1. Android Graphics Architecture Overview 2015.08.20
3. Android graphics stack overview • App acquires its own Surface(s) from SurfaceFlinger ◦ comes with a Canvas and a graphics buffer • App uses Canvas to draw the screen ◦ underlying implementations may use OpenGL or software render engine (e.g. SKIA) • SurfaceFlinger composes final screen from Surfaces ◦ get Activity status from ActivityManager ◦ get z-order information from WindowManager • Gralloc maps to the framebuffer device (fb0)
4. Android View component • Button, TextView… are all Views • A page layout is composed of a tree of Views • Actual drawing behavior implemented in onDraw() method of each View ◦ Display List: a set of graphic commands ◦ commands can be mapped to OpenGL commands • Create DeferredDisplayList in order to optimize the rendering order ◦ analyze the overlapping… relationships ◦ minimize GPU usage
5. Android View component • An example of Display List (button) ◦ Save 3 ◦ DrawPatch ◦ Save 3 ◦ ClipRect 20.00, 4.00, 99.00, 44.00, 1 ◦ Translate 20.00, 12.00 ◦ DrawText 9, 18, 9, 0.00, 19.00, 0x17e898 ◦ Restore ◦ RestoreToCount 0 • Can be mapped to gl-prefix OpenGL commands
6. 2D rendering path • Can be rendered by HW or SW ◦ HWUI: hardware accelerated using OpenGL ES 2.0 ◦ Skia: software render engine
7. 3D rendering path • App can instead create GLSurfaceView • Use OpenGL ES bindings for Java • Either use vendor GPU driver or software-based PixelFlinger to render the drawing to Surface
8. SurfaceFlinger Compose, but not render!
9. SurfaceFlinger • Services connections from activities (client) via Binder interface ISurfaceComposer (server) • Activity acquires Surface from SurfaceFlinger ◦ created by ISurfaceComposer • Receives activity status from ActivityManager • Receives window status (visibility, z-order) from WindowManager • Composes multiple Surfaces into a single image ◦ by HWComposer: also generates VSYNC
10. SurfaceFlinger • GraphicBuffer ◦ allocated by Gralloc, accessed using mmap ◦ pixel format: RGB/RGBA/RGBO • Project Butter ◦ VSYNC ◦ Triple Buffer ◦ Choreographer ◦ http://www.androidpolice.com/2012/07/12/getting-to-know-andr oid-4-1-part-3-project-butter-how-it-works-and-what-it-added/
11. VSYNC Signal • Generated by HWComposer ◦ HW source: register callback of HAL ◦ or SW source: VSyncThread • Distributed by SurfaceFlinger ◦ Client can create an event connection to SurfaceFlinger’s MessageQueue to receive the VSync event ◦ SurfaceFlinger inherits HWComposer::EventHandler to handle onVSyncRecieved() and notify listeners
12. Application • Each page has its View Tree • Need to traverse the tree when ◦ App or page being launched ◦ External event: touch, key press ◦ Internal event: UI control change, View.Visibility • How to traverse ◦ Post a request to Choreographer (if no request left) ◦ Choreograpger calls perfromTraversals() when VSYNC signal triggered
13. Application • Inside performTraversals() ◦ performMeasure(): calculate size of UI controls ◦ performLayout(): calculate UI layout ◦ performDraw() • Inside performDraw() ◦ High level: draw to Canvas (based on Surface in Java level) ◦ Low level ▪ Lock Surface (native level) to dequeue a buffer from BufferQueue ▪ Render to buffer by OpenGL ES or SKIA ▪ Unlock Surface to enqueue the buffer
14. Surface (native level) • Each app/page can acquire one or more Surface/Layer • Done by using ISurfaceComposerClient to connect to SurfaceFlinger’s Binder service • ISurfaceComposerClient will return a SurfaceControl, then use it to create Surface • One of two native windows in Android graphic systems (another one is for SurfaceFlinger) • OpenGL ES render to the buffer and enqueue to BufferQueue of Surface, act as a “producer”
15. BufferQueue • A producer/consumer pattern ◦ Producer: Application (Surface) ◦ Consumer: SurfaceFlinger • Buffer operation ◦ Application: dequeue()->write buffer->enqueue() ◦ SurfaceFlinger: acquire()->read buffer->release() • When a buffer being queued ◦ Layer listens to onFrameAvailable() callback ◦ Call Layer’s onFrameQueued() to increment counter variable: mQueuedFrames
16. BufferQueue read buffer write buffer Application Surfaceflinger
