Contributing to Construct Hub with projen

I spoke at the CDK chapter of the Japan AWS User Group about contributing to Construct Hub using projen.

Transcript

1. Contributing to
   Construct Hub with projen
   JAWS-UG CDK #1
   June 1st, 2022
   Hayato Kosugi


   View Slide

2. About Me
   • Cloud Engineer @ Saison Information Systems
   • AWS Community Builder (Fall of 2020)
   • 2019 - 2022 APN AWS Top Engineers in Japan
   • 11x AWS Certified
   2
   @hayaok3 @hayao-k


   View Slide

3. What is Construct Hub?
   • Registry for discovering and sharing Construct Libraries
   published by community, AWS, and AWS partners.
   • December 2021 - GA on same date as AWS CDK v2
   • More than 1k Construct Libraries available
   • https://constructs.dev/
   3


   View Slide

4. How to get listed on Construct Hub
   • JSII-compatible
   • For multi-language support
   • Open-source license
   • Apache, BSD, EPL, MPL-2.0, ISC, and CDDL or MIT
   • Published to npm Registry with CDK Keyword
   • cdk, awscdk, aws-cdk, cdk8s, or cdktf
   • Meet requirements, appear in Construct Hub in 30 minutes
   4


   View Slide

5. View Slide

6. Recommend
   developing with projen
   6


   View Slide

7. Problems when developing with TypeScript
   • Management of project configurations has become more
   complex in recent years
   • For TypeScript Project
   • package.json, tsconfig.json, .gitignore, eslint, jest, etc.
   • Learn by example but difficult
   7


   View Slide

8. What is Projen?
   • A new generation of project generators
   • Applied construct programming model to project configuration
   • Tools to define and maintain project configurations in code
   • projen manages configuration files such as package.json and
   tsconfig.json, etc.
   • Manage them continuously (Not only create)
   • https://github.com/projen/projen
   8


   View Slide

9. • node - Node.js project.
   • project - Base project.
   • python - Python project.
   • react - React project without TypeScript.
   • react-ts - React project with TypeScript.
   • typescript - TypeScript project.
   • typescript-app - TypeScript app.
   Built-in Project types
   • awscdk-app-java - AWS CDK app in Java.
   • awscdk-app-py - AWS CDK app in Python.
   • awscdk-app-ts - AWS CDK app in TypeScript.
   • awscdk-construct - AWS CDK construct library project.
   • cdk8s-app-ts - CDK8s app in TypeScript.
   • cdk8s-construct - CDK8s construct library project.
   • cdktf-construct - CDKTF construct library project.
   • java - Java project.
   • jsii - Multi-language jsii library project.
   • nextjs - Next.js project without TypeScript.
   • nextjs-ts - Next.js project with TypeScript.
   9
   $ mkdir awesome-project
   $ cd awesome-project
   $ git init
   $ npx projen new PROJECT-TYPE
   🤖 Synthesizing project...
   awscdk-construct is project type for creating jsii-compatible construct library


   View Slide

10. Create Construct Library project
    • projen new awscdk-construct
    • Files required for development are
    generated.
    • package.json, tsconfig, GitHub Actions
    Workflow, etc.
    • Customize settings in .projenrc.js
    • Minimum CDK versions to support
    • Dependencies with other libraries
    • Library name in each package manager, etc.
    10


    View Slide

11. .projenrc.js example
    11
    • Apply changes with projen command
    • No manual editing
    • Build fails if edited manually
    • e.g., publishToPypi
    • python added to jsii configuration in
    package.json
    • Step to publish to PyPI added to
    release.yml (GitHub Actions)
    API Reference
    https://projen.io/api/API.html#projen-awscdk-awscdkconstructlibrary
    const { awscdk } = require('projen');
    const cdkVersion = '2.25.0';
    const project = new awscdk.AwsCdkConstructLibrary({
    author: 'hayao-k',
    authorAddress: '30886141+hayao-k@users.noreply.github.com',
    cdkVersion,
    defaultReleaseBranch: 'main',
    name: 'cdk-sample-lib',
    repositoryUrl: 'https://github.com/hayao-k/cdk-sample-lib.git',
    description: 'Sample AWS CDK Construct Library by projen',
    keywords: ['sample'],
    license: 'Apache-2.0',
    deps: [
    `@aws-cdk/aws-apigatewayv2-alpha@${cdkVersion}-alpha.0`,
    `@aws-cdk/aws-apigatewayv2-integrations-alpha@${cdkVersion}-alpha.0`,
    'other-useful-lib'
    ],
    publishToPypi: {
    distName: 'cdk-sample-lib',
    module: 'cdk_sample_lib',
    },
    });
    project.synth();


    View Slide

12. Easily automated release
    • Build workflow (.github/workflows/build.yml)
    • Run at creating a pull request
    • Tampering checks and building library
    • Release workflow (.github/workflows/release.yml)
    • Run at push to release branch
    • Tampering checks and building library
    • Semantic Versioning with Conventional Commits
    • Publish to GitHub Releases, each language registry
    12


    View Slide

13. Guide with sample code
    • A Beginner's Guide to Create AWS
    CDK Construct Library with projen
    • https://dev.to/aws-builders/a-beginner-s-
    guide-to-create-aws-cdk-construct-library-
    with-projen-5eh4
    • Featured on Construct Hub!!
    13


    View Slide

14. Summary
    • Construct Hub
    • Construct Hub is a place to discover CDK constructs
    • Many useful libraries
    • We can publish our library
    • projen
    • Dramatically eases project configuration management and CI/CD
    • Easily publish your libraries to Construct Hub
    • Awesome developer experience
    14


    View Slide

15. Happy Constructing!
    15


    View Slide
