoft.com/dafny
    https://www.flickr.com/photos/marcusjb/440973101/

    View Slide

  46. Dafny
    Useful for education. Correctness more important than executability. Looks like code contracts but proven at compile time! Imperative code.
    We often ask what might go wrong with our code. Instead we should ask what must go right?
    Solver proves that mathematical and imperative definitions equivalent. Important, especially for optimization. Similar to 180 example.

    View Slide

  47. Who uses Dafny? Rice University “Reasoning about algorithms”

    View Slide

  48. https://www.flickr.com/photos/ayman/21226117
    F* based on F#. Subsumes F7 and other MSR projects.

    View Slide

  49. Append function for length-indexed list.
    Heavy effort, heavy return.
    Remember C# variance annotations: Useful, even if you don’t write them!

    View Slide

  50. Interesting use of F7/F* is MiTLS, a fully verified implementation of TLS. Verifies both TLS specification itself and MiTLS implementation.

    View Slide

  51. F7 source for miTLS. This will be verified, then dependent types “compiled away.” Result is…

    View Slide

  52. Compiles to (correct) F#.

    View Slide

  53. Funny thing about formally verifying specs.
    Sounds awesome that the code meets spec.

    View Slide

  54. TLA+
    http://research.microsoft.com/en-us/um/people/lamport/tla/tla.html
    "Writing is nature’s way of letting you know how sloppy your thinking is." Richard Guindon
    "Mathematics is nature’s way of letting you know how sloppy your writing is.... Formal mathematics is nature’s way of letting you know how sloppy your mathematics is."
    Leslie Lamport
    "Specification is not an end in itself; it is just a tool that an engineer should be able to use when appropriate." p. 76
    "TLA+ is particularly effective at revealing concurrency errors—ones that arise through the interaction of asynchronous components." TLA book, p. 76.

    View Slide

  55. http://lorinhochstein.wordpress.com/2014/06/04/crossing-the-river-with-tla/
    TLA+ exhaustively and maybe not totally efficiently checks all possible states of your system. Unlike QuickCheck, it doesn’t do reducing. Also unlike QC, it
    forces you to specify your system in probably the simplest possible form.

    View Slide

  56. Nice feature: Can produce very pretty output via LaTeX. Equivalent of previous ASCII.

    View Slide

  57. http://somethingofthatilk.com/index.php?id=135

    View Slide

  58. View Slide

  59. View Slide

  60. View Slide

  61. Who Uses TLA+?
    http://research.microsoft.com/en-us/um/people/lamport/tla/formal-methods-amazon.pdf
    Back to the real world: Anything on AWS: Netflix, Heroku

    View Slide

  62. WHAT HAVE WE LEARNED?
    Thinking about specification, and formal specs keep you honest! Force you to consider whole problem.
    Make a spec which is internally consistent. Double entry check vs. code.
    Useful when problem domain too large (AWS) or too complex (Ruby) to test.
    Proves optimized code equivalent to readable code.

    View Slide

  63. ARE FLYING
    CARS A BAD
    IDEA?
    https://www.flickr.com/photos/bobjagendorf/4934950194/
    Tooling is an issue. Proving production code matches spec can be challenging. __agl verify ECC C code
    Impractical for complex systems. Good when it makes you simplify!
    Exhaustive testing, when possible, can give you similar return for less effort. Not always possible.

    View Slide

  64. Gratitude
    The people of Microsoft Research

    Others I’ve learned from

    SMT-LIB: Laurentiu Nicola (blog comment)

    Dafny: Swarat Chaudhuri’s articles

    TLA+: Chris Newcombe, Tim Rath, Fan Zhang, Bogdan
    Munteanu, Marc Brooker, and Michael Deardeuff and
    Lorin Hochstein’s blog

    Photographers (credited on each slide where used)

    My family, employer, and coworkers, for putting up with
    me spending time on this stuff

    View Slide

  65. CRAIG STUNTZ
    @CraigStuntz
    [email protected]
    http://blogs.teamb.com/craigstuntz
    http://www.meetup.com/Papers-We-Love-Columbus/
    Least interesting part, but….
    Questions?

    View Slide
