Vowel Purity and Rhyme Evidence in Old Chinese Reconstruction

Vowel Purity and Rhyme Evidence in Old Chinese Reconstruction

Talk held at the 29th Meeting on East Asian Linguistics (2016-07-04, Paris)

Johann-Mattis List

July 04, 2016
Tweet

More Decks by Johann-Mattis List

Other Decks in Science

Transcript

  1. Vowel Purity and Rhyme
    Evidence in Old Chinese
    Reconstruction
    Johann-Mattis List (CRLAO)

    View Slide

  2. Introduction

    View Slide

  3. Rhyme Evidence in Old Chinese Reconstruction
    ● the morpheme-syllabic character of the Chinese writing
    system does not give us many clues regarding the exact
    pronunciation of Chinese during its oldest stages
    ● rhyme patterns in old Chinese poetry, like the Shījīng 詩經
    (1050 - 600 BC), are therefore important for Old Chinese
    reconstruction
    ● rhyme pattern analysis has a long tradition in Chinese
    traditional scholarship, but it has never been thoroughly
    systematized

    View Slide

  4. Traditional Rhyme Pattern Analysis
    ● traditional rhyme pattern analysis (sīguàn shéngqiān fǎ 絲
    貫繩牽法 follows a greedy approach
    ○ start from words which could be shown to rhyme with
    each other in one poem
    ○ cluster words greedily into clusters by looking for
    words which occur across poems

    View Slide

  5. Traditional Rhyme Pattern Analysis

    View Slide

  6. Traditional Rhyme Pattern Analysis

    View Slide

  7. Traditional Rhyme Pattern Analysis

    View Slide

  8. Traditional Rhyme Pattern Analysis

    View Slide

  9. Traditional Rhyme Pattern Analysis

    View Slide

  10. Traditional Rhyme Pattern Analysis

    View Slide

  11. Traditional Rhyme Pattern Analysis
    ● unfortunately, the traditional rhyme analysis favors
    lumping of rhyme categories over splitting
    ● no more than about 30 categories were identified by the
    traditional rhyme analysis up to the middle of the 20th
    century
    ● only later, Baxter’s (1992) hypotheses-testing approach to
    quantitative rhyme data made it possible to postulate
    more distinct (52) categories

    View Slide

  12. Vowel Purity and Rhyme Evidence

    View Slide

  13. Vowel Purity and Rhyme Evidence
    ● Ho (2016) criticises Baxter and Sagart’s (2014)
    reconstruction of Old Chinese by pointing to many rhymes
    in which words with different main vowels rhyme
    ● this principle, that says that old Chinese poetry was strictly
    avoiding the rhyming of words with different vowels could
    be called the principle of “vowel purity” in rhymes

    View Slide

  14. Vowel Purity and Rhyme Evidence
    ● Ho’s (2016) argument rests on two fundamental
    assumptions
    a. Baxter and Sagart’s (2014) Old Chinese reconstruction
    is in strong conflict with the principle of vowel purity
    b. vowel purity was a key principle in Old Chinese
    rhyming

    View Slide

  15. Vowel Purity and Rhyme Evidence
    ● assumption b. is very difficult to check, and we find many
    counter-examples both in Chinese rhyme traditions and in
    a cross-linguistic comparison of rhyme traditions
    ● assumption a. can be easily checked, but unlike Ho
    (2016), we need to check it quantitatively and
    comparatively for different OC reconstruction systems

    View Slide

  16. Vowel Purity and Rhyme Evidence
    ● Ho’s (2016) argument against Baxter and Sagart (2014):
    ○ lacks any concrete examples
    ○ confuses conflicts between traditional rhyme
    categories and the rhyme categories by Baxter and
    Sagart (2014) with actual conflicts with vowel purity

    View Slide

  17. Vowel Purity and Rhyme Evidence
    ● Ho’s (2016) argument against Baxter and Sagart (2014):
    ○ lacks any concrete examples
    ○ confuses conflicts between traditional rhyme
    categories and the rhyme categories by Baxter and
    Sagart (2014) with actual conflicts with vowel purity
    “It is a firm linguistic fact that rhyming should be based on identity of vowels.
    Interpretation should, of course, be based upon facts. Facts precede and matter
    more than interpretation.” (Ho 2016: 183)

    View Slide

  18. Vowel Purity and Rhyme Evidence
    ● Ho’s (2016) argument against Baxter and Sagart (2014):
    ○ lacks any concrete examples
    ○ confuses conflicts between traditional rhyme
    categories and the rhyme categories by Baxter and
    Sagart (2014) with actual conflicts with vowel purity
    “It is a firm linguistic fact that rhyming should be based on identity of vowels.
    Interpretation should, of course, be based upon facts. Facts precede and matter
    more than interpretation.” (Ho 2016: 183) → yes, let’s work with pure facts!

    View Slide

  19. Evaluating Vowel Purity in
    Reconstruction

    View Slide

  20. Materials: Rhyme Network
    The Shījīng Browser
    ● rhyme data from the Shījīng following Baxter (1992)
    ● digitized and converted to machine-readable format in List
    (under review)
    ● data online available in form of a Shījīng Browser (http:
    //digling.org/shijing/)

    View Slide

  21. Materials: Rhyme Network
    DEMO of
    http://digling.org/shijing/

    View Slide

  22. Materials: Rhyme Network
    The Shījīng Rhyme Network
    ● a network of all words rhyming in the Shījīng (List under review)
    ● rhyme words are nodes in the networks (1996 nodes in total)
    ● links between nodes reflect instances in which two words rhyme in the
    Shījīng according to Baxter’s (1992) analysis
    ● an automatic analysis of the patterns, in which community-detection
    algorithms were used to search for potential rhyme groups is available
    at http://digling.org/shijing/infomap.html

    View Slide

  23. Materials: Rhyme Network
    DEMO of
    http://digling.org/shijing/infomap.html

    View Slide

  24. Materials: Reconstruction Systems
    ● Baxter and Sagart (2014): online available for download
    ● Karlgren (1954): provided by Eastling (http://www.eastling.org)
    ● Wáng Lì (1980): provided by Eastling
    ● Pān Wúyùn (2000): provided by Eastling
    ● Zhèngzhāng (2003): provided by Eastling
    ● Starostin (1989): provided by Tower of Babel (http://starling.
    rinet.ru)
    ● Li (1971): provided by Eastling

    View Slide

  25. Materials: Reconstruction Systems
    ● Not all data is complete, since not all sources give
    reconstructions for all characters in the Shījīng
    ● 1213 character readings occur in all seven datasets
    ● two analyses are carried out:
    ○ “complete coverage”: analysis for the character readings
    which occur in all seven reconstruction systems
    ○ “partial coverage”: analysis for all character readings
    available for a given reconstruction system

    View Slide

  26. Materials: Reconstruction Systems

    View Slide

  27. Methods: Testing Vowel Purity in Rhyme Networks
    The Problem
    ● List (under review) uses community detection algorithms to
    determine possible rhyme categories in the Shījīng and to
    compare these with Old Chinese
    ● vowel purity, however, does not exclusively determine which
    words rhyme with each other, since we know that other
    aspects, like the coda, also contribute to rhyming
    ● on the other hand, vowel purity should restrict certain rhymes

    View Slide

  28. Methods: Testing Vowel Purity in Rhyme Networks
    The Problem
    We search for a measure that reflects the tendency of vowel purity
    in a network model. But vowel purity does only to a certain extent
    coincide with rhyme categories. We thus do not search for a
    measure that tells us something about the quality of communities
    that we determine, but a measure that tells us to which degree the
    topology of our network is in conflict with the characteristics of the
    nodes.

    View Slide

  29. Methods: Testing Vowel Purity in Rhyme Networks

    View Slide

  30. Methods: Testing Vowel Purity in Rhyme Networks

    View Slide

  31. Methods: Testing Vowel Purity in Rhyme Networks

    View Slide

  32. Methods: Testing Vowel Purity in Rhyme Networks

    View Slide

  33. Methods: Testing Vowel Purity in Rhyme Networks

    View Slide

  34. Methods: Testing Vowel Purity in Rhyme Networks
    Conductance as a measure of cluster purity?
    ● The conductance of a group of nodes in a network estimates the
    degree of its isolation or fragmentation (Leskovec et al. 2008).
    ● List (under review) uses conductance to compare the purity of six-
    vowel systems (Baxter and Sagart 2014) in contrast with Middle
    Chinese vowel systems in the Shījīng rhyme network.
    ● But conductance has shortcomings when comparing different clusters
    across graphs: When averaging conductance scores for each cluster
    (vowel), systems with less vowels are favored.

    View Slide

  35. Methods: Testing Vowel Purity in Rhyme Networks
    Modularity as a measure for cluster purity?
    ● Modularity of a given set of clusters in a network is the fraction of the
    edges within a cluster subtracted by the number of edges expected at
    random. (Newman 2006)
    ● Modularity can be positive or negative, with positive values indicating
    that communities are potentially present. (Newman 2006)
    ● Modularity suffers from a low resolution limits if networks become
    large or nodes do not share many links.

    View Slide

  36. Methods: Testing Vowel Purity in Rhyme Networks
    Assortativity
    ● Assortativity (Newman 2003) tests whether nodes sharing
    connections in a graph are also similar regarding other characteristics.
    ● Adapted to our rhyme network, this means that we test whether words
    that rhyme in the Book of Odes share also the same vowel.
    ● This seems to be exactly what we are looking for: a measure for the
    degree to which a given reconstruction system reflects the
    assumption that words with identical vowels tend to rhyme.

    View Slide

  37. Methods: Testing Vowel Purity in Rhyme Networks
    Assortativity
    high assortativity

    View Slide

  38. Methods: Testing Vowel Purity in Rhyme Networks
    Assortativity
    low assortativity

    View Slide

  39. Results

    View Slide

  40. Results: General Remarks

    View Slide

  41. Results: General Remarks

    View Slide

  42. Results: General Remarks

    View Slide

  43. Results: General Remarks

    View Slide

  44. Results: General Remarks

    View Slide

  45. Results: General Remarks
    Coding Rhymes
    by Vowel Quality:
    ■ a
    ■ e
    ■ i
    ■ o
    ■ u
    ■ ə

    View Slide

  46. Results: General Remarks
    Coding Rhymes
    by Vowel Quality:
    ■ a
    ■ e
    ■ i
    ■ o
    ■ u
    ■ ə

    View Slide

  47. Results: General Remarks
    Coding Rhymes
    by Vowel Quality:
    ■ a
    ■ e
    ■ i
    ■ o
    ■ u
    ■ ə

    View Slide

  48. Results: Detailed Comparison
    1213 Nodes 1471 - 1996 nodes

    View Slide

  49. Results: Detailed Comparison
    1213 Nodes 1471 - 1996 nodes

    View Slide

  50. Results: Detailed Comparison
    1213 Nodes 1471 - 1996 nodes
    None of the systems shows a 100% vowel purity, but apparently, Baxter and Sagart (2014)
    outperform all other reconstructions regarding vowel purity!

    View Slide

  51. Conclusion and Discussion

    View Slide

  52. Discussion
    ● the reconstruction by Baxter and Sagart (2014) corresponds
    closer to the criterion of vowel purity than the other systems
    compared
    ● the quantitative investigation shows that the critics by Ho (2016)
    do not hold
    ● the rather high assortativity scores reported for almost all
    reconstruction systems shows that vowel purity is a principle
    that is reflected in all reconstructions (albeit with different rigor)

    View Slide

  53. Discussion: Caveats
    1. the comparison lacks full coverage for all reconstruction
    systems, which may have influenced the results (although I
    expect no larger differences)
    2. errors both in the rhyme networks and the reconstruction
    systems might have further influenced the results
    3. we should be careful with the idea of vowel purity itself: it is by
    no means proven that it was a driving principle for those who
    created the poems in the Shījīng
    4. we should ideally compare our study with an alternative rhyme
    network, like the one by Wáng (1980)

    View Slide

  54. Conclusion
    Despite potential errors and further limits of the analysis, this study could
    (hopefully) show that
    ● thorough quantitative comparison can give us new insights into our
    problems in Old Chinese reconstruction
    ● instead of dismissing theories or reconstructions by spurious or non-
    existing examples or assumptions, exhaustive evaluations give us a
    fresh perspective on our problems
    ● In order to tackle our data-problems in the future, collaborative efforts
    are required and people should try to share all their data as
    transparently as possible

    View Slide

  55. Many thanks to Philippe Lopez (Team Adaptation, Integration,
    Reticulation, Evolution, UPMC) for providing invaluable help with
    the network analysis, and to Laurent Sagart (CRLAO) for helpful
    discussions and for providing the Old Chinese data!
    Supplementary material with all code and all detailed
    reconstructions available at:
    https://gist.github.com/LinguList

    View Slide

  56. Thanks for your attention!
    Many thanks to Philippe Lopez (Team Adaptation, Integration,
    Reticulation, Evolution, UPMC) for providing invaluable help with
    the network analysis, and to Laurent Sagart (CRLAO) for helpful
    discussions and for providing the Old Chinese data!
    Supplementary material with all code and all detailed
    reconstructions available at:
    https://gist.github.com/LinguList

    View Slide
