  1. Testing Docker Images Security Bsides Manchester, August 2017

  2. Jose Manuel Ortega Software Engineer & Security Researcher @jmortegac jmortega.github.io

  3. Agenda • Introduction to docker security • Security best practices

    • Tools for auditing docker images
  4. Docker • “Docker containers wrap up a piece of software

    in a complete filesystem that contains everything it needs to run: code, runtime, system tools, system libraries – anything you can install on a server. This guarantees that it will always run the same, regardless of the environment it is running in.”
  5. Docker Security • Docker provides an additional layer of isolation,

    making your infrastructure safer by default. • Makes the application lifecycle fast and easier,reducing risks in your applications
  6. Docker Security • Docker uses several mechanisms for security: ◦

    Linux kernel namespaces ◦ Linux Control Groups (cgroups) ◦ The Docker daemon ◦ Linux capabilities (libcap) ◦ Linux security mechanisms like AppArmor or SELinux
  7. Docker Security • Namespaces:provides an isolated view of the system

    where processes cannot see other processes in other containers • Each container also gets its own network stack. • A container doesn’t get privileged access to the sockets or interfaces of another container.
  8. Docker Security • Cgroups: kernel feature that limits and isolates

    the resource usage(CPU,memory,network) of a collection of processes. • Linux Capabilities: divides the privileges of root into distinct units and smaller groups of privileges.
  9. DockerHub

  10. DockerFile https://github.com/CenturyLinkLabs/dockerfile-from-image

  11. Docker images • Images are extracted in a chrooted sub

    process, being the first-step in a wider effort toward privilege separation. • From Docker 1.10, all images are stored and accessed by the cryptographic checksums of their contents, limiting the possibility of an attacker causing a collision with an existing image Docker Content Trust.
  12. Docker Content Trust • Protects against untrusted images • Can

    enable signing checks on every managed host • Signature verification transparent to users • Guarantee integrity of your images when pulled • Provides trust from publisher to consumer • export DOCKER_CONTENT_TRUST=1 • ~/.docker/trust/trusted-certificates/
  13. Security Best Practices

  14. DockerFile Security • Do not write secrets(users and passwords). •

    Remove unnecessary setuid, setgid permissions (Privilege escalation) • Download packages securely using GPG and certificates • Try to restrict an image or container to one service
  15. Security best practices • To disable setuid rights, add the

    following to the Dockerfile of your image
  16. Security best practices • Don’t run containers with --privileged flag

    • The --privileged flag gives all capabilities to the container. • docker run --privileged ... • docker run --cap-drop=ALL --cap-add=CAP_NET_ADMIN ...
  17. Security best practices capabilities • How do we add/remove capabilities?

    • Use cap-add and cap-drop with docker run/create • Drop all capabilities which are not required • docker run --cap-drop ALL --cap-add $CAP
  18. Security best practices capabilities • Manual management within the container:

    docker run --cap-add ALL • Restricted capabilities with root: docker run --cap-drop ALL --cap-add $CAP • No capabilities: docker run --user
  19. Security best practices capabilities

  20. Security best practices • Set a specific user. • Don’t

    run your applications as root in containers.
  21. Security best practices • We can verify the integrity of

    the image • Checksum validation when pulling image from docker hub • Pulling by digest to enforce consistent
  22. Security best practices • Check packages installed in the container

  23. Docker security is about limiting and controlling the attack surface

    on the kernel.
  24. Docker least privileges • Do not run processes in a

    container as root to avoid root access from attackers. • Enable User-namespace (disabled by default) • Run filesystems as read-only so that attackers can not overwrite data or save malicious scripts to the image. • Cut down the kernel calls that a container can make to reduce the potential attack surface. • Limit the resources that a container can use (SELinux/AppArmor)
  25. Containers and volumes read-only 15

  26. Checklist Dockerfile

  27. Checklist building/maintaining/consuming

  28. AUDITING TOOLS

  29. Docker images scanning • You can scan your images for

    known vulnerabilities • There are tools for that, like Docker Security Scanning, Docker Bench Security and CoreOS Clair • Find known vulnerable binaries
  30. Docker Security Scanning https://docs.docker.com/docker-cloud/builds/image-scan/ • Checks based on best practices

    for hosts and containers • Find Common Vulnerabilities and Exposures (CVEs)
  31. Docker Security Scanning • Checks against CVE database for image

    layers • Binary scanning of all components in the image • Performs binary scan to pick up on statically linked binaries • Analyses libraries statically compiled in the image • Generates a reports that shows if there are CVE in the libraries inside the image
  32. Docker Security Scanning 15 25

  33. Docker Security Scanning

  34. Docker CVE https://www.docker.com/docker-cve-database

  35. Security pipeline

  36. Clair (Container Vulnerability Analysis Service) https://github.com/coreos/clair Vulnerability Static Analysis for

    Containers
  37. Clair Use cases • You've found an image by searching

    the internet and want to determine if it's safe enough for you to use in production. • You're regularly deploying into a containerized production environment and want operations to alert or block deployments on insecure software.
  38. None
  39. None
  40. Docker Bench Security https://github.com/docker/docker-bench-security Checks based on best practices for

    hosts and containers
  41. Docker bench security • Open-source tool for running automated tests

    • Inspired by the CIS Docker 1.11 benchmark • Runs against containers currently running on same host • Checks for AppArmor, read-only volumes, etc...
  42. None
  43. Docker bench security

  44. Docker bench security • The host configuration • The Docker

    daemon configuration • The Docker daemon configuration files • Container images and build files • Container runtime • Docker security operations
  45. Docker bench security • The Docker daemon configuration • [WARN]

    2.1- Restrict network traffic between containers • [WARN] 4.1 - Create a user for the container [WARN] * Running as root: • [WARN] 5.4 - Restrict Linux Kernel Capabilities within containers [WARN] * Capabilities added: CapAdd=[audit_control] • [WARN] 5.13 - Mount container's root filesystem as readonly [WARN] * Container running with root FS mounted R/W:
  46. 15 25 22

  47. Docker Slim https://github.com/docker-slim/docker-slim Optimize and secure your Docker containers

  48. Other tools • OpenSCAP Container Compliance • Lynis • Twistlock

    • Dockscan • Aqua Security • Dagda
  49. OpenScap Clair Lynis TwistLock DockScan Images and Containers Images and

    Containers DockerFile Images, containers, packages. Kubernetes Mesos. Docker server RedHat /Fedora /CentOS based containers Debian /Ubuntu /CentOS based containers Linux and Unix based Systems Linux and Unix based Systems Docker and container installations
  50. Lynis • Lynis is a Linux, Mac and Unix security

    auditing and system hardening tool that includes a module to audit Dockerfiles. • lynis audit dockerfile <file>
  51. • https://github.com/CISOfy/lynis-docker

  52. Dagda • Static analysis of known vulnerabilities on Docker containers

    • Allows monitoring Docker containers for detecting anomalous activities
  53. Dagda • Python 3 • MongoDB • PyMongo • Requests

    • Python-dateutil • Joblib • Docker-py • Flask • Flask-cors • PyYAML
  54. • python3 dagda.py check --docker_image <image_name> • python3 dagda.py history

    <image_name> --id <Id_Scan>
  55. None
  56. None
  57. Conclusions Signing • Secure & sign your source Dependences •

    Pin & verify your dependencies Content Trust • Sign your artifacts with Docker Content Trust Privileges • Least Privilege configurations
  58. References • https://docs.docker.com/engine/security • http://www.oreilly.com/webops-perf/free/files/dock er-security.pdf • http://container-solutions.com/content/uploads/201 5/06/15.06.15_DockerCheatSheet_A2.pdf •

    https://www.openshift.com/promotions/docker-sec urity.html
  59. References • Docker Content Trust • https://docs.docker.com/engine/security/trust/content_trust • Docker Security

    Scanning • https://docs.docker.com/docker-cloud/builds/image-scan • https://blog.docker.com/2016/04/docker-security • http://softwaretester.info/docker-audit/
  60. Books
