SecureScala

Slides for the presentation at Scala Symposium 2016, Amsterdam

1. Introduction Secure Scala Evaluation Conclusion SecureScala: Scala Embedding of Secure Computations Markus Hauck 1 Savvas Savvides 2 Patrick Eugster 2 Mira Mezini 3 Guido Salvaneschi3 1codecentric AG 2Purdue University 3TU Darmstadt October 30, 2016 Markus Hauck - SecureScala: Scala Embedding of Secure Computations 1
2. Introduction Secure Scala Evaluation Conclusion The Current Situation cloud computing offers cheap processing power we have more data available than ever Markus Hauck - SecureScala: Scala Embedding of Secure Computations 2
3. Introduction Secure Scala Evaluation Conclusion The Current Situation cloud computing offers cheap processing power we have more data available than ever but what about sensitive data? Markus Hauck - SecureScala: Scala Embedding of Secure Computations 2
4. Introduction Secure Scala Evaluation Conclusion A Possible Solution use encryption? decrypt for computation = danger of leak need to compute over encrypted data: secure function evaluation using garbled circuits Markus Hauck - SecureScala: Scala Embedding of Secure Computations 3
5. Introduction Secure Scala Evaluation Conclusion A Possible Solution use encryption? decrypt for computation = danger of leak need to compute over encrypted data: secure function evaluation using garbled circuits Homomorphic Encryption Schemes fully homomorphic (FHE) partial homomorphic (PHE) Markus Hauck - SecureScala: Scala Embedding of Secure Computations 3
6. Introduction Secure Scala Evaluation Conclusion Homomorphic Encryption Schemes perform operation on cipher text without decryption fully homomorphic encryption schemes support at least multiplication and addition far too expensive for practical use partial homomorphic encryption schemes in most cases support only one operation collection of schemes for multiple operations significant overhead but usable in practice Markus Hauck - SecureScala: Scala Embedding of Secure Computations 4
7. Introduction Secure Scala Evaluation Conclusion Contribution What currently: special purpose / external DSL goal: use general purpose language Markus Hauck - SecureScala: Scala Embedding of Secure Computations 5
8. Introduction Secure Scala Evaluation Conclusion Contribution What currently: special purpose / external DSL goal: use general purpose language How implement embedded DSL in Scala user: no cryptographic knowledge external libraries! Markus Hauck - SecureScala: Scala Embedding of Secure Computations 5
9. Introduction Secure Scala Evaluation Conclusion A First Approach use an ADT to encode encrypted integers sealed trait EncInt case class PaillierEnc(...) extends EncInt // addition case class ElGamalEnc(...) extends EncInt // multiplication case class AesEnc(...) extends EncInt // equality case class OpeEnc(...) extends EncInt // ordering Markus Hauck - SecureScala: Scala Embedding of Secure Computations 6
10. Introduction Secure Scala Evaluation Conclusion Defining Addition Naively def add(lhs: EncInt, rhs: EncInt): EncInt = (lhs,rhs) match { case (x@PaillierEnc(...),y@PaillierEnc(...)) => x + y case (_,_) => convert(lhs) + convert(rhs) } both operands encrypted under same scheme = easy just use homomorphic property of Paillier different schemes? We need to convert conversion = decryption + encryption Markus Hauck - SecureScala: Scala Embedding of Secure Computations 7
11. Introduction Secure Scala Evaluation Conclusion Defining Addition Naively def add(lhs: EncInt, rhs: EncInt): EncInt = (lhs,rhs) match { case (x@PaillierEnc(...),y@PaillierEnc(...)) => x + y case (_,_) => convert(lhs) + convert(rhs) } both operands encrypted under same scheme = easy just use homomorphic property of Paillier different schemes? We need to convert conversion = decryption + encryption decryption in the cloud? Markus Hauck - SecureScala: Scala Embedding of Secure Computations 7
12. Introduction Secure Scala Evaluation Conclusion Defining Addition Naively def add(lhs: EncInt, rhs: EncInt): EncInt = (lhs,rhs) match { case (x@PaillierEnc(...),y@PaillierEnc(...)) => x + y case (_,_) => convert(lhs) + convert(rhs) } both operands encrypted under same scheme = easy just use homomorphic property of Paillier different schemes? We need to convert conversion = decryption + encryption decryption in the cloud? bad! Markus Hauck - SecureScala: Scala Embedding of Secure Computations 7
13. Introduction Secure Scala Evaluation Conclusion Roadmap Idea: write an embedded DSL Free Monad Free Applicative Both Markus Hauck - SecureScala: Scala Embedding of Secure Computations 8
14. Introduction Secure Scala Evaluation Conclusion Free Monads popular technique in Haskell for DSLs define base functor for operations get a monad for free to sequence them programs are first class, write interpreter Markus Hauck - SecureScala: Scala Embedding of Secure Computations 9
15. Introduction Secure Scala Evaluation Conclusion Define Base Functor for Operations sealed trait CryptoF[+K] case class Plus[K]( lhs: EncInt, rhs: EncInt, k: PaillierEnc => K ) extends CryptoF[K] def plus(lhs: EncInt, rhs: EncInt) = Free.lift(Plus(lhs,rhs,identity)) type Crypto[A] = Free[CryptoF,A] define infix operators: +,*,. . . Markus Hauck - SecureScala: Scala Embedding of Secure Computations 10
16. Introduction Secure Scala Evaluation Conclusion Writing Programs can use monadic combinators (for free) 1 // 20 * 2 + 2 2 val program: Crypto[EncInt] = for { 3 x1 <- EncInt(20) * EncInt(2) // or mult(20,2) 4 x2 <- x1 + EncInt(2) // or plus(x1,2) 5 } yield x2 6 7 // monadic left fold from Scalaz 8 def sumList(z: EncInt)(xs: List[EncInt]) = 9 xs.foldLeftM(z)(_+_) Markus Hauck - SecureScala: Scala Embedding of Secure Computations 11
17. Introduction Secure Scala Evaluation Conclusion Interpreting Programs — Plus def interpret[A](key: KeyRing)(p: Crypto[A]): A = p.resume match { // ... case -\/(Plus(l,r,k)) => (l,r) match { case (lhs@PaillierEnc(_),rhs@PaillierEnc(_)) => interpret(key)(k(lhs + rhs)) case _ => val lhs = convertToPaillier(key)(l) val rhs = convertToPaillier(key)(r) interpret(key)(k(lhs + rhs)) } // ... } def convertToPaillier: KeyRing => EncInt => PaillerEnc Markus Hauck - SecureScala: Scala Embedding of Secure Computations 12
18. Introduction Secure Scala Evaluation Conclusion Interpreting Programs Markus Hauck - SecureScala: Scala Embedding of Secure Computations 13
19. Introduction Secure Scala Evaluation Conclusion Free Monads — Review write programs without caring about encryption schemes programs are first class, interpreter used to execute them swap interpreters adds flexibility Markus Hauck - SecureScala: Scala Embedding of Secure Computations 14
20. Introduction Secure Scala Evaluation Conclusion Free Monads — Review write programs without caring about encryption schemes programs are first class, interpreter used to execute them swap interpreters adds flexibility free monads have drawbacks no static analysis forced sequential execution Markus Hauck - SecureScala: Scala Embedding of Secure Computations 14
21. Introduction Secure Scala Evaluation Conclusion Forced Sequential Execution 7 + 7 + 7 + 7 + 7 + 7 Markus Hauck - SecureScala: Scala Embedding of Secure Computations 15
22. Introduction Secure Scala Evaluation Conclusion Forced Sequential Execution 7 + 7 + 7 + 7 + 7 + 7 convert operands Markus Hauck - SecureScala: Scala Embedding of Secure Computations 15
23. Introduction Secure Scala Evaluation Conclusion Forced Sequential Execution 7 + 7 + 7 + 7 + 7 + 7 homomorphic property Markus Hauck - SecureScala: Scala Embedding of Secure Computations 15
24. Introduction Secure Scala Evaluation Conclusion Forced Sequential Execution 7 + 7 + 7 + 7 + 7 + 7 no conversion needed, homomorphic property Markus Hauck - SecureScala: Scala Embedding of Secure Computations 15
25. Introduction Secure Scala Evaluation Conclusion Forced Sequential Execution 7 + 7 + 7 + 7 + 7 + 7 convert operand, exploit homomorphic property, and so on . . . Problem we cannot look ahead, the continuation needs an argument Markus Hauck - SecureScala: Scala Embedding of Secure Computations 15
26. Introduction Secure Scala Evaluation Conclusion Free Applicative Functors free applicative functor are less expressive than free monads applicative functors: “lifting” of pure functions over effectful arguments can not depend on effectful results (this is the essence of (>>=)/flatMap) Markus Hauck - SecureScala: Scala Embedding of Secure Computations 16
27. Introduction Secure Scala Evaluation Conclusion Free Applicative Functors free applicative functor are less expressive than free monads applicative functors: “lifting” of pure functions over effectful arguments can not depend on effectful results (this is the essence of (>>=)/flatMap) Why switch? implicit parallel execution static analysis Markus Hauck - SecureScala: Scala Embedding of Secure Computations 16
28. Introduction Secure Scala Evaluation Conclusion Implicit Parallel Execution 7 + 7 + 7 + 7 + 7 + 7 convert operands in parallel Markus Hauck - SecureScala: Scala Embedding of Secure Computations 17
29. Introduction Secure Scala Evaluation Conclusion Implicit Parallel Execution 7 + 7 + 7 + 7 + 7 + 7 homomorphic property Markus Hauck - SecureScala: Scala Embedding of Secure Computations 17
30. Introduction Secure Scala Evaluation Conclusion Implicit Parallel Execution 7 + 7 + 7 + 7 + 7 + 7 done Markus Hauck - SecureScala: Scala Embedding of Secure Computations 17
31. Introduction Secure Scala Evaluation Conclusion Implicit Parallel Execution 7 + 7 + 7 + 7 + 7 + 7 done different to monadic version: parallel conversion structure of the computation is known = static analysis Markus Hauck - SecureScala: Scala Embedding of Secure Computations 17
32. Introduction Secure Scala Evaluation Conclusion Static Analysis and Program Transformation free applicative functors, inspect and transform programs count number of different schemes count number of conversions needed perform conversion (might involve network) in a separate phase batch conversion requests for huge number of requests Markus Hauck - SecureScala: Scala Embedding of Secure Computations 18
33. Introduction Secure Scala Evaluation Conclusion Combining Both Approaches free monads: depend on previous effects free applicative functors: implicit parallelism + static analysis solution: use monads on the outside, applicative where possible Markus Hauck - SecureScala: Scala Embedding of Secure Computations 19
34. Introduction Secure Scala Evaluation Conclusion Combining Both Approaches free monads: depend on previous effects free applicative functors: implicit parallelism + static analysis solution: use monads on the outside, applicative where possible different types for programs: type Crypto[A] = FreeAp[CryptoF, A] type CryptoM[A] = Free[Coproduct[CryptoF,Embed,?], A] Markus Hauck - SecureScala: Scala Embedding of Secure Computations 19
35. Introduction Secure Scala Evaluation Conclusion Interpreter interpreters provide two methods for the two program types by default applicative programs can be executed like monadic programs we can specialize applicative interpretation trait CryptoInterpreter[F[_]] { def interpret[A](p: CryptoM[A]): F[A] def interpretA[A](p: Crypto[A]): F[A] = interpret(embed(p)) } Markus Hauck - SecureScala: Scala Embedding of Secure Computations 20
36. Introduction Secure Scala Evaluation Conclusion Putting It Together Markus Hauck - SecureScala: Scala Embedding of Secure Computations 21
37. Introduction Secure Scala Evaluation Conclusion Putting It Together Markus Hauck - SecureScala: Scala Embedding of Secure Computations 21
38. Introduction Secure Scala Evaluation Conclusion Putting It Together Markus Hauck - SecureScala: Scala Embedding of Secure Computations 21
39. Introduction Secure Scala Evaluation Conclusion Putting It Together Markus Hauck - SecureScala: Scala Embedding of Secure Computations 21
40. Introduction Secure Scala Evaluation Conclusion Evaluation Recall the goals embedded DSL for non-domain experts usable with libraries practical performance Markus Hauck - SecureScala: Scala Embedding of Secure Computations 22
41. Introduction Secure Scala Evaluation Conclusion Writing Programs applicative and monad provide a lot of functionality for free effectful mapping (traverse) monadic folding (foldLeftM,foldRightM) lifting functions (Applicative) and many more (Scalaz, Cats) Markus Hauck - SecureScala: Scala Embedding of Secure Computations 23
42. Introduction Secure Scala Evaluation Conclusion Embedded DSL 1 def wordCountText(input: EncString): 2 CryptoM[List[(OpeString,Int)]] = 3 input.split("""\s+""") >>= wordCount 4 5 def wordCount(input: IList[EncString]): 6 Crypto[List[(OpeString,Int)]] = 7 input.traverse(toOpeStr). 8 map(_.groupBy(identity).map(_.length).toList) Markus Hauck - SecureScala: Scala Embedding of Secure Computations 24
43. Introduction Secure Scala Evaluation Conclusion CEP — License Plates Markus Hauck - SecureScala: Scala Embedding of Secure Computations 25
44. Introduction Secure Scala Evaluation Conclusion CEP — License Plates sealed trait LicensePlateEvent { def car: EncString def speed: EncInt def time: Long } case class CarStart(...) extends LicensePlateEvent case class CheckPoint(...) extends LicensePlateEvent case class CarGoal(...) extends LicensePlateEvent Markus Hauck - SecureScala: Scala Embedding of Secure Computations 26
45. Introduction Secure Scala Evaluation Conclusion CEP — License Plates SELECT car AS license, number, speed FROM CheckPoint WHERE Interp.isTooFast(speed) object Interp { val keyRing: KeyRing = KeyRing.create val interpret = LocalInterpreter(keyRing) val speedLimit: EncInt = encrypt(keyRing)(130) def isTooFast(s: EncInt): Boolean = interpret(s > speedLimit) } Markus Hauck - SecureScala: Scala Embedding of Secure Computations 27
46. Introduction Secure Scala Evaluation Conclusion CEP — License Plates Markus Hauck - SecureScala: Scala Embedding of Secure Computations 28
47. Introduction Secure Scala Evaluation Conclusion More Evaluation in the Paper Microbenchmark of different interpreters WordCount RxScala GUI CEP with Esper Markus Hauck - SecureScala: Scala Embedding of Secure Computations 29
48. Introduction Secure Scala Evaluation Conclusion Conclusion SecureScala: embedded DSL in Scala write programs working over encrypted data significant overhead, but still usable can be used in combination with libraries Markus Hauck - SecureScala: Scala Embedding of Secure Computations 30
49. Introduction Secure Scala Evaluation Conclusion Conclusion SecureScala: embedded DSL in Scala write programs working over encrypted data significant overhead, but still usable can be used in combination with libraries Thank you for your attention Markus Hauck - SecureScala: Scala Embedding of Secure Computations 30
50. Introduction Secure Scala Evaluation Conclusion Secure Scala: Scala Embedding of Secure Computations Markus Hauck - SecureScala: Scala Embedding of Secure Computations 31
51. Appendix Markus Hauck - SecureScala: Scala Embedding of Secure Computations 32
52. Interpreting Programs def interpret[A](key: KeyRing)(p: Crypto[A]): A = p.resume match { case \/-(x) => x // handle cases of base functor } Markus Hauck - SecureScala: Scala Embedding of Secure Computations 33
53. Reactive Programming — RxBank RxScala — Reactive Extensions for Scala scenario: collection of bank accounts events: transfer random amount of money between random accounts colorize in GUI based on balance Markus Hauck - SecureScala: Scala Embedding of Secure Computations 34
54. Reactive Programming — RxBank Markus Hauck - SecureScala: Scala Embedding of Secure Computations 35
55. Reactive Programming — RxBank 2.7 ts/s ≈ 6 redraws per second Markus Hauck - SecureScala: Scala Embedding of Secure Computations 36
