Fast List Scrolling with ORMLite

"Buttery-smooth" list scrolling is an important part of ensuring a good user experience on Android. But achieving this when rendering data from multiple database tables can be tricky. This talk will describe the steps I took to debug the performance issues and arrive at a solution using ORMLite.

Originally presented at Toronto Android Developers Meetup (http://www.meetup.com/ToAndroidDev/events/230143896/).

A key part of this slide deck are the animated screen captures, which are lost during the conversion to PDF. For the original slides, please go to Google Slides: https://docs.google.com/presentation/d/1L9nNONHQWAHVaC4Qwpu3sZ2yaXw1wnB6CX_rCch4mcM/edit?pref=2&pli=1#slide=id.g12a97b667f_0_291

Transcript

1. Fast List Scrolling with ORMLite Toronto Android Developers Meetup 2016-04-13
2. Eric Fung
3. INTRODUCTION 1
4. Goal: Responsive UI List scrolling can be tricky Learn About CursorAdapter, ORMLite, Traceview, Deferred Updates, Section Headings From Problem to Solution Walkthrough of how I debugged
5. INTRODUCTION ◦ Shopify helps entrepreneurs sell things ◦ App for merchants to manage their store’s orders and products
6. ◦ Displays title, thumbnail and inventory ◦ List is sectioned by first letter of title INTRODUCTION
7. PROBLEM 2
8. PROBLEM ◦ Few products in test stores ◦ Try >1500 ◦ Spinner visible for 20s!
9. PROBLEM Once loaded, scrolling was smooth
10. Adapter ◦ Bridge between ListView and data ◦ Renders data into views REVIEW ORM ◦ Technique to access DB from OO language ◦ Classes instead of rows ◦ Updates are just setter calls
11. EXISTING IMPLEMENTATION Photo by Sonja Langford ◦ Fetch rows, store into array ◦ Compute section headings ◦ ArrayAdapter ◦ S-L-O-W
12. USE A CURSORADAPTER 3
13. USE A CURSORADAPTER Seems obvious! ◦ Cursor is a DB control that lets you traverse results ◦ Fits with ListView and Adapter Why didn’t we use it? ◦ All rows needed to compute section headings
14. USE A CURSORADAPTER ◦ ORMLite’s latest release (Dec 2013) doesn’t have it ◦ PR submitted mid-2014 based on https://github. com/campnic/ormlite-android- extras ◦ But not released… ◦ Build your own JAR or use JitPack
15. ◦ Load time negligible ◦ But… content judders while scrolling ◦ UI thread can’t keep up ◦ Section headings lost USE A CURSORADAPTER
16. “ The key to a smoothly scrolling ListView is to keep the application’s main thread … free from heavy processing. Ensure you do any disk access, network access, or SQL access in a separate thread. https://developer.android.com/training/improving- layouts/smooth-scrolling.html
17. USE A CURSORADAPTER ◦ 60fps = <17ms per frame ◦ Images loaded in background ✔ ◦ Database queries via CursorLoader ✔ ◦ What else is slowing down the UI thread? Photo by Bhavyesh Acharya
18. METHOD PROFILING 4
19. METHOD PROFILING ◦ Android Device Monitor is a suite of tools for debugging and analysis: DDMS, OpenGL Tracer, HierarchyViewer, Systrace, Traceview ◦ Not to be confused with Android Monitor
20. TRACEVIEW Logs method execution over time and shows execution data, per-thread timelines, and call stacks. Good for tracking down performance problems in your source code.
21. HOW TO 1. Launch app 2. Start method profiling 3. Interact with app (fling list) 4. Stop profiling
22. TRACEVIEW More info: https://developer.android.com/tools/performance/index.html
23. METHOD PROFILING ◦ There was a lot of activity on the main thread ◦ The profiling pane revealed these calls to be DB calls ◦ But why?
24. METHOD PROFILING ◦ Inventory information comes from a foreign table! Photo by Ondrej Supitar
25. ◦ Variants are a different version of a product ◦ Merchants want to know if any products are low on inventory DATA MODEL
26. @ForeignCollectionField(eager = false) private Collection<ProductVariant> variants; ORMLITE FOREIGN COLLECTIONS ◦ Modelled in ORMLite through a ForeignCollection ◦ Define whether fetching model also fetches its foreign collections (eager vs. lazy)
27. public int numberOfOutOfStockVariants() { int count = 0; for (ProductVariant variant : variants) { if (variant.isOutOfStock()) { count++; } } return count; } ORMLITE FOREIGN COLLECTIONS Can you spot the DB access?
28. “ http://ormlite.com/javadoc/ormlite-core/doc- files/ormlite_2.html#Foreign-Collection …the collection is considered to be "lazy" and will iterate over the database using the Dao.iterator() only when a method is called on the collection.
29. public int numberOfOutOfStockVariants() { int count = 0; for (ProductVariant variant : variants) { if (variant.isOutOfStock()) { count++; } } return count; } ORMLITE FOREIGN COLLECTIONS We’d like to keep this abstraction
30. Don’t display all rows Paginate at bottom Return join of tables Joined result set not supported in ORMLite Denormalize Put inventory in product, maintain integrity ALTERNATIVES
31. UPDATE VIEW IN BACKGROUND 5
32. 1. When product is rendered, queue fetch of variants 2. Track which view needs updating 3. Fetch variants in background 4. When data is available, compute inventory 5. Update the view IDEA
33. 1. Adapter puts entry into shared structure, mapping product to view 2. Adapter sends message to worker to fetch variants 3. Worker processes messages in FIFO order 4. Fetches variant and computes inventory 5. Removes entry from data structure, updates view IMPLEMENTATION
34. FETCH DATA IN BACKGROUND Smooth scrolling at last! Last thing is to restore the section headings
35. ◦ Why do we care? ▫ It’s in the designs ▫ It allows you to enable fast scrolling ◦ Built-in AlphabetIndexer was way too slow ƌ ◦ Various blog posts about CursorAdapter + SectionIndexer ƌ SECTION HEADINGS
36. PRECOMPUTING SECTION INDICES 6
37. Section A group of list items with something in common, e.g. first letter of title, album artist SECTIONINDEXER Indices ◦ Given index of section, return adapter position ◦ Given adapter position, return section it belongs to
38. If we knew the count of items in each group of products that start with the same letter, we could easily calculate the section indices Hint hint! SECTIONINDEXER
39. SELECT SUBSTR(UPPER(title),1,1) AS section, COUNT(*) FROM `products` GROUP BY section ORDER BY section A|125 B|123 C|153 D|69 … GENERATE SECTION INDICES WITH SQL
40. ◦ Executes fast ◦ Pre-compute and pass to Adapter ◦ Define a wrapping list adapter on top of CursorAdapter GENERATING SECTION INDICES WITH SQL
41. SUCCESS AT LAST Place your screenshot here Photo by Laney Griner
42. CONCLUSION 7
43. CONCLUSION ◦ Smooth list scrolling is essential for good UX ◦ Use CursorAdapter with DB data to back your ListView ◦ Profile your app to find hot spots ◦ Defer updating views if needed ◦ Sometimes SQL > Java
44. Thanks! QUESTIONS? @gnufmuffin efung@acm.org efung
45. CREDITS ◦ Template by SlidesCarnival ◦ Photographs by Unsplash
