Outline • Architecture • Features • App Servers • Datastore
• Services • Restrictions • Codelab • Q & A. (optional) -
Architecture Overview Request Frontend App Servers Big Table Image Service
Static Files Memcache Task Q. … Datastore API Memcache API Image API -
GAE App Servers • GAE is an application platform for
running your apps. • Uses Google’s infrastructure • A *.appspot.com domain (customized domain name is fine) • Compromises Python or Java runtime • Provides APIs to access storage and services • Scales on demand • Pay as you need -
GAE Datastore • Store the persistent data. • A kind
of Key-Value database built on GFS. • Scalable • Access through Datastore API or GQL • Dynamically add/remove -ing properties is okay. Relational Database Datastore -
GAE Storages • BlobStore • Store the static data (for
upload/serving files) • Quota limits (ref. doc) • Memcache • Distributed in-memory data cache • 1MB entity -
GAE Services (increasing) • Image Service • Scale, resize, crop,
transform, … an image • Mail Service • Send/Receive Emails • Task Queue Service • Put tasks in queue and execute them later (avoid exceeding quota limit) • User Service • Authentication user with Google account (or OpenID) -
GAE Services (increasing) • URL Fetch Service • Fetch data
from other websites • OAuth Service • Help build an OAuth-based API services. • XMPP Service • Send/Receive XMPP messages (e.g., Google Talk) -
Restrictions • Quota • Quota is extensible if the billing
enabled • Types of quotas • CPU time • The capacity of data storages • The bandwidth of incoming/outgoing request/responses • The frequency of API calls • Limits • 1MB data entity (datastore, blobstore, memcache) • 30 sec. lifetime of a request • URL Fetch: 32MB data and 10 minutes • Image service: 1600px image • … -
Google Apps and Marketplace • GAE-based application can be installed
into the Google Apps. • If you want to use a custom domain name for the app, you should use that domain to register Google Apps. • Authenticate Google Apps’ users. • Sell your app on the Google Apps Marketplace. -
Create a GAE App • Go to http:// appengine.google.com •
Do an authorization process via SMS while you’re first-time logging in. Your application ID -
Create a Project • Create a app.yaml file in your
project. # app.yaml application: your-app-id version: 1 runtime: python api_version: 1 handlers: - url: /.* handler: main.py URL Routings Appliaction identifier -
Main Handler #!/usr/bin/env python # -*- coding: utf-8 -*- from
google.appengine.ext import webapp from google.appengine.ext.webapp.util import run_wsgi_app class IndexPage(webapp.RequestHandler): def get(self): self.response.out.write('<h1>Hello, world</h1>') def main(): app = webapp.WSGIAppliaction([ ('/', IndexPage), ], debug=True) run_wsgi_app(app) if __name__ == '__main__': main() -
Start a Local Development Server • Now, your project directory
contains 2 files: • app.yaml • main.py • Start the development server, it servers http://localhost:8080 Start the dev server Use this URL test your app -
Deployment • Use appcfg.py script (in GAE SDK) to deploy
your project. Start deploying… Auth your GAE account Complete deployment -
Application Management • Use the dashboard to monitor your app
from: http://www.flickr.com/photos/kevin814/3587610731/ -
Code Lab: Simple Guestbook • Goal: • Create a GAE-based
application. • Learn how to use Datastore API • Learn the webapp framework and template • Use User service for authentication • Access data offline • Attachments: • blank.zip: The blank project directory. • gbook-1.zip: The website flow and URL routings • gbook-2.zip: Design the data models • gbook-3.zip: Authenticate with Google account • gbook-4.zip: Use template for output
