ToC Lean Ops

Software applications become more and more complex, it have become much more difficult to have one holistic view of it all.

Common practice for many IT departments in software companies is jumping from solving one local maxima problem to another with disregard of the big whole.

For some time now the software development practice neighbour has been borrowing some of the solutions to managing themselves from an unexpected direction - industrial manufacturing.

Leading ideas for these solutions have been defined by Deming, Toyota, Motorola and Eliyahu Goldratt with his Theory of Constraints.

It is time for operations to get into the game!

Learn some of these life changing practices and solve ALL the operation problems once and for all!

Transcript

1. Amazing Ops
   using Theory of Constraints & Lean


   View Slide

2. Should you listen to me?


   View Slide

3. I read all these books


   View Slide

4. sharing what I learned


   View Slide

5. ○ History & People
   ○ Theory of Constraints
   ○ Lean / Toyota Production System
   ○ Lean IT


   View Slide

6. History & People


   View Slide

7. Japan occupied by the Allied Powers until 1952.
   WWII to 1953 U.S. provided $5.9b to "Aid Asia".
   non-Marshall Plan
   $2.4b to Japan.
   $282m to Israel
   wikipedia.org/wiki/Marshall_Plan
   Japan post-WWII
   history
   &
   people


   View Slide

8. Statistics Prof. NY Uni. of Business.
   Worked from 1947 onwards in Japan.
   Emphasis on statistical process control.
   Quality = Result of work efforts / Total costs.
   wikipedia.org/wiki/W._Edwards_Deming
   William Edwards Deming
   history
   &
   people


   View Slide

9. W. Edwards Deming 1900 - 1993
   people
   &
   history
   history
   &
   people


   View Slide

10. W. Edwards Deming 1900 - 1993
    It is not necessary to change.
    Survival is not mandatory.
    In God we trust;
    all others must bring data.
    people
    &
    history
    history
    &
    people


    View Slide

11. W. Edwards Deming 1900 - 1993
    people
    &
    history
    history
    &
    people
    doing his best
    It is not enough to do your best;
    you must know what to do,
    and then do your best.


    View Slide

12. Joseph Moses Juran
    Thought leader on Cost of Poor Quality.
    Applied the Pareto Principle to quality issues.
    Cultural resistance = Root of quality issues.
    wikipedia.org/wiki/Joseph_M._Juran
    history
    &
    people


    View Slide

13. Joseph M. Juran 1904 - 2008
    history
    &
    people


    View Slide

14. Joseph M. Juran 1904 - 2008
    Goal setting has traditionally been
    based on past performance.
    This practice has tended to perpetuate
    the sins of the past.
    We cannot solve our problems with the same thinking
    we used when we created them.
    - Albert Einstein
    history
    &
    people


    View Slide

15. Taiichi Ohno 大野耐
    The father of the Toyota Production System
    Devised the seven Muda 無駄
    Just In Time
    wikipedia.org/wiki/Taiichi_Ohno
    history
    &
    people


    View Slide

16. Taiichi Ohno 1912 - 1990
    Where there is no Standard
    there can be no Kaizen.
    Costs do not exist to be calculated.
    Costs exist to be reduced.
    The more inventory a company has,
    the less likely they will have what they need.
    history
    &
    people


    View Slide

17. Eliyahu Moshe Goldratt
    Israely physicist turned business guru.
    Theory of Constraints author.
    .םיצוליאה תרות הגוה
    wikipedia.org/wiki/Eliyahu_M._Goldratt
    history
    &
    people


    View Slide

18. Eliyahu M. Goldratt 1947 - 2011
    history
    &
    people


    View Slide

19. Eliyahu M. Goldratt 1947 - 2011
    An hour saved at a non-bottleneck
    is a mirage.
    history
    &
    people


    View Slide

20. Theory of Constraints
    wikipedia.org/wiki/Theory_of_Constraints


    View Slide

21. ToC Measures
    T
    of Constraints
    ○ Throughput
    ○ Inventory
    ○ Operating Cost
    Until the product is bought - nothing was sold.


    View Slide

22. Traditional
    Inventory = ↑ Profit
    ○ overproduction
    ○ busy = efficient
    Operational Cost #1
    ○ Sub-system optimization
    ○ Cost center disease
    ToC Measures
    T
    of Constraints
    Theory of Constraints
    Inventory = ↓ Profit
    ○ sell inventory
    ○ extra work discouraged
    Throughput #1
    ○ Systemic optimization
    ○ Continuous Improvement


    View Slide

23. ToC order of Measures
    T
    of Constraints
    1. ↑ Throughput
    2. ↓ Inventory
    3. ↓ Operating Cost


    View Slide

24. ToC Steps
    T
    of Constraints
    1. Identify the constraints
    2. Exploit the constraint
    3. Subordinate and sync to the constraint
    4. Elevate performance of the constraint
    5. Repeat


    View Slide

25. ToC - What is a Constraint?
    T
    of Constraints
    Constraint = Capacity cannot meet demand


    View Slide

26. meet Herbie


    View Slide

27. Identify the Constraint(s)
    T
    of Constraints
    signs:
    ○ people queue
    ○ inventory buildup
    ○ units to be processed
    ○ work in progress / backlog


    View Slide

28. Exploit the Constraint
    T
    of Constraints
    Maximize its utilization toward productive
    throughput - Don't allow it to be idle.
    time lost at the constraint is lost forever;
    it can never be made up
    H


    View Slide

29. Subordinate and Sync to the Constraint
    T
    of Constraints
    Drum - production rate of the constraint sets rate for the
    system, both upstream & downstream.
    Buffer - Placed in front of the drum (upstream) to keep
    constraint busy, have no throughput disruption.
    Rope - Actions taken to tie the rate at which material is
    released into the system to production rate of the drum.
    H


    View Slide

30. Subordinate and Sync to the Constraint
    T
    of Constraints
    Drum - Buffer - Rope
    Drum
    Buffer
    Rope


    View Slide

31. Elevate performance of the Constraint
    T
    of Constraints
    H


    View Slide

32. ToC Pitfalls
    Perfectly Balanced Line
    ● Elevating 'all' constraints by elimination
    ● Multiple constraints = Loss of control
    ● Floating Bottlenecks =
    Unpredictable & Unmanageable


    View Slide

33. Lean
    Toyota Production System
    wikipedia.org/wiki/Toyota_Production_System


    View Slide

34. Lean Foundation
    Jidoka
    Autonomation
    Built-in quality
    Stop at abnormalities
    Just in Time
    Single piece flow
    Pull production
    Takt time production
    People
    People
    People
    People
    Heijunka


    View Slide

35. Autonomation
    1. Detect the abnormality.
    2. Stop.
    3. Fix or correct the immediate condition.
    4. Investigate the root cause and install a
    countermeasure.
    Jidoka 自働化
    Lean
    TPS


    View Slide

36. Mistake proofing
    avoid (yokeru) mistakes (poka)
    Poka-yoke ポカヨケ
    Lean
    TPS


    View Slide

37. Just in Time
    Lean
    TPS
    Provide customer what he needs,
    at the right time and in the right quantity.
    ○ Single piece flow
    ○ Pull production
    ○ Takt time


    View Slide

38. Kanban 看板
    Lean
    TPS
    kanban = card
    Used by downstream processes to signal upstream.


    View Slide

39. Heijunka 平準化
    Lean
    TPS
    Smooth processing and production.
    ○ Leveling
    ○ Sequencing
    ○ Stability and standardization


    View Slide

40. The Deming Cycle
    wikipedia.org/wiki/PDCA
    originates from Francis Bacon (Novum Organum, 1620) aka. Scientific Method
    Plan Do Check Act
    change
    control


    View Slide

41. Muda 無駄 the seven wastes
    Lean
    TPS
    ○ Transportation
    ○ Inventory
    ○ Motion
    ○ Waiting
    ○ Over-processing
    ○ Over-production
    ○ Defects


    View Slide

42. Before it moves, hold it,
    Before it goes wrong, mend it,
    Drain off water in winter before it freezes,
    Before weeds grow, sow them to the breezes,
    Can foresee
    Harmful events and not allow them to be.
    - Chapter 64 of the 道德經 Tao Teh Ching
    by Lao Tzu, 600 BC
    wayist.org/ttc compared/


    View Slide

43. Prevention - the 5Ss
    ○ Sort
    ○ Straighten
    ○ Scrub
    ○ Systemize
    ○ Standardize
    Lean
    TPS
    shadow box


    View Slide

44. Kaizen 改善
    Lean
    TPS
    Good Change / Improvement / Change for the better
    ○ Eliminate "hard" work - Muri 無理
    ○ Perform experiments (PDCA)
    ○ Participation of people in the improvement


    View Slide

45. Genchi Genbutsu 現地現物
    Go and see.
    Go to the Gemba 現場, the real place.
    Go to where the work gets done.
    Lean
    TPS


    View Slide

46. Lean IT Operations
    wikipedia.org/wiki/Lean_software_development


    View Slide

47. Principles
    ○ Eliminate waste
    ○ Amplify learning
    ○ Decide as late as possible
    ○ Deliver as fast as possible
    ○ Empower the team
    ○ Build integrity in
    ○ See the whole
    Lean
    IT


    View Slide

48. "Think big,
    act small,
    fail fast;
    learn rapidly"
    Lean
    IT


    View Slide

49. Agile History
    1970 Tom Gilb publishing Evolutionary Project Management (EVO)
    1974 E.A.Edmonds paper introduces Adaptive Software Development process
    1990s Agile methods vs. heavyweight project management methods
    2001 Manifesto for Agile Software Development
    2005 Declaration of Interdependence by Alistair Cockburn and Jim Highsmith
    Lean
    IT


    View Slide

50. Devops History
    1993 Mark Bugess creates CFEngine and presents in a paper at the CERN
    computing conference
    2005 Puppet Labs founded by Luke Kanies
    2008 first Velocity conference by O'Reilly focusing on web performance and
    operations
    2008 Jesse Robbins & Adam Jacob found OpsCode
    2009 Patrick Debois talks about DevOps and organizes the first DevOpsDays in
    Belgium
    Lean
    IT


    View Slide

51. Recommended books/video/audio
    ○ The Goal
    bit.ly/the-goal
    ○ The Phoenix Project
    bit.ly/the-phoenix-project
    ○ Office Space
    bit.ly/office-space-movie
    ○ NUMMI Final Days
    bit.ly/nummi-final-days


    View Slide

52. www.devops.co.il
    Evgeny Zislis
    about.me/kesor


    View Slide

53. ?
    bit.ly/toc-lean-ops
