  1. sleepyholder
    HITCON 2016

    View Slide

  2. Challenge overview

    View Slide

  3. Challenge overview
    ● Menu driven:
    ○ Keep secret
    ○ Wipe secret
    ○ Renew secret

    View Slide

  4. Challenge overview
    Keep secret
    if (***_secret_flag == 0) {
    ***_secret = calloc(1, ***_SIZE);
    ***_secret_flag = 1;
    read(0, ***_secret, ***_SIZE);
    }
    SMALL_SIZE = 40 (fast chunk)
    BIG_SIZE = 4000 (large chunk)
    HUGE_SIZE = 400000

    View Slide

  5. Challenge overview
    Renew secret
    if (***_secret_flag == 1) {
    read(0, ***_secret, ***_SIZE);
    }
    // but no renew for huge secret

    View Slide

  6. Challenge overview
    Wipe secret
    free(***_secret); // Vulnerability - Double Free
    ***_secret_flag = 0;
    // But no wipe for huge secret

    View Slide

  7. Problem
    ● Unlike ‘secretholder’, we cannot allocate ‘huge_secret’ through ‘top_chunk’

    View Slide

  8. Solution
    ● Hint given: ‘malloc_consolidate’
    ● malloc_consolidate: Removes all chunks in fastbin, consolidate if possible,
    insert back into unsorted bin - used to prevent fragmentation.
    ● ‘malloc_consolidate’ is called in certain cases. One of them being: ‘allocating
    a large chunk and no candidate chunk found in any bin’ [code].
    ● Fast chunks in fastbin are still considered ‘in_use’ to prevent consolidation.
    ● Trick: Freeing a fastbin doesn’t set the PREV_IN_USE bit of next chunk to 1.
    Allocating a fast chunk from a fastbin also doesn’t set the bit to 1. It simply
    assumes that it already is 1.

    View Slide

  9. Attack
    1. Keep small-> fast chunk allocated
    2. Keep big -> large chunk allocated
    3. Wipe small -> fast chunk inserted in fastbin (PREV_IN_USE of large chunk is
    still set)
    4. Keep huge -> no candidate chunk in any bin, ‘malloc_consolidate’ causes
    fast chunk in unsorted bin and then into small bin. PREV_IN_USE of large
    chunk cleared to 0.
    5. Wipe small -> chunk again inserted in fast chunk, PREV_IN_USE bit of large
    chunk still 0.
    6. Keep small -> chunk returned from fastbin, PREV_IN_USE bit of large chunk
    still 0.

    View Slide

  10. Attack
    ● Create a fake chunk in small secret with fd pointing to ‘small_secret - 3’ and
    bk pointing to ‘small_secret - 2’.
    ● Adjust previous size of ‘big_secret’. PREV_IN_USE bit already 0
    ● Free ‘big_secret’
    ● ‘small_secret’ now points to a few bytes before ‘big_secret’ -> Arbitrary write

    View Slide

  11. Attack (similar to ‘secretholder’)
    ● Update read’s GOT with puts@plt and leak out libc address of say puts’ GOT
    ● Calculate system’s libc address and update free’s GOT with it.
    ● Free any chunk with ‘/bin/sh\x00’

    View Slide

  12. https://github.com/DhavalKapil/ctf-writeups/blob/master/hitcon-2016/sleepyholder/
    exploit.py
    [Exploit]
