1. ©2014 KUDELSKI GROUP / All rights reserved.
   SURICATA IDS
   Julien Bachmann


   View Slide

2. 2 ©2014 KUDELSKI GROUP / All rights reserved.
   INTRODUCTION
   IDS or IPS ?
   Intrusion Detection System
   Intrusion Prevention System
   Based on signatures
   Vulnerability centric


   View Slide

3. 3 ©2014 KUDELSKI GROUP / All rights reserved.
   INTRODUCTION
   Vulnerability centric
   Prevention and detection based
   Assume you know all possible threats
   Signature based detection
   Some behavioral approach but not so common
   No feedback
   Opposite to threat centric approach


   View Slide

4. 4 ©2014 KUDELSKI GROUP / All rights reserved.
   INTRODUCTION
   Threat centric
   Suppose prevention will fail…
   Based on attackers TTPs
   Tools, Tactics and Procedures
   Uses bad experiences as feedback to improve


   View Slide

5. 5 ©2014 KUDELSKI GROUP / All rights reserved.
   INTRODUCTION
   Suricata
   Open Source project
   Run by the Open Information Security Foundation
   Initiative by DHS in 2008…
   … but now supported by group of vendors


   View Slide

6. 6 ©2014 KUDELSKI GROUP / All rights reserved.
   INTRODUCTION
   Also an IPS
   NetFilter on Linux
   ipfw on BSD
   Mode
   Bridge


   View Slide

7. 7 ©2014 KUDELSKI GROUP / All rights reserved.
   INTRODUCTION
   Setup on Linux
   # iptables –I FORWARD –j NFQUEUE
   # suricata –c … -q 0
   …
   # iptables –F
   Rules
   drop keyword


   View Slide

8. 8 ©2014 KUDELSKI GROUP / All rights reserved.
   INTRODUCTION
   Why not SNORT ?
   Only solution for quite some time
   Which has an aging core (ok, v3 is out…)
   Support multi-threading
   Support for capture cards
   or PF_RING on commodity hardware
   10Gb/s on Xeon with 8 cores
   GPU acceleration for regexp matching!
   who doesn’t have a GPU in their IDS nowadays?


   View Slide

9. 9 ©2014 KUDELSKI GROUP / All rights reserved.
   INTRODUCTION
   PF_RING


   View Slide

10. 10 ©2014 KUDELSKI GROUP / All rights reserved.
    INTRODUCTION
    Signatures
    Support for SNORT ones
    except SO rules
    EmergingThreats
    Customs
    including LUA scripts for detection with some logic


    View Slide

11. 11 ©2014 KUDELSKI GROUP / All rights reserved.
    INTRODUCTION
    Deployment
    Packages or easily self-compiled
    Configuration
    suricata.yaml
    Rules management
    oinkmaster


    View Slide

12. 12 ©2014 KUDELSKI GROUP / All rights reserved.
    INTRODUCTION
    For testing purposes
    The Security Onion
    Stamus Networks SELKS


    View Slide

13. 13 ©2014 KUDELSKI GROUP / All rights reserved.
    INTRODUCTION
    Why would I use this ?
    Complimentary to commercial solution
    Write your custom rules
    newly published vulnerability
    malware infection
    ongoing incident response
    capitalize on previous attacks
    Threat centric approach


    View Slide

14. 14 ©2014 KUDELSKI GROUP / All rights reserved.
    INTRODUCTION
    Deployment strategies
    Important rule: Know your network
    Ingress / Egress points
    Internet access proxies
    VPN
    Partners
    Copy traffic using port mirroring


    View Slide

15. 15 ©2014 KUDELSKI GROUP / All rights reserved.
    INTRODUCTION


    View Slide

16. 16 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES 101 | PROTOCOL DETECTION
    Basic idea
    Look everywhere in the packet
    Not very fine-grained
    alert tcp $EXTERNAL_NET any -> $HOME_NET any (msg:"looking everywhere for
    overflow"; flow:established; content:"|41 41 41 41|"; content:"|42 42|";
    distance:0; classtype:shellcode-detect; sid:1; rev:1;)


    View Slide

17. 17 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES 101 | PROTOCOL DETECTION
    Next idea
    Specify ports
    What if $ADMIN changed default ports?
    alert tcp $EXTERNAL_NET any -> $HOME_NET [80, 8080] (msg:"looking for web
    requests"; flow:established; content:"GET /"; nocase; classtype:not-suspicious;
    sid:1; rev:1;)


    View Slide

18. 18 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES 101 | PROTOCOL DETECTION
    Better idea
    Specify protocol
    Let the engine detect it for you
    alert http $EXTERNAL_NET any -> $HOME_NET any (msg:"looking for web requests";
    flow:established; content:"GET"; http_method; nocase; classtype:not-suspicious;
    sid:1; rev:1;)


    View Slide

19. 19 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES 101 | PROTOCOL DETECTION
    Better idea
    What about the next one?
    alert http $EXTERNAL_NET any -> $HOME_NET any (msg:"looking for web requests";
    flow:established; content:“GET"; content:“POST"; http_method; nocase;
    classtype:not-suspicious; sid:1; rev:1;)


    View Slide

20. 20 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES 101 | DEMO
    Analyze malware communications
    Malware.pcap


    View Slide

21. 21 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES 101 | DEMO
    • Analyze malware communications
    – alert tcp any any -> $HOME_NET any (msg:"CyberEye RAT session";
    content:"ANABILGI|" sid:1; rev:1;)


    View Slide

22. 22 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES 101 | PROTOCOL DETECTION
    Several implemented
    HTTP
    DNS
    SMB
    SSH
    FTP
    TLS
    Jabber
    …
    Allows to match specific fields


    View Slide

23. 23 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES 101 | PROTOCOL DETECTION
    Wait, TLS and SSH? Isn’t it encrypted?
    Not so fast, no TLS decryption on the fly
    Mainly allows to extract information
    Fingerprint
    IssuerDN
    …


    View Slide

24. 24 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES 101 | PROTOCOL DETECTION
    Use case
    Remember Comodo story?
    Log proactively


    View Slide

25. 25 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES ADVANCED | FILES
    No need to dig the PCAPs manually
    Possible to extract files matching rules
    Enable file-store in suricata.yaml


    View Slide

26. 26 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES ADVANCED | FILES
    Store all PDF files
    alert http $EXTERNAL_NET any -> $HOME_NET any (msg:"PDF downloaded";
    fileext:"pdf"; filestore; sid:1; rev:1;)
    alert http $EXTERNAL_NET any -> $HOME_NET any (msg:"PDF downloaded";
    filemagic:"PDF document"; filestore; sid:1; rev:1;)


    View Slide

27. 27 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES ADVANCED | FILES
    Detect suspicious files upload
    alert http $EXTERNAL_NET any -> $DMZ any (msg:"possible webshell upload attempt";
    fileext:"png"; filemagic:!"PNG"; filestore; sid:1; rev:1;)


    View Slide

28. 28 ©2014 KUDELSKI GROUP / All rights reserved.
    RULES ADVANCED | FILES
    Whitelisting uploaded files
    alert http $HOME_NET any -> $EXTERNAL_NET any (msg:"file upload"; fileext:"exe";
    filemd5:!know_good.txt; filestore; sid:1; rev:1;)


    View Slide

29. 29 ©2014 KUDELSKI GROUP / All rights reserved.
    MONITORING | TOOLS
    How do I review the events?
    syslog: not that practical
    Graphical tools
    $COMMERCIAL_PRODUCT
    Snorby
    OSSIM
    Sguil
    ELK


    View Slide

30. 30 ©2014 KUDELSKI GROUP / All rights reserved.
    MONITORING | ELK
    ElasticSearch Logstash Kibana
    Not really in that order
    Logstash : read logs and forward and/or transform
    ElasticSearch : indexed storage
    Kibana : web interface to ES


    View Slide

31. 31 ©2014 KUDELSKI GROUP / All rights reserved.
    MONITORING | ELK
    Configuration in Suricata
    1. Enable EVE output
    2. Configure Logstash to read from EVE file
    3. Profit


    View Slide

32. 32 ©2014 KUDELSKI GROUP / All rights reserved.
    MONITORING | DEMO
    SELK
    Using Stamus Network SELK


    View Slide

33. 33 ©2014 KUDELSKI GROUP / All rights reserved.
    CONCLUSION | FINAL WORDS
    Things I did not discuss
    Sensor hardening
    LUA scripting engine
    Rules sets comparison


    View Slide

34. 34 ©2014 KUDELSKI GROUP / All rights reserved.
    CONCLUSION | FINAL WORDS
    Things to keep in mind
    There are alternative to commercial tools
    Preconfigured distributions
    Incident response can benefit custom rules
    ELK stack becoming more and more used in DFIR


    View Slide
