Hunting Moby Dick: An Introduction to Docker

Transcript

1. Hunting Moby Dick: An
   Introduction to Docker
   Jaime Arias
   December 2017


   View Slide

2. Introduction
   Why Docker ?
   1
   2


   View Slide

3. Why Docker
   ◎ “Dockerized” apps are completely portable
   and can run anywhere.
   ◎ Developers can automate their build
   pipeline and share artifacts with Docker
   Hub.
   ◎ “Dockerized” apps are isolated from their
   surroundings.
   “W ” - M
   “I f USB ” - M
   “T f R 3.Y I R 3.X” - M
   3


   View Slide

4. Why Docker
   4


   View Slide

5. Installation
   https://www.docker.com
   2
   5


   View Slide

6. Download & Installation
   N 6


   View Slide

7. OSX Installation
   7


   View Slide

8. OSX Installation
   8


   View Slide

9. OSX Configuration
   9


   View Slide

10. Ubuntu Installation
    Link: https://tinyurl.com/docker-ubuntu
    1. Update the apt package index
    2. Install packages to allow apt to use a repository over HTTPS
    10


    View Slide

11. Ubuntu Installation
    Link: https://tinyurl.com/docker-ubuntu
    3. Add Docker’s official GPG key:
    4. Use the following command to set up the stable repository.
    11


    View Slide

12. Ubuntu Installation
    Link: https://tinyurl.com/docker-ubuntu
    1. Update the apt package index
    2. Install the latest version of Docker CE
    3. Add your user to the docker group
    12


    View Slide

13. Testing Installation
    13


    View Slide

14. Basic Commands
    https://tinyurl.com/docker-commands
    3
    14


    View Slide

15. Basic Commands
    docker COMMAND --help
    Print COMMAND usage.
    docker pull NAME[:TAG]
    Pull an image or a repository
    from Docker Hub to the machine.
    docker images
    Show all top level images, their
    repository and tags, and their
    size.
    docker rmi IMAGE
    Remove one or more images.
    15


    View Slide

16. Basic Example
    16


    View Slide

17. Basic Commands
    docker run --rm [OPTIONS] IMAGE [COMMAND] [ARGS]
    Run a COMMAND with specific ARGS in a new container.
    OPTIONS
    ◎ --detach, -d Run container in background and print container ID
    ◎ --env, -e Set environment variables
    ◎ --interactive, -i Keep STDIN open
    ◎ --name Assign a name to the container
    ◎ --publish, -p Publish a container’s port(s) to the host
    ◎ --rm Automatically remove the container when it exits
    ◎ --tty, -t Allocate a pseudo-TTY
    ◎ --volume, -v Bind mount a volume
    17


    View Slide

18. Basic Example
    18


    View Slide

19. Basic Example
    19


    View Slide

20. Data: https://tinyurl.com/pyhrf-test
    Basic Example
    20


    View Slide

21. Basic Example
    21


    View Slide

22. Basic Example
    Viewer: https://tinyurl.com/mango-viewer
    22


    View Slide

23. Basic Commands
    docker exec CONTAINER
    Run a command in a running
    container.
    docker ps -a
    List the running containers.
    docker stop CONTAINER
    Stop one or more running
    containers.
    docker rm -f CONTAINER
    Remove one or more containers
    23


    View Slide

24. Basic Example
    Instructions: https://tinyurl.com/docker-rstudio
    24


    View Slide

25. Basic Example
    25


    View Slide

26. Create a Docker Image
    https://tinyurl.com/dockerfile-ref
    4
    26


    View Slide

27. Dockerfile
    File: http://tinyurl.com/frama-docker
    27


    View Slide

28. Build & Publish
    Build
    1. Create a Dockerfile (recipe)
    2. Build an image from the Dockerfile in the
    current directory and tag it
    Publish
    1. Retag a local image for a private registry
    2. Log in to a registry (Docker Hub)
    3. Push an image to the registry (upload)
    28


    View Slide

29. Basic Commands
    docker build -t NAME[:TAG] PATH
    Build an image from a Dockerfile.
    docker login [SERVER]
    Log in to a Docker registry
    docker push NAME[:TAG]
    Push an image or a repository to a
    registry
    docker tag SOURCE TARGET
    Create a tag TARGET_IMAGE that
    refers to SOURCE_IMAGE
    29


    View Slide

30. Basic Example
    30


    View Slide

31. Docker & Mistis’ Cluster
    5
    Avoiding Jean-François ...
    31


    View Slide

32. Basic Commands
    docker save -o PATH IMAGE
    Save one or more images to a tar archive
    docker load -i PATH
    Load an image from a tar archive.
    32


    View Slide

33. Basic Example
    L M
    C M
    33


    View Slide

34. Thanks!
    Any questions?
    34


    View Slide

35. Credits
    Special thanks to all the people
    who made and released these
    awesome resources for free:
    ◎ Presentation template by
    SlidesCarnival
    ◎ Photographs by Unsplash
    35
