Processing camera input on Android

Processing and analysing images from the camera in an Android application has always been a complicated thing to solve. Despite Google making a big overhaul of the camera APIs with camera2, developers still struggled with even the simplest tasks such as scanning QR-codes or doing text detection.

At Google IO 2019, we got a new library from Google to make our work easier. The new library is called CameraX and significantly simplifies the common tasks we have when working with the camera on Android. In this session, we will learn how to use the CameraX API for any kind of processing and computer vision. After this session, you’ll feel much more confident to implement the camera processing the way you wanted, without having to resort to heavy libraries that rely on the legacy APIs.

Transcript

1. PROCESSING
   CAMERA INPUT
   ON ANDROID
   @ERIKHELLMAN
   SPEAKERDECK.COM/ERIKHELLMAN


   View Slide

2. AGENDA
   EAN: 0121 7155
   Name: Eggs, 6-pack


   View Slide

3. ANDROID CAMERA APIS
   > android.hardware.Camera (Legacy)
   > android.hardware.camera2 (Camera 2)
   > androidx.camera (CameraX)


   View Slide

4. ANDROID CAMERA APIS
   > android.hardware.Camera (Legacy)
   > android.hardware.camera2 (Camera 2)
   > androidx.camera (CameraX)


   View Slide

5. COMPUTER VISION ON ANDROID
   > ML Kit
   > ZXing
   > OpenCV
   > OpenGL ES
   > RenderScript
   > Play Services Vision API


   View Slide

6. DEPRECATED APIS
   > ML Kit
   > ZXing
   > OpenCV
   > OpenGL ES
   > RenderScript
   > Play Services Vision API


   View Slide

7. VIABLE CANDIDATES
   > ML Kit
   > OpenCV
   > OpenGL ES
   > RenderScript


   View Slide

8. EXCLUDED DUE TO COMPLEXITY
   > ML Kit
   > OpenCV
   > OpenGL ES
   > RenderScript


   View Slide

9. COMPUTER VISION ON ANDROID:
   CAMERAX + ML KIT1
   1 Also works on iOS!


   View Slide

10. GET STARTED QUICKLY!


    View Slide

11. GRADLE DEPENDENCIES
    dependencies {
    // CameraX Core
    implementation "androidx.camera:camera-core:$camerax_version"
    // If you want to use Camera2 extensions
    implementation "androidx.camera:camera-camera2:$camerax_version"
    // Add Firebase ML Kit for easy computer vision functions!
    implementation "com.google.firebase:firebase-ml-vision:$firebaseVersion"
    }


    View Slide

12. SETUP CAMERA PREVIEW
    val previewConfig = PreviewConfig.Builder()
    .setLensFacing(CameraX.LensFacing.BACK)
    .build()
    val preview = Preview(previewConfig)
    val viewFinder = findViewById(R.id.viewFinder)
    preview.setOnPreviewOutputUpdateListener { previewOutput ->
    viewFinder.surfaceTexture = previewOutput.surfaceTeexture
    }
    CameraX.bindToLifecycle(this, preview)


    View Slide

13. SETUP ML KIT FOR BARCODE DETECTION
    val options = FirebaseVisionBarcodeDetectorOptions.Builder()
    .setBarcodeFormats(FirebaseVisionBarcode.FORMAT_ALL_FORMATS)
    .build()
    val detector = FirebaseVision.getInstance()
    .getVisionBarcodeDetector(options)


    View Slide

14. SETUP CAMERAX IMAGE ANALYZER
    val imageAnalysisConfig = ImageAnalysisConfig.Builder()
    .setImageReaderMode(ImageAnalysis.ImageReaderMode.ACQUIRE_LATEST_IMAGE)
    .setTargetResolution(Size(1024, 768))
    .build()
    val imageAnalysis = ImageAnalysis(imageAnalysisConfig)
    imageAnalysis.setAnalyzer { image, rotationDegrees ->
    // TODO Perform image analysis...
    }
    CameraX.bindToLifecycle(this, imageAnalysis)


    View Slide

15. ANALYSE IMAGES WITH ML KIT
    imageAnalysis.setAnalyzer { image, rotationDegrees ->
    val imageRotation = degreesToFirebaseRotation(rotationDegrees)
    image?.image?.let {
    val visionImage = FirebaseVisionImage.fromMediaImage(it, imageRotation)
    detector.detectInImage(visionImage)
    .addOnSuccessListener { barcodes ->
    displayDetectedBarcode(barcodes)
    }
    }
    }


    View Slide

16. IT WORKS, BUT...


    View Slide

17. VIEW FINDER


    View Slide

18. BAD AND GOOD VIEW FINDER


    View Slide

19. VIEW FINDER LAYOUT
    android:id="@+id/viewFinder"
    android:layout_width="0dp"
    android:layout_height="0dp"
    app:layout_constraintDimensionRatio="16:9"
    app:layout_constraintEnd_toEndOf="parent"
    app:layout_constraintHorizontal_bias="0.0"
    app:layout_constraintStart_toStartOf="parent"
    app:layout_constraintTop_toTopOf="parent" />


    View Slide

20. VIEW FINDER SKEWED (16:9)


    View Slide

21. VIEW FINDER SKEWED (4:3)


    View Slide

22. VIEW FINDER CORRECT (4:3)


    View Slide

23. WEIRD, BUT ALSO CORRECT


    View Slide

24. GOOGLE CAMERAX SAMPLES (SIMPLIFIED)
    val matrix = Matrix()
    val centerX = viewFinderSize.width / 2f
    val centerY = viewFinderSize.height / 2f
    val bufferRation = previewSize.height / previewSize.width.toFloat()
    val scaledHeight = viewFiderSize.width
    val scaledWidth = Math.roung(viewFinderSize.width * bufferRatio)
    val xScale = scaledWidth / viewFinderSize.width.toFloat()
    val yScale = scaledHight / viewFinderSize.height.toFloat()
    matrix.preScale(xScale, yScale, centerX, centerY)


    View Slide

25. CAMERAX VIEW FINDER


    View Slide

26. SCALE AND CROP! (SIMPLIFIED)
    val matrix = Matrix()
    val centerX = viewFinderSize.width / 2f
    val centerY = viewFinderSize.height / 2f
    val previewRatio = previewSize.width / previewSize.height.toFloat()
    val viewFinderRatio = viewFinderSize.width / viewFinderSize.height.toFloat()
    // Assume view finder is wider than its height
    matrix.postScale(1.0f, viewFinderRatio * previewRatio, centerX, centerY)


    View Slide

27. View Slide

28. TEXTUREVIEW TRANSFORMS
    ON ANDROID
    WWW.HELLSOFT.SE/TEXTUREVIEW-TRANSFORMS-ON-ANDROID/


    View Slide

29. YUV COLOR
    ENCODING


    View Slide

30. View Slide

31. View Slide

32. View Slide

33. −.4 −.3 −.2 −.1 +.1 +.2 +.3 +.4
    −.1
    +.1
    +.2
    +.3
    +.4
    −.2
    −.3
    −.4
    V
    U


    View Slide

34. YUV ENCODING


    View Slide

35. YUV AND ANDROID CAMERA FRAMES
    imageAnalysis.setAnalyzer { image, rotationDegrees ->
    // image.format is always ImageFormat.YUV_420_888
    }


    View Slide

36. CONVERT YUV TO RGB (FROM WIKIPEDIA)
    void YUVImage::yuv2rgb(uint8_t yValue, uint8_t uValue, uint8_t vValue,
    uint8_t *r, uint8_t *g, uint8_t *b) const {
    int rTmp = yValue + (1.370705 * (vValue-128));
    int gTmp = yValue - (0.698001 * (vValue-128)) - (0.337633 * (uValue-128));
    int bTmp = yValue + (1.732446 * (uValue-128));
    *r = clamp(rTmp, 0, 255);
    *g = clamp(gTmp, 0, 255);
    *b = clamp(bTmp, 0, 255);
    }


    View Slide

37. GRAYSCALE TO THE RESCUE!


    View Slide

38. EXTRACT GRAYSCALE PIXELS
    fun extractGrayscaleFromImage(image: Image): Pair {
    val size = Size(image.width, image.height)
    val yBuffer = image.planes[0].buffer
    val grayPixels = ByteBuffer.allocate(yBuffer.capacity());
    grayPixels.put(yBuffer)
    grayPixels.flip()
    return grayPixels to size
    }


    View Slide

39. CAMERAX
    GOTCHAS!


    View Slide

40. CAMERAX ANALYZER
    MUST BE SYNCHRONOUS!2
    imageAnalysis.setAnalyzer { image, rotationDegrees ->
    // This will crash - analysis must be synchronous!
    // See https://issuetracker.google.com/issues/139207716
    GlobalScope.launch { analyzeImage(image); }
    }
    2 Except when converting to FirebaseVisionImage!


    View Slide

41. CAMERAX ANALYZER
    CAN'T USE IMAGEWRITER!
    val imageWriter = ImageWriter(renderScriptSurface, 1)
    imageAnalysis.setAnalyzer { image, rotationDegrees ->
    // This will crash - CameraX will call Image.close()!
    // See https://issuetracker.google.com/issues/139207716
    val mediaImage = image?.image
    if (mediaImage != null) {
    imageWriter.queueInputImage(image.image)
    }
    }


    View Slide

42. ENABLE TORCH (BACK CAMERA)
    val previewConfig = PreviewConfig.Builder()
    .setLensFacing(CameraX.LensFacing.BACK)
    .build()
    val preview = Preview(previewConfig)
    preview.enableTorch(true)


    View Slide

43. ANALYZE EVERY IMAGE
    val imageAnalysisConfig = ImageAnalysisConfig.Builder()
    .setImageReaderMode(ImageAnalysis.ImageReaderMode.ACQUIRE_NEXT_IMAGE)
    .setImageQueueDepth(5)
    .setTargetResolution(Size(1024, 768))
    .build()


    View Slide

44. ANALYZE IMAGES IN PARALLEL
    // Thread pool with 5 threads
    val executor = Executors.newFixedThreadPool(5)
    val imageAnalysisConfig = ImageAnalysisConfig.Builder()
    .setImageReaderMode(ImageAnalysis.ImageReaderMode.ACQUIRE_NEXT_IMAGE)
    .setImageQueueDepth(5)
    .setTargetResolution(Size(1024, 768))
    .build()
    imageAnalysis.setAnalyzer { image, rotationDegrees ->
    // Analysis can run in parallel
    }
    CameraX.bindToLifecycle(this, imageAnalysis)


    View Slide

45. ANALYZE LATEST IMAGE (RECOMMENDED!)
    val imageAnalysisConfig = ImageAnalysisConfig.Builder()
    .setImageReaderMode(ImageAnalysis.ImageReaderMode.ACQUIRE_LATEST_IMAGE)
    .setImageQueueDepth(5)
    .setTargetResolution(Size(1024, 768))
    .build()


    View Slide

46. CAMERAX ANALYSIS API
    IS TARGET FOR CHANGE!


    View Slide

47. ML KIT


    View Slide

48. FIREBASE ML KIT


    View Slide

49. AUTO-DOWNLOAD REQUIRED ML MODELS
    (OPTIONAL)

    ...
    android:name="com.google.firebase.ml.vision.DEPENDENCIES"
    android:value="ocr" />




    View Slide

50. CONVERT ROTATION DEGREES
    TO FIREBASE ROTATION
    fun degreesToFirebaseRotation(degrees: Int): Int = when(degrees) {
    0 -> FirebaseVisionImageMetadata.ROTATION_0
    90 -> FirebaseVisionImageMetadata.ROTATION_90
    180 -> FirebaseVisionImageMetadata.ROTATION_180
    270 -> FirebaseVisionImageMetadata.ROTATION_270
    else -> throw Exception("Rotation must be 0, 90, 180, or 270.")
    }


    View Slide

51. TEXT RECOGNITION
    val detector = FirebaseVision.getInstance().onDeviceTextRecognizer
    val image = FirebaseVisionImage.fromMediaImage(mediaImage, rotation)
    val result = detector.processImage(image)
    .addOnSuccessListener { resultText ->
    // Task completed successfully
    }
    .addOnFailureListener {
    // Task failed with an exception
    }


    View Slide

52. TEXT RECOGNITION
    val resultText = result.text
    for (block in result.textBlocks) {
    val blockText = block.text
    val blockConfidence = block.confidence
    val blockLanguages = block.recognizedLanguages
    val blockCornerPoints = block.cornerPoints
    val blockFrame = block.boundingBox
    for (line in block.lines) {
    val lineText = line.text
    val lineConfidence = line.confidence
    val lineLanguages = line.recognizedLanguages
    val lineCornerPoints = line.cornerPoints
    val lineFrame = line.boundingBox
    for (element in line.elements) {
    val elementText = element.text
    val elementConfidence = element.confidence
    val elementLanguages = element.recognizedLanguages
    val elementCornerPoints = element.cornerPoints
    val elementFrame = element.boundingBox
    }
    }
    }


    View Slide

53. AUTO ML


    View Slide

54. CAMERAX AND AUTO ML
    dependencies {
    implementation 'com.google.firebase:firebase-ml-vision:23.0.0'
    implementation 'com.google.firebase:firebase-ml-vision-automl:18.0.1'
    }


    View Slide

55. CONFIGURE FIREBASE-HOSTED MODEL
    val conditions = FirebaseModelDownloadConditions.Builder()
    .requireWifi()
    .build()
    val remoteModel = FirebaseRemoteModel.Builder("my_remote_model")
    .enableModelUpdates(true)
    .setInitialDownloadConditions(conditions)
    .setUpdatesDownloadConditions(conditions)
    .build()
    FirebaseModelManager.getInstance().registerRemoteModel(remoteModel)


    View Slide

56. DOWNLOAD THE MODEL
    FirebaseModelManager.getInstance()
    .downloadRemoteModelIfNeeded(remoteModel)
    .addOnSuccessListener {
    // Model downloaded!
    }
    .addOnFailureListener {
    // Ooops!
    }


    View Slide

57. CONFIGURE THE IMAGE LABLER
    val labelerOptions = FirebaseVisionOnDeviceAutoMLImageLabelerOptions.Builder()
    .setRemoteModelName("my_remote_model")
    .setConfidenceThreshold(threshold)
    .build()
    val labeler = FirebaseVision.getInstance()
    .getOnDeviceAutoMLImageLabeler(labelerOptions)


    View Slide

58. PROCESS IMAGE
    labeler.processImage(image)
    .addOnSuccessListener { labels ->
    for (label in labels) {
    val text = label.text
    val confidence = label.confidence
    }
    }


    View Slide

59. CONCLUSIONS
    > CameraX is still in alpha, but ready to use today
    > CameraX Analysis must be synchronous
    > View finder transform is tricky
    > ML Kit covers most use cases


    View Slide

60. THANK YOU FOR
    LISTENING!
