Keep your sanity with compositional tracing

Keep your sanity
with compositional tracing
Photo by Esther Wilhelmsson on Unsplash
Jakub Kozłowski |>
Typelevel Summit |>
New York City |>
12.03.2020
speakerdeck.com/kubukoz

View Slide

Standard ways of inspecting live systems

Inspecting distributed systems

Implementation hackery!
In this talk

View Slide

type Result = Int
val processPayment: String => Result = { ... }
val result = processPayment(paymentId)
Scenario: process payment with an ID

View Slide

logger.info(s"Started processing payment $paymentId")
logger.info(s"Finished processing payment with result $result")
%date{YYYY-MM-dd HH:mm:ss.SSS} [%level] %message%n%xException
Let's log things!

View Slide

2020-03-07 19:21:39.817 [INFO] Started processing payment 3
2020-03-07 19:21:39.820 [INFO] Finished processing payment with result 10
Let's log things!

View Slide

Which result came from which paymentId?
Let's log things!

View Slide

%date{YYYY-MM-dd HH:mm:ss.SSS} [%level] [%thread] %message%n%xException
Let's add the executing thread!

View Slide

%date{YYYY-MM-dd HH:mm:ss.SSS} [%level] [%thread] %message%n%xException
2020-03-07 19:26:38.490 [INFO] [scala-execution-context-global-17] Started processing payment 2
2020-03-07 19:26:38.493 [INFO] [scala-execution-context-global-15] Finished processing payment with result 81
Let's add the executing thread!

View Slide

View Slide

...
...
...
2020-03-07 19:27:38.493 [INFO] [scala-execution-context-global-19] Oh, one more thing
Is this still the same request?
When is the request over?

View Slide

2020-03-07 19:26:38.493 [INFO] [scala-execution-context-global-15] Finished processing payment 3 with result 81
So... logging payment ID in each message?

View Slide

So... logging payment ID in each message?
Have fun grepping!

View Slide

package org.slf4j
//rough Scala translation
object MDC {
def put(key: String, value: String): Unit
def putCloseable(key: String, value: String): Closeable
def remove(key: String): Unit
def getCopyOfContextMap(): Map[String, String]
def clear(): Unit
//...
}
Mapped Diagnostic Context (MDC)

View Slide

val requestId = UUID.randomUUID().toString()
Using.resource(MDC.putCloseable("RequestId", requestId)) { _ =>
}
%date{YYYY-MM-dd HH:mm:ss.SSS} [%level] [%mdc{RequestId:--}] %message%n%xException
Logging with MDC

View Slide

}
2020-03-07 20:24:26.236 [INFO] [9a7ef5de-eac2-413a-903b-8516ff956f8c] Started processing payment 3
2020-03-07 20:24:26.236 [INFO] [29e707e5-5186-4e31-9d6b-9f73e96d4198] Started processing payment 1
2020-03-07 20:24:26.236 [INFO] [c2db42d8-8a1b-4e9d-b826-bf7fd680058a] Started processing payment 2
2020-03-07 20:24:26.238 [INFO] [29e707e5-5186-4e31-9d6b-9f73e96d4198] Finished processing payment with result 25
2020-03-07 20:24:26.238 [INFO] [c2db42d8-8a1b-4e9d-b826-bf7fd680058a] Finished processing payment with result 76
2020-03-07 20:24:26.238 [INFO] [9a7ef5de-eac2-413a-903b-8516ff956f8c] Finished processing payment with result 88
Logging with MDC

View Slide

}
2020-03-07 20:24:26.236 [INFO] [9a7ef5de-eac2-413a-903b-8516ff956f8c] Started processing payment 3
2020-03-07 20:24:26.236 [INFO] [29e707e5-5186-4e31-9d6b-9f73e96d4198] Started processing payment 1
2020-03-07 20:24:26.236 [INFO] [c2db42d8-8a1b-4e9d-b826-bf7fd680058a] Started processing payment 2
2020-03-07 20:24:26.238 [INFO] [29e707e5-5186-4e31-9d6b-9f73e96d4198] Finished processing payment with result 25
2020-03-07 20:24:26.238 [INFO] [c2db42d8-8a1b-4e9d-b826-bf7fd680058a] Finished processing payment with result 76
2020-03-07 20:24:26.238 [INFO] [9a7ef5de-eac2-413a-903b-8516ff956f8c] Finished processing payment with result 88
last log with request id - end of request
Logging with MDC

View Slide

val processPayment: String => Future[Result] = { ... }
processPayment(paymentId).map { result =>
}
}
What if the thread changes?

View Slide

val processPayment: String => Future[Result] = { ... }
}
}
2020-03-07 20:44:10.781 [INFO] [96a4e310-1f2d-4670-80c8-eb28c0561e4a] Started processing payment 2
2020-03-07 20:44:10.781 [INFO] [1afb3aa6-c7ec-4c56-b9a8-c5ccf2c13cf3] Started processing payment 1
2020-03-07 20:44:10.781 [INFO] [d857fe1d-48cf-4f58-b369-8705b31f9b8d] Started processing payment 3
2020-03-07 20:44:10.790 [INFO] [-] Finished processing payment with result 46

What happened?
What if the thread changes?

View Slide

Async programming on the JVM
doThing { result =>
doOtherThing(result) { secondResult =>
doMoreThings(result, secondResult)
}
}

View Slide

Async programming in Scala
doThing.flatMap { result =>
doOtherThing(result).flatMap { secondResult =>
doMoreThings(result, secondResult)
}
}

View Slide

Async programming in Scala
for {
result <- doThing
secondResult <- doOtherThing(result)
out <- doMoreThings(result, secondResult)
} yield out

View Slide

What happens in map / flatMap ?
Future
.successful(42)
.map(f)
.map(g)

View Slide

Future
.successful(42)
.map(f)(ec1)
.map(g)(ec2)

View Slide

Future
.successful(42)
.map(f)(ec1)
.map(g)(ec2)
ec1.execute {
() =>
val x = f(42)
ec2.execute {
val y = g(x)
...
}
}

View Slide

Where is context lost?
ec1.execute {
() =>
val x = f(42)
...
}

View Slide

Propagating context between submission to EC and execution
def runWithContext[A](ctx: Map[String, String])(f: => A): A = {
val oldContext = getContext()
setContext(ctx)
try f
finally setContext(oldContext)
}

View Slide

// Simplified definitions
type Runnable = () => Unit
type ExecutionContext = Runnable => Unit

View Slide

object mdcWithContext {
def getContext(): Map[String, String] =
MDC.getCopyOfContextMap().asScala.toMap
def setContext(ctx: Map[String, String]): Unit =
MDC.setContextMap(ctx.asJava)
}

View Slide

object mdcWithContext {
def getContext(): Map[String, String] =
MDC.getCopyOfContextMap().asScala.toMap
def setContext(ctx: Map[String, String]): Unit =
MDC.setContextMap(ctx.asJava)
}
def mdcAware(ec: ExecutionContext): ExecutionContext =
runnable => {
val rootContext = mdcWithContext.getContext()
ec(() => mdcWithContext.runWithContext(rootContext)(runnable()))
}

View Slide

Mapping on an instrumented ExecutionContext
val rootContext = getContext()
ec1.execute { () =>
val storedContext1 = getContext()
setContext(rootContext)
try {
val x = f(42)
//...
} finally {
setContext(storedContext1)
}
}
ec1.execute {
() =>
val x = f(42)
...
}

View Slide

ec1.execute {
() =>
val x = f(42)
...
}
ec1.execute { () =>
try {
val x = f(42)
//...
} finally {
}
}

View Slide

ec1.execute { () =>
try {
val x = f(42)
//...
} finally {
}
}

View Slide

implicit val ec = mdcAware(ExecutionContext.global)
Keeping MDC on task submission to ExecutionContext

View Slide

implicit val ec = mdcAware(ExecutionContext.global)
2020-03-07 20:47:23.779 [INFO] [85c52920-4271-40f0-a150-d34bf4f8b5ec] Started processing payment 2
2020-03-07 20:47:23.779 [INFO] [78e9ccbc-98cb-440a-848c-d72f917857dd] Started processing payment 1
2020-03-07 20:47:23.779 [INFO] [d57bf741-51fc-45e6-a6ca-58f6488c9d05] Started processing payment 3
2020-03-07 20:47:23.785 [INFO] [d57bf741-51fc-45e6-a6ca-58f6488c9d05] Finished processing payment with result 96
2020-03-07 20:47:23.787 [INFO] [78e9ccbc-98cb-440a-848c-d72f917857dd] Finished processing payment with result 77
2020-03-07 20:47:23.785 [INFO] [85c52920-4271-40f0-a150-d34bf4f8b5ec] Finished processing payment with result 55
Keeping MDC on task submission to ExecutionContext

View Slide

Sure!
implicit val contextShift: ContextShift[IO] = IO.contextShift(ec)
Does this work with IO?

View Slide

val processPayment: String => IO[Result] = { ... }
def executeRequest(paymentId: String) = {
val requestId = ju.UUID.randomUUID().toString()
}
}
}
Let's try it

View Slide

}
}
}
2020-03-08 16:20:47.088 [INFO] [-] Started processing payment 2
Let's try it

View Slide

}
}
}
Let's try it
Lazy evaluation!

View Slide

Little lesson in hackery
def getContext(): Map[String, String]
def setContext(ctx: Map[String, String]): Unit
def runWithContext[A](
ctx: Map[String, String]
)(f: => A): A = {
setContext(ctx)
try f
finally setContext(rootContext)
}

View Slide

val getContext: IO[Map[String, String]]
def setContext(ctx: Map[String, String]): IO[Unit]
def withContext[A](
)(f: IO[A]): IO[A] =
getContext.flatMap { rootContext =>
setContext(ctx)
.bracket(_ => f)(
_ => setContext(rootContext)
)
}
Impure
Little lesson in hackery
def getContext(): Map[String, String]
def setContext(ctx: Map[String, String]): Unit
def runWithContext[A](
)(f: => A): A = {
setContext(ctx)
try f
finally setContext(rootContext)
}
Pure

View Slide

val getContext: IO[Map[String, String]] = IO(MDC.getCopyOfContextMap().asScala.toMap)
def setContext(ctx: Map[String, String]): IO[Unit] = ???

View Slide

def setContext(ctx: Map[String, String]): IO[Unit] = IO(MDC.setContextMap(ctx.asJava))
That'll work... for MDC
Hack #1 - just set the context

View Slide

Why does this work?
withContext(newContext)(
fa = launchMissiles
)
def setContext(ctx: Map[String, String]): IO[Unit] =
IO(MDC.setContextMap(ctx.asJava))

View Slide

Why does this work?
fa = IO.shift(mdcAware(ec)) *>
launchMissiles
)
IO(MDC.setContextMap(ctx.asJava))

View Slide

IO.async[Unit] { cb =>
runWithContext(ctx) {
cb(Right(()))
}
}
Hack #2 - use runWithContext and async

View Slide

cb(Right(()))
}
}
This will work* for APIs that don't directly provide setContext
Hack #2 - use runWithContext and async
* - with one more change we'll see in a minute

View Slide

Why does THAT work? - IO.async 101
object IO {
def async[A](k: (Either[Throwable, A] => Unit) => Unit): IO[A]
}
How do Fibers Work? A Peek Under the Hood
https://youtu.be/x5_MmZVLiSM

View Slide

object IO {
} cb

View Slide

object IO {
} cb
val sleep5s = IO.async[Int] { cb: (Either[Throwable, Int] => Unit) =>
scheduler.schedule(cb(Right(42)), 5.seconds)
}
val prog = sleep5s.flatMap(i => IO(sendMissiles(count = i)))

View Slide

}
Mental model

View Slide

}
val cb = {
case Right(i: Int) => sendMissiles(count = i)
case Left(e) => throw e
}
Mental model

View Slide

}
val cb = {
case Right(i: Int) => sendMissiles(count = i)
case Left(e) => throw e
}
Mental model
val prog = scheduler.schedule(sendMissiles(42), ...)
=>

View Slide

Why does this work?
fa = launchMissiles
) *> remainder
cb(Right(()))
}
}

View Slide

Why does this work?
fa = IO.shift(mdcAware(ec)) *>
launchMissiles
) *> remainder
cb(Right(()))
}
}

View Slide

But wait, there's more!
IO.shift *>
cb(Right(()))
}
}

View Slide

(Cats) IO trampolines callbacks for stack safety
def showAsync(tag: String): IO[Unit] =
println(s"before $tag")
cb(Right(()))
println(s"after $tag")
}
showAsync("cb1") *>
showAsync("cb2") *>
IO(println("foo"))

View Slide

(Cats) IO trampolines callbacks for stack safety
cb(Right(()))
}
showAsync("cb1") *>
showAsync("cb2") *>
IO(println("foo"))
before cb1
before cb2
after cb2
foo
after cb1

View Slide

Shifting before async makes sure running cb evaluates the continuation immediately
IO.shift *> IO.async[Unit] { cb =>
cb(Right(()))
}
showAsync("cb1") *>
showAsync("cb2") *>
IO(println("foo"))
before cb1
after cb1
before cb2
foo
after cb2

View Slide

Which one should I use?
The idea is still pretty fresh, but right now:

View Slide

Which one should I use?
The idea is still pretty fresh, but right now:
def setContext(ctx: Map[String, String]): IO[Unit] = IO(MDC.setContextMap(ctx.asJava))
def withContext[A](
)(f: IO[A]): IO[A] =
getContext.flatMap { rootContext =>
setContext(ctx)
.bracket(_ => f)(
_ => setContext(rootContext)
)
}
Hack #1 (for simplicity)

View Slide

View Slide

Are we done?
Let's wait till 3:00 am

View Slide

Who called this application?
Are we done?

View Slide

What applications did it call? Which URLs?
Are we done?

View Slide

What were the response times?
Are we done?

View Slide

How long did the whole call take?
Are we done?

View Slide

How long did the whole call take?
Were there any (caught) errors?
Are we done?

View Slide

Logs are linear
19:43:59.023 [INFO] Started processing payment 1
19:43:59.026 [INFO] Calling database
19:43:59.137 [INFO] Got result from database
19:43:59.154 [INFO] Calling remote service
19:43:59.155 [INFO] Reading file
19:43:59.208 [INFO] Called remote service
19:43:59.360 [INFO] Read file
def executeRequest(paymentId: String) =
for {
_ <- logger.info(s"Started processing payment $paymentId")
_ <- logger.info("Calling database")
_ <- callDatabase
_ <- logger.info("Got result from database")
result <- (
logger.info("Calling remote service") *>
callRemoteService <*
logger.info("Called remote service"),
logger.info("Reading file") *>
readFile <*
logger.info("Read file")
).parMapN(combineResults)
} yield result
time
Have fun subtracting timestamps!

View Slide

What we need
span("process") {
for {
_ <- logger.info(s"Processing payment $paymentId")
_ <- span("db")(callDatabase)
result <- (
span("remote")(callRemoteService),
span("file")(readFile)
} yield result
}

View Slide

What we need
span("process") {
for {
_ <- logger.info(s"Processing payment $paymentId")
_ <- span("db")(callDatabase)
result <- (
span("remote")(callRemoteService),
span("file")(readFile)
} yield result
}
- immediately see order of execution

- concurrency becomes obvious

- inspect details on demand (expand span)

View Slide

"...a form of structured logging that assumes duration and hierarchy"
Source: https://tersesystems.com/blog/2020/03/10/a-taxonomy-of-logging/
Distributed tracing

View Slide

Distributed tracing
Trace

View Slide

Distributed tracing
Trace
Span

View Slide

Distributed tracing solutions

View Slide

Case study
- log before

- async call to database (simulated by sleep)

- async call to remote service

- log afterwards
new BusinessLogic[F] {
def execute(args: Args): F[Result] =
for {
_ <- Logger[F].info(show"Executing request $args")
_ <- Timer[F].sleep(100.millis)
_ <- client.successful(POST(uri"http://localhost:8080/execute"))
_ <- Logger[F].info(show"Executed request $args")
} yield Result(show"${args.message} finished")
}
Reference implementation (no tracing)
Check out the source code for details (repo linked in ﬁnal slide)

View Slide

Create our own model of a span for simplicity

Keep track via parameter passing

Provide to logger/client which will set info as MDC

Convert to zipkin model and report manually after each span
Reporting traces - direct, no-magic approach

View Slide

Simple span model
final case class Span(
name: String,
traceId: String,
spanId: String,
parentSpanId: Option[String],
values: Map[String, String]
)

View Slide

def databaseCall(rootSpan: Span) =
newSpan(
"db-call",
rootSpan,
Map("db.query" -> "select * from users where id = ?")
) { span =>
logger.info(span.toMap)("Running db call") *>
IO.sleep(100.millis)
}

View Slide

newSpan(
"db-call",
rootSpan,
) { span =>
}
def clientCall(rootSpan: Span) =
newSpan("remote-call", rootSpan) { child =>
client.successful(
POST(
uri"http://localhost:8080/execute",
child.toTraceHeaders.toList: _*
)
)
}

View Slide

newSpan(
"db-call",
rootSpan,
) { span =>
}
def clientCall(rootSpan: Span) =
newSpan("remote-call", rootSpan) { child =>
client.successful(
POST(
uri"http://localhost:8080/execute",
child.toTraceHeaders.toList: _*
)
)
}
def execute(args: Args, span: Span): IO[Result] =
for {
_ <- logger.info(span.toMap)(show"Executing request $args")
_ <- databaseCall(span)
_ <- clientCall(span)
_ <- logger.info(span.toMap)(show"Executed request $args")

View Slide

What we'll get in UI
(applies to all our approaches here)

View Slide

Distributed tracing - Kamon, same threadlocal magic as MDC
val databaseCall =
childSpan(
"db-call",
) {
logger.info("Running db call") *>
}
val clientCall =
childSpan("remote-call") {
//grab context before, set it again afterwards
Tracing[IO].keepSpanAround {
client.successful(POST(uri"http://localhost:8080/execute"))
}
}
def execute(args: Args): IO[Result] =
for {
_ <- logger.info(show"Executing request $args")
_ <- databaseCall
_ <- clientCall
_ <- logger.info(show"Executed request $args")

View Slide

Comparison
Direct tracing (parameter passing)
- Lots of boilerplate

- Viral (inﬂuences APIs on all levels)

- Extra work to integrate with MDC

- Reporting done manually

+ Zero magic

+ No loss of context
Kamon tracing (instrumentation)
- Lots of magic (AOP, thread locals)

- Complex and fragile instrumentation for async IO

- Each interface for async needs special instrumentation

+ No changes in APIs

+ No boilerplate

+ Lots of integrations

+ Handles reporting for you

+ Context passed to MDC

View Slide

trait BusinessLogic[F[_]] {
def execute(args: Args, span: Span): F[Result]
}
trait AnotherProgram[F[_]] {
def summary(result: Result, span: Span): F[Unit]
}
def execute(args: Args): F[Result]
}
def summary(result: Result): F[Unit]
}
=>
Who's the winner?
Both solutions have shortcomings. Ideally...

No boilerplate

No magic

No virality

Lots of integrations

MDC support

Automatic reporting

View Slide

@finalAlg
def execute(args: Args): F[Result]
}
@finalAlg
def summary(result: Result): F[Unit]
}
def program[F[_]: FlatMap: BusinessLogic: AnotherProgram: Trace](args: Args): F[Unit] =
for {
result <- Trace[F].span("execute")(BusinessLogic[F].execute(args))
_ <- Trace[F].span("summary")(AnotherProgram[F].summary(result))
} yield ()
type M[A] = ???
def execute(args: Args): M[A] = program[M](args)
What would it look like?

View Slide

What's the F?
def program[F[_]: FlatMap: BusinessLogic: AnotherProgram: Trace](args: Args): F[Unit] =
for {
result <- Trace[F].span("execute")(BusinessLogic[F].execute(args))
_ <- Trace[F].span("summary")(AnotherProgram[F].summary(result))
} yield ()
def execute(args: Args) = program[?????](args)

View Slide

final case class MyMagicMonadForContext[F[_], Context, A](impl: Context => F[A])
Let's make a new monad

View Slide

final case class MyMagicMonadForContext[F[_], Context, A](impl: Context => F[A]) {
def flatMap[B](
f: A => MyMagicMonadForContext[F, Context, B]
)(
implicit F: Monad[F]
): MyMagicMonadForContext[F, Context, B] = MyMagicMonadForContext { ctx =>
impl(ctx).flatMap(f(_).impl(ctx))
}
def local(f: Context => Context): MyMagicMonadForContext[F, Context, A] =
MyMagicMonadForContext(f andThen impl)
def scope(ctx: Context): MyMagicMonadForContext[F, Context, A] = local(_ => ctx)
}
Let's make a new monad

View Slide

We made a new monad!

View Slide

type AuthenticatedT [F[_], A] = MyMagicMonadForContext[F, User, A]
type Transactional [F[_], A] = MyMagicMonadForContext[F, Connection, A]
type Traced [F[_], A] = MyMagicMonadForContext[F, Span, A]
type WithTenant [F[_], A] = MyMagicMonadForContext[F, ClientId, A]

View Slide

type ZIO[-R, +E, +A] = MyMagicMonadForContext[EitherT[IO, E, *], R, A]
semantically ;)

View Slide

type ZIO[-R, +E, +A] = MyMagicMonadForContext[EitherT[IO, E, *], R, A]
semantically ;)
https://youtu.be/7xSfLPD6tiQ?t=707
cats

View Slide

Hint:
Did we make a new monad?

View Slide

final case class Kleisli[F[_], -A, B](run: A => F[B])
Hint:

View Slide

final case class Kleisli[F[_], -A, B](run: A => F[B])
Hint:
type ReaderT[F[_], -A, B] = Kleisli[F, A, B]
val ReaderT = Kleisli

View Slide

Why is ReaderT the perfect ﬁt
- automatic passing of context

- get current context for free with Kleisli.ask: Kleisli[F, A, A]
- change context in a region easily with local

View Slide

However...
- we still need integrations (wrapping clients in ones that take headers from context in Kleisli)

- we need an escape hatch for when we really need MDC

- we need a cool library that provides a nice API on top of Kleisli...

View Slide

Natchez API
trait Span[F[_]] {
def put(fields: (String, TraceValue)*): F[Unit]
def kernel: F[Kernel]
def span(name: String): Resource[F, Span[F]]
}
trait Trace[F[_]] {
def put(fields: (String, TraceValue)*): F[Unit]
def kernel: F[Kernel]
def span[A](name: String)(k: F[A]): F[A]
}
object Trace {
implicit def kleisliInstance[F[_]: Bracket[*[_], Throwable]]: Trace[Kleisli[F, Span[F], *]] = ...
}

View Slide

Quick teaser of usage
for {
_ <- Trace[F].span("db")(Timer[F].sleep(100.millis))
_ <- client.successful(POST(uri"http://localhost:8080/execute"

View Slide

type Traced[A] = Kleisli[IO, Span[IO], A]
val businessLogic = BusinessLogic.instance[Traced]
def exec(msg: String): IO[Result] =
Zipkin
.entryPoint[IO]("client", blocker)
.use {
_.root(msg).use {
businessLogic.execute(Args(msg)).run
}
}
for {

View Slide

Zipkin
.use {
_.root(msg).use {
}
}
for {
def kleisliTracedClient[F[_]: Bracket[*[_], Throwable]: Defer](
underlying: Client[F]
): Client[Kleisli[F, Span[F], *]] = ...

View Slide

for {
def kleisliTracedClient[F[_]: Bracket[*[_], Throwable]: Defer](
underlying: Client[F]
): Client[Kleisli[F, Span[F], *]] = ...
Zipkin
.use {
_.root(msg).use {
}
}
This should eventually be delegated to e.g. http4s server wrapper

View Slide

Integrations?
As of now Soon In the meantime...
Using Kamon for reporting?

View Slide

Does it work?
Open the examples of this talk and see for yourself (including temporary custom zipkin integration)

View Slide

Thank you
blog.kubukoz.com
@kubukoz
Slides: speakerdeck.com/kubukoz
Code: git.io/Jv6mN
Find me on YouTube! (https://youtube.com/channel/UCBSRCuGz9laxVv0rAnn2O9Q)

View Slide

Keep your sanity with compositional tracing

Keep your sanity with compositional tracing

Jakub Kozłowski

More Decks by Jakub Kozłowski

Other Decks in Programming

Featured

Transcript
