Deep Learning for CT Reconstruction: From Concept to Practices

Deep Learning for CT Reconstruction: From Concept to Practices

Refresher Course by Jong Chul Ye, CT Meeting 2018, The Fifth International Conference on Image Formation in X-Ray Computed Tomography, May 20-23, 2018, Salt Lake City, USA

A3d61bc22cd700a92e7d4136a4d29e8f?s=128

Jong Chul Ye

May 23, 2018
Tweet

Transcript

  1. Jong Chul Ye Bio-Imaging & Signal Processing Lab. Dept. Bio

    & Brain Engineering Dept. Mathematical Sciences KAIST, Korea Refresher Course Deep Learning for CT Reconstruction: From Concept to Practices This can be downloaded from http://bispl.weebly.com
  2. Course Overview •  Introduction •  CNN review •  Deep learning:

    biological origin •  Deep learning: mathematical origin •  Applications to CT •  Programming Example
  3. Deep Learning Age •  Deep learning has been successfully used

    for classification, low-level computer vision, etc •  Even outperforms human observers
  4. 3

  5. Low-dose CT with Adversarial loss

  6. Sparse-view CT with Variational Network Chen et al, “LEARN”, arXiv:1707.09636

  7. CT Filter design using Neural Network Würfl, Tobias, et al.

    2016.
  8. •  Successful demonstra5on of deep learning for various image reconstruc5on

    problems –  Low-dose x-ray CT (Kang et al, Chen et al, Wolterink et al) –  Sparse view CT (Jin et al, Han et al, Adler et al) –  Interior tomography (Han et al) –  Stationary CT for baggage inspection (Han et al) –  CS-MRI (Hammernik et al, Yang et al, Lee et al, Zhu et al) –  US imaging (Yoon et al ) –  Diffuse optical tomography (Yoo et al) –  Elastic tomography (Yoo et al) –  etc •  Advantages –  Very fast reconstruction time –  Significantly improved results Other works
  9. WHY DEEP LEARNING WORKS FOR RECON ? DOES IT CREATE

    ANY ARTIFICIAL FEATURES ?
  10. First CNN: LeNet (LeCun, 1998)

  11. Convolutional Layer

  12. Pooling Layer Figure from Leonardo Araujo Aantos

  13. Too Simple to Analyze.. Convolution & pooling à stone age

    tools of signal processing What do they do ?
  14. Dark Age of Applied Mathematics ?

  15. CNN – BIOLOGICAL ORIGIN A LAYMAN’S EXPLANATION

  16. 15 http://klab.smpp.northwestern.edu/wiki/images/4/43/NTM2.pdf Emergence of Hiearchical Features

  17. 16 http://www.vicos.si/File:Lhop-hierarchy-second.jpg •  LeCun et al, Nature, 2015 Hierarchical representation

  18. Visual Information Processing in Brain 17 Kravitz et al, Trends

    in Cognitive Sciences January 2013, Vol. 17, No. 1
  19. Retina, V1 Layer 18 Receptive fields of two ganglion cells

    in retina à convolution Orientation column in V1 http://darioprandi.com/docs/talks/image-reconstruction-recognition/graphics/pinwheels.jpg Figure courtesy by distillery.com
  20. “The Jennifer Anniston Cell” 19 Quiroga et al, Nature, Vol

    435, 24, June 2005
  21. 20

  22. CNN – MATHEMATICAL UNDERSTANDING

  23. Why Deep Learning works for recon ? Existing views 1:

    unfolded iteration •  Most prevailing views •  Direct connec5on to sparse recovery –  Cannot explain the filter channels Jin, arXiv:1611.03679
  24. Why Deep Learning works for recon ? Existing views 2:

    generative model •  Image reconstruc5on as a distribu5on matching –  However, difficult to explain the role of black-box network Bora et al, Compressed Sensing using Generative Models, arXiv:1703.03208
  25. Our Proposal: Deep Learning == Deep Convolutional Framelets •  Ye

    et al, “Deep convolutional framelets: A general deep learning framework for inverse problems”, SIAM Journal Imaging Sciences, 11(2), 991-1048, 2018.
  26. Matrix Representation of CNN Figure courtesy of Shoieb et al,

    2016
  27. Hankel Matrix: Lifting to Higher Dimensional Space

  28. Why we are excited about Hankel matrix ? T -T

    0 n1 -n1 0 * FRI Sampling theory (VeEerlie et al) and compressed sensing
  29. ︙ ︙ 1 2 3 4 5 6 7 8

    9 -1 0 1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9 12 2 3 4 5 6 7 8 9 12 13 3 4 5 6 7 8 9 10 10 10 10 0 11 11 11 1 2 3 4 5 Finite length convolution Matrix Representation * ALOHA : Annihilating filter based LOw rank Hankel matrix Approach * Jin KH et al. IEEE TCI, 2016 * Jin KH et al.,IEEE TIP, 2015 * Ye JC et al. IEEE TIT, 2016 Annihilating filter-based low-rank Hankel matrix
  30. Missing elements can be found by low rank Hankel structured

    matrix comple5on Nuclear norm Projec5on on sampling posi5ons min m kH ( m ) k⇤ subject to P⌦(b) = P⌦( f ) RankH(f) = k * Jin KH et al IEEE TCI, 2016 * Jin KH et al.,IEEE TIP, 2015 * Ye JC et al., IEEE TIT, 2016 m Annihilating filter-based low-rank Hankel matrix
  31. Algorithmic Flow

  32. 18. APR. 2015. 31 * Image Inpainting Results

  33. 32

  34. Low-rank Hankel matrix in Image

  35. 18. APR. 2015. 34 Algorithmic Flow ALOHA Computationally Heavy

  36. Key Observation Data-Driven Hankel matrix decomposition => Deep Learning • 

    Ye et al, “Deep convolutional framelets: A general deep learning framework for inverse problems”, SIAM Journal Imaging Sciences, 11(2), 991-1048, 2018.
  37. H d(f) H d(f) = ˜ T ˜ T C

    C = T H d(f) C = T (f ~ ) Encoder: ˜ T = I ˜ = PR(V ) H d(f) = U⌃V T Unlifting: f = (˜C) ~ ⌧(˜ ) : Non-local basis : Local basis : Frame condition : Low-rank condition convolution pooling un-pooling convolution : User-defined pooling : Learnable filters H pi (gi) = X k,l [Ci]kl e Bkl i Decoder: Deep Convolutional Framelets (Y, Han, Cha; 2018)
  38. Single Resolution Network Architecture

  39. Multi-Resolution Network Architecture

  40. Role of ReLU: Conic encoding D. D. Lee and H.

    S. Seung, Nature, 1999 ReLU: positive framelet coefficients Conic encoding à part by representation similar to visual cortex
  41. https://www.youtube.com/watch?v=DdC0QN6f3G4 Relativity: Lifting to the Space-time à linear trajectory High

    Dimensional Lifting in Relativity Falling apple Apple at rest Universal law of gravity: 3-D Space à curved trajectory Falling apple Apple at rest
  42. Compressed Sensing Hankel Structured Matrix Comple7on Deep Learning 49 From

    CS to Deep Learning: Coherent Theme
  43. DEEP NETWORKS FOR CT

  44. Low-Dose CT •  To reduce the radiation exposure, sparse-view CT,

    low-dose CT and interior tomography. Sparse-view CT (Down-sampled View) Low-dose CT (Reduced X-ray dose) Interior Tomography (Truncated FOV)
  45. 52 Wavelet transform level 2 level 1 level 3 level

    4 Wavelet recomposition + Residual learning : Low-resolution image bypass High SNR band CNN (Kang, et al, Medical Physics 44(10))
  46. Routine dose Quarter dose (Kang, et al, Medical Physics 44(10)

    2017)
  47. Routine dose AAPM-Net results (Kang, et al, Medical Physics 44(10)

    2017)
  48. WavResNet results (Kang et al, TMI, 2018)

  49. WavResNet results (Kang et al, TMI, 2018)

  50. MBIR Our latest Result C D WavResNet results

  51. Full dose Quarter dose

  52. Full dose Quarter dose

  53. Sparse-View CT •  To reduce the radiation exposure, sparse-view CT,

    low-dose CT and interior tomography. Sparse-view CT (Down-sampled View) Low-dose CT (Reduced X-ray dose) Interior Tomography (Truncated FOV)
  54. Multi-resolution Analysis & Receptive Fields

  55. Problem of U-net Pooling does NOT satisfy the frame condition

    JC Ye et al, SIAM Journal Imaging Sciences, 2018 Y. Han et al, TMI, 2018. ext > ext = I + > 6= I
  56. Improving U-net using Deep Conv Framelets •  Dual Frame U-net

    •  Tight Frame U-net JC Ye et al, SIAM Journal Imaging Sciences, 2018 Y. Han and J. C. Ye, TMI, 2018
  57. U-Net versus Dual Frame U-Net

  58. Tight-Frame U-Net JC Ye et al, SIAM Journal Imaging Sciences,

    2018 Han et al, TMI, 2018
  59. 90 view recon U-Net vs. Tight-Frame U-Net •  JC Ye

    et al, SIAM Journal Imaging Sciences, 2018 •  Y. Han and J. C. Ye, TMI, 2018
  60. None
  61. None
  62. •  Figures from internet 9 View CT for Baggage Screening

  63. 9 View CT for Baggage Screening

  64. 1st view 2nd view 3rd view 4th view 5th view

    6th view 7th view 8th view 9th view
  65. FBP

  66. TV

  67. Ours

  68. ROI Reconstruction •  To reduce the radiation exposure, sparse-view CT,

    low-dose CT and interior tomography. Sparse-view CT (Down-sampled View) Low-dose CT (Reduced X-ray dose) Interior Tomography (Truncated FOV)
  69. Deep Learning Interior Tomography Han et al, arXiv preprint arXiv:1712.10248,

    (2017): CT meeting 2018.
  70. Ground Truth FBP

  71. TV Chord Line Ours 8~10 dB gain

  72. Ground Truth Chord Line TV Ours

  73. Still Unresolved Problems.. •  Cascaded geometry of deep neural network

    •  Generalization capability •  Optimization landscape •  Training procedure •  Extension to classification problems
  74. DEEP LEARNING - PRACTICES

  75. Dataset of Natural Images •  MNIST (http://yann.lecun.com/exdb/mnist/) –  Handwritten digits.

    •  SVHN (http://ufldl.stanford.edu/housenumbers/) –  House numbers from Google Street View. •  ImageNet (http://www.image-net.org/) –  The de-facto image dataset. •  LSUN (http://lsun.cs.princeton.edu/2016/) –  Large-scale scene understanding challenge. •  Pascal VOC ( http://host.robots.ox.ac.uk/pascal/VOC/) –  Standardized image dataset. •  MS COCO (http://cocodataset.org/#home) –  Common Objects in Context. •  CIFAR-10 / -100 (https://www.cs.utoronto.ca/~kriz/cifar.html) –  Tiny images data set. •  BSDS300 / 500 ( https://www2.eecs.berkeley.edu/Research/ Projects/CS/vision/grouping/resources.html) –  Contour detection and image Segmentation resources. https://en.wikipedia.org/wiki/List_of_datasets_for_machine_learning_research https://www.kaggle.com/datasets
  76. Dataset for Medical Images •  HCP (https://www.humanconnectome.org/) –  Behavioral and

    3T / 7T MR imaging dataset. •  MRI Data (http://mridata.org/) –  Raw k-space dataset acquired on a GE clinical 3T scanner. •  LUNA (https://luna16.grand-challenge.org/data/) –  Lung Nodule analysis dataset acquired on a CT scanner. •  Data Science Bowl (https://www.kaggle.com/c/data-science-bowl-2017) –  A thousand low-dose CT images. •  NIH Chest X-rays (https://nihcc.app.box.com/v/ChestXray-NIHCC) –  X-ray images with disease labels. http://www.cancerimagingarchive.net/ https://www.kaggle.com/datasets •  TCIA Collections (http://www.cancerimagingarchive.net/) •  De-identifies and hosts a large archive of medical images of cancer accessible for public download. •  The data are organized as “Collections”, typically patients related by a common disease, image modality (MRI, CT, etc).
  77. Libraries for Deep learning •  TensorFlow (https://www.tensorflow.org/) –  Python • 

    Theano ( http://deeplearning.net/software/theano/) –  Python •  Keras (https://keras.io/) –  Python •  Caffe (http://caffe.berkeleyvision.org/) –  Python •  Torch (or PyTorch) (http://torch.ch/) –  C / C++ (or Python) •  Deeplearning4J ( https://deeplearning4j.org/) –  Java •  Microsoft Cognitive Toolkit (CNTK) ( https://www.microsoft.com/en-us/cognitive- toolkit/) –  Python / C / C++ •  MatConvNet ( http://www.vlfeat.org/matconvnet/) –  Matlab
  78. Implementation on MatConvNet Download the MatConvNet Provide the pre-trained models

  79. Step 1: Compile the toolbox 1.  Unzip the MatConvNet toolbox.

    2.  Open ‘vl_compilenn.m’ in Matlab.
  80. Step 1: Compile the toolbox (cont.) 3.  Check the options

    such as enableGpu and enableCudnn. 4.  Run the ‘vl_compilenn.m’. * To use GPU processing (false true), you must have CUDA installed. ( https://developer.nvidia.com/cuda-90-download-archive ) ** To use cuDNN library (false true), you must have cuDNN installed. ( https://developer.nvidia.com/cudnn )
  81. Step 2: Prepare dataset As a classification example, MNIST consists

    of as follows, Images % struct-type Data % handwritten digit image labels % [1, …, 10] set % [1, 2, 3], 1, 2, and 3 indicate train, valid, and test set, respectively. Data Labels 6
  82. Step 2: Prepare dataset (cont.) •  As a segmentation example,

    U-Net dataset consists of as follows, –  Images % struct-type Ø  data % Cell image Ø  labels % [1, 2], Mask image. 1 and 2 indicate back- and for-ground, respectively. Ø  set % [1, 2, 3] Data Labels
  83. Step 3: Implementation of the network architecture •  Developers only

    need to program the network architecture code because MatConvNet supports the network training framework. Support famous network architectures, such as alexnet, vggnet, resnet, inceptionent, and so on.
  84. Step 3: Implementation of the architecture (cont.) –  The implementation

    details of U-Net U-Net can be implemented, recursively. Stage 0 Stage 1 Stage 2 Stage 3 Stage 4
  85. Step 3: Implementation of the architecture (cont.) 1.  Create objects

    of network and layers. Encoder Part Skip + Concat Part Decoder Part •  The structure of Stage 0 Network Part
  86. Step 3: Implementation of the architecture (cont.) 2.  Connect each

    layers. •  The structure of Stage 0 Layer Name ( string-type ) Layer object ( object ) Input Name ( string-type ) Output Name ( string-type ) Parameters Name ( string-type ) All objects and names must be unique.
  87. Step 3: Implementation of the architecture (cont.) 3.  Implement recurrently

    the each stages and add a loss function. Previous parts (3.1 and 3.2) become functional as ‘add_block_unet’.
  88. Step 4: Network hyper-parameter set up •  MatConvNet supports the

    default hyper-parameters as follows, Refer the cnn_train.m ( or cnn_train_dag.m ) The supported hyper-parameters 1.  The size of mini-batch 2.  The number of epochs 3.  Learning rate 4.  Weight decay factor 5.  Solvers such as SGD, AdaDelta, AdaGrad, Adam, and RMS The kind of Optimization Solvers
  89. Step 5: Run the training script 1. Training script 2.

    Training loss 3. Training loss graph •  Blue : train •  Orange : valid
  90. Acknowledgements CT Team •  Yoseob Han •  Eunhee Kang • 

    Jawook Goo US Team •  Shujaat Khan •  Jaeyong Hur MR Team •  Dongwook Lee •  Juyoung Lee •  Eunju Cha •  Byung-hoon Kim Image Analysis Team •  Boa Kim •  Junyoung Kim Optics Team •  Sungjun Lim •  Junyoung Kim •  Jungsol Kim •  Taesung Kwon
  91. THANK YOU This presentation material can be downloaded from http://bispl.weebly.com
