Using the Symfony Messenger

Slides for my workshop at Dutch PHP Conference 2019.

Transcript

1. Dutch PHP Conference 2019
   USING THE SYMFONY MESSENGER


   View Slide

2. AGENDA
   1. Quick introduction round
   2. Setting up the project skeleton,
   while I guide you through the example code
   3. Presentation: Introduction to messenger-concepts
   4. Task 1: Introduce synchronous message processing
   5. Presentation: Transports for async processing
   6. Task 2: Pick your challenge(s)
   7. Questions


   View Slide

3. GOALS
   Have fun
   Learn about the Messenger component
   Just 3 hours won't make you an expert, but hopefully you:
   • have a feeling whether this component is useful to you
   • maybe you get interested in message-based architecture
   Feel free to ask questions at any time.
   If you have suggestions how I can better suit your learning style,
   please let me know and I will adjust


   View Slide

4. WHO AM I
   Denis Brumann
   Software Developer at SensioLabs Germany in Berlin
   Twitter: @dbrumann Email: denis.brumann@sensiolabs.de
   Personal Focus:
   • Migrating client's legacy projects
   Symfony experience:
   • started with 2.0
   • currently using 3.4 in client project
   • for private projects I try to use latest version possible


   View Slide

5. SETTING UP THE PROJECT
   git remote add dpc2019 \
   https://github.com/dbrumann/dpc2019-workshop.git
   git fetch dpc2019
   git checkout -b develop dpc2019/master \
   --no-track


   View Slide

6. CORE CONCEPTS
   Message
   Data Object containing all relevant data
   Message Bus
   Takes a message and delegates it to the right recipient
   Message Handler
   Takes a Message-object and handles it, i.e. processes it


   View Slide

7. ADVANCED CONCEPTS
   Envelope
   Wrapper for a Message and contextual info (stamps)
   Stamp
   Provides context to/from a Middleware
   Middleware
   Controls the behavior of the Message Bus


   View Slide

8. MESSAGE BUS
   interface MessageBusInterface
   {
   /**
   * Dispatches the given message.
   *
   * @param object|Envelope $message The message or the message
   * pre-wrapped in an envelope
   * @param StampInterface[] $stamps
   */
   public function dispatch($message, array $stamps = []): Envelope;
   }


   View Slide

9. SENDING A MESSAGE
   class MyService
   {
   private $messageBus;
   public function __construct(MessageBusInterface $messageBus)
   {
   $this->messageBus = $messageBus;
   }
   public function doSomething(string $url)
   {
   $this->messageBus->dispatch(new TakeScreenshotMessage($url));
   }
   }


   View Slide

10. SENDING A MESSAGE
    public function index(Request $request): Response
    {
    if ($request->isMethod('POST')) {
    $url = trim($request->request->get('url'));
    $this->dispatchMessage(new TakeScreenshotMessage($url));
    }
    return $this->render('screenshot.html.twig');
    }


    View Slide

11. TASK 1
    • Install the Messenger component
    • Modify
    App\Registration\Registration::register()
    or the corresponding Controller-action
    App\Controller\RegistrationController::register()
    to use the Messenger instead
    • Create a Message-object (you can take the Form-object as a reference point)
    • Dispatch the Message using the MessageBus


    View Slide

12. View Slide

13. TASK 1
    • Install the Messenger component
    • Modify
    App\Registration\Registration::register()
    or the corresponding Controller-action
    App\Controller\RegistrationController::register()
    to use the Messenger instead
    • Create a Message-object (you can take the Form-object as a reference point)
    • Dispatch the Message using the MessageBus
    • Create a MessageHandler


    View Slide

14. HANDLING MESSAGES
    class TakeScreenshotHandler implements MessageHandlerInterface
    {
    public function __invoke(TakeScreenshotMessage $message)
    {
    ...
    }
    }


    View Slide

15. HANDLING MESSAGES
    class ScreenshotMessageSubscriber implements MessageSubscriberInterface
    {
    public static function getHandledMessages(): iterable
    {
    yield TakeScreenshotMessage::class => [
    'method' => 'takeScreenshot'
    ];
    }
    public function takeScreenshot(TakeScreenshotMessage $message)
    {
    ...
    }
    }


    View Slide

16. View Slide

17. https://github.com/dbrumann/dpc2019-workshop/tree/task1/sync_register
    git checkout dpc2019/task1/sync_register
    https://github.com/dbrumann/dpc2019-workshop/tree/task1/split_handler
    git checkout dpc2019/task1/split_handler


    View Slide

18. Message
    Broker
    publish
    subscribe


    View Slide

19. View Slide

20. View Slide

21. View Slide

22. AVAILABLE TRANSPORTS
    AMQP (RabbitMQ)
    Redis
    Doctrine (using a DBAL-Connection)
    InMemory (for tests)
    Need more? Enqueue provides many more adapters


    View Slide

23. IMPORTANT COMMANDS
    bin/console messenger:setup-transports
    bin/console messenger:consume


    View Slide

24. PICK YOUR CHALLENGE(S)
    • Validating messages inside the MessageBus
    • Sending registration mails with Symfony Mailer
    (using async transport)
    • Creating an implicit workflow using many sync/async-handled
    messages
    • Adding capability to deal with failing messages
    • Looking into CQRS
    • Creating a CommandBus, (QueryBus), EventBus


    View Slide

25. View Slide

26. framework:
    messenger:
    transports:
    sync: 'sync://'
    async: '%env(MESSENGER_TRANSPORT_DSN)%'
    routing:
    # Route your messages to the transports
    App\Message\RequestRegistrationQuery: 'sync'
    App\Message\RegisterUserCommand: 'async'
    App\Message\UserRegisteredEvent: 'async'


    View Slide

27. # default configuration
    retry_strategy:
    max_retries: 3
    delay: 1000 # delay for first retry
    multiplier: 2 # multiply delay with each try
    max_delay: 0
    # service: null
    # id for custom RetryStrategy


    View Slide

28. framework:
    messenger:
    failure_transport: 'failed'
    transports:
    ...
    failed: 'doctrine://default?queue_name=failed'
    routing:
    ...


    View Slide

29. bin/console messenger:failed:show
    bin/console messenger:failed:retry
    bin/console messenger:failed:remove


    View Slide

30. $envelope = $this->dispatchMessage($form->getData());
    $token = $envelope->last(HandledStamp::class)->getResult();
    ENVELOPES & STAMPS


    View Slide

31. Questions?


    View Slide

32. Thank You!
